Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 32 | 9 | 824 MHz - 824 MHz | 169.04 mW | 127KG7D | 1
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesOutput power listed is conducted.
This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. This module can only be used when installed in a host device that follows the required instructions for use of a trace reference design and an antenna type as described in this filing.
The host integrator must follow the integration instructions provided by the module manufacturer and ensure that the composite-system end product complies with the FCC requirements by a technical assessment or evaluation to the FCC rules and to KDB Publication 996369.
The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required.
The module grantee is responsible for providing the documentation to the system integrator on restrictions of use, for continuing compliance of the module.
Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures.
The maximum antenna gain for compliance with radiated power limits and RF exposure requirements is 9.0 dBi for LTE FDD 2/25 frequency band, 6.0 dBi for LTE FDD 4 frequency band, 7.1 dBi for LTE FDD 5/26 frequency band, 6.6 dBi for LTE FDD 12 frequency band, 6.9 dBi for LTE FDD 13 frequency band, 6.6 dBi for LTE FDD 17 frequency band, 6.0 dBi for LTE FDD 66 frequency band, 6.6 dBi for LTE FDD 85 frequency band.
This device contains functions that are not operational in U.S. Territories. This filing is only applicable for U.S. operations.
