WELCOME TO WYZE IN THE BOX Wyze Home Monitoring is an automated monitoring service designed to keep your home saf e and report thr eat s even when you can’t r eview Events by yourself. During an emergency, an agent from the monitoring center will reach out to you and dispatch authoritie s if necessar y. Wyze Sense Hub × 1 Wyze Keypad × 1 Contact Sensor × 2 Wyze Entry Motion Sensor × 1 Quick Start Guide × 1 Window Decals × 2 Hub The brains of your new security system. The Sense Hub connects sensor s to the Wyze app and has a built-in sir en to war d to your home internet via WiFi or Ethernet o would-be intruders. Connect the Hub and make sur e it’s placed in a central location for best cover age. Keypad Placed near your door, t he Wyze Sense Keypad makes it easy to quickly arm and disarm your system. Motion Sensor Designed to detect people and not pets. Place it high on the wall for best coverage. Entry Sensor Always know when your doors are open or left open. Mount on primary entry/exits and windows. ACTIVATION To activ at e Wyze Home Monitoring, enter your activ ation code thr ough the following link: services.wyze.com Note: If you ordered a Wyze Cor e Star ter Kit online, y ou may activat e your Home Monitoring thr ough your email. Total installation time should take less than 40 minutes. Befor e you get star ted, make sur e you have a step ladder or stool handy and a scr ewdriver if you plan to mount your motion sensor in a corner. Make sur e to follow the in-app guide to ensur e your devices are added to your Wyze account and installed properly. IN STALLATION & SETUP SETUP Control and monitor your entir e home via the Wyze app. T o get star ted, simply download the Wyze app to your mobile phone and log in or create an account. 1 HARDWARE OVERVIEW To star t your Home Monitoring setup, navigate to the Wyze app, and go into the Home Monitoring Tab. When your Home Monitoring license is activ at ed, you can tap on the ‘Star t Setup' button. This will guide you thr ough the installation process. Not seeing thi s scr een? Go to services.wyze.com to activ at e. WYZE SENSE HUB WYZE SENSE KEYPAD Ensur e your phone’s Bluetooth is turned on Click on the Monitoring tab in the bottom navigation bar of the Wyze app Use the included cables to plug the device into a nearby outle t and router . If your router is not locat ed in a central location, you can also connect the Hub to WiFi Rai se the two antennas Press the Reset button on the back of t he device Follow the in-app instructions to complete setup After the Hub is set up, you will be prompted to add additional devices. Click on each device to begin setup. batteries Replace the batter y cover Slide the mounting plate and battery cover o to insert 3 AA Press the Reset button Name your keypad Clean the desir ed mounting location and wait for it to dry completely Use the adhesive back or screws to secure the mounting plate to the wall Attach your keypad to the mounting plate NOTE: the adhesive is semi-permanent and may peel paint when removed The Keypad is designed to be mounted on the wall near your door and connects to the Hub. MOTION SENSOR Remove the plastic batter y tab. If you previously removed it, pr ess and hold the reset button until the status light flashes 3 times Name your sensor Clean the desir ed mounting location and wait for it to dry completely Use the adhesiv e backing to secure the mounting plate to the desir ed location Use scr ews for optional added security Attach sensor to mounting plate Mount on wall or corner ~7 feet high Avoid placing it near heat sources (v ents, lamps, etc.) Ensur e Wyze logo is on the LEFT side 123 PIN ENTRY & EXIT DELAYS Control how much time you allow to disarm your system befor e an alarm. You may choose between 0 to 180 seconds. If you do not disarm your system, an alarm will begin. Entry Delay Control the amount of t ime for people to leave your home befor e the system is armed. You may choose between 0 to 180 seconds. Exit Delay Change your Entry & Exit Delay Go into the Home Monitoring Tab Scr oll to the bottom to find the Home Monitoring Settings button Navigate to Entry & Exit Delay Choose your delay time for Home or Away 1 2 3 4 1 Enter your PIN and then press the checkmark and your desir ed mode Your PIN will be used to disarm your system or cancel an Emergency Response request. This PIN will be enter ed thr ough the Wyze Sense Keypad or thr ough the Wyze app. Go into the Home Monitoring Tab Scr oll to the bottom and tap into Home Monitoring Settings Tap Home & Away Choose the sensor s that you would like for each mode HOW TO ARM & DISARM YOUR SYSTEM HOW TO CHOOSE SENSORS FOR HOME & AWAY MODE Arm/Disarm thr ough Keypad What is a PIN? Press the Disarmed, Home, or Away button in the Home Monitoring tab Arm/Disarm thr ough Wyze app NEED HELP? Contact our support team: https://support.wyze.com Join our Community: https://wyze.com/community Scan the QR code to learn more USER MANUAL Wyze Home Monitoring 2 1 2 3 4 5 6 1 2 3 4 5 6 7 1 2 3 4 5 6 1 1 1 2 3 4 Activ at e thr ough your Keypad Press & hold the Emergency Button on the right side of your Keypad Activ at e thr ough Wyze app Go into the Home Monitoring Tab Tap the Emergency But ton icon on the top right side Confirm on the dialog to activ at e the Emergency But ton EMERGENCY BUTTON The Emergency But ton will be used to manually activ at e Alarm Response. Alarm Response will trigger an alarm and notif y our monitoring service provider, Noonlight. SAFE WORDS A Saf e Wor d is a secret wor d chosen by you and used by your monitoring agent to verify your saf ety. It is important to choose a wor d that can be pronounced cle arly in high-str ess situations. During an activ e alarm, our monitoring agent will contact you to confirm your saf ety. If you are unable to repeat your saf e wor d, our monitoring agent may dispatch emergency services to your location. What is a Saf e Wor d? Change your Saf e Wor d Go into the Home Monitoring Tab Scr oll to…

Text truncated - open the document above for the full version.

Rev 1/26/2023 TianJin HuaLai Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023/3/23 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2ANJHSS100BX TianJin HuaLai Technology Co.,Ltd. (“Guoqing Wang”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, ------------------------------- Guoqing Wang Rev 1/26/2023 TianJin HuaLai Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023/3/23 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2ANJHSS100BX TianJin HuaLai Technology Co.,Ltd. (“Guoqing Wang”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, ------------------------------- Guoqing Wang

TianJin H No.10 Jin Date: 03/ Federal C Authoriza 7435 Oa Columbia Grantee US TianJin H Agent, LL 2ANJHS TianJin HuaLai Technology Co.,Ltd. United S t marketing Commiss later. FCC US the desi g Technolo 2ANJHS Designa t Company FRN: 003 Address: Contact P Phone: 7 Email: Su Sincerely Company Company Signatur e HuaLai Tech nPing Road, Y /23/2023 Communicat ation and Ev kland Mills R a, MD 21046 Code: 2ANJ S Agen HuaLai Techn LC to accept S100MX; FC tates for no l g and import sion-related a Agent, LLC, gnated agent ogy Co.,Ltd.fo S100KX; FC ted Agent In y Name: FCC 33402884 3722 Illinoi s Person: Tim 708-571-3148 upport@FCC y, y: TianJin HuaLai Technology Co.,Ltd. y Representa e: nology Co.,L Ya An Street tions Comm valuation Div Road 6 JH t – Atte nology Co.,L t service of p CC ID: 2ANJ ess than one tation of the a administrativ accepts as o t for the purp or (FCC ID: 2 CC ID: 2ANJ nformation: C US Agent, s Avenue, Sa Payne 8 CUSAgent.co ative: Guoqin Ltd. ,Nankai Distr ission vision station Ltd.certifies, t process on ou JHSS100KX , accepts to maintain an agent of service of process in the e year after e applicable eq ve or judicial of the date o pose of accep 2ANJHSS10 HSS100EX) LLC aint Charles, om ng Wang rict Tianjin, C Statem that as of [DA ur behalf for ; FCC ID: 2 A either the gra quipment wit proceeding i of the filing of pting service 00BX; FCC I ). IL, 60174, U Designat Designat Signature China ent / Pa ATE], we hav (FCC ID: 2A ANJHSS100 antee has pe thin the U.S. involving the f this applica e of process o D: 2ANJHSS USA ted Agent: FC ted Agent Re e: art 2.91 ve designate ANJHSS100B EX). ermanently te , or the conc e equipment, ation, the obli on behalf of S100MX; FC CC US Agen epresentative 1(d)(7) ed FCC US BX; FCC ID: erminated all clusion of any whichever is igation of bei TianJin Hua CC ID: nt, LLC e: Tim Payne : l y s ing Lai e

TianJin HuaLai Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2023/3/23 SUBJECT: FCC Application for (FCC ID: 2ANJHSS100BX) To Whom It May Concern: I, the undersigned, hereby states this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules, and will apply the Supplier's Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. I understand the following FCC requirements: 1. Devices subject to the SDoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm (Select the "accredited" option to search for FCC recognized accredited test firms.) 2. Pt 2.1077 contains the list of information that must be included in the Supplier's Declaration of Conformity, which must be supplied with each product sold. The SDoC compliance info shall be included in the User’s Manual or as a separate sheet. The info must contain the name, address, and phone number of the responsible party, which must be located within the United States. According to 2.909(b), the responsible party is either the Manufacturer or if the product is imported the Importer. Regards, TianJin HuaLai Technology Co.,Ltd. ------------------------------- Guoqing Wang

\\192.168.0.6\rf无线2\3.2023年案件\3月\邓飘\2.15-C230131001-LCSA021423039E-陈婉君-Hub-FCCID\form\POA_Letter.docx TianJin HuaLai Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2023/3/23 SUBJECT: FCC Application for (FCC ID: 2ANJHSS100BX) To Whom It May Concern: We, the undersigned, hereby authorize Gavin Liang at Shenzhen LCS Compliance Testing Laboratory Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen LCS Compliance Testing Laboratory Ltd.on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ------------------------------- Guoqing Wang

Rev 11/20/07 TianJin HuaLai Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ANJHSS100BX Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram “Block Diagram.pdf” Schematics “Schematic.pdf” Operational Description “Operation Description.pdf” The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: confidentiality period is 180 days. Exhibit Type File Name User Manual “User Manual.pdf” External Photos “External Photos.pdf” Internal Photos “Internal Photos.pdf” Test Setup Photos “Test Setup Photos.pdf” Sincerely, ------------------------------- Guoqing Wang

Page 1 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8

SHEET 1 OF 2 ROKU PNDESCRIPTIONROKU REV. 0002005520 ARTWORK, LASER ETCH, OWL2, HOME MONITORING SYSTEM, HUB 020923 03 REV.DRAWN BYCHECKED BYDATEDATEDESCRIPTION SHEETS REV’D 01 RONG 102522INITIAL RELEASEALLPERIN102522 02 HENDERSON 120122UPDATED TITLE AND ADDED SHEET WITH LOGO, ADDED TMALL PERIN120122 03LIN020923 REMOVED DVT 2 FROM REGULATORY, ADDED DATE CODE, UPDATED FCC ID 2 PERIN020923 DO NOT SCALE; ARTWORK PLACEMENT 1:1 LASER-ETCHED GRAPHIC COLOR: PMS COOL GRAY 8U LASER-ETCH POSITION TOLERANCE ± 0.2MM 1 2 3 4 NOTES UNLESS OTHERWISE SPECIFIED 13.50mm 66.94mm COOL GRAY 8 U 4.23mm 5.55mm 9*9 SHEET 2 OF 2 ROKU PNDESCRIPTIONROKU REV. 0002005520 ARTWORK, LASER ETCH, OWL2, HOME MONITORING SYSTEM, HUB 020923 03 DO NOT SCALE; ARTWORK PLACEMENT 1:1 LASER-ETCHED GRAPHIC COLOR: PMS COOL GRAY 8U CENTER ARTWORK OVER CENTERLINES LASER-ETCH POSITION TOLERANCE ± 0.2MM FOR DATE CODE: WWYY WW= WEEK OF CALENDAR YEAR YY= LAST TWO DIGITS OF CALENDAR YEAR 1 2 3 4 5 6 NOTES UNLESS OTHERWISE SPECIFIED Monitoring Hub Model: SS100BX Made in China Input: 5V 1A FCC ID: 2ANJHSS100BX Dev ID: XXXXXXXXXXXX MAC: XX:XX:XX:XX:XX:XX Date Code: WWYY Only use the power supply provided. 26.00mm 43.75mm COOL GRAY 8 U C L1 C C L2 C Gotham Medium 6.5 pt Dev ID: S0X912C32E1E MAC: 7C:67:AB:3A:60:2B Date: 1523

Page 1 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 BT ANT SRD ANT WIFI ANT Page 2 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8

Page 1 of 6 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information EUT : Roku Monitoring Hub Test Model : SS100BX Power Supply : Input: 5V1000mA For Adapter Input: 100-240V~, 50/60Hz, 0.25A Max For Adapter Output: 5V1000mA Hardware Version : GW3U-P1.0-V1.8 Software Version : 6.0.0.39 Bluetooth : Frequency Range : 2402MHz ~ 2480MHz Channel Number : 40 channels for Bluetooth V5.0 (DTS) Channel Spacing : 2MHz for Bluetooth V5.0 (DTS) Modulation Type : GFSK for Bluetooth V5.0 (DTS) Bluetooth Version : V5.0 Antenna Description : Internal Antenna0, 3.8dBi (max.) WIFI(2.4G Band) : Frequency Range : 2412MHz ~ 2462MHz Channel Spacing : 5MHz Channel Number : 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) Modulation Type : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : External Antenna1, 2.2dBi (max.) SRD : Frequency Range : 906.8MHz, 910MHZ, 913.2MHz Channel Number : 3 Modulation Type : GFSK Antenna Description : External Antenna2, 2.0dBi (Max.) Page 2 of 6 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density Page 3 of 6 FCC ID: 2ANJHSS100BX Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Internal Antenna0 2400-2500 MHz 3.8dBi BT Antenna External Antenna1 2400-2500 MHz 2.2dBi WIFI Antenna External Antenna2 906.8-913.2MHz 2.0dBi SRD Antenna 6. Conducted Power [BT LE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 18.64 19 2440 18.82 39 2480 18.87 [2.4G WLAN] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 17.25 6 2437 17.33 11 2462 18.27 IEEE 802.11g 1 2412 19.10 6 2437 19.75 11 2462 19.14 IEEE 802.11n HT20 1 2412 18.53 6 2437 18.79 11 2462 18.54 IEEE 802.11n HT40 …
