2AN8F-M2012QUV Sterilization Desk Clock with Wireless Charging

08.08 2020 Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Instruction Manual EPB-BM20 READ ALL INSTRUCTIONS CAREFULLYBEFORE USE AND KEEP THIS MANUAL In the Box • EPB-BM20 Bamboo 5000mAh Dual Port Power Bank with Wireless Charger (x1) • Power Cable (x1) • User Manual (x1) This product is NOT a toy, keep away from children and pets. Only use the device according to the instructions in this manual. Never use the device for anything other than its intended purpose. Do not open this device or attempt to repair the unit yourself if it is not working properly. Doing so risks fire, shock or injury. When not in use, the device should be stored in a dry, cool location, away from sources of water or heat. Do not expose device or power cable to extreme temperatures (heat or cold), open flames, humid or wet conditions. Do not submerge in water. Do not use in a location where the device or power cable could fall into liquid. Unplug the charging cable when not in use. Do not pull the charging cable to disconnect, or use the cable as a handle. Do no use if device or power cable is damaged. If device or power cable is damaged, it MUST be serviced or replaced by the manufacturer or its service agent before using again. Low battery may cause dysfunction. Do not over charge battery. This device contains a built-in battery and should not be disposed of with regular household waste. Please consult the local authorities on the correct way to dispose of this device. Attachments on the back of your device can impede effectiveness of the wireless charger, and lead to overheating. Remove attachments from your device before charging on this wireless charger. Safety Precautions • • • • • • • • • • • • • Product ①Wireless Charging Surface ②Micro USB Input Port ③USB-A Output ④LED Indicators ⑤ ON/OFF Button Instructions Charge the power bank fully before usage. Connect the provided power cable to a power source and to the micro USB port on the power bank. The LED indicator will flash while the power bank is in charging and stay solid when the power bank is fully charged. Charging the Power Bank • Using the cable of the device you wish to charge, connect the charging cable to your mobile phone/device with the appropriate connector and the USB-A end to the USB-A output of the power bank. The LED indicator will illuminate when charging. Remove the USB cable from your mobile phone/device when it is fully charged. Charging mobile phones and other electronic devices • • • Press the ON/OFF button to turn on the wireless charging function. The LED Indicator will glow GREEN indicating the power bank is in wireless charging standby mode. Place a wireless charging enabled device on the charging surface, the device will begin to charge automatically. The LED will glow RED while device is charging. Note: If the LED indicator is flashing when the wireless charger is in use, either the device is NOT wireless charging enabled, or there is an object between the device and charging pad interfering with the charging process. Wireless Charging Instruction • • Tech Specifications • Battery Capacity: 5000mAh/3.7V 18.5Wh • Micro USB Input: 5V/2A • USB-A Output: 5V/2A (Total Max) • Wireless Output: 5W FCC Information This device complies with Part 15 of the FCC Rules. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. ① ④ ② ③ ⑤ Made in China Caution: Any changes or modifications not expressly approved could void the user’s authority to operate the equipment. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • • • • Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 100 mm 130 mm 100 mm 130 mm

ShenZhen Mossloo Industrial Co.,Ltd 2020.8.27 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product Name: Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Trademark: N/A Model Number(s): M2012Q, EPB-BM20 FCC ID: 2AN8F-M2012Q To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Orders Cheng /Manager Contact information / address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China

ShenZhen Mossloo Industrial Co.,Ltd 2020.8.27 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Orders Cheng /Manager Contact information / address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China

Shenzhen Mossloo Industrial Co.,Ltd Model Difference 2020-80-27 Product Name: Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Trademark: N/A Model Number(s): M2012Q, EPB-BM20 FCC ID: 2AN8F-M2012Q All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature: Client’s name / title : Orders Cheng /Manager Contact information / address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China

External Photos

Size:30*15mm FCC ID: 2AN8F-M2012Q This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Location

Internal Photos Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 1 of 14 RF EXPOSURE REPORT For FCC ID: 2AN8F-M2012Q Product Name: Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Trademark: N/A Model Number: M2012Q EPB-BM20 Prepared For : ShenZhen Mossloo Industrial Co.,Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Aug. 04, 2020 - Aug. 12, 2020 Date of Report : Aug. 12, 2020 Report No.: BCTC2008000392-1E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 2 of 14 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Mossloo Industrial Co.,Ltd Address ................................. : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Manufacture's Name ............ : Shenzhen Mossloo Industrial Co.,Ltd Address ................................. : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Product description Product name ........................... : Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Trademark ............................ : N/A Model and/or type reference : M2012Q Serial Model : EPB-BM20 Power Supply : DC 3.7V From Battery Input: DC 5V/2A From adapter USB Output: 5V/2A(Max) Wireless Charging Output: 5W Standards ............................. : FCC CFR 47 part1, 1.1307(b), 1.1310 This device described above has been tested by BCTC, and the test results show that the equipment under And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Willem Wang Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 3 of 14 Table of Contents Page 1 . GENERAL INFORMATION 4 1.1. Independent Operation Mode 4 1.2. Test Supporting System 4 2 . LIST OF TEST AND MEASUREMENT INSTRUMENTS 5 2.1. For conducted emission at the mains terminals test 5 3. METHOD OF MEASUREMENT 6 3.1. Applicable Standard 6 3.2. Test Modes 6 3.3. MAXIMUM PERMISSIBLE EXPOSURE 6 4. TEST RESULT 7 4.1. Conducted Emission at the Mains Terminals Test 7 4.2. Equipment Approval Considerations: 8 4.3. E and H field Strength 9 5. Photographs of test set-up 10 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 4 of 14 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: 1.1.1. Charging 1.2. Test Supporting System Adapter Description : Adapter Model No. : BCTC-002 Power Input : AC 100-240V~50/60Hz Output: 5V 2A DC Line : Unshielded, Detachable 1m Mobile phone Model No. : iphone8P Model No. : iphone Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 5 of 14 2. LIST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Exposure Level Tester Narda ELT-400 N-0231 Jul. 15, 2020 Jul. 14, 2021 Magnetic field probe 100cm2 Narda B-Field Probe 100cm2 M0675 Jul. 15, 2020 Jul. 14, 2021 843 Chamber ETS 843 84301 Aug. 27, 2020 Aug. 26, 2023 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 6 of 14 3. METHOD OF MEASUREMENT 3.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is calculated. According KDB680106 D01v03: RF Exposure Wireless Charging Apps v02. 3.2. Test Modes Test Modes keeping TX+Charging mode 3.3. MAXIMUM PERMISSIBLE EXPOSURE Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 7 of 14 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Note: Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) The measurement probe was placed at test distance (15cm) which is between the edge of the charger and the geometric centre of probe. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. e) The EUT were measured according to the dictates of KDB 680106D01v03. Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 8 of 14 4.2. Equipment Approval Considerations: The EUT does comply with item 5(b) of KDB 680106 D01v03 1) Power transfer frequency is less than 1MHz Yes, the device operate in the frequency range from 112-220KHz 2) Output power from each primary coil is …

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-013 Ver.：A.0 Page 1 of 21 FCC TEST REPORT FCC ID: 2AN8F-M2012Q Product Name: Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Trademark: N/A Model Number: M2012Q EPB-BM20 Prepared For : ShenZhen Mossloo Industrial Co.,Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Aug. 04, 2020 - Aug. 12, 2020 Date of Report : Aug. 12, 2020 Report No.: BCTC2008000392-2E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-013 Ver.：A.0 Page 2 of 21 TABLE OF CONTENTS TEST REPORT DECLARATION .................................................................................................. 3 1. GENERAL INFORMATION ........................................................................................................ 4 1.1. Report information .......................................................................................................................... 4 1.2. Measurement Uncertainty .............................................................................................................. 4 1.3. Test Facility ...................................................................................................................................... 4 1.4. Test Uncertainty .............................................................................................................................. 4 2. PRODUCT DESCRIPTION ......................................................................................................... 5 2.1. EUT Description .............................................................................................................................. 5 2.2. Test mode ........................................................................................................................................ 5 2.3. Block Diagram of EUT Configuration ........................................................................................... 5 2.4. Test Conditions ................................................................................................................................ 6 2.5. Description Of Support Units (Conducted Mode) ....................................................................... 6 3. TEST RESULTS SUMMARY ..................................................................................................... 7 4. TEST EQUIPMENT USED .......................................................................................................... 8 4.1. For Conducted Emission Test ....................................................................................................... 8 4.2. For Radiated Emission Measurement ......................................................................................... 8 5. CONDUCTED EMISSION TEST ................................................................................................ 9 5.1. Block Diagram of Test Setup......................................................................................................... 9 5.2. Test Standard .................................................................................................................................. 9 5.3. Conducted Emission Limit ............................................................................................................. 9 5.4. EUT Configuration on Test ............................................................................................................ 9 5.5. Operating Condition of EUT ........................................................................................................ 10 5.6. Test Procedure .............................................................................................................................. 10 5.7. Test Result ..................................................................................................................................... 10 6. RADIATED EMISSION MEASUREMENT ............................................................................. 13 6.1. Block Diagram of Test Setup....................................................................................................... 13 6.2. Test Standard and Limit ............................................................................................................... 14 6.3. EMI Test Receiver Setup ............................................................................................................. 15 6.4. Test Procedure .............................................................................................................................. 15 6.5. Test Result ..................................................................................................................................... 15 7. EUT TEST PHOTOS .................................................................................................................. 19 8. EUT PHOTOS ............................................................................................................................. 21 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000392-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-013 Ver.：A.0 Page 3 of 21 TEST REPORT DECLARATION Applicant : Shenzhen Mossloo Industrial Co.,Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China EUT Description : Bamboo 5000mAh Dual Port Power Bank with Wireless Charger Bamboo Model Number : M2012Q EPB-BM20 Test Model : M2012Q Test Standards: FCC Part 15 C This device d…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Conducted Measurement Photos Shenzhen BCTC Testing Co., Ltd. Radiated Measurement Photos 9KHz-30MHz 30MHz-1GHz
