2ANDX-CJX00Smart Jump Rope

130*90mm（展开450*130mm) 80g书写纸 4折5页 4C A/0 03.11.04.08030 A/0 / 说明书 物料编号 品 名 规格描述 版 本 批准 审核 设计 图 号 深 圳 市 伊 欧 乐 科 技 有 限 公 司 过程人员日期 130*90mm 风琴4折5页 80g书写纸 4C / 技术要求 规 格 材 质 印 刷 表面处理 蒋竹清2023.3.14 Turn on: Press the Mode Button for 1s Mode switch: Press the Mode Button for 1s Numbers/Time setting: Press the Mode Button for a short time Switch to view numbers/time: Press the Mode Button for a short time Completion of exercise: Click the Mode Button twice or stop jumping for 5 minutes Turn off: Press the Mode Button for 3s or stop jumping for 5 minutes a. b. c. d. e. f. Thank you for purchasing arboleaf Smart Jump Rope! To ensure safety and avoid any property damage, please read this manual carefully and keep it for future reference. Instructions When using this device, the following basic precautions should be followed. 1. Do not use the jump rope for something other than its intended use. 2. This is not a toy. Children shall not play with this product. 3. Do not skip rope before and within half an hour after a meal to avoid physical discomfort, and do not drink a lot of water before skipping rope. 4. If you feel shortness of breath or any discomfort, slow down to get circulation back to normal, then stop. 5. Do not keep the jump rope in a magnetic area or a magnet-influenced space, which may result in malfunction and battery loss. 6. Bending or twisting the jump rope may break the external and/or internal parts of the product. 7. Ambient temperature significantly below or above room temperature and any liquid component including water and humidity may damage the parts. 8. Do not use strong chemical agents or cleaner to clean the jump rope, it may cause discoloring or corrosion of the exterior part. Tip: It is recommended to grip the handle of the rope with the Mode Button facing upward for easy reading of the display. About the product 1.Whats in the Box 2 × Handles 1 × Rope 2 × Rope Buckles 2 × Cordless Ball 1 x Charging Cable 1 × User Manual 3.Product Introduction 2.Product Parameters Product Name: Smart Jump Rope Model: CJ20B Handle Size: 33×183mm/1.3×7.2inch Rope Length: 3m/9.8ft (Adjustable) Rope Material: PVC a.Press the Mode Button for 1s to turn on the jump rope. b.Start to rope skip and the skipping number will be shown on the display. Tips: Under free jump mode, the maximum number for a once is 9,999 times, and the longest time is 99 minutes and 59 seconds. It goes into completion when each value comes into the peak. a. Press the Mode Button to enter the Time Countdown mode. b. Press to select rope skipping time from 1min to 60min on the jump rope and long press to get started. c. The jump rope will play three beeps as a reminder of the completion of the target. The display will automatically show the final number. d. To stop during the set time or to manually save the data to the jump rope, just press and hold the Mode Button. Tips: Under time countdown mode, the jump rope support for sequential cycle settings for 1min/2min/3min/4min/5min/8min/10min/15min/30min/60min. Time less than 99 minutes and 59 seconds can be set in the app. 4.About charging Select the handle with Mode Button, open the rubber at the bottom of the handle, next insert the USB cable into the charging port, then connect it to the power. It will automatically turn off when charging, and the power indicator starts flashing. 5.If the jump rope can’t work, please follow the below steps: a.Check whether the battery power is sufficient or not b.Bluetooth is enabled or not c.Reset your smartphone d.Turn off and re-enable the Bluetooth Training Mode Setting (1)Set the Free Jump Mode Arboleaf APP Operation Guide (2)Set the Time Countdown Mode 1.Download the arboleaf app. Search "arboleaf" from Apple Store / Google Play or scan the QR code below to download the app. Warranty Terms & Policy This product is covered by a one-year manufacturer's warranty, and a great customer service for the lifetime of your scale. Your jump rope is warranted against defects in materials and workmanship for one year from the original purchaser from the date of purchase. Free replacement is provided during the warranty period. Proof of purchase is required. This warranty is non-transfer- able. Void Warranty The warranty is void if the product has been subjected to mechani- cal damage, mistreatment, or any other use that the product is not intended for. This warranty is in lieu of all other warranties and limits the liability of the manufacturer. 2.Open the app, and allow Bluetooth permission. Turn on location permission when using an Android phone. 3.Create a arboleaf account. Sign up and complete your profile. Pair your jump rope. On your app home screen, Click Devices>Add device, then choose Jump rope, and turn on your jump rope by pressing the Mode Button; Next Tap Jump Rope-CJ20B and Connect button, and finally click Finish. Your jump rope has successfully paired. 4.3 Training Modes Instruction Free Training a. Slide up to find Jump rope on the home page, Click Free training to enter the Free Jump mode. b. Click "GO" and count 3s to start skipping. c. Click "End" to end the Free Jump mode, and then click "Confirm" to get your rope-skipping data. (If less than 5, your skipping number will not be recorded.) Time Training a. Slide up to find Jump rope on the home page, Click Time training to enter the time countdown Jump mode. b. Click "GO" and count 3s to start skipping. c. Click "End" to end the Time mode, and then click "Confirm" to get your rope-skipping data. (If less than 5, your skipping number will not be recorded.) Counting Mode a.Slide up to find Jump rope on the home page, Click Counting training to enter the Number countdown mode. b.Click "GO" to start numbers countdown. c.Click "End" to end the Numbers Countdown mode, and then confirm to get your rope-skipping data. (If less than 5, your skipping number will not be recorded.) 1. Straighten the rope to your armpits (as shown). Try jumping and check whether the rope length is suitabl…

Text truncated - open the document above for the full version.

AttestationStatements (date)2023/3/24 TO:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046,USA RE:AttestationStatementsPart2.911(d)(7)requestfor(2ANDX-CJX00#) (ShenzhenYolandaTechnologyCo.,Ltd.),theundersigned,herebyauthorize(Global eFitIncorporated)toactasourdesignatedU.S.agentforserviceofprocess,(Shenzhen YolandaTechnologyCo.,Ltd.)acceptstomaintainanagentfornolessthanoneyear afterthegranteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment. (GlobaleFitIncorporated)acceptstheresponsibilitytoactasdesignatedU.S.agentfor serviceofprocess. ApplicantInformation： Companyname:ShenzhenYolandaTechnologyCo.,Ltd. ContactName:Huangwenhai Address:Room201,JinfulaiBuilding,No.49-1,DabaoRoad,DalangArea,Xinan Street,Baoan,ShenzhenChina TelephoneNo:0755-21635022 Email:[email protected] Signature [name] U.S.AgentInformation: CompanyName:GlobaleFitIncorporated Address:17304PrestonRoadSuite800DallasTX.75252，U.S.A. FRN:0033523366 ContactName:LiZhang TelephoneNo:214-205-0490 Email:[email protected] Signature [name]

Typevariancedeclaration Ourcompany'sproductsSmartJumpRope,therearethefollowing models:CJ20A,CJ20B，CJ20C,CJ20D,CJ20E,CJ20F,CJ20G,CJ20H,CJ20I, CJ20J,CJ20K,CJ20L,CJ20M,CJ20N,CJ20O,CJ20P,CJ20Q,CJ20R,CJ20S, CJ20T,CJ20U,CJ20V,CJ20W,CJ20X,CJ20Y,CJ20Z,thesemodelsare differencesincolor,theinternalcircuitandradiofrequencypartis completelyconsistent. Signature： Companyname：ShenzhenYolandaTechnologyCo.,Ltd

ProductName: SmartJumpRope

ProductName: SmartJumpRope

RFExposureevaluation ProductName: SmartJumpRope FCCID: 2ANDX-CJX00 TestStandard: KDB447498D04GeneralRFExposureGuidance v01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 Antgain=1.2dBi MAXoutputpower：-0.78dBm@2402MHz ERP=-0.78+1.2-2.15=-1.73dBm WORSECASE: 10^-0.078=0.863mW<2.715mW ThenSARevaluationisnotrequired

ReportNo.:BLA-EMC-202303-A4202 Page 31 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A4202 Page 32 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202303-A4202 Page 33 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section6.10.5 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 14.1LIMITS Frequency(MHz) Field strength(microvolts/meter) Measurement distance(meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above9605003 Remark:Theemissionlimitsshownintheabovetablearebasedonmeasurementsemployinga CISPRquasi-peakdetectorexceptforthefrequencybands9-90kHz,110-490kHzandabove1000 MHz.Radiatedemissionlimitsinthesethreebandsarebasedonmeasurementsemployingan averagedetector,thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermitted averagelimitsspecifiedabovebymorethan20dBunderanyconditionofmodulation. ReportNo.:BLA-EMC-202303-A4202 Page 34 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14.2BLOCKDIAGRAMOFTESTSETUP 14.3PROCEDURE a.Forbelow1GHz,theEUTwasplacedonthetopofarotatingtable0.8metersabovethegroundata3 or10metersemi-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthe highestradiation. b.Forabove1GHz,theEUTwasplacedonthetopofarotatingtable1.5metersabovethegroundata3 meterfully-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionofthehighest radiation. c.TheEUTwasset3or10metersawayfromtheinterference-receivingantenna,whichwasmountedon thetopofavariable-heightantennatower. d.Theantennaheightisvariedfromonemetertofourmetersabovethegroundtodeterminethe maximumvalueofthefieldstrength.Bothhorizontalandverticalpolarizationsoftheantennaaresetto makethemeasurement. e.Foreachsuspectedemission,theEUTwasarrangedtoitsworstcaseandthentheantennawastuned toheightsfrom1meterto4meters(forthetestfrequencyofbelow30MHz,theantennawastunedto heights1meter)andtherotatabletablewasturnedfrom0degreesto360degreestofindthemaximum reading. f.Thetest-receiversystemwassettoPeakDetectFunctionandSpecifiedBandwidthwithMaximumHold Mode. g.IftheemissionleveloftheEUTinpeakmodewas10dBlowerthanthelimitspecified,thentesting couldbestoppedandthepeakvaluesoftheEUTwouldbereported.Otherwisetheemissionsthatdidnot have10dBmarginwouldbere-testedonebyoneusingpeak,quasi-peakoraveragemethodasspecified andthenreportedinadatasheet. ReportNo.:BLA-EMC-202303-A4202 Page 35 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] h.TesttheEUTinthelowestchannel,themiddlechannel,theHighestchannel. i.TheradiationmeasurementsareperformedinX,Y,ZaxispositioningforTransmittingmode,andfound theXaxispositioningwhichitistheworstcase. j.Repeataboveproceduresuntilallfrequenciesmeasuredwascomplete. Remark1:Level=ReadLevel+CableLoss+AntennaFactor-PreampFactor Remark2:Forfrequenciesabove1GHz,thefieldstrengthlimitsarebasedonaveragelimits.However, thepeakfieldstrengthofanyemissionshallnotexceedthemaximumpermittedaveragelimitsspecified abovebymorethan20dBunderanyconditionofmodulation.Fortheemissionswhosepeaklevelis lowerthantheaveragelimit,onlythepeakmeasurementisshowninthereport. ReportNo.:BLA-EMC-202303-A4202 Page 36 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14.4TESTDATA [TestMode:TXlowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A4202 Page 37 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXlowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A4202 Page 38 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202303-A4202 Page 39 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXhighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202303-A4202 Page 40 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202303-A4202 Page 41 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15CONDUCTEDSPURIOUSEMISSIONS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.6&Section11.11 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 15.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthehighest levelofthedesiredpower,basedoneitheranRFconductedoraradiated measurement,providedthetransmitterdemonstratescompliancewiththepeak conductedpowerlimits.Ifthetransmittercomplieswiththeconductedpower limitsbasedontheuseofRMSaveragingoveratimeinterval,aspermittedunder paragra…

Text truncated - open the document above for the full version.

ReportNo.:BLA-EMC-202303-A4202 Page 61 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 19.6APPENDIXF:CONDUCTEDSPURIOUSEMISSION TestResult TestModeAntennaChannel FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 2402 Reference-1.15-1.15---PASS 30~1000-1.15-57.64<=-21.15PASS 1000~26500-1.15-51.24<=-21.15PASS 2440 Reference-1.85-1.85---PASS 30~1000-1.85-57.93<=-21.85PASS 1000~26500-1.85-47.08<=-21.85PASS 2480 Reference-1.60-1.60---PASS 30~1000-1.60-58.05<=-21.6PASS 1000~26500-1.60-42.59<=-21.6PASS ReportNo.:BLA-EMC-202303-A4202 Page 62 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TestGraphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 ReportNo.:BLA-EMC-202303-A4202 Page 63 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BLE_1M_Ant1_2402_1000~26500 BLE_1M_Ant1_2440_0~Reference ReportNo.:BLA-EMC-202303-A4202 Page 64 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BLE_1M_Ant1_2440_30~1000 BLE_1M_Ant1_2440_1000~26500 ReportNo.:BLA-EMC-202303-A4202 Page 65 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 ReportNo.:BLA-EMC-202303-A4202 Page 66 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] BLE_1M_Ant1_2480_1000~26500 ReportNo.:BLA-EMC-202303-A4202 Page 67 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] APPENDIXA:PHOTOGRAPHSOFTESTSETUP RadiatedSpuriousEmissions ReportNo.:BLA-EMC-202303-A4202 Page 68 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ConductedEmissionsatACPowerLine(150kHz-30MHz) ReportNo.:BLA-EMC-202303-A4202 Page 69 of 69 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] APPENDIXB:PHOTOGRAPHSOFEUT ReferencetothetestreportNo.BLA-EMC-202303-A4201 ----ENDOFREPORT---- Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthis reportreferonlytothesample(s)tested.WithoutwrittenapprovalofBlueAsia,thisreportcan’tbe reproducedexceptinfull.

Productspecification QuickReferenceDate Antennamoduleonthesystemboard FrequencRange2400~2500MHz Ant.PortInputPwr.(dBm)0(Typ.BTclass2outputpower) Tot.Rad.Pwr.(dBm)-1.2(Inputpwr–losspwr) PeakEIRP(dBm)1.2 Directivity(dBi)1(alldirectionantenna) Efficiency(dB)60.2% Gain(dBi)1.2(PeakGainXY-plane) MaximumPower(dBm)1.7(XY-plane) MinimumPower(dBm)-4(XY-plane) Avg.Power(dBm)-0.5(XY-plane) InputImpendence(ohm)50 PolarizationTypeVertical&Horizontal V.S.W.R<1.4 Manufacturer’snameShenzhenYolandaTechnologyCo.,Ltd Address Room201,JinfulaiBuilding,No.49-1,Dabao Road,DalangArea,XinanStreet,Baoan, Shenzhen,China Allthetechnicaldataandinformationcontainedhereinaresubjecttochangewithoutpriornotice AntennaLayout&moduleonthesystemboard AntennaGain GainTable [email protected] PeakAvg.PeakAvg.PeakAvg. ModuleBoard 1.2-0.51.2-3.61.1-3.060.2% RetumLoss TheEnvironmentofAntennaRadiationPattem 3Dradiationpatterndiagram XY-planeXZ-planeYZ-plane

ProductName: SmartJumpRope RadiatedSpuriousEmissions ConductedEmissionsatACPowerLine(150kHz-30MHz)
