Display icon description Charging icon will light up when charging Wi-Fi icon will light up when WiFi connected Bluetooth icon will light up when Bluetooth connected Muscle mass icon BMI icon Body fat% icon Low power reminder Overload reminder Feet Posture Hands Posture Step on scale barefoot. Don't let your feet and thighs touch each other Feet heels should not touch each other or make feet turn in The feet should not touch each other Put your thumbs on the oval electrodes and the four fingers on the strip electrodes and hold them. Let the handle cable is facing down Please do not hold it in fist The handle cable should not face up Product Front Product Back Appearance Hand electrodes Charging/handle cable port Reset hole Hand electrodes Handle cable Foot ITO electrodes Display screen Installation /ChargingWarning Insert handle cable into the type-c port at the top of the scale The first use requires to charge or insert the reset hole to activate the device Professional Body Composition Analyzer CS10A User’s Manual ModelCS10A Dimension Scale320 x 300 x 21 mm Handle317 x 35 x 23 mm Outputs(LED screen) Weight, Body Fat%, BMI, Muscle(Skeletal Muscle Mass) Power supply 400mAh lithium battery Working current <300mA Data transmission Bluetooth and WiFi Testing MethodDirect segmental Multi-frequency BIA Method Accessories CS10A scale, Measuring handle Type-C charging cable, User's manual Product Specifications This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. FCC ID: 2ANDX-CS10A Now, you can check the metrics and depth measurement report on the app 34 5 Tap the device name on the pairing page Keep standing on the scale and holding the handle for 10-15seconds. When your metrics appears on the APP, congratulations! you have successfully completed the measurement Pair the scale with WiFi Note: 1. If you didn't pair the scale with WiFi after the first measurement, you can select the device with the WiFi logo in "Device Management" to configure the WiFi settings 2. Once you pair the scale with WiFi, you can always use WiFi to connect it without Bluetooth on After completing the first measurement, it will ask you whether need to pair the scale with WiFi, tap"OK" Enter the correct WiFi password (Remark: This device only supports 2.4GHz WiFi, so please choose a stable 2.4GHz WiFi) Wait for connecting scale to WiFi. At this time, the WiFi icon will flash on the scale Congratulation! You have succesfully paired your scale to WiFi 1 2 34 Stand straightly, make sure your arms are extended from your body and wear light clothes and don't let your arms touch your waist Arms are bent inward Arms are too high Arms are bent too low Wear too heavy clothes Test Posture Precautions 1. People with blow medical devices should not use this device Implantable medical electronic devices such as cardiac pacemakers Artificial heart and other medical electronic equipment Wearable medical electronic equipment such as electrocardiograph 2. Do not jump on the device 3. Please measure at the same time and under the same conditions every day 4. To ensure accurate measurement, please place the scale on a hard and flat floor 5. When there is a big deviation in measuring the weight, you can try to use a small object such as a needle to insert the mechanical reset hole Reset hole App Usage Pairing and measurement Open Feelfit, turn on Bluetooth ( above Android 6.0 system requests to enable location access), click "+" and select the " Device Management" Step on the scale with bare and dry feet 12 Search and download "Feelfit" in the App Store or Google play Download the APP Weight Range0.2-180kg(0.4Ib-396Ib) Electrode MethodTetrapolar 8-Point Tactile Electrode Methods Display typeLED    NN

䫔곜
(Ꜥ晜紺
$ 㼓꬗㼓䏀 When the scale displays "Lo", it means that the scale battery is low and needs to be charged. As shown in the picture below, please use the USB cable and the charging head(daily mobile phone charging head 5A/1A is available) to charge

S21052601909 Model: CS10A Photo 1 Photo 2 S21052601909 Model: CS10A Photo 3 Photo 4 S21052601909 Model: CS10A Photo 5 Photo 6 S21052601909 Model: CS10A Photo 7

后标贴 物料编号 品 名 规格描述 版 本 批准 审核 设计 图 号 文件 编号 深 圳 市 伊 欧 乐 科 技 有 限 公 司 过程 人员 日期 鲁婉蓉 2021/7/23 A/ / 0 技 术 要 求 规格：59.5*27.5mm 4-R=1mm 材质：50# 透明龙 印刷：黑色印刷 覆光膜 59.5*27.5mm R1 50#透明龙 单黑印刷 光膜 A/0 Model: CS10A Product Name: Smartscale Dimension: 320 x 300x 21 mm Weight Range: 0.2~ 180kg Power supply: 400mAh lithium battery Testing Method: Direct segmental Multi-frequency BIA Method This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interferencereceived, includinginterference thatmay cause undesired operation. Please search and download "Feelfit" APP in App Store or Google Play

S21052601909 Model: CS10A Photo 1 Photo 2 S21052601909 Model: CS10A Photo 3 Photo 4 S21052601909 Model: CS10A Photo 5 Photo 6 ANT S21052601909 Model: CS10A Photo 7 Photo 8 S21052601909 Model: CS10A Photo 9 Photo 10

FCC ID: 2ANDX-CS10A RF EXPOSURE EVALUATION Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. WIFI Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n 10g SAR Exclusion threshold SAR test exclusion 2.412 12.59 18.155 12±113 19.953<56.197537.50YES 2.437 12.04 15.996 12±113 19.953<56.229577.50YES 2.462 12.03 15.959 12±113 19.953<56.261447.50YES 2.412 12.64 18.365 12±113 19.953<56.197537.50YES 2.437 11.18 13.122 12±113 19.953<56.229577.50YES 2.462 12.69 18.578 12±113 19.953<56.261447.50YES 2.412 12.62 18.281 12±113 19.953<56.197537.50YES 2.437 11.06 12.764 12±113 19.953<56.229577.50YES 2.462 12.81 19.099 12±113 19.953<56.261447.50YES 2.422 12.33 17.100 12±113 19.953<56.210367.50YES 2.437 11.19 13.152 12±113 19.953<56.229577.50YES 2.452 11.27 13.397 12±113 19.953<56.248717.50YES 802.11b 802.11g 802.11n HT20 802.11n HT40 BLE Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n 10g SAR Exclusion threshold SAR test exclusion 2.4025.62 3.648 6±17 5.012<51.553527.50YES 2.4404.64 2.911 5±16 3.981<51.243737.50YES 2.4806.08 4.055 6±17 5.012<51.578547.50YES GFSK Note: The product does not support simultaneous launch Conclusion: For the max result : 6.26144≤ 7.5 for 10-g SAR, No SAR is required. Signature: Date: 2021-07-22 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.
