Nordic Thingy:53 Hardware User Guide 4471_002 / 2022-06-17 Contents Revision history. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv 1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 2Kit content. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 2.1 Downloadable content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3Firmware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 3.1 Programming Nordic Thingy:53 . . . . . . . . . . . . . . . . . . . . . . . . . . 10 4Hardware description. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 4.1 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4.2 Hardware figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4.3 nRF5340 SoC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 4.3.1 NFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 4.3.2 USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 4.3.3 Antenna selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 4.3.4 RF measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 4.4 nRF21540 RF FEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.5 Pin maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 4.6 Motion sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.7 Environmental sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 4.8 Microphone and buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4.9 External memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4.10 LEDs and buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 4.10.1 RGB LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 4.10.2 Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 4.11 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 4.11.1 nPM1100 PMIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 4.11.2 Battery voltage monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 4.11.3 External 3.3 V regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 4.11.4 Sensor power control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 4.11.5 Current measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 4.12 Programming and debugging interface . . . . . . . . . . . . . . . . . . . . . . . 28 4.13 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 4.13.1 Current measurement and debug interface . . . . . . . . . . . . . . . . . . . 29 4.13.2 Expansion board interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . 30 4.13.3 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 4.13.4 Test points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 4.13.5 Solder bridge configuration . . . . . . . . . . . . . . . . . . . . . . . . . 34 5Regulatory notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 5.1 FCC regulatory notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 5.2 Extended FCC modification statement . . . . . . . . . . . . . . . . . . . . . . . 36 5.3 FCC Title 47 CFR Part 15.247 . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 5.4 FCC Title 47 CFR Part 2.1091, 2.093, 1.1307 . . . . . . . . . . . . . . . . . . . . . 37 5.5 CE regulatory notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 5.6 ETSI EN 300 328 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 5.7 EN IEC 62311:2020 and IEC 62479:2021 . . . . . . . . . . . . . . . . . . . . . . 39 4471_002 ii 5.8 REACH SVHC statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Recommended reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44 Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 4471_002 iii Revision history DateDescription 2022-06-17First release 4471_002 iv 1 Introduction The Nordic Thingy:53 ™ is a battery-operated prototyping platform for Internet of Things (IoT). It is ideal for rapid development of prototypes for IoT systems. The Nordic Thingy:53 includes sensors that gather data about its own movements and the surrounding environment. Temperature, humidity, air quality, air pressure, color, audio, and light data can be easily extracted for local or remote analysis. For input, the Nordic Thingy:53 offers two user-programmable buttons. Visual output is achieved with an RGB indicator LED, while a buzzer can provide audible output. The preprogrammed firmware on the Nordic Thingy:53 allows to connect to the nRF Edge Impulse mobile application that can be used to sample training and test data from the Nordic Thingy:53 sensors. The sampled data can be used to train machine learning models in the Edge Impulse Studio. Trained machine learning models can be deployed to the Nordic Thingy:53 through Bluetooth ® Low Energy using the nRF Edge Impulse mobile application. The firmware has been developed using the nRF Connect Software Development Kit (SDK). The preprogrammed firmware on the Nordic Thingy:53 can be easily updated through Bluetooth Low Energy to other samples from the nRF Connect SDK using the nRF Programmer application for iOS and Android or through Universal Serial Bus (USB) using the nRF Connect Programmer. The firmware can be updated and debugged also by using an external programmer or debug probe, for example, the nRF5340 Development Kit (DK) or a J-Link device supporting Arm ® Cortex ® -M33. The Nordic Thingy:53 integrates the nRF5340 SoC which supports Bluetooth Low Energy, 802.15.4, and Near…

Text truncated - open the document above for the full version.

Thingy:53 Label Design and Placement Right label: Placed on cardboard box. Left label: Placed on printed circuit board (PCB). PCB Label Placement Cardboard box Label Placement

WLA.01 Antenna 1 Frequency [MHz]Efficiency [%]Peak Gain [dBi]Efficiency (Average Gain) dB 20005,15903011-10,26059914-12,87431908 20025,237183347-10,18532372-12,80902195 20045,413397774-9,945326805-12,66530037 20065,55533506-9,865371704-12,55289745 20085,590614304-9,906694412-12,52540493 20105,623551458-9,877252579-12,49989319 20125,772275105-9,718125343-1,24E+01 20146,00775145-9,502790451-1,22E+01 20166,192961335-9,42870903-1,21E+01 20186,281394511-9,35813427-1,20E+01 20206,374852359-9,272704124-1,20E+01 20226,532761455-9,145223618-1,18E+01 20246,655243784-9,080028534-1,18E+01 20266,669393927-9,071905136-1,18E+01 20286,65858835-9,069239616-1,18E+01 20306,728235632-9,015275955-1,17E+01 20326,851795316-8,921667099-1,16E+01 20346,977168471-8,844873428-1,16E+01 20367,125411928-8,748206139-1,15E+01 20387,307416946-8,635425568-1,14E+01 20407,47333914-8,528508186-1,13E+01 20427,558901608-8,479499817-1,12E+01 20447,715003192-8,408842087-1,11E+01 20467,992219925-8,225700378-1,10E+01 20488,265334368-8,03139782-1,08E+01 20508,384078741-7,985284328-1,08E+01 20528,497042954-7,971775532-1,07E+01 20548,672107011-7,872323513-1,06E+01 20568,912696689-7,732599735-1,05E+01 20589,034466743-7,725710869-1,04E+01 20608,997678757-7,80858469-1,05E+01 20629,087954462-7,753276825-1,04E+01 20649,439298511-7,507452965-1,03E+01 20669,863232076-7,329181671-1,01E+01 206810,12357846-7,299430847-9,95E+00 207010,32375097-7,223833561-9,86E+00 207210,56443155-7,042653084-9,76E+00 207410,90630293-6,846305847-9,62E+00 207611,12530977-6,802937508-9,54E+00 207811,28142029-6,749658585-9,48E+00 208011,58649921-6,555576324-9,36E+00 208211,96120307-6,349648952-9,22E+00 208412,11091951-6,347630501-9,17E+00 208612,06786782-6,410097122-9,18E+00 208812,16434762-6,344094276-9,15E+00 209012,56905943-6,149849415-9,01E+00 209213,12843263-5,945767879-8,82E+00 209413,38698417-5,90278101-8,73E+00 209613,42089176-5,918147564-8,72E+00 209813,56119663-5,860654354-8,68E+00 210013,87622207-5,740567207-8,58E+00 210214,08589482-5,671241283-8,51E+00 210414,16150779-5,659793854-8,49E+00 210614,24757987-5,631311893-8,46E+00 210814,40816373-5,579033852-8,413913727 211014,54215646-5,538944721-8,373711586 211214,61120546-5,53197813-8,353138924 211414,75473046-5,497005463-8,310687065 211614,96170908-5,441929817-8,250187874 211815,12811184-5,393713474-8,202153206 212015,30637592-5,361155987-8,151276588 212215,58968872-5,272785187-8,07162571 212415,95911831-5,14908886-7,969911098 212616,15939587-5,086229324-7,915748596 212816,14641547-5,14058876-7,919238567 213016,20798409-5,15346241-7,902709961 213216,70267135-4,949003696-7,772140503 213417,15427339-4,767416-7,656276703 213617,17178524-4,806598186-7,651845455 213816,91677272-4,947662354-7,716825008 214016,91653281-4,938535213-7,71688652 214217,34018624-4,789262772-7,609462738 214417,79239178-4,648853302-7,497656345 214618,12017709-4,564633369-7,418375492 214818,532978-4,453205109-7,320548058 215019,14338619-4,24896431-7,179812431 215219,57421154-4,142385483-7,083157063 215419,8971346-4,096412659-7,012094498 215620,26153356-4,027817249-6,933276653 215820,76501101-3,883404732-6,826678276 216021,25478685-3,724353075-6,725432396 216221,56476229-3,630313635-6,66255331 216421,77919596-3,591365099-6,619581699 216622,10482955-3,517077684-6,555128098 216822,50075042-3,436988115-6,478029728 217022,79843986-3,39462018-6,420948982 217223,42257798-3,249070644-6,30365324 217424,41978306-3,015999317-6,122581959 217625,67620873-2,780859947-5,904691219 217826,60784125-2,64388299-5,749903679 218027,06700861-2,555894375-5,675597191 218227,32610703-2,479073048-5,634222507 218427,86119282-2,344857454-5,550002575 218628,42783034-2,229153872-5,462562561 218828,81435454-2,14721036-5,403911114 219029,24403548-2,059962034-5,339627266 219229,5594126-2,00646162-5,293042183 219429,67352867-2,004934072-5,27630806 219629,67559695-1,977014065-5,276005268 219829,98295724-1,870593905-5,231255531 220030,84887564-1,727903843-5,107606411 220232,0615083-1,56667614-4,940160751 220432,91013837-1,458958387-4,826703072 220633,51153433-1,350680113-4,748056889 220834,29414332-1,215312004-4,647800446 221035,02579927-1,091642022-4,556119442 221235,04992127-1,042300701-4,553129196 221434,55534577-1,041321039-4,61484766 221634,52788591-1,023499727-4,618299961 221835,15741825-0,947754979-4,539830208 222035,66331565-0,882170856-4,477782726 222235,57467163-0,847046494-4,488591194 222435,19175947-0,870289385-4,535590172 222635,18627584-0,869749367-4,536266804 222835,48077643-0,818793058-4,500068665 223035,79048812-0,768517852-4,462323666 223236,01140976-0,741703689-4,43559885 223436,38968766-0,696436703-4,390216351 223636,78811193-0,628547311-4,342925072 223836,83805764-0,576214552-4,337032795 224036,69451773-0,577049434-4,353988171 224236,74560189-0,571859717-4,347946644 224437,00143695-0,53257972-4,31781435 224636,92733347-0,516582608-4,326520443 224836,30260229-0,599957526-4,400622368 225035,8402729-0,668507695-4,456286907 225236,00217104-0,652038157-4,436713219 225436,06148958-0,653864324-4,429563522 225635,60489416-0,73870194-4,484903336 225835,13343632-0,820262551-4,542793751 226035,21828353-0,813626289-4,532318115 226235,62218249-0,773915946-4,482794762 226435,69301367-0,787556291-4,474167824 226635,51843762-0,841929495-4,495461464 226835,56247354-0,83716315-4,490080357 227035,83422899-0,796575308-4,457019329 227235,59478223-0,850799203-4,486136913 227435,1791203-0,933682799-4,537150383 227635,04069149-0,958225012-4,554273129 227835,19060016-0,942131579-4,535733223 228035,14518142-0,978503048-4,541342258 228235,00724733-1,015558839-4,558420658 228435,31089723-0,885764837-4,520912647 228636,06564403-0,795913577-4,429062843 228836,11575067-0,916604817-4,423033714 229034,90145802-1,124031782-4,571564198 229234,09267664-1,115163445-4,673388958 229434,57710445-0,94385618-4,612113953 229635,84064841-0,871290207-4,456241608 229836,39785647-0,912032485-4,389241695 230035,94750762-0,947797537-4,443312168 230235,37342846-0,952068925-4,513228416 230435,45215428-…

Text truncated - open the document above for the full version.

SPE-11-8-146/M/SS Page 1 of 17 SPECIFICATION Part No. WLA.01 Model 2.4GHz High Efficiency Loop Antenna Description 2.5dBi 2400MHz to 2500MHz WLAN/WIFI/Bluetooth/Zigbee Features 3.2*1.6*0.5mm Low Profile Peak gain 2.5dBi 50 Ohm Impedance RoHS Compliant SPE-11-8-146/M/SS Page 2 of 17 1. Introduction The WLA.01 2.4GHz Loop antenna is a high efficiency, miniature SMD, edge mounted ceramic antenna for very small space requirements for Wi-Fi, WLAN, Zigbee, Bluetooth, and 802.11 applications. The WLA.01 uses the main PCB as its ground plane, thereby increasing Antenna Efficiency. It is tuned for different PCB sizes by simply changing the value of the matching circuit. At 3.2mm*1.6mm*0.5mm, the WLA.01 is one of the smallest antennas available worldwide. This antenna is delivered on tape and Reel. Many module manufacturers specify peak gain limits for any antennas that are to be connected to that module. Those peak gain limits are based on free-space conditions. In practice, the peak gain of an antenna tested in free-space can degrade by at least 1 or 2dBi when put inside a device. So ideally you should go for a slightly higher peak gain antenna than mentioned on the module specification to compensate for this effect, giving you better performance. Upon testing of any of our antennas with your device and a selection of appropriate layout, integration technique, or cable, Taoglas can make sure any of our antennas’ peak gain will be below the peak gain limits. Taoglas can then issue a specification and/or report for the selected antenna in your device that will clearly show it complying with the peak gain limits, so you can be assured you are meeting regulatory requirements for that module. For example, a module manufacturer may state that the antenna must have less than 2dBi peak gain, but you don’t need to select an embedded antenna that has a peak gain of less than 2dBi in free-space. This will give you a less optimized solution. It is better to go for a slightly higher free-space peak gain of 3dBi or more if available. Once that antenna gets integrated into your device, performance will degrade below this 2dBi peak gain due to the effects of GND plane, surrounding components, and device housing. If you want to be absolutely sure, contact Taoglas and we will test. Choosing a Taoglas antenna with a higher peak gain than what is specified by the module manufacturer and enlisting our help will ensure you are getting the best performance possible without exceeding the peak gain limits. 1.1 Applications • Bluetooth earphone systems • Hand-held devices when Bluetooth/Wi-Fi functions are needed, e.g., Smart phone. • IEEE802.11 b/g • ZigBee • Wireless PCMCIA cards or USB dongle SPE-11-8-146/M/SS Page 3 of 17 2. Specifications The WLA.01 is designed to mount at the center of the edge of an evaluation board of 80 x 40mm.The antenna performance was measured with the WLA.01 mounted on the evaluation board with SMA(F) connector. No Parameter Specification* 1 Center Frequency 2400-2500MHz 2 Dimensions 3.2*1.6*0.5mm 3 VSWR 2 max 4 Polarization Linear 5 Bandwidth 100MHz min. 6 Gain Peak 2.5dBi typ. 7 Efficiency 84% typ. 8 Impedance 50 W Mechanical 9 Dimensions 3.2*1.6*0.5mm 10 Material Ceramic Environmental 11 Operating Temperature -40°C~+85°C 12 Storage Temperature -40°C~+105°C 13 Temperature Coefficient（τf） 0 ± 20 ppm @-20ºC to +80ºC 14 Recommended Reel Storage Condition 5°C to 40°C Relative Humidity 20% to 70% * The data was measured by a CTIA Authorized Test Lab. ** Center frequency will be offset to working frequency according to the conditions of user’s Ground plane and radome. SPE-11-8-146/M/SS Page 4 of 17 3. Electrical Specification (80*40mm ground plane) 3.1 Return Loss(S11) SPE-11-8-146/M/SS Page 5 of 17 3.2 VSWR SPE-11-8-146/M/SS Page 6 of 17 4. Radiation Pattern (Customize Design) 4.1 Radiation Pattern (80mmX40mm ground plane) X Z Y SPE-11-8-146/M/SS Page 7 of 17 4.2 3D Gain pattern @2442MHz SPE-11-8-146/M/SS Page 8 of 17 4.3 Efficiency Table SPE-11-8-146/M/SS Page 9 of 17 4.4 Efficiency vs Frequency SPE-11-8-146/M/SS Page 10 of 17 5. Layout Guide 5.1 Solder Land Pattern Land pattern for soldering (grey marking areas) is as shown below. A matching circuit similar to the one shown in section 5.3 is also required. SPE-11-8-146/M/SS Page 11 of 17 5.2 Solder Land Pattern This antenna includes a fine tuning element (as shown in the land patterns above) that can be used to slightly shift antenna resonance. 5.3 Matching Circuit Like all antennas, surrounding components, enclosures, and changes to the GND plane dimensions can alter performance. A pi-matching network like the one shown below is required in case adjustments need to be made. The antenna EVB has a similar matching network. The components on the EVB are a good starting point for a new design, but will need to be adjusted upon integration for best performance. The zero ohm resistor is needed for the ability to solder down a coax pigtail to make measurements with a vector network analyzer. SPE-11-8-146/M/SS Page 12 of 17 6. Antenna Drawings 6.1 Antenna Main Body 6.2 Antenna with EVB SPE-11-8-146/M/SS Page 13 of 17 6.3 Footprint on EVB SPE-11-8-146/M/SS Page 14 of 17 7. Packaging 6000pcs WLA.01 per Carton Dimensions: 340*340*90mm Weight:3.5Kg 6000pcs WLA.01 per Tape and Reel Dimensions: Ø330*60mm Weight: 3.23Kg 47mm 60mm 9 0mm Ø 3 3 0mm 340mm 340mm SPE-11-8-146/M/SS Page 15 of 17 7.1 Tape Dimensions (unit: mm) 7.2 Pocket Dimensions (unit: mm) Feature Specifications Tolerances W 12 ±0.30 P 8 ±0.10 E 1.75 ±0.10 F 5.5 ±0.10 P2 2 ±0.10 D 1.5 ±0.10 Po 4 ±0.10 10Po 40 ±0.20 Feature Specifications Tolerances Ao 1.9 ±0.10 Bo 3.5 ±0.10 Ko 0.8 ±0.10 t 0.3 ±0.05 SPE-11-8-146/M/SS Page 16 of 17 8. Recommended Reflow Temp Profile The WLA.01 Loop Antenna can be assembled following either Sn-Pb or Pb-Free assembly processes. The recommended soldering temperatures are as follows: SPE-11-8-146/M/SS Page 17 of 17 Ta o g l a s m a k e s n o wa r ra n t i e s b a s e…

Text truncated - open the document above for the full version.

PAA102 PAA103 PAA101 COA1 PAA202 PAA203 PAA201 COA2 PABz102 PABz101 COBz1 PAC102 PAC101 COC1 PAC201 PAC202 COC2 PAC302 PAC301 COC3 PAC401 PAC402 COC4 PAC502 PAC501 COC5 PAC601 PAC602 COC6 PAC702 PAC701 COC7 PAC802 PAC801 COC8 PAC901 PAC902 COC9 PAC1001 PAC1002 COC10 PAC1102 PAC1101 COC11 PAC1201 PAC1202 COC12 PAC1301 PAC1302 COC13 PAC1401 PAC1402 COC14 PAC1502 PAC1501 COC15 PAC1601 PAC1602 COC16 PAC1701 PAC1702 COC17 PAC1802 PAC1801 COC18 PAC1902 PAC1901 COC19 PAC2101 PAC2102 COC21 PAC2302 PAC2301 COC23 PAC2402 PAC2401 COC24 PAC2502 PAC2501 COC25 PAC2602 PAC2601 COC26 PAC2702 PAC2701 COC27 PAC2802 PAC2801 COC28 PAC2902 PAC2901 COC29 PAC3401 PAC3402 COC34 PAC3502 PAC3501 COC35 PAC3602 PAC3601 COC36 PAC3702 PAC3701 COC37 PAC3802 PAC3801 COC38 PAC3902 PAC3901 COC39 PAC4001 PAC4002 COC40 PAC4101 PAC4102 COC41 PAC4201 PAC4202 COC42 PAC4301 PAC4302 COC43 PAC4401 PAC4402 COC44 PAC4501 PAC4502 COC45 PAC4601 PAC4602 COC46 PAC4701 PAC4702 COC47 PAC4802 PAC4801 COC48 PAC4901 PAC4902 COC49 PAC5001 PAC5002 COC50 PAC5101 PAC5102 COC51 PAC5202 PAC5201 COC52 PAC5302 PAC5301 COC53 PAC5402 PAC5401 COC54 PAC5502 PAC5501 COC55 PAC5602 PAC5601 COC56 PAC5702 PAC5701 COC57 PAC5801 PAC5802 COC58 PAC5901 PAC5902 COC59 PAC6001 PAC6002 COC60 PAD104 PAD103 PAD102 PAD101 COD1 PAD201 PAD202 COD2 PAD301 PAD302 COD3 PAD401 PAD402 COD4 PAFB102 PAFB101 COFB1 PAFid100 COFid1 PAFid200 COFid2 PAFid300 COFid3 PAH10 COH1 PAH20 COH2 PAH30 COH3 PAJ101 PAJ103 PAJ102 COJ1 PAJ202 PAJ203 PAJ201 COJ2 PAJ303 PAJ301 PAJ302 PAJ300 COJ3 PAJ402 PAJ401 COJ4 PAJ500 PAJ504 PAJ503 PAJ502 PAJ501 PAJ505 COJ5 PAJ600 PAJ6013 PAJ6012 PAJ6011 PAJ6010 PAJ609 PAJ608 PAJ607 PAJ606 PAJ605 PAJ604 PAJ601 PAJ602 PAJ603 PAJ60 COJ6 PAJ802 PAJ801 COJ8 PAL102 PAL101 COL1 PAL202 PAL201 COL2 PAL302 PAL301 COL3 PAL401 PAL402 COL4 PAL501 PAL502 COL5 PAL1101 PAL1102 COL11 PALD103 PALD102 PALD101 PALD104 COLD1 PAP102 PAP101 PAP104 PAP103 PAP100 COP1 PAP302 PAP301 COP3 PAP402 PAP401 COP4 PAP501 PAP502 COP5 PAP800 PAP807 PAP802 PAP804 PAP806 PAP808 PAP8010 PAP801 PAP803 PAP805 PAP809 COP8 PAP90 PAP9011 PAP9012 PAP9010 PAP909 PAP908 PAP9013 PAP907 PAP9014 PAP9016 PAP905 PAP9017 PAP904 PAP9018 PAP903 PAP9019 PAP902 PAP9020 PAP901 PAP9015 PAP906 COP9 PAQ301 PAQ303 PAQ304 PAQ305 PAQ306 PAQ302 COQ3 PAQ401 PAQ403 PAQ404 PAQ406 PAQ405 PAQ402 COQ4 PAQ503 PAQ501 PAQ502 COQ5 PAQ701 PAQ702 PAQ703 PAQ704 PAQ705 PAQ706 COQ7 PAQ803 PAQ801 PAQ802 COQ8 PAR102 PAR101 COR1 PAR202 PAR201 COR2 PAR301 PAR302 COR3 PAR401 PAR402 COR4 PAR701 PAR702 COR7 PAR902 PAR901 COR9 PAR1001 PAR1002 COR10 PAR1101 PAR1102 COR11 PAR1202 PAR1201 COR12 PAR1302 PAR1301 COR13 PAR1402 PAR1401 COR14 PAR1501 PAR1502 COR15 PAR1601 PAR1602 COR16 PAR2102 PAR2101 COR21 PAR2201 PAR2202 COR22 PAR2302 PAR2301 COR23 PAR2401 PAR2402 COR24 PAR2501 PAR2502 COR25 PAR2601 PAR2602 COR26 PAR2701 PAR2702 COR27 PAR2801 PAR2802 COR28 PAR2901 PAR2902 COR29 PAR3002 PAR3001 COR30 PAR3102 PAR3101 COR31 PAR4401 PAR4402 COR44 PAR4501 PAR4502 COR45 PAR4601 PAR4602 COR46 PAR4701 PAR4702 COR47 PAR4801 PAR4802 COR48 PASB102 PASB101 COSB1 PASB202 PASB201 COSB2 PASB301 PASB302 COSB3 PASB401 PASB402 COSB4 PASB502 PASB501 COSB5 PASB602 PASB601 COSB6 PASB701 PASB702 COSB7 PASB2002 PASB2001 COSB20 PASB2102 PASB2101 COSB21 PASB2202 PASB2201 COSB22 PAST102 PAST101 COST1 PAST202 PAST201 COST2 PAST302 PAST301 COST3 PAST402 PAST401 COST4 PAST502 PAST501 COST5 PAST602 PAST601 COST6 PAST702 PAST701 COST7 PAST802 PAST801 COST8 PASW100 PASW106 PASW104 PASW105 PASW102 PASW101 PASW103 COSW1 PASW202 PASW201 COSW2 PASW301 PASW302 COSW3 PATP101 COTP1 PATP201 COTP2 PATP301 COTP3 PATP401 COTP4 PATP501 COTP5 PATP601 COTP6 PATP701 COTP7 PATP801 COTP8 PATP901 COTP9 PATP1001 COTP10 PATP1101 COTP11 PATP1201 COTP12 PATP1301 COTP13 PATP1401 COTP14 PATP1501 COTP15 PATP1601 COTP16 PATP1701 COTP17 PATP1801 COTP18 PATP1901 COTP19 PATP2001 COTP20 PATP2101 COTP21 PATP2201 COTP22 PATP2301 COTP23 PATP2401 COTP24 PATP2501 COTP25 PATP2601 COTP26 PATP2701 COTP27 PATP2801 COTP28 PATP2901 COTP29 PATP3001 COTP30 PATP3101 COTP31 PATP3201 COTP32 PATP3301 COTP33 PATP3401 COTP34 PATP3501 COTP35 PATP3601 COTP36 PATP3701 COTP37 PATP3801 COTP38 PATP3901 COTP39 PATP4001 COTP40 PATP4101 COTP41 PATP4201 COTP42 PATP4301 COTP43 PATP4401 COTP44 PATP4501 COTP45 PATP4601 COTP46 PATP4701 COTP47 PAU10B4 PAU10A21 PAU10B10 PAU10L31 PAU10A5 PAU10A15 PAU10A1 PAU10AL1 PAU10AL31 PAU10A31 PAU10A27 PAU10AL29 PAU10AL27 PAU10AK30 PAU10B30 PAU10AJ1 PAU10104 PAU10AL25 PAU10AL23 PAU10AL21 PAU10AL19 PAU10AL17 PAU10AL15 PAU10AL13 PAU10AL11 PAU10AL9 PAU10AL7 PAU10AL5 PAU10AL3 PAU10AK28 PAU10AK26 PAU10AK18 PAU10AK16 PAU10AK14 PAU10AK12 PAU10AK10 PAU10AK8 PAU10AK6 PAU10AK4 PAU10AK2 PAU10AH2 PAU10AF2 PAU10AG1 PAU10AE1 PAU10AC31 PAU10AC1 PAU10AA31 PAU10AA1 PAU10Y2 PAU10W31 PAU10W1 PAU10V2 PAU10U31 PAU10U1 PAU10T2 PAU10R31 PAU10R1 PAU10N31 PAU10N1 PAU10L1 PAU10K2 PAU10J31 PAU10J1 PAU10H2 PAU10G31 PAU10G1 PAU10F2 PAU10E31 PAU10E1 PAU10D2 PAU10C31 PAU10C1 PAU10B22 PAU10B20 PAU10B18 PAU10B16 PAU10B14 PAU10B12 PAU10B8 PAU10B6 PAU10B2 PAU10A25 PAU10A23 PAU10A19 PAU10A17 PAU10A13 PAU10B24 PAU10B26 PAU10B28 PAU10AE31 PAU10AG31 PAU10AJ31 PAU10AK24 PAU10AK22 PAU10AK20 PAU10AD2 PAU10P2 PAU10M2 PAU10AB2 PAU10 COU1 PAU2010 PAU202 PAU203 PAU2017 PAU2016 PAU2015 PAU2014 PAU2013 PAU2012 PAU2011 PAU209 PAU208 PAU207 PAU206 PAU205 PAU204 PAU201 COU2 PAU30A1 PAU30A2 PAU30A3 PAU30A4 PAU30A5 PAU30B1 PAU30B2 PAU30B3 PAU30B4 PAU30B5 PAU30C1 PAU30C2 PAU30C3 PAU30C4 PAU30C5 PAU30D1 PAU30D2 PAU30D3 PAU30D4 PAU30D5 PAU30E1 PAU30E2 PAU30E3 PAU30E4 PAU30E5 COU3 PAU40B2 PAU40B1 PAU40A2 PAU40A1 COU4 PAU50B2 PAU50B1 PAU50A2 PAU50A1 COU5 PAU603 PAU604 PAU605 PAU601 PAU602 COU6 PAU7014 PAU7013 PAU7012 PAU707 PAU706 PAU705 PAU7011 PAU7010 PAU709 PAU708 PAU704 PAU703 PAU702 PAU701 COU7 PAU801 PAU802 PAU803 PAU804 PAU805 PAU806 PAU807 PAU808 PAU809 PAU8010 PAU8011 PAU8012 PAU8013 …
