2AOHHTURBOXC2290Smart Module

Thundercomm AIOT ENABLEA Thundercomm TurboX C2290/CM2290 SOM Datasheet Rev.V1.7.1 Aug 29,2023 DN:tc-j-13117.1 Thundercomm Thundercomm TurboX C2290/CM2290 SOM Datasheet Revision History Version Date Author Description V1.0 Mar 16,2021 Qiming Duan Initial release V1.1 Aug 11,2021 Qiming Duan Add the followingsections: · 1.6.Stencil design and aperture ·1.7.Module laser marking V1.2 Aug 16,2021 Qiming Duan Add the followingsections: · 1.3.Major component location ·1.8.SMT assembly guide V1.3 Oct 09,2021 Qiming Duan ·Update memory and DMIC description in Table 1-2.Key features and performance of C(M)2290 SOM ·Change definitionof Pin#128,Pin#139 and Pin#189199 in Table 2-2.Pin assignment ·Add a note at the end of 2.2.Interfaces detail description ·Update Table 2-3.Pin definition of power supply interface and add a note in 2.2.1.Power supply interface. ·Update Table 2-8.GPIO QUP configuration and add a note in 2.2.6.QCM2290 GPIO. ·Update Table 2-10.PMIC GPIO interface pad parameters V1.4 Feb 11,2022 Qiming Duan Update display support information in Table 1-1.Key features and performance of QCM2290 processor:remove DisplayPort. V1.4.1 Mar 01,2022 Qiming Duan Update the note below Table 2-8.GPIO QUP configuration V1.5 May 25,2022 Qiming Duan ·Remove C-PHY 1 from Table 1-1. ● Remove SoundWire relevant information. ·Update Table 1-2,Table 2-2,Table 2-3,and Table 3-4. ·Update Figure 1-1,Figure 1-2,Figure 1-4 and Figure 1-5 Figure 1-8 ·Remove GPIO_8,GPIO_9,GPIO_10 and GPIO_11 from Table 2-8 ·Update the following sections: 口 1.6.Stencil design and aperture 1.7.Module laser marking 03.2.Operating conditions ·Add introduction in 3.1.Absolute maximum ratings ·Complete the contents of 3.16.Power consumption ·Complete the contents of 3.18.RF performance. ·Add new section 3.19.GPS performance. CopyrightO 2023 Thundercomm Technology Co.,Ltd.All rights reserved. TUR30X Thundercomm Thundercomm TurboX C2290/CM2290 SOM Datasheet V1.6 July 12,2022 Qiming Duan ·Update Table 1-2. ·Update Figure 1-1,Figure 1-2,Figure 1-4,Figure 1-5,and Figure 1-6 ·Update description of Pad#75 in Table 2-2. ·Add Table 2-3 and Table 3-2. ·Update operating temperature scope to:-25°C to 75°C. ·Complete thermal test data in 3.17.Thermal ·Fix format problems. V1.7 Apr 17,2023 Qiming Duan ·Update Table 1-2 ·Update 1.4.Mechanical size. ·Add Chapter 4.Packaging V1.7.1 Aug 29,2023 Qiming Duan ·Add note*to Table 1-2 ·Update 1.8.SMT assemblyguide CopyrightC 2023 ThundercommTechnology Co.,Ltd.All rights reserved. TUR30X Thunder comm Thundercomm TurboX C2290/CM2290 SOM Datasheet Table List Table 1-1.Key features and performance of QCM2290 processor Table 1-2.Key features and performance ofC(M)2290 SOM Table 2-1.Interface description Table 2-2.Pin assignment Table2-3.RF interfaces for CM2290 only Table 2-4.Pin definitionof power supply interface Table 2-5.Pin definition of control signals Table 2-6.Pad description of USB interface Table 2-7.Pad description ofcamera interface Table 2-8.Display interface pad description Table 2-9.GPI0 QUP configuration Table 2-10.Pad description of GPIO interface Table 2-11.PMIC GPIO interface pad parameters Table 2-12.Pad description of SDI0 Table 2-13.Pad description of UIM Table 2-14.Pad description of SWR,SLIMbus,and 12S interfaces Table 2-15.Pad description of RF interface Table 3-1.Absolute rating condition Table 3-2.Operating conditions Table 3-3.IC temperature Table 3-4.Input power pad parameters Table 3-5.Output power pad parameters Table 3-6.Digital GPIO characteristics Table 3-7.SD card 2.95Vdigital I/O interface characteristics Table 3-8.SD card 1.8Vdigitall/0 interface characteristics Table3-9.UIM 2.95V digital I/0 interface characteristics Table 3-10.UIM 1.8Vdigital l/O interface characteristics Table 3-11.Supported MIPI CSI standards and exceptions Table 3-12.Supported MIPI DSI standards and exceptions Table 3-13.USB standards andexceptions Table 3-14.Supported SDI0 standards and exceptions Table 3-15.Supported 12S standards and exceptions CopyrightC 2023 Thundercomm Technology Co.,Ltd.All rights reserved. TUR30X Thundercomm Thundercomm TurboX C2290/CM2290 SOM Datasheet Table 3-16.12S timing characteristics Table 3-17.DMIC parameters Table 3-18.Supported I2C standards and exceptions Table 3-19.Supported I3C standards and exceptions Table 3-20.SPI parameters Table 3-21.RG LED parameters Table 3-22.Flash LEDparameters Table 3-23.C2290 Power consumption Table 3-24.CM2290 Power consumption Table 3-25. Thermal test condition Table 3-26. Thermal test result Table 3-27.RF Performance Table 3-28.GPS Performance Table 4-1.BOM list of packaging CopyrightO 2023 Thundercomm Technology Co.,Ltd.All rights reserved. TUR30X Thunder comm Thundercomm TurboX C2290/CM2290 SOM Datasheet About This Document ·Illustrations in this documentation might look different from your product. ·Depending on the model,some optional accessories,features,and software programs might not be available on your device. ·Depending on the version of operating systems and programs,some user interface instructions might not be applicable toyour device. ·Documentation content is subject to change without notice.Thundercomm makes constant improvements on the documentation of your computer,including this guidebook. CopyrightO 2023 Thundercomm Technology Co.,Ltd.All rights reserved. TUR30X Thundercomm Thundercomm TurboXC2290/CM2290 SOM Datasheet —1— Table of Contents Chapter 1. Overview ..................................................................................................................... 3- 1.1. Keyfeatures ......................................................................................................................... 3- 1.2. Hardware block diagram ....................................................................................................... 4- 1.3. Major componentlocation .................................................................................................... 6- 1.4. Mechanical size ....................…

Text truncated - open the document above for the full version.

Rev 4/01/2024 Thundercomm Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-08-22 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AOHHTURBOXC2290 [Thundercomm Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, shaolei Ke (Applicant printed name) Rev 4/01/2024 Thundercomm Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-08-22 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AOHHTURBOXC2290 [Thundercomm Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, shaolei Ke (Applicant printed name)

Thundercomm Technology Co., Ltd No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Date: 08/22/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AOHHTURBOXC2290 US Agent – Attestation Statement / Part 2.911(d)(7) Thundercomm Technology Co., Ltd certifies, that as of 08/22/2024, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AOHHTURBOXC2290. Thundercomm Technology Co., Ltd accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Thundercomm Technology Co., Ltd for FCC ID: 2AOHHTURBOXC2290 Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Thundercomm Technology Co., Ltd FRN: 0027050566 Designated Agent: FCC US Agent, LLC Company Representative: shaolei Ke Designated Agent Representative: Tim Payne Signature: Signature:

Thundercomm Technology Co., Ltd Date: 2024-08-30 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AOHHTURBOXC2290 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description Operation Description for software security The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, shaolei Ke Grantee Contact’s Signature Thundercomm Technology Co., Ltd

Thundercomm Technology Co., Ltd Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: 2AOHHTURBOXC2290 Items to be covered by Single modular transmitters. Answer from applicant 1. The modular transmitter must have its own RF shielding. YES, Please refer to External Photos. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes, it is fulfilled. The EUT has buffered data inputs to insure compliance with Part 15 requirements under conditions of excessive data rates or over modulation.Please see the Schematics exhibit. 3. The modular transmitter must have its own power supply regulation. YES, the modular has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(b)(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). YES, it is Monopole antenna. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes, the module is tested in a stand-alone configuration as the test photos show. 6. The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number in accordance with 15.212 (a)(1)(vi)(A) / (B). YES, please refer to the exhibition label sample for this module. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. YES, please refer to the user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 1.1310, 2.1091, 2.1093, and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. YES, RF exposure statement is attached in the user manual. Note: A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with the requirements above. Name and surname of applicant (or authorized representative): shaolei Ke Date: 2024-08-30 Signature: __________________________

Thundercomm Technology Co., Ltd Wi-Fi Channel 12 and 13 Declaration Letter Date: 2024-08-22 We, the undersigned company Company Name: Thundercomm Technology Co., Ltd Address: No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Declare that: Product description: Smart Module Type designation: TurboX C2290 Brand: TurboX FCC ID: 2AOHHTURBOXC2290 Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: shaolei Ke Tel: +86 010-82036511 Email: [email protected]

Thundercomm Technology Co., Ltd Declaration of Authorization We Name: Thundercomm Technology Co., Ltd Address: No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3,Jinshagang 1st Road, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s) and signing all the related documents including 731 forms: Product description: Smart Module Type designation: TurboX C2290 Trademark: TurboX FCC ID: 2AOHHTURBOXC2290 on our behalf. Date:2024-08-22 City: Chongqing Name: shaolei Ke Function: Manager Signature:

Project No.: 2407C144 Page 2 of 6 Project No.: 2407C144 Page 6 of 6 EUT onboard BT&WiFi Ant. EUT: TurboX C2290

Smart Module TurboX C2290 SKU11 TSN:XXXXXXXXXXXXTPN: C22 90 - D33 - 3690 W 53 FCC ID: 2AOHHTURBOXC2290

Project No.: 2407C144 Page 1 of 6 ATTACHMENT PHOTOGRAPHS OF EUT Project No.: 2407C144 Page 3 of 6 Project No.: 2407C144 Page 4 of 6 Project No.: 2407C144 Page 5 of 6

Report No.: BTL-FCCP-5-2407C144 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2AOHHTURBOXC2290 Project No. : 2407C144 Equipment : Smart Module Brand Name : TurboX Test Model : TurboX C2290 Series Model : N/A Applicant : Thundercomm Technology Co., Ltd Address : No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Manufacturer : Thundercomm Technology Co., Ltd Address : No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Factory : MIKI TECHNOLOGY HUIZHOU Address : 39 Guangtai Road, Huinan Science Park, Huizhou City Date of Receipt : Jul. 22, 2024 Date of Test : Jul. 24, 2024 ~ Aug. 14, 2024 Issued Date : Aug. 28, 2024 Report Version : R00 Test Sample : Engineering Sample No.: DG2024072344 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 & KDB 447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Sheldon Ou Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-5-2407C144 Page 2 of 4 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-5-2407C144 R00 Original Report. Aug. 28, 2024 Valid Report No.: BTL-FCCP-5-2407C144 Page 3 of 4 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: whe re: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna 2. ANTENNA SPECIFICATION For BT&LE&2.4G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 TG.55.8113 Monopole N/A 1.69 Note: The antenna gain is provided by the manufacturer. For 5G: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 TG.55.8113 Monopole N/A 0.7 Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-5-2407C144 Page 4 of 4 3. CALCULATED RESULT For BT : Antenna Gain (dBi) Antenna Gain (numeric) Max. Peak Output Power (dBm) Max. Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 1.69 1.4757 10.63 11.5611 0.00340 1 Complies For LE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Peak Output Power (dBm) Max. Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 1.69 1.4757 6.26 4.2267 0.00124 1 Complies For 2.4G Hz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 1.69 1.4757 19.06 80.5378 0.02366 1 Complies For 5G Hz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 0.7 1.1749 17.07 50.9331 0.01191 1 Complies Note: (1)The calculated distance is 20 cm. (2)Output power including tune up tolerance(tune up tolerance: 0.5 dB). (3)Ratio=Power Dens ity (S) (mW/cm 2 )/Limit of Power Density (S) (mW/cm 2 ) (4)BT, LE, WLAN 2.4GHz and WLAN 5GHz can not simultaneous transmission. End of Test Report

Report No.:BTL-FCCP-1-2407C144 Page 1 of 80 FCC Radio Test Report FCC ID: 2AOHHTURBOXC2290 This report concerns: Original Grant Project No. : 2407C144 Equipment : Smart Module Brand Name : TurboX Test Model : TurboX C2290 Series Model : N/A Applicant : Thundercomm Technology Co., Ltd Address : No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Manufacturer : Thundercomm Technology Co., Ltd Address : No. 107, Middle Datagu Road, Xiantao Street, Yubei District, Chongqing, China, 401122 Factory : MIKI TECHNOLOGY HUIZHOU Address : 39 Guangtai Road, Huinan Science Park, Huizhou City Date of Receipt : Jul. 22, 2024 Date of Test : Jul. 24, 2024 ~ Aug. 14, 2024 Issued Date : Aug. 28, 2024 Report Version : R00 Test Sample : Engineering Sample No.: DG20240722112 for radiated and AC Power Line Conducted, DG2024072344 for conducted Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Sheldon Ou Approved by : Chay Cai Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.:BTL-FCCP-1-2407C144 Page 2 of 80 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.:BTL-FCCP-1-2407C144 Page 3 of 80 Table of Contents Page REPORT ISSUED HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 11 3.3 PARAMETERS OF TEST SOFTWARE 12 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 SUPPORT UNITS 13 3.6 CUSTOMER INFORMATION DESCRIPTION 13 4 . AC POWER LINE CONDUCTED EMISSIONS 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 14 4.3 DEVIATION FROM TEST STANDARD 14 4.4 TEST SETUP 15 4.5 EUT OPERATING CONDITIONS 15 4.6 TEST RESULTS 15 5 . RADIATED EMISSIONS 16 5.1 LIMIT 16 5.2 TEST PROCEDURE 17 5.3 DEVIATION FROM TEST STANDARD 18 5.4 TEST SETUP 18 5.5 EUT OPERATING CONDITIONS 20 5.6 TEST RESULTS - 9 KHZ TO 30 MHZ 20 5.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 20 5.8 TEST RESULTS - ABOVE 1000 MHZ 20 6 . NUMBER OF HOPPING FREQUENCY 21 6.1 LIMIT 21 6.2 TEST PROCEDURE 21 Report No.:BTL-FCCP-1-2407C144 Page 4 of 80 Table of Contents Page 6.3 DEVIATION FROM STANDARD 21 6.4 TEST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 TEST RESULTS 21 7 . AVERAGE TIME OF OCCUPANCY 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION FROM STANDARD 22 7.4 TEST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 TEST RESULTS 22 8 . HOPPING CHANNEL SEPARATION 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM STANDARD 23 8.4 TEST SETUP 23 8.5 EUT OPERATION CONDITIONS 23 8.6 TEST RESULTS 23 9 . BANDWIDTH 24 9.1 LIMIT 24 9.2 TEST PROCEDURE 24 9.3 DEVIATION FROM STANDARD 24 9.4 TEST SETUP 24 9.5 EUT OPERATION CONDITIONS 24 9.6 TEST RESULTS 24 10 . MAXIMUM OUTPUT POWER 25 10.1 LIMIT 25 10.2 TEST PROCEDURE 25 10.3 DEVIATION FROM STANDARD 25 10.4 TEST SETUP 25 10.5 EUT OPERATION CONDITIONS 25 10.6 TEST RESULTS 25 11 . CONDUCTED SPURIOUS EMISSION 26 11.1 LIMIT 26 Report No.:BTL-FCCP-1-2407C144 Page 5 of 80 Table of Contents Page 11.2 TEST PROCEDURE 26 11.3 DEVIATION FROM STANDARD 26 11.4 TEST SETUP 26 11.5 EUT OPERATION CONDITIONS 26 11.6 TEST RESULTS 26 12 . MEASUREMENT INSTRUMENTS LIST 27 13 . EUT TEST PHOTO 29 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 35 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 38 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 43 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 46 APPENDIX E - NUMBER OF HOPPING FREQUENCY 59 APPENDIX F - AVERAGE TIME OF OCCUPANCY 61 APPENDIX G - HOPPING CHANNEL SEPARATION 66 APPENDIX H - BANDWIDTH 68 APPENDIX I - MAXIMUM OUTPUT POWER 70 APPENDIX J - CONDUCTED SPURIOUS EMISSION 73 APPENDIX K - DECLARATION FOR BLUETOOTH DEVICE 78 Report No.:BTL-FCCP-1-2407C144 Page 6 of 80 REPORT ISSUED HISTORY Report No. Vers…

Text truncated - open the document above for the full version.

SPE-19-8-061-D Po: TG.55.8113 DDescription: 5G/4G Terminal Mount Monopole Antenna with 90 o Hinged SMA (M) FFeatures: Covering Sub 6GHz 5G NR Bands Covering Worldwide 4G Bands 600MHz-6GHz Bandwidth High Efficiency up to 80% 3G/2G Fallback with NB-IoT and CAT-M capabilities 90 o Hinged Right Angle SMA (M) Connector Straight Dimensions: 172 x 23.9 x 13 mm Right Angle Dimensions: 148 x 42.4 x 13 mm RoHS & REACH Compliant o: 8113 с SPE-19-8-061-D www.taoglas.com









































Taoglas makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Taoglas reserves all rights to this document and the information contained herein. Reproduction, use or disclosure to third parties without express permission is strictly prohibited.

1. Introduction 3 2. Specifications 4 3. Antenna Characteristics 7 4. Radiation Patterns 9 5. Mechanical Drawing 75 6. Packaging 76 7. Application Note 77 Changelog 79
т SPE-19-8-061-D www.taoglas.com The Taoglas TG.55.8113 is a 5G/4G monopole antenna, designed primarily for use with modules and devices that require high efficiency and peak gain. It delivers best in class throughput on all major cellular bands worldwide, perfect for access points, terminals, and routers. The TG.55 covers many 5G NR Sub 6GHz bands including the new Extended LTE Band 71. It has an SMA (M) connector as standard and is an ideal solution for any device requiring reliable performance in a slim form factor. Typical Applications include: - Gateways & Routers - Smart Metering - Vending Machines - Industrial IoT - Smart Home - Connected Enterprise The TG.55 exhibits an efficiency of up to 80% across wideband 5G/4G bands and is backward compatible with 3G/2G cellular applications. The TG.55 is a fully omnidirectional antenna as seen in the radiation patterns and is stable across all bands. The SMA (M) connector hinge mechanism allows the antenna to be rotated into the preferred orientation which helps to avoid other antennas or objects. This also helps with isolation by pointing the antennas in different directions when used in MIMO systems or when other antennas are present on the same device. The antenna blade can swivel 90 degrees from the connector accommodating different installation configurations. The TG.55.8113 is also available with a white enclosure – TG.55.8113W. The connector can also be customized based on an MOQ. Contact your regional Taoglas customer support team to request these services or additional support to integrate and test this antenna’s performance in your device. 1. Introduction esigned primarily for use with modules and devices ilhhlljll l b d у SPE-19-8-061-D www.taoglas.com Electrical Frequency (MHz) 5G NR Band 71 LTE 700 GSM 850/900 5G NR B 74, 75, 76 GPS L1 DCS UMTS1 LTE 2600 5G NR B 77, 78, 79 LTE 5200 617 ~698 698 ~824 824 ~960 1427 ~1518 1563 ~1587 1710 ~1880 1920 ~2170 2300 ~2690 3300 ~5000 5150 ~5925 Efficiency (%) Free space straight 35.93 25.92 38.33 38.08 46.37 69.80 59.03 44.92 50.45 45.96 Free space bent 43.77 30.56 51.77 44.23 53.07 78.02 65.02 51.53 48.91 34.98 On 30x30 cm GND edge straight 44.39 39.43 59.39 49.21 57.94 66.24 52.47 42.63 24.71 21.90 On 30x30 cm GND edge bent 42.05 30.02 52.28 46.78 48.79 68.89 54.17 39.78 21.31 22.53 On 30x30 cm GND centre straight 9.12 7.30 21.46 38.09 51.59 65.46 48.14 42.25 36.68 24.48 On 30x30 cm GND centre bent 4.88 10.77 34.32 36.52 46.16 60.36 47.55 42.15 36.82 21.93 Average Gain (dB) Free space straight -4.45 -5.86 -4.16 -4.19 -3.34 -1.56 -2.29 -3.48 -2.97 -3.38 Free space bent -3.59 -5.15 -2.86 -3.54 -2.75 -1.08 -1.87 -2.88 -3.11 -4.56 On 30x30 cm GND edge straight -3.53 -4.04 -2.26 -3.08 -2.37 -1.79 -2.80 -3.70 -6.07 -6.60 On 30x30 cm GND edge bent -3.76 -5.23 -2.82 -3.30 -3.12 -1.62 -2.66 -4.00 -6.71 -6.47 On 30x30 cm GND centre straight -10.40 11.37 -6.68 -4.19 -2.87 -1.84 -3.17 -3.74 -4.36 -6.11 On 30x30 cm GND centre bent -13.12 -9.68 -4.64 -4.37 -3.36 -2.19 -3.23 -3.75 -4.34 -6.59 Peak Gain (dBi) Free space straight -0.68 -2.14 0.15 -0.74 -0.59 1.37 0.93 0.73 1.51 1.73 Free space bent 0.14 -1.88 0.58 0.87 1.98 3.09 2.45 1.69 1.50 0.70 On 30x30 cm GND edge straight 0.94 -0.32 2.56 1.00 1.26 1.93 1.42 1.24 -0.84 -1.48 On 30x30 cm GND edge bent 0.63 -1.99 -0.02 -0.59 0.37 1.66 0.49 0.13 0.53 -0.25 On 30x30 cm GND centre straight -5.47 -5.46 0.02 0.75 2.30 3.44 2.48 2.36 4.66 2.40 On 30x30 cm GND centre bent -9.07 -6.11 -1.12 3.76 4.99 6.10 4.84 3.46 3.92 1.80 Impedance 50Ω Polarization Linear Radiation Pattern Omni Max. input power 2W 2. Specifications ф SPE-19-8-061-D www.taoglas.com Mechanical SMA Connector Diameter 13mm Planner Dimension 172mm * 23.88mm Casing ABS + PC Connector SMA (M) Weight 24.3g Environmental Temperature Range -40°C to 85°C Humidity Non-condensing 65°C 95% RH х SPE-19-8-061-D www.taoglas.com 5G/4G Bands Band Number 5GNR / FR1 / LTE / LTE-Advanced / WCDMA / HSPA / HSPA+ / TD-SCDMA
