2AORE-B6Flydigi Mobile Phone Cooling Fan B6

英文说明书 B6 1.初次使用，接通电源即开启散热器的智能变频 模式；确保充电器的输出功率为5V 2A或以上。 1. First to use: The default mode is the Smart Frequency Conversion mode. Notice: 5V 2A or higher charger output is required. 飞智散热器B6 背夹版使用说明书 FlydigiMobile Phone Cooling Fan B6 User Manual 手持手机，抵住上槽后向上推 Hold mobile phone and push up against upper pull hook 2.按键开关：单击可控制开启或关闭散热器。 2.Power Switch: Click can control the cooling fan on and off switch 扫描二维码，下载飞智游戏厅 Scanning QR code (left) to download FlydigiGame Center. 开启蓝牙连接散热器，可以切换多种模式，查看线上教程 Turn on the Bluetooth to connect Cooling fan can change to multiple modes, view more tutorials. 产品名称：飞智散热器B6 磁吸版 Product Name：FlydigiMobile Phone Cooling Fan B6 产品型号：FlydigiB6 Model：FlydigiB6 包装内容：飞智散热器B6、充电线*1 In the box: Cooling Fan, Type-C Cable 智能变频 Smart Frequency Conversion 散热器会根据温度自动调节制冷功率，建议搭配20W及以上功率充电器，否则无法激活最大功率。 Cooling fan will auto adjusts cooling power for safe use of your phone. It is recommended to use a 20W or above power charger, otherwise the maximum power cannot be activated. 额定输出 Rated Output 散热器会根据所选挡位输出制冷功率，建议搭配20W及以上功率充电器，否则无法激活最大功率 Cooling fan will output cooling power according to the selected level. It is recommended to use a 20W or above power charger, otherwise the maximum power cannot be activated. 常见问题Q & A 1.是否必须配备20W及以上功率充电器？ Q1: Is it necessary to pair with a charger with outpower of 20W and above? 为了激活散热器的最大功率，建议配备。 A1: In order to active maximum power, we recommend to pair with. 2.为什么散热器突然不工作？ Q2: Why does the Cooling fan suddenly stop working? 当产品温度过高时会触发自动保护机制，自动停止工作，请静置放凉后再重新启动。 A2: When the temperature of the product is too high, the automatic protection mechanism will be triggered, which will automatically stop working. Please put it in a cool place and make sure before restarting. 中文：自用户购买之日15天内出现质量问题，可联系购买店铺，进行退货或换货处理。 英文：If quality problems occur within 15 days from the date of purchase, the user can contact the purchase shop for return or exchange. This table is based on the regulations of SJ/T 11364-2014 Indicates that the concentration of the toxic or hazardous substance in all homogeneous materials in this part is below the limit requirement in GB/T26572-2011 Indicates that the concentration of the toxic or hazardous substance in at least one homogeneous material of this part exceeds the limit requirement in GB/T26572-2011 The environmentally-friendly use period of this product is 10 years based on normal operating conditions Name and Concentration of Toxic or Hazardous Substances and Elements 自用户购买之日15天内出现质量问题，可联系购买店铺，进行退货或换货处理。 If quality problems occur within 15 days from the date of purchase, the user can contact the purchase shop for return or exchange. Federal Communications Commission (FCC) Statement The device has been evaluated to meet general RF exposure requirement, The device can be used in portable exposure condition without restriction Federal Communication Commission (FCC) Radiation Exposure Statement Power is so low that no RF exposure calculation is needed. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment. Such modifications or changes could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation, This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with th e instructions, may cause harmful interference to radiocommunications. However, there is no guarantee that interference will not occur in a particular installation. lf th is equipment does cause harmful interference to radio or television reception. which can be determined oy turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/ TV technician for help.

Shanghai Flydigi Electronics Technology Co., Ltd. 2022-12-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize DongGuan Anci Electronic Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co., Ltd. Rm1108, No.258 Guoxia Rd, Yangpu District

Shanghai Flydigi Electronics Technology Co., Ltd. 2022-12-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Flydigi Mobile Phone Cooling Fan B6/Model: B6 /FCC ID: 2AORE-B6) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram ,Operational Description,Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co., Ltd. Rm1108, No.258 Guoxia Rd, Yangpu District

Labe and Location

ANT

RF EXPOSURE EVALUATION EUT Specification EUT Flydigi Mobile Phone Cooling Fan B6 Model Number B6 FCC ID 2AORE-B6 Antenna gain (Max) 2.08dBi Operation Frequency GFSK: 2402-2480MHz Input Rating DC 5V2A, 9V2A Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK Max. output power -0.93dBm(0.0008W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. GFSK: According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Tiger Xu Date: 2022-12-16 Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK -1.02 -1±1 0 0.309968 3 2440 GFSK -0.94 -1±1 0 0.312410 3 2480 GFSK -0.93 -1±1 0 0.314960 3

TRF No.: 01-R001-3A-LE TRF Originator: GTG TRF Date: 2022-06-29 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT FCC PART 15 SUBPART C REQUIREMENT OF Flydigi Mobile Phone Cooling Fan B6 Model No.: B6 Trademark: N/A FCC ID: 2AORE-B6 Report No.: E01A22120188F00101 Issue Date: December 21, 2022 Prepared for Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108,No.258 Guoxia Rd, Yangpu District, Shanghai, China. Prepared by Dong Guan Anci Electronic Technology Co., Ltd. 1-2 Floor, Building A, No.11, Headquarters 2 Road, Songshan, Lake Hi-tech Industrial Development Zone, Dongguan City, Guangdong Pr., China.. This report shall not be reproduced, except in full, without the written approval of Dong Guan Anci Electronic Technology Co., Ltd. 2 of 51 Report No.: E01A22120188F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. VERIFICATION OF COMPLIANCE Applicant: Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108,No.258 Guoxia Rd, Yangpu District, Shanghai, China. Manufacturer: SHENZHEN KING CHUANG TECH & ELECTRONIC CO.,LTD 58 Guangtian Road, Luotian Neighbour, Yanluo Street, Baoan District, Shenzhen, China (Postal Code 518127) Product Description: Flydigi Mobile Phone Cooling Fan B6 Trade Mark: N/A Model Number: B6 We hereby certify that: The above equipment was tested by Dong Guan Anci Electronic Technology Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2022). Date of Test : December 12, 2022 to December 16, 2022 Prepared by : Tomas Yang/Editor Approved & Authorized Signer : Tiger Xu / Supervisor 3 of 51 Report No.: E01A22120188F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / E01A22120188F00101 4 of 51 Report No.: E01A22120188F00101 TRF No.: 01-R001-3A-LE Global Testing , Great Quality. Table of Contents 1. GENERAL INFORMATION ................................................................................................... 6 1.1 PRODUCT DESCRIPTION .......................................................................................................... 6 1.2 TEST METHODOLOGY .............................................................................................................. 6 2. TEST FACILITY ...................................................................................................................... 7 3. DESCRIPTION OF TEST MODES....................................................................................... 8 4. SUMMARY OF TEST RESULTS ....................................................................................... 10 6DB BANDWIDTH MEASUREMENT ............................................................................................. 10 5. TEST SYSTEM UNCERTAINTY ........................................................................................ 11 6. CONDUCTED EMISSIONS TEST ..................................................................................... 12 6.1 MEASUREMENT PROCEDURE: ................................................................................................ 12 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 12 6.3 MEASUREMENT EQUIPMENT USED: ........................................................................................ 12 6.4 CONDUCTED EMISSION LIMIT ..................................................................................................... 12 6.5 MEASUREMENT RESULT: ....................................................................................................... 13 6.5 CONDUCTED MEASUREMENT PHOTOS: ....................................................................................... 15 7. RADIATED EMISSION TEST ............................................................................................. 16 7.1 MEASUREMENT PROCEDURE ................................................................................................. 16 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 18 7.3 MEASUREMENT EQUIPMENT USED: ........................................................................................ 19 7.4 RADIATED EMISSION LIMIT .......................................................................................................... 20 7.5 MEASUREMENT RESULT .......................................................................................................... 21 7.6 RADIATED MEASUREMENT PHOTOS: ........................................................................................... 28 8. 6DB BANDWIDTH MEASUREMENT ............................................................................... 29 8.1 MEASUREMENT PROCEDURE ................................................................................................. 29 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................ 29 8.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 29 8.4 LIMIT ........................................................................................................................................ 30 8.5 MEASUREMENT RESULTS: ..................................................................................................... 30 9. MAXIMUM PEAK OUTPUT POWER TEST .............................................................................. 33 9.1 MEASUREMENT PROCEDURE ................................................................................................. 33 9.2 TEST SET-UP (BLOCK DIAG…
