2AON4-N3Starvis Dual Dash Camera 1080P With Super Night Vision

MOBILE PHONE APP CONNECTION AND OPERATION Built-in Wi-Fi module, this system can connect mobile phone through Android or IOS APP, please check below for its setting. 1. Scan the QR code below to quickly install your mobile app. 3. Enter mobile phone interface, turn on Wi-Fi and connect Wi-Fi ID (default name CVRDV_M5_*,"*"is system MAC address), enter initial password: 12345678. After the connection is successful, the main interface Wi-Fi icon will change from “ ” to “ ”. 2. In the main interface of the dash camera, short press “ ” to enter the menu setting page, select Wi-Fi, and set it to “open”. At this time, the Wi-Fi name and password will be displayed on the main interface, and the Wi-Fi icon will change from “ ” to “ ”, as shown below. AndroidIOS Local Album Picture folder Setting Recording mode Capture mode Video switch Delete Download to local album Close Front / middle / rear video switch 5. Click “ ” to enter the list of recorded videos, click “Edit” to switch between front and back video, download the video to the local, delete videos in batches, etc. See the gure below. 4. Open mobile phone APP, user can check the recording video and operate accordingly. Start /stop recording Video folder Serial No.: 2020WGV030GD1029 Tap the icon “ ” in the main interface to proceed to the menu settings MENU SETTINGS Stamp: Can set “Date + logo / Date / Off”.Movie Mode: Can set “ FHD30 / HD30”. Exposure: Can set “ Up / Down”. Wifi: Can set “on / off”.File playback: “Normal le” and “Event le” are optional. Sound Record: Can set“on / off”.Beep: Can set “on / off”. Volume: Can set “Up / Down”.Movie Clip Time: Can set “1min / 2mins / 3mins”. Time Lapes (Optinoal): Can set “on / off”. Turn on the “time lapses” video function. When the car is turned off and the machine is in the ignition disconnected state, the machine will prompt to enter the “time lapses” video. When the voltage is low, the machine will stop recording automatically to avoid car engine can’t start properly because of low voltage. When playing a video, it turns a long video of slow motion into a short video of fast motion, similar to fast forward playback in movies. For example, when recording for 1 minute, the video is compressed to 1 second, and the recording for 1 hour is changed to 1 minute to play. LCD Power Save: Can set “off / 1min / 3mins”. After exiting the menu, the mirror will start to count the time once there are no operations. The screen will auto turn off when it reaches the time you set. Language: “English/Simplied Chinese/Traditional Chinese”. (Languages may increase without notice) ReturnPreviousNextConrm Power Off: Can set “Never / 1min / 3mins”. After exiting the menu, the mirror will start to count the time once there are no operations. The device will auto turn off when it reaches the time you set. Protect Level (G-sensor): Can set “Off / High / Middle / Low”. With G-sensor function, dash camera can automatically save the video as event le when it detects acceleration of gravity changes greatly. For example, when car crash happens. The event le will be locked and cannot be overwritten in record cycle mode. It can only be manually deleted one by one or formatted. Parking Monitoring (Optinoal): Can set “Off / High / Middle / Low”. Turn on the parking monitoring function. When the car is turned off and the machine is in the ignition disconnected state, the machine senses that the car is subject to an external collision. The machine will power up to record 10 seconds of video and enter the sleep state after ten seconds. Format SD-Card: If it’s not necessary to save the videos in card, user can delate all videos (both normal video and event les) by formatting. APP Download: Android version / IOS version / Built-in APP QR code. Clock Setting: Can set “year/month/day”, “hour/min/sec”. System time can be marked on the video. Delete files: Can delete “Normal ie” and “Event le” . Flicker: Can set “50Hz / 60Hz”. Each country has different supply frequency due to geographical reason. Standard frequency of dash camera lens is constant 50Hz. When the supply frequency inconsistent with frequency standard the image on the device will appear joggling phenomenon. At this point users should adjust Frequency to consistent with supply frequency. Reset Setup: After making a lot of custom settings,users can reset the device to the original factory settings.

GlobalMediaIndustryGroupCo., Ltd. Date: 2022-06-02 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Long Term Confidentiality FCC ID: 2AON4-N3 To WhomIt May Concern, Pursuantto the provisionsof the Commission’s rules Title 47 Sections§0.457 and §0.459,we are requestingthe Commissionto withholdthe followingattachment(s)as confidential documentsfrom public disclosureindefinitely. Thesedocumentscontaindetailedsystemand equipmentdescriptionsand are consideredas proprietaryinformationin operationof the equipment.The public disclosureof these documents might be harmfulto our companyand would give competitorsan unfair advantagein the market. SchematicDiagram Block Diagram Parts List OperationalDescription Tune-upProcedure It is our understandingthat all measurementtest reports,FCC ID label formatand correspondenceduringthe certificationreviewprocesscannotbe grantedas confidential documentsand this informationwill be availablefor public reviewonce the grant of equipment authorizationis issued. Sincerely, Signature: Name:SelinaWang Title: Sales Manager

Global Media Industry Group Co., Ltd. 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Agent Authorization Company: Global Media Industry Group Co., Ltd. Address: 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Product Name: Starvis Dual Dash Camera 1080P With Super Night Vision Model Number(s): WGV-030-D Product Description: Starvis Dual Dash Camera 1080P With Super Night Vision We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature:Date: 2022-06-02 Name:Selina Wang Title:Sales Manager Company: Global Media Industry Group Co., Ltd.

Page 1 of 4 Appendix C: Photographs of EUT Product: Starvis Dual Dash Camera 1080P With Super Night Vision Model: WGV-030-D External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkand Location Model:WGV-030-D Label: Size:L*W=25*20mm Location Starvis Dual Dash Camera 1080P With Super Night Vision

Page 1 of 6 Appendix C: Photographs of EUT Product: Starvis Dual Dash Camera 1080P With Super Night Vision Model: WGV-030-D Internal Photos Antenna Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AON4-N3 Test Report No. ............... : TCT220505E013 Date of issue ................... : Jun. 01, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Manufacturer's name ... : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Product Name ................. : Starvis Dual Dash Camera 1080P With Super Night Vision Trade Mark ...................... : imirror Model/Type reference..... : WGV-030-D Rating(s).......................... : DC 12V Date of receipt of test item ......................................... : May 05, 2022 Date (s) of performance of test ................................... : May 05, 2022 - Jun. 01, 2022 Tested by (+signature) ... : Aaron MO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220505E013 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT220505E013 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Starvis Dual Dash Camera 1080P With Super Night Vision Model/Type reference........... : WGV-030-D Sample Number....................: TCT220505E012-0101 Operation Frequency ........... : 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) Channel Separation .............. : 5MHz Number of Channel .............. : 11 for 802.11b/802.11g/802.11n(HT20) Modulation Technology ....... : 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) Data speed ............................ : 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps 802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps 802.11n: Up to 150Mbps Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : 0dBi Rating(s)................................ : DC 12V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT220505E013 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 12V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT220505E013 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communicat…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AON4-N3 Test Report No. ............... : TCT220505E012 Date of issue ................... : Jun. 01, 2022 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: TCT Testing Industrial Park Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Manufacturer's name ... : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : Starvis Dual Dash Camera 1080P With Super Night Vision Trade Mark ...................... : imirror Model/Type reference..... : WGV-030-D Rating(s).......................... : DC 12V Date of receipt of test item ......................................... : May 05, 2022 Date (s) of performance of test ................................... : May 05, 2022 - Jun. 01, 2022 Tested by (+signature) ... : Aaron MO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT220505E012 Page 2 of 79 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 6 4. Facilities and Accreditations .................................................................. 7 4.1. Facilities ................................................................................................................. 7 4.2. Location ................................................................................................................. 7 4.3. Measurement Uncertainty ..................................................................................... 7 5. Test Results and Measurement Data ..................................................... 8 5.1. Antenna requirement ............................................................................................ 8 5.2. Conducted Emission ............................................................................................. 9 5.3. Maximum Conducted (Average) Output Power ................................................ 10 5.4. Emission Bandwidth ........................................................................................... 11 5.5. Power Spectral Density ....................................................................................... 12 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 13 5.7. Radiated Spurious Emission Measurement ...................................................... 15 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT220505E012 Page 3 of 79 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : Starvis Dual Dash Camera 1080P With Super Night Vision Model/Type reference........... : WGV-030-D Sample Number....................: TCT220505E012-0101 Operation Frequency ........... : 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) Channel Separation .............. : 5MHz Number of Channel .............. : 11 for 802.11b/802.11g/802.11n(HT20) Modulation Technology ....... : 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) Data speed ............................ : 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps 802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps 802.11n: Up to 150Mbps Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : 0dBi Rating(s)................................ : DC 12V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. 1.3. Operation Frequency For 802.11b/g/n(HT20) Channel Frequency Channel Frequency Channel Frequency Channel Frequency 1 2412MHz 4 2427MHz 7 2442MHz 10 2457MHz 2 2417MHz 5 2432MHz 8 2447MHz 11 2462MHz 3 2422MHz 6 2437MHz 9 2452MHz -- -- Note: In section 15.31(m), regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the highest frequency of channel were selected to perform the test, and the selec…

Text truncated - open the document above for the full version.

Page 1 of 1 Appendix B: Photographs of Test Setup Product: Starvis Dual Dash Camera 1080P With Super Night Vision Model: WGV-030-D Radiated Emission
