2AMYQ-2025G580Robotic vacuum cleaner

18 Charging instruction 01. For the very first operation, please let the robot run out of power. 02. Please charge the robot for 12 hours for the first time of operation. When the charge is done, the Control button light turns off. 03. lf the robot is out of service for a long time, please turn off the power switch. 04. Please charge the robot as soon as possible after the battery is used up. 05. The product can only use the power adapter and charger provided by the factory. 06. The battery should be repaired and replaced by the after-sales service center. Instructions for Use 19 Instructions for Use Switching Modes Power on Pause The pause function is to switch the robot from the operating mode to the selected mode, and the robot can be paused by the following operations: 01.Press the “ ” button on the robot to pause the robot. 02.Press the power on/off button on the remote controller to pause the robot. Notice: After the machine is paused, the machine can be re-operated. Sleep Sleep mode means that the robot is stopped and the indicator light is off. If the Robot is not active within 10 minutes, the robot will enter Sleep mode automatically. Note: If the robot is out of service for a long time, please turn off the robot. 01. Long press the " " on the machine to turn on or turn off the machine. 02. Press the " " control button on the machine or the cleaning button on the APP to start the machine working. 20 Instructions for Use Use of Water Tank When charging, please remove the water tank to avoid danger Open the tank sealing cap, fill it with enough water and slowly inject water How to add water When charging, please remove the water tank to avoid danger How to fix the microfiber mop? Cover the sealing plug of the water tank, stick the soakaway cloth on the Velcro at the bottom of the drag plate, and then install it on the bottom of the two-in-one water tank. 21 Instructions for Use When charging, please remove the water tank to avoid danger How to install the water tank? Press the release button on the dust box to remove it then install the water tank 22 Instructions for Use Cleaning Modes The robot will perform the plan will clean along the cleaning in S shape according to the room environment. Only available by App control, After setting the forbidden area, the robot will not enter the forbidden area of the room. restricted area Plan Cleaning ( S shape Cleaning ) Setting Forbidden Area 23 Instructions for Use Relocation by LDS In the process of cleaning, if you move the sweeper to a new place after suspension, and restart it, it seeks to relocate. If the relocation is successful, the sweeper continues to clean. If it fails, the previous cleaning map will be lostit will restart a new cleaning. Location A Be moved to Relocalization Location B Spot cleaning The robot will take its current position as the center and clean a specific spot of your home according to a spiral route. 24 Product Maintenance 5.1 Side brush cleaning and replacement Check the side brush condition from time to time to see if it has been damaged or wrapped with foreign objects. Clean the side brush with a cleaning tool or a rag. When the side brush is damaged and cannot be used, please replace it in time, L and R side brush should be corresponding. 5.2 Maintenance of T wo-in-one tank Press the Two-in-one tank release button to remove the Two-in-one tank 25 Product Maintenance Open dust bin cover, and dump garbage Remove the primary filterand remove the high-efficient filter and filter sponge. It is not recommended to wash the high-efficient filter with water. Please put off the debris carefully. 26 Product Maintenance Wash the dust box and pre-filter. Reomve the mop 27 Product Maintenance Wash and dry th Pour out the rest of water from the water tank 28 Product Maintenance 1. Dry the Two-in-one tank and filter components. Keep them dry to ensure a longer service. 2. After the pre-filter is used for 15-30 days, it should be washed once. 3. The maximum service life of the high-efficient filter is 3 months. 1. Reinstall the mopthe pre-filter and high-efficient filter in Two-in-one tank. 2. Before installing the filter, make sure that the high-efficient filter and the pre-filter are dry. 3. Do not expose the high-efficient filter and the pre-filter to sunlight. 29 Product Maintenance 5.3 Maintenance of R olling Brush Components Open the rolling brush components Remove the rolling brush and clean off all debris and hair. 30 Product Maintenance 5.4 Maintenance of Other Components Use the cleaning tools or a dry soft cloth to periodically clean the electrode slice of robot chassis and the sensor window. lectrode slice ensor Use a cleaning tool or soft cloth to clean the charging terminal Charging terminal 31 6.1 Faults Description FaultsPossible Reasons Solutions The robot can not be charged. The robot is stuck during work. The robot goes back to recharge without finishing the cleaning work. The robot does not perform cleaning work automatically as scheduled Remote control malfunctions (effective range is 5 m) When the robot is working, there is a missed sweep, the route is chaotic, the deviation is reversed,and the APP side cleaning map shows irregularities and is not neat. The electrodes between the main body and the charging base are not contacted properly. Make sure that the electrodes between the main body and the charging base are properly contacted. Keep charging the robot when it is not working to better prepare for next cleaning assignment. The robot will try to get itself out automatically.However,please help it manually if it failed. The charging base is switched off while the robot is switched on,which leads to the loss of power. The robot detects that the power may be not enough and automatically goes back to recharge. The robot works at different speeds on dif ferent floor types.For example,it works longer on the wood floors than on carpets The robot is not switched on and the robot can not perform cleaning…

Text truncated - open the document above for the full version.

ROBOTIC VACUUM CLEANER USER MANUAL (Before using this product,please read the safety instructions below and follow all the routine safety precautions) 1. Wi-Fi Setup Instructions Content 3.1 Name of Parts 3.2 Products Specifi cations 3.3 Product feature 4.1 Attention 4.2 Remote Controller Instructions 4.3 Operating Instructions 5.1 Side B ru sh Cleaning and Repl acement 5.2 Maintenance of Two-in-one tank 5.3 Mainte nance of Rollin g Bru sh Components 5.4 Maintenance of Other Components 6.1 Common F au lts 6.2 Repl ac eable Modules 6. Common Faults 4. Instructions for Use 5. Product Maint enance 2.Safety Instr uctions 3.Product Components 2 WIFI settings instructions In order to improve the product, we reserve the right to update the APP and software. Figure8Figure9Figure10 Figure4 Figure5 Figure6Figure7 Figure15Figure16 3. Hotspot network configuration After logging in, click "Add Device" in the middle of the screen as Figure 15 shows or click "+" in the upper right corner to add a device. Select small appliances and robot vacuum cleaners on the device addingpage( as shown in Figure 16). 3 WIFI settings instructions In order to improve the product, we reserve the right to update the APP and software. Step 3: After the device is connected to APP, the next step is to select the household wifi of (as shown in Figure 11). Click the wifi name bar to select the available wifi, return to the app and enter the corresponding password and click Next. The app will auto connect to the cleaner and enter the waiting interface shown in Figure 12. Then you need to wait for the network configuration done. Then enter the interface shown in Figure 13. Click Done. Then return to the home page of the app (as shown in Figure 14). Figure11 Figure12 Figure13Figure14 As shown in Figure 17, click the double arrows sign to select the wifi that the machine needs to connect to, then return to the app main interface, enter the corresponding password and click Next. Follow the prompts in APP (Figure 18) to operate with robot,press and hold the power button on robot top panel to power on the cleaner. After the power-on prompt voice is played, press and hold the recharge button (refer to the product composition for the specific button information) until the wifi light flashes and the corresponding prompt voice plays. Click "light flashes" to enter the next step as the Figure 19 shows and select the AP Mode. Then skip to the next step as Figure 20 shows, click "Go to connecting" to jump to the wifi signal list, conneting the Wi-Fi named SmartLife-xxxx in Figure 20 and then return to the app. Figure17Figure18 Figure19 Figure20 After returning to the app, you will automatically enter the waiting interface as shown in Figure 21. Then wait till the APP auto skip to next step. After successfully connecting, the home page will display the connecting device (as shown in Figure 22). Figure21Figure22 4 WIFI settings instructions In order to improve the product, we reserve the right to update the APP and software. 5 Safety Instruction Before using this product,please read the safety instructions below and follow all the routine safety precautions. Safety considerations of Main Body and Accessories Please read the instructions carefully and keep them for future reference. Any operation that does not conform to the instructions may cause damage to the product. Please note that this product has a laser module, IEC-60825: class 1, wavelength: 775-800nm, laser radiation power: 5mW. War ning 01.Do not disassemble,repair or refit the product without authorization;otherwise it may damage the product or pose a hazard. 02.Do not use the product in an environment with risk of fire or explosion. 03.This product can only use the original power adapter;otherwise the product may be damaged or catch on fire. 04.Do not stand or sit on this product;doing so could damage the product or cause it to fall over. 05.When the metal part of the power plug is dusty,please wipe it with a dry cloth. 06.The power adapter is applied to a 100-240V AC voltage.Please plug into the socket properly and keep away from children. 07.Do not wash or soak the main body and electronic accessories in the water;otherwise the product may be damaged by a short circuit. 08.Do not damage,load weight on,heat,pull,or bend it. 09.During cleaning,please pay attention to the safety of toddlers and elders at home to avoid injury. (Please pay special attention to toddlers). 10.This product is for home use.Please do not use it outdoors. 11.Do not allow metal and conductive materials to come in contact with the battery;doing so may cause a short circuit. Attentions 01.Do not touch the product with wet hands;doing so may cause an electric shock. 02.Please do not place the product in places where it could easily fall,such as tables,chairs,high platforms in room,etc. 03.The product has a sophisticated design and should be protected from long-term exposure to sunlight. 04.Please do not use the product in humid environments,such as bath-rooms. 05.Please do not place the product near cigarette butts,lighters or other open fires. 06.Please clean the product after finishing charging. 07.Please turn off the power switch on the side of the robot when the product is out of service for a long time. 6 Safety Instruction 08. Please check carefully to see if the power adapter is connected to the socket prior to use,to avoid damage to the robot. 09.Before using the product,please remove all vulerable items on the floor,such as glass, lamps,and items such as wires and curtains that may entangle with the side brush and suction passages. 10.When the dust box is full,please empty it before using again. 11.Please do not use the robot to clean the construction waste. 12.Before the product is scrapped,please remove the battery from the robot.When you remove the battery,please ensure that the product is not connected to a power supply. Please recycle the battery safety or environmental protection. Safety Consid…

Text truncated - open the document above for the full version.
