2AON4YVL-096A-M39S9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam

YVL-096A-M39S FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Page 1 of 4 Appendix C: Photographs of EUT Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkandLocation Model:YVL-096A-M39S Label: Size:L*W=40*20mm Location

Page 1 of 4 Appendix C: Photographs of EUT Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S Internal Photos Antenna Page 2 of 4 Page 3 of 4 Page 4 of 4

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AON4YVL-096A-M39S Test Report No. ............... : TCT230314E002 Date of issue ................... : Mar. 20, 2023 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Manufacturer's name ... : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Product Name ................. : 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Trade Mark ...................... : imirror Model/Type reference..... : YVL-096A-M39S, YK-096A-M39S Rating(s).......................... : DC 12V/ 24 V Date of receipt of test item ......................................... : Mar. 14, 2023 Date (s) of performance of test ................................... : Mar. 14, 2023- Mar. 20, 2023 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT230314E002 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT230314E002 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model/Type reference........... : YVL-096A-M39S Sample Number....................: TCT230314E001-0101 Operation Frequency ........... : 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) Channel Separation ............. : 5MHz Number of Channel .............. : 11 for 802.11b/802.11g/802.11n(HT20) Modulation Technology ....... : 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) Data speed ............................ : 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps 802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps 802.11n: Up to 150Mbps Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : 3.32dBi Rating(s)................................ : DC 12V/ 24 V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 YVL-096A-M39S Other models YK-096A-M39S Note: YVL-096A-M39S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, YK-096A-M39S has no front lens and no ultracapacitor. So the test data of YVL-096A-M39S can represent the remaining models. Report No.: TCT230314E002 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 12V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT230314E002 Page 5 of 6 Hotline: 400-6611…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AON4YVL-096A-M39S Test Report No. ............... : TCT230314E001 Date of issue ................... : Mar. 20, 2023 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Manufacturer's name ... : Global Media Industry Group Co., Ltd. Address ........................... : 2F, Bldg A, No. 46, Xingye 1st Rd, Fenghuang, Fuyong, Bao'an, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Trade Mark ...................... : imirror Model/Type reference..... : YVL-096A-M39S, YK-096A-M39S Rating(s).......................... : DC 12V/ 24 V Date of receipt of test item ......................................... : Mar. 14, 2023 Date (s) of performance of test ................................... : Mar. 14, 2023- Mar. 20, 2023 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT230314E001 Page 2 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 4 2. Test Result Summary .............................................................................. 5 3. General Information ................................................................................. 6 3.1. Test environment and mode ................................................................................. 6 3.2. Description of Support Units ................................................................................ 7 4. Facilities and Accreditations .................................................................. 8 4.1. Facilities ................................................................................................................. 8 4.2. Location ................................................................................................................. 8 4.3. Measurement Uncertainty ..................................................................................... 8 5. Test Results and Measurement Data ..................................................... 9 5.1. Antenna requirement ............................................................................................ 9 5.2. Conducted Emission ........................................................................................... 10 5.3. Maximum Conducted (Average) Output Power ................................................ 11 5.4. Emission Bandwidth ........................................................................................... 12 5.5. Power Spectral Density ....................................................................................... 13 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 14 5.7. Radiated Spurious Emission Measurement ...................................................... 16 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT230314E001 Page 3 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model/Type reference........... : YVL-096A-M39S Sample Number....................: TCT230314E001-0101 Operation Frequency ........... : 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) Channel Separation ............. : 5MHz Number of Channel .............. : 11 for 802.11b/802.11g/802.11n(HT20) Modulation Technology ....... : 802.11b: Direct Sequence Spread Spectrum (DSSS) 802.11g/802.11n: Orthogonal Frequency Division Multiplexing(OFDM) Data speed ............................ : 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps 802.11g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps 802.11n: Up to 150Mbps Antenna Type ........................ : Internal Antenna Antenna Gain ........................ : 3.32dBi Rating(s)................................ : DC 12V/ 24 V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 YVL-096A-M39S Other models YK-096A-M39S Note: YVL-096A-M39S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, YK-096A-M39S has no front lens and no ultracapacitor. So the test data of YVL-096A-M39S can represent the remaining models. Report No.: TCT230314E001 Page 4 of 78 Hotline: 40…

Text truncated - open the document above for the full version.

Report No.: TCT230314E001 Page 70 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Appendix B: Photographs of Test Setup Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S Radiated Emission Report No.: TCT230314E001 Page 71 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Appendix C: Photographs of EUT Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S External Photos Report No.: TCT230314E001 Page 72 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT230314E001 Page 73 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT230314E001 Page 74 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT230314E001 Page 75 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S Internal Photos Report No.: TCT230314E001 Page 76 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT230314E001 Page 77 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT230314E001 Page 78 of 78 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com *****END OF REPORT*****

SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 One Antennaspecificationforapproval Customername Gomeidi Model YV096-M39specialrearviewmirror-8188FTVmodule Antenna frequency 2.4GHZ Antenna function WIFIantenna Antenna material FPC FPCcolor black model SF1948A-1B2-A Materialnumber SF1948A-1L11G-115-A CustomerPart Number WardacceptedthesignatureClientacknowledgessignature structurePurchase Documentcontrolstructure radiofrequencyengineering ToexamineQC ResponsibleLTTToexamine date 2023.03.31 Sealarea date 2023.03.31 Sealarea SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Two Serial number CertificationnumberMaterialtypeDateofissueRemarks 1A2220186128101ER1 Tinnedcopper wire 2022-05-17 Oneyear 2CANEC2227657302 halogen 2022-12-28 Oneyear 3CANEC2227657303 Adhesive 2022-12-28 Oneyear 4SHAEC23000346911 FEPsheath 2023-01-13 Oneyear 5SHAEC22004639301 FEPinsulation 2022-12-15 Oneyear 6SZXEC2203054804 Tinwire 2022-09-19 Oneyear 7SZXEC2203054808 Tin 2022-09-19 Oneyear 8ETR22300684 Printingink 2022-08-09 Oneyear 9EKR22501369 Substrate 2022-05-27 Oneyear 10CANEC2227574118 EVAfoam 2023-01-03 Oneyear 11SZXEC2202709609 Conductive cloth 2022-08-16 Oneyear 12CANEC2218227002 Goldplating 2022-08-30 Oneyear SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Three tableofContents 一:DeviceSupport&TestableAntennaType ................................ 1 二: Overview ....................................................................................... 2 三:Matchingcircuitdiagram&machinepicture&antennapicture3 四:Antennastandingwaveratio&AntennaEfficiency ... 4 五:Antennamap ............................................................................... 5 六:3Dpattern ................................................................................. 6 七:Structuraldrawing ................................................................ 7 SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Four 一: DeviceSupport&TestableAntennaType SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Five 二: Overview (1)Antennaperformance 1.ThisapprovalsheetsupportsforMIDproject.FPCantennasincludeinthisproject.Thisreport isfortheperformanceofWIFIantenna. 2.Antennashapesize：MeettherequirementofMID 3.Antennaband：2400MHz~2500MHz 4.Antennamaterial：AntennamaterialmeettherequirementofMID 5.Adhesiveperformance：AdhesiveperformancemeettherequirementofMID 6.Antennaperformancemeetthespecbelow： Description2.4GHZ~2.5GHzUnits VSWR ≤2.0 AverageAntennaGain ≥-4.5 dB AntennaEfficiency≥40% FeedImpedance50ohms OperatingTemperature-40to+85degC Polarization/AzimuthLinear/Omni-directional (2)MechanicalInformation MechanicalDimension CableLength115mm/GRAY DescriptionWIFIantenna MaterialFPC CoaxialCable50Ω/O.D.1.13mm Environmental OperationTemperature-40to+85degC StorageTemperature-40to+85degC SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Six 三: Matchingcircuitdiagram&machinepicture&antennapicture (1)Matchingcircuit (2)Machinepicture&antennapicture NA RF NA NA NA NA NA SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Seven 四:Antennastandingwaveratio&AntennaEfficiency SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6th Floor,BuildingB, HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao 'an District, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Eight 五:Antennamap SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135QianjinSecondRoad,Bao'anDistrict, Shenzhen CityTel:0755-29985185Fax:0755-27487028 Nine 六:3Dpattern 七:Structuraldrawing f 115 +2 -0 f f f SWARD SWD-FM-RD-012 A.0/2019.12 ķ7HUPLQDO outward ĸ f f

Page 1 of 1 Appendix B: Photographs of Test Setup Product: 9.66 inch 1080P Streaming Media Mirror Monitor With Built-in Dash Cam Model: YVL-096A-M39S Radiated Emission
