Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
LW014-WB Datasheet MOKO TECHNOLOGY LTD. www.mokosmart.com Version 1.0 LW014-WB Datasheet Introduction LW014-WB is a wristband that combines LoRaWAN network transmission with Bluetooth and GPS fix technologies, it can be used for indoor and outdoor positioning. Lw014-WB supports multiple alarms for indoor and outdoor emergency situation. With the wristband design, it’s easy to wear and convenient to use. LW014 is applicable to hospitals, nursing homes, schools and factories. Key Features ➢ Long-range & Low-power communication ➢ Multi-mode positioning fusion ➢ anti-accidental touch ➢ Shift-Long comfort, Weightless Wearing Experience ➢ Multiple working mode ➢ IP66 water proof Mechanical Size Description LW014-WB Datasheet 2 www.mokosmart.com General Specifications Categories Parameter Value LoRa Wireless Specification LoRa Protocol LoRaWAN V1.0.3 Lora Frequency EU868/AU915/US915/AS923/IN865/KR920/RU 864/AS923-1/AS923-2/AS923-3/AS923-4 Tx Power Max 22dBm LoRa Communication Distance Up to 5 km (in urban open space) BLE Wireless Specification Bluetooth® (BLE) 4.2 TX Power Max 4 dBm BLE Broadcast Distance Up to 50m in free space BLE Scan Distance (1M PHY) Up to 150m in free space Power Supply Power Supply 300 mAh rechargeable battery Physical Specification Protection level IP66 Dimension 46.7*41.0*15.2mm Weight 41.9g Application Specification Power Switch power button Operation Temperature/ Storage Temperature -20°C ~ 60°C Operation Humidity 10%~90% Certification CE/FCC/Reach/RoHS pending approval Ordering Information Product Type Description Notes LW014-WB US915 LW014-WB EU868 Wristband Subnet except US915 and EU868 also supported, please consult with moko before ordering MOKO TECHNOLOGY LTD. 4F,Buidling2, Guanghui Technology Park, MinQing Rd, Longhua, Shenzhen, Guangdong, China Tel:86-755-23573370-829 LW014-WB Datasheet 3 www.mokosmart.com Support_ lora @mokotechnology.com https://www.mokosmart.com FCC warning statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: Companyname:HOPEKCORPORATIONINC FRN:0034562900 ContactName:YangyangXu Address:16755CoyoteBushDrUnit84,SanDiego,CA92127UnitedStates TelephoneNo:561-875-9826 Email:[email protected] Applicant: Companyname:MOKOTECHNOLOGYLIMITED GranteeCode:2AO94 FCCID:2AO94-LW014 FRN:0027351667 ContactName:JinghuiChen Address:Factory201,107PinshunRdGuixiangcommunity,GuanlanStreet, Longhua,Shenzhen,GuangdongProvince,China518110 TelephoneNo:86-755-23956710 FaxNo:+86-755-23956710 Email:[email protected] MOKOTECHNOLOGYLIMITEDcertifiesthat,asofthedateofthisfilingoftheapplicationwith theTCB,[HOPEKCORPORATIONINC]isourdesignatedUSagentforserviceofprocessfor theabovereferencedFCCID.MOKOTECHNOLOGYLIMITEDacceptstomaintainanagentfor nolessthanoneyearafterthegranteehasterminatedallmarketingandimportationorthe conclusionofanycommissionrelatedproceedinginvolvingequipment.[HOPEKCORPORATION INC]accepts,asofthedateofthefilingoftheapplication,theobligationofthedesignatedUS agentforserviceofprocessfortheabovereferenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:2026-06-10 Applicant’sName:JinghuiChenUSAgent’sName:YangyangXu Title:SEOTitle:Manager Signature:Signature:
MOKO TECHNOLOGY LIMITED June 9, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2AO94-LW014 [MOKO TECHNOLOGY LIMITED] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Jinghui Chen MOKO TECHNOLOGY LIMITED June 9, 2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2AO94-LW014 [MOKO TECHNOLOGY LIMITED] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Jinghui Chen
MOKO TECHNOLOGY LIMITED Difference Description We MOKO TECHNOLOGY LIMITED state: Product name: Smart Button Model(s): LW014, LW014-H, LW014-W All the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the difference is the model name and watchband. Signature: June 12, 2026 Name: Jinghui Chen Position: SEO Company Name: MOKO TECHNOLOGY LIMITED Address: Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, Guangdong Province, China 518110 Tel: 86-755-23956710 Fax: +86-755-23956710 Email: [email protected]
MOKO TECHNOLOGY LIMITED 6/9/2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product Name: Smart Button FCC ID: 2AO94-LW014 Model(s): LW014 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Schematic Diagram, Block Diagram, Operational Description) required to be submitted with this application be permanently withheld from public review. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market Please contact me if there is any information you may need. Sincerely, Signature: June 9, 2026 Name Jinghui Chen Position SEO Company Name MOKO TECHNOLOGY LIMITED Address Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, Guangdong Province, China 518110 Tel 86-755-23956710 Fax +86-755-23956710 Email [email protected]
MOKO TECHNOLOGY LIMITED 6/9/2026 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen PSI Testing Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This agreement expires one year from the current date. Sincerely, Signature: June 9, 2026 Name Jinghui Chen Position SEO Company Name MOKO TECHNOLOGY LIMITED Address Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, Guangdong Province, China 518110 Tel 86-755-23956710 Fax +86-755-23956710 Email [email protected]
Page 1 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix II external photos FCC ID: 2AO94-LW014 Page 2 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 3 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 4 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 5 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 6 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 7 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 8 of 8 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China ------End------
Label and Location Material: Silk-screen Font color: White Label and Location
Page 1 of 5 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix III internal photos FCC ID: 2AO94-LW014 Page 2 of 5 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 3 of 5 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 4 of 5 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Page 5 of 5 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China ------End------ ANT LORA ANT BT
Page 1 of 1 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix IV RF Exposure evaluation FCC ID: 2AO94-LW014 According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison. BLE: Worse case output power is as below: [2480MHz: 0.88dBm] Maximum output power is 0.88dBm (1.22 mW). (1.22mW /5mm)·[√2.480(GHz)]= 0.39<3.0 for 1-g SAR. LORA: Worse case output power is as below: [915MHz: 4.57dBm] Maximum output power is 4.57dBm (2.87 mW). (2.87mW /5mm)·[√0.915(GHz)]= 0.55<3.0 for 1-g SAR. Then SAR evaluation is not required.
Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Page 1 of 59 Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China FCC TEST REPORT FCC ID: 2AO94-LW014 On Behalf of MOKO TECHNOLOGY LIMITED Smart Button Model No.: LW014, LW014-H, LW014-W Prepared for : MOKO TECHNOLOGY LIMITED Address : Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 Prepared By : Shenzhen PSI Testing Co., Ltd. Address : 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Report Number : psi2604211-C01-R01 Date of Receipt : April 24, 2026 Date of Test : April 24, 2026–May 20, 2026 Date of Report : May 20, 2026 Version Number : V0 Page 2 of 59 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China TABLE OF CONTENTS Description Pag e 1. Summary Of Standards And Results----------------------------------------------------------------------- 6 1.1. Description of Standards and Results ---------------------------------------------------------------- 6 2. General Information --------------------------------------------------------------------------------------------- 7 2.1. Description of Device (EUT) ---------------------------------------------------------------------------- 7 2.2. Accessories of Device (EUT) -------------------------------------------------------------------------- 8 2.3. Tested Supporting System Details -------------------------------------------------------------------- 8 2.4. Block Diagram of Connection Between EUT and Simulators ----------------------------------- 8 2.5. Test Mode Description ----------------------------------------------------------------------------------- 9 2.6. Software test version and power setting information --------------------------------------------- 9 2.7. Test Conditions ------------------------------------------------------------------------------------------ 10 2.8. Test Facility----------------------------------------------------------------------------------------------- 10 2.9. Measurement Uncertainty ---------------------------------------------------------------------------- 10 2.10. Test Equipment List ------------------------------------------------------------------------------------- 11 3. Spurious Emission -------------------------------------------------------------------------------------------- 12 3.1. Test Limits ------------------------------------------------------------------------------------------------ 12 3.2. Block Diagram of Test setup ------------------------------------------------------------------------- 13 3.3. Test Procedure ------------------------------------------------------------------------------------------ 15 3.4. Test Results ---------------------------------------------------------------------------------------------- 16 4. Power Line Conducted Emission ------------------------------------------------------------------------- 22 4.1. Test Limits ------------------------------------------------------------------------------------------------ 22 4.2. Test Procedure ------------------------------------------------------------------------------------------ 22 4.3. Test Setup ------------------------------------------------------------------------------------------------ 22 4.4. Test Results ---------------------------------------------------------------------------------------------- 23 5. Out-of-band Emissions -------------------------------------------------------------------------------------- 26 5.1. Test Limits ------------------------------------------------------------------------------------------------ 26 5.2. Test Procedure ------------------------------------------------------------------------------------------ 26 5.3. Test Setup ------------------------------------------------------------------------------------------------ 26 5.4. Test Results ---------------------------------------------------------------------------------------------- 26 6. Conducted Maximum Output Power --------------------------------------------------------------------- 37 6.1. Test limits ------------------------------------------------------------------------------------------------- 37 6.2. Test Procedure ------------------------------------------------------------------------------------------ 37 6.3. Test Setup ------------------------------------------------------------------------------------------------ 37 6.4. Test Results ---------------------------------------------------------------------------------------------- 37 7. Peak Power Spectral Density ------------------------------------------------------------------------------ 44 7.1. Test limits ------------------------------------------------------------------------------------------------- 44 7.2. Test Procedure ------------------------------------------------------------------------------------------ 44 7.3. Test Setup ------------------------------------------------------------------------------------------------ 44 7.4. Test Results ---------------------------------------------------------------------------------------------- 44 8. Occupied Bandwidth------------------------------------------------------------------------------------------ 48 8.1. Test limits ------------------------------------------------------------------------------------------------- 48 8.2. Test Procedure ------------------------------------------------------------------------------------------ 48 8.3. Test Setup ------------------------------------------------------------------------------------------------ 48 8.4. Test Results -----------…
Text truncated - open the document above for the full version.
Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Page 1 of 34 Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China FCC TEST REPORT FCC ID: 2AO94-LW014 On Behalf of MOKO TECHNOLOGY LIMITED Smart Button Model No.: LW014, LW014-H, LW014-W Prepared for : MOKO TECHNOLOGY LIMITED Address : Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 Prepared By : Shenzhen PSI Testing Co., Ltd. Address : 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Report Number : psi2604211-C01-R02 Date of Receipt : April 24, 2026 Date of Test : April 24, 2026–May 20, 2026 Date of Report : May 20, 2026 Version Number : V0 Page 2 of 34 Report No.: psi2604211-C01-R02 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye W est Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China TABLE OF CONTENTS Description Page 1. Summary Of Standards And Results--------------------------------------------------------------------------- 5 1.1. Description of Standards and Results -------------------------------------------------------------------- 5 2. General Information ------------------------------------------------------------------------------------------------- 6 2.1. Description of Device (EUT) -------------------------------------------------------------------------------- 6 2.2. Accessories of Device (EUT) ------------------------------------------------------------------------------ 7 2.3. Tested Supporting System Details ------------------------------------------------------------------------ 7 2.4. Block Diagram of Connection Between EUT and Simulators --------------------------------------- 7 2.5. Test Mode Description --------------------------------------------------------------------------------------- 8 2.6. Software test version and power setting information ------------------------------------------------- 8 2.7. Test Conditions ------------------------------------------------------------------------------------------------ 9 2.8. Test Facility----------------------------------------------------------------------------------------------------- 9 2.9. Measurement Uncertainty ---------------------------------------------------------------------------------- 9 2.10. Test Equipment List ---------------------------------------------------------------------------------------- 10 3. Spurious Emission ------------------------------------------------------------------------------------------------ 11 3.1. Test Limits ---------------------------------------------------------------------------------------------------- 11 3.2. Block Diagram of Test setup ----------------------------------------------------------------------------- 12 3.3. Test Procedure ---------------------------------------------------------------------------------------------- 13 3.4. Test Results -------------------------------------------------------------------------------------------------- 14 4. Power Line Conducted Emission ----------------------------------------------------------------------------- 19 4.1. Test Limits ---------------------------------------------------------------------------------------------------- 19 4.2. Test Procedure ---------------------------------------------------------------------------------------------- 19 4.3. Test Setup ---------------------------------------------------------------------------------------------------- 19 4.4. Test Results -------------------------------------------------------------------------------------------------- 20 5. Out-of-band Emissions ------------------------------------------------------------------------------------------ 23 5.1. Test Limits ---------------------------------------------------------------------------------------------------- 23 5.2. Test Procedure ---------------------------------------------------------------------------------------------- 23 5.3. Test Setup ---------------------------------------------------------------------------------------------------- 23 5.4. Test Results -------------------------------------------------------------------------------------------------- 23 6. Conducted Maximum Output Power ------------------------------------------------------------------------- 26 6.1. Test limits ----------------------------------------------------------------------------------------------------- 26 6.2. Test Procedure ---------------------------------------------------------------------------------------------- 26 6.3. Test Setup ---------------------------------------------------------------------------------------------------- 26 6.4. Test Results -------------------------------------------------------------------------------------------------- 26 7. Peak Power Spectral Density ---------------------------------------------------------------------------------- 28 7.1. Test limits ----------------------------------------------------------------------------------------------------- 28 7.2. Test Procedure ---------------------------------------------------------------------------------------------- 28 7.3. Test Setup ---------------------------------------------------------------------------------------------------- 28 7.4. Test Results -------------------------------------------------------------------------------------------------- 28 8. Occupied Bandwidth---------------------------------------------------------------------------------------------- 30 8.1. Test limits ----------------------------------------------------------------------------------------------------- 30 8.2. Test Procedure -----------------------------------------------------------------------------…
Text truncated - open the document above for the full version.
深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. HUACHUANG TECHNOLOGY LTD Antenna Test Report Tester :Hu Lin Date : 2025 / 07 / 21 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 1. Device Profile 2. LORA Test 3. BT Test 4. GPS Test 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 1. Device Profile GPS Antenna BT Antenna LORA Antenna 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Agilent E5071CS-Parameter Test 2. LORA Antenna Test 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Antenna Passive Test X Y Z X Y Z 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Passive Test For Frequency/Mh z Efficiency/dBEfficiency/%MaxGain/dBi 850-11.167.66-6.09 860-10.68.71-5.57 870-10.429.08-5.82 880-9.6410.86-5.44 890-10.099.79-6.19 900-10.29.55-6.36 910-10.748.43-7.16 920-11.317.4-7.81 930-11.946.4-8.38 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 2D-Etotal(850/930Mhz) Phi02DPhi902DTheta902D 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(850Mhz) 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(930Mhz) 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Agilent E5071CS-Parameter Test 3. BT Antenna Test 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Antenna Passive Test X Y Z X Y Z 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Passive Test Frequency/Mh z Efficiency/dBEfficiency/%MaxGain/dBi 2400-9.7510.59-1.97 2410-9.5910.98-2.59 2420-9.9110.21-2.1 2430-9.8310.41-3 2440-9.8510.36-2.44 2450-9.6610.82-2.88 2460-9.9310.16-2.9 2470-9.9110.21-3.13 2480-10.0010-3.34 2490-9.7510.59-2.88 2500-10.379.18-3.84 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 2D-Etotal(2400/2450/2500Mhz) Phi02DPhi902DTheta902D 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(2400Mhz) 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(2450Mhz) 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(2500Mhz) 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Agilent E5071CS-Parameter Test 4. GPS Antenna Test 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Antenna Passive Test X Y Z X Y Z 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. Passive Test Frequency/Mh z Efficiency/dBEfficiency/%MaxGain/dBi 1500-9.710.72-3.77 1510-8.9712.68-3.08 1520-8.713.49-2.95 1530-8.5114.09-2.84 1540-8.3214.72-2.71 1550-8.3614.59-2.68 1560-8.5314.03-2.62 1570-8.2914.83-2.71 1580-8.6213.74-2.8 1590-8.8613-2.96 1600-9.4411.38-3.39 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 2D-Etotal(1570Mhz) Phi02DPhi902DTheta902D 深圳市安特通讯科技有限公司 ANT Communication Technology(Shenzhen)Co., LTD. 3D-Etotal(1570Mhz)
Page 1 of 2 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Appendix I Test Setup Photo FCC ID: 2AO94-LW014 Spurious Radiation Emissions Test (<1G) Spurious Radiation Emissions Test (>1G) Page 2 of 2 Report No.: psi2604211-C01-R01 Shenzhen PSI Testing Co., Ltd. Tel: 0755-23011775 | E-mail: [email protected] | http://www.psi-lab.com Add: 1-2/F., Building 5, Yudafu Industrial Park, No.10, Xingye West Road, Shajing Subdistrict, Bao'an District, Shenzhen, Guangdong, China Condu…
Text truncated - open the document above for the full version.
16755 Coyote Bush Dr Unit 84 · CA, 92127 · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.22 mW |
| 2 | 15C | 915 MHz - 915 MHz | 2.86 mW |

Bluetooth Beacon
Equipment Class
DTS - Digital Transmission System
Bluetooth Beacon
Equipment Class
DTS - Digital Transmission System
Bluetooth Beacon
Equipment Class
DTS - Digital Transmission System
BLE to Cellular Gateway
Equipment Class
DTS - Digital Transmission System
Bluetooth-LoRaWAN Gateway
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
