2AN8FMSL-W6012QPhoto Frame Wireless Charger

******************************************************** MADE IN CHINA Photo Frame Wireless Charger Instruction Manual MSL-W6012Q 1 x Wireless Charging Frame 1 x Micro-USB to USB Cable 1 x Instruction Manual Input: DC 5V/2A Wireless Output: 5W 1. 2. 3. 4. • • Wireless Charging Surface LED Indicator Micro USB Input Placement for wireless charging supported device(can be vertical or horizontal) What’s included: Features: * WARNING-When using this product, basic precautions should always be followed: Read all the instructions before use. Never store or use this product in temperatures below 32°F (0°C) or above 115°F (45°C). Do not overcharge your phone. The unit may become hot under excessive use. Remove your phone once it is fully charged. Never charge your phone for more than 7 hours at a time. To reduce the risk of injury, close supervision is required when the product is used near children. Do not expose the device to moisture. Do not use the device in excess of its output rating. Overload outputs above the rating may result in a risk of fire or injury. Do not use the device if damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not disassemble the device. For repairs, seek a qualified service professional. Incorrect reassembly may result in a risk of fire or injury. Do not expose the device to fire or excessive temperatures. Exposure to fire or temperatures above 104°F (40°C) may result in explosion. To ensure product safety, ensure that qualified service professionals use only identical replacement parts. Attachments on the back of your phone can impede the effectiveness of the wireless charger, and lead to overheating. Please remove attachments from the phone before charging on this device. 1. 2. 3. SAFETY PRECAUTIONS: Place the wireless charging supported device on the charging surface(1), the device will begin to charge automatically. LED indicator(on the right side) will flash green when device is charging. Note: When wireless charging, if the LED indicator(on the left side) is turn RED the device is either NOT a wireless charging device or there is an object between the deviceand charging surface interfering with the charging process. • 4. • INSTRUCTIONS: Wireless Charging Function: Connect the Micro-USB to USB cable (incl.) to a power source and to the Micro USB port behind the photo frame(3). Once connected the LED indicator(2)will flash two times then turn into solid greenright side indicating the device is on standby mode is ready to begin charging. • 5. 6. 7. 8. 9. 1. 3. 4. 2. 2. 10. 11. 12. 13. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

Shenzhen Mossloo Industrial Co.,Ltd Agent Authorization Company: Shenzhen Mossloo Industrial Co.,Ltd Address: Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Product Name: Photo Frame Wireless Charger Model Number(s): MSL-W6012Q Product Description: Photo Frame Wireless Charger We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/3/19 Name: Orders Cheng Title: Manager Company: Shenzhen Mossloo Industrial Co.,Ltd

Shenzhen Reo-link Digital Technology Co, Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/3/19 Subject; Request for Confidentiality FCC ID: 2AN8FMSL-W6012Q To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Orders Cheng Title: Manager

External Photos

Size:40*20mm Label location FCC ID: 2AN8FMSL-W6012Q This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos Transmitter Antenna

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 1 of 9 RF EXPOSURE REPORT For FCC ID: 2AN8FMSL-W6012Q Product Name: Photo Frame Wireless Charger Trademark: N/A Model Number: MSL-W6012Q Prepared For : Shenzhen Mossloo Industrial Co., Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Mar. 05, 2020 to Mar. 11, 2020 Date of Report : Mar. 11, 2020 Report No.: BCTC2003000112-1E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 2 of 9 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Mossloo Industrial Co., Ltd Address ................................. : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Manufacture's Name ............ : Shenzhen Mossloo Industrial Co., Ltd Address ................................. : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Product description Product name............................ : Photo Frame Wireless Charger Trademark ........................... : N/A Model and/or type reference : MSL-W6012Q Serial Model : N/A Power Supply : Input: DC 5V/2A Wireless Output: 5W Standards ............................. : FCC CFR 47 part1, 1.1307(b), 1.1310 This device described above has been tested by BCTC, and the test results show that the equipment under And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Sam zeng Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 3 of 9 Table of Contents Page 1 . GENERAL INFORMATION 4 1.1 . Independent Operation Mode 4 1.2 . Test Supporting System 4 2 .LIST OF TEST AND MEASUREMENT INSTRUMENTS 5 2.1 . For conducted emission at the mains terminals test 5 3. METHOD OF MEASUREMENT 6 3. 1.Applicable Standard 6 3. 2. Test Modes 6 3. 3. MAXIMUM PERMISSIBLE EXPOSURE 6 4. TEST RESULT 7 4.1. Conducted Emission at the Mains Terminals Test 7 4.2. Equipment Approval Considerations: 8 4.3. E and H field Strength 9 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 4 of 9 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: 1.1.1. Charging 1.2. Test Supporting System Adapter Description : Adapter Model No. : BCTC-002 Power Input : AC 100-240V~50/60Hz Output: 5V 2A DC Line : Unshielded, Detachable 1m Mobile phone Model No. : iphone8P Model No. : iphone Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 5 of 9 2.LIST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Exposure Level Tester Narda ELT-400 N-0231 Jul. 15, 2019 Jul. 14, 2020 Magnetic field probe 100cm2 Narda B-Field Probe 100cm2 M0675 Jul. 15, 2019 Jul. 14, 2020 843 Chamber ETS 843 84301 Aug. 27, 2018 Aug. 26, 2021 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 6 of 9 3. METHOD OF MEASUREMENT 3. 1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is calculated. According KDB680106 D01v03: RF Exposure Wireless Charging Apps v02. 3. 2. Test Modes Test Modes keeping TX+Charging mode 3. 3. MAXIMUM PERMISSIBLE EXPOSURE Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 7 of 9 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Note: Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) The measurement probe was placed at test distance (15cm) which is between the edge of the charger and the geometric centre of probe. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. e) The EUT were measured according to the dictates of KDB 680106D01v03. Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-009 Ver.：A.0 Page 8 of 9 4.2. Equipment Approval Considerations: The EUT does comply with item 5(b) of KDB 680106 D01v03 1) Power transfer frequency is less than 1MHz Yes, the device operate in the frequency range from 120-220KHz 2) Output power from each primary coil is less than or equal to 10 watts. Yes, the maximum output power of the primary coil is 5W. 3) The transfer system includes only single primary and secondary coils. This includes c…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-2E FCC TEST REPORT FCC ID: 2AN8FMSL-W6012Q Product Name: Photo Frame Wireless Charger Trademark: N/A Model Number: MSL-W6012Q Prepared For : Shenzhen Mossloo Industrial Co., Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Mar. 05, 2020 to Mar. 11, 2020 Date of Report : Mar. 11, 2020 Report No.: BCTC2003000112-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-013 Ver.：A.0 Page 1 of 21 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-2E TABLE OF CONTENTS TEST REPORT DECLARATION .................................................................................................. 3 1. GENERAL INFORMATION ........................................................................................................ 4 1.1. Report information .......................................................................................................................... 4 1.2. Measurement Uncertainty .............................................................................................................. 4 1.3. Test Facility ...................................................................................................................................... 4 1.4. Test Uncertainty .............................................................................................................................. 4 2. PRODUCT DESCRIPTION ......................................................................................................... 5 2.1. EUT Description .............................................................................................................................. 5 2.2. Test mode ........................................................................................................................................ 5 2.3. Block Diagram of EUT Configuration ........................................................................................... 5 2.4. Test Conditions ................................................................................................................................ 5 2.5. Description Of Support Units (Conducted Mode) ....................................................................... 6 3. TEST RESULTS SUMMARY ..................................................................................................... 7 4. TEST EQUIPMENT USED.......................................................................................................... 8 4.1. For Conducted Emission Test ....................................................................................................... 8 4.2. For Radiated Emission Measurement ......................................................................................... 8 5. CONDUCTED EMISSION TEST ................................................................................................ 9 5.1. Block Diagram of Test Setup ......................................................................................................... 9 5.2. Test Standard .................................................................................................................................. 9 5.3. Conducted Emission Limit ............................................................................................................. 9 5.4. EUT Configuration on Test ............................................................................................................ 9 5.5. Operating Condition of EUT ........................................................................................................ 10 5.6. Test Procedure .............................................................................................................................. 10 5.7. Test Result ..................................................................................................................................... 10 6. RADIATED EMISSION MEASUREMENT ............................................................................. 13 6.1. Block Diagram of Test Setup ....................................................................................................... 13 6.2. Test Standard and Limit ............................................................................................................... 14 6.3. EMI Test Receiver Setup ............................................................................................................. 15 6.4. Test Procedure .............................................................................................................................. 15 6.5. Test Result ..................................................................................................................................... 15 7. EUT TEST PHOTOS .................................................................................................................. 19 8. EUT PHOTOS ............................................................................................................................. 21 Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-013 Ver.：A.0 Page 2 of 21 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-2E TEST REPORT DECLARATION Applicant : Shenzhen Mossloo Industrial Co., Ltd Address : Road One No.4, Science Industrial Park, Shangxue Village, Bantian Street, Longgang District, Shenzhen, China EUT Description : Photo Frame Wireless Charger Model Number : MSL-W6012Q Test Standards: FCC Part 15 C This device described above has been tested by BCTC, and the test results show that the equipment under And it is applicable only to the tested sample identified in the report. This report shall not be repr…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-2E T est Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 2 8.EUT TEST PHOTOS Conducted Measurement Photos Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2003000112-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 2 Radiated Measurement Photos 9KHz-30MHz 30MHz-1GHz Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000767E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 5 EMF Test photos Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000767E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 5 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000767E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 5 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912000767E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 5 ※※※※※ ※※※※※ END OF REPORT
