2AORE-S32Flydigi Supercharged Laptop Cooler BS3 Pro

FLYDIGI Supercharged Laptop Cooler BS3 Pro Series Stand User Manual Product Introduction Model: Flydigi BS3 ,Flydigi BS3 Pro Cooler Installation & Usage 1、Adjust the lever Pull out the pull rod to the appropriate length 2、Flip up the baffle Flip up the two end shields 3、Determine height Pull out the tripod and adjust it to the appropriatheight 4、Insert the power supply Plug the type-C power supply cable into the power supply port and short press the power button to power on (5V2A Only for computer USB—C port power supply.In order to unlock the maximum performance gear, it is recommended to use a power adapter of ≥ PD 18W to power the BS3 Pro standard version, and for the Pro version, it is recommended use a power adapter of ≥ PD 27W to power it.) 5、Sealed alignment Place the computer's air inlet inside the sponge ring of the radiator to create a sealed and leak free space 6 、Dust Cleanable Remove the lower shell and use a brush to clean the dust off the dust filter. Operation&Tips Operation Short press the button - In the shutdown state, short press to turn on the device; Short press to switch gears when turned on Long press the button - press and hold for 1 second to turn off the device, press and hold for 10 seconds to flash the gear indicator and clear Bluetooth pairing information Tips Level status luminaires always on - Fixed speed mode, the number of lit lights is related to the fixed speed gear. Level status luminaires breathing Intelligent frequency conversion mode. APP installation and connection use Enter www.FLYDIGI.com in the browser to enter the official website of Feizhi, find the software download, and downloadizhi Space Station 3.0 or 4.0. Open the FLYDIGI Space Station, select the BS3 Pro series, and click to connect according to the tutorial. Space Station Page Description Frequently Asked Questions Q: Unable to enable the maximum gear? A: When powered by a computer or some A-C chargers, due to output protocol restrictions, the maximum gear cannot be enabled. The BS3 Pro Standard version requires a PD charger of ≥18W, and the BS3 Pro Pro version requires a PD charger of ≥27W. Q: Does it support flat placement? A: Yes, it does. Q: Can a liquid metal computer be used? A: Yes, it can. The stand has four height levels: flat, 10 degrees, 20 degrees, and 30 degrees. When the liquid metal is evenly heated, all four angles are within the safe deviation range. Q: Why can't a PD charger greater than 18W/27W enable overclocking? A: Some brands of A-C chargers cannot enable overclocking mode due to protocol limitations. It is recommended to replace with a PD charger greater than 18W. Q: A PD charger greater than 18W/27W can't enable overclocking? A: Some brands of A-C chargers cannot enable the overclocking gear due to protocol restrictions. It is recommended to use a PD charger greater than 18W. Q: What temperature does the Space Station display for the device? A: The Space Station automatically scans all the device's temperature sensors to calculate the overall machine temperature. Q: Why can't the Space Station read the temperature? A: Please click "Upload Log" to report the computer model and CPU model to assist us in adapting to more computer models. Q: Why can't I enable smart frequency conversion? A: Please click "Upload Log" to report the computer model and CPU model to assist us in adapting to more computer models. Q: Can the dust filter be removed? A: The machine has two dust filter . The external dust filter is removable and can be washed directly with water, while the internal dust filter is not removable. FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ￮ This device may not cause harmful interference. ￮ This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: ￮ Reorient or relocate the receiving antenna. ￮ Increase the separation between the equipment and receiver. ￮ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ￮ Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. After-sales service 1、For all genuine products purchased from FLYDIGI, the products can be returned or exchanged 7 days of normal use and without affecting the secondary sale. 2、If there is a quality issue within 15 days, a new will be exchanged with the shipping fee borne by the merchant. 3、Within one year, there is a warranty, and the shipping fee is borne each party. 4、Warranty service is limited to problems that occur within the warranty period and during normal use; all damages caused by abnormal use (fs and damages caused by not using, maintaining, and storing the product according to the product manual), or repairs after the expiration of the warranty period, the user bear the cost of repair. Returns and exchanges: If there is a quality problem …

Text truncated - open the document above for the full version.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-04-03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AORE-S32) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-04-03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AORE-S32) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-04-03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-04-03 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Flydigi Supercharged Laptop Cooler BS3 Pro /Model: Flydigi BS3 Pro /FCC ID: 2AORE-S32) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram, Operational Description, Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

External

Internal Antenna

RF EXPOSURE EVALUATION EUT Specification EUT Flydigi Supercharged Laptop Cooler BS3 Pro Model Number Flydigi BS3 Pro FCC ID 2AORE-S32 Antenna gain (Max) 2.08dBi Operation Frequency 2402-2480MHz Power Supply DC 9V Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK Max. output power -2.92dBm(0.5105mW) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BLE: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK（1M） -2.96 -3±1 -2 0.195590 3 2440 GFSK（1M） -3.24 -3±1 -2 0.197131 3 2480 GFSK（1M） -4.39 -4±1 -3 0.157858 3 2402 GFSK（2M） -2.92 -3±1 -2 0.195590 3 2440 GFSK（2M） -3.1 -3±1 -2 0.197131 3 2480 GFSK（2M） -4.27 -4±1 -3 0.157858 3 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Alan He Date: 2026-03-05

Onboard antenna specification 2、characteristic lUltra-small size：2.8*9.95mm l50 ohmage lmaximum gain：2.08dBi lOp erates in the 2.4GHz band超 3、Antenna S parameter 10 dB O perating bandwidth:156MHz C enter bandS11：[email protected] 4、antenna gain 2.4GHz：ma ximum gain1.86dBi EFace： Nanjing Qinheng Microelectronics Co., LTD Adress: No. 18 Ningshuang Road, Yuhuatai District, Nanjing 1、 Onboard antenna detailed dimensions: Model：QH07 Unit: mm H Face： 2.44GHz：maximum gain2.08dBi EFace： Gain：5dBi Gain：1.9dBi Gain：5dBi Gain：5dBi Gain：5dBi Gain：1.9dBi Gain：1.9dBi Gain：1.9dBi HFace： 2.48GHz：maximum gain2.02dBi EFace： Gain：5dBi Gain：5dBi Gain：5dBi Gain：5dBi Gain：1.85dBi Gain：1.85dBi Gain：1.85dBi Gain：1.85dBi HFace： Gain：5dBi Gain：5dBi Gain：5dBi Gain：5dBi Gain：1.95dBi Gain：1.95dBi Gain：1.95dBi Gain：1.95dBi

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For Flydigi Supercharged Laptop Cooler BS3 Pro MODEL NUMBER: Flydigi BS3 Pro REPORT NUMBER: E04A26030163F00301 ISSUE DATE: March 29, 2026 FCC ID: 2AORE-S32 Prepared for Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A26030163F00301 Page 2 of 73 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 March 29, 2026 Initial Issue REPORT NO.: E04A26030163F00301 Page 3 of 73 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2020, Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2020, Clause 11.9.1.3 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth and 99% Occupied Bandwidth ANSI C63.10-2020, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2020, Clause 11.10.2 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2020, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2020, Clause 11.11 & Clause 11.12 FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2020, Clause 11.6 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A26030163F00301 Page 4 of 73 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS..................................................................................... 5 2. TEST METHODOLOGY......................................................................................................... 6 3. FACILITIES AND ACCREDITATION..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. MAXIMUM CONDUCTED OUTPUT POWER ........................................................... 9 5.4. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.5. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ........................................................... 9 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 10 5.1. SETUP DIAGRAM .................................................................................................. 10 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 11 7. ANTENNA PORT TEST RESULTS ..................................................................................... 13 7.1. Conducted Output Power ........................................................................................ 13 7.2. 6dB Bandwidth ........................................................................................................ 14 7.3. Power Spectral Density ........................................................................................... 16 7.4. Conducted Band edge and spurious emission ........................................................ 17 7.5. Duty Cycle .............................................................................................................. 19 8. RADIATED TEST RESULTS ............................................................................................... 20 8.1. Radiated Band edge and Spurious Emission .......................................................... 26 9. ANTENNA REQUIREMENT ................................................................................................ 38 10. AC POWER LINE CONDUCTED EMISSION ......................................................... 39 11. TEST DATA - Appendix A ..................................................................................... 42 REPORT NO.: E04A26030163F00301 Page 5 of 73 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Shanghai Flydigi Electronics Technology Co., Ltd. Address: Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Manufacturer Information Company Name: Shanghai Flydigi Electronics Technology Co., Ltd. Address: Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. EUT Information Product Description: Flydigi Supercharged Laptop Cooler BS3 Pro Model: Flydigi BS3 Pro Brand: FLYDIGI, Sample Rec…

Text truncated - open the document above for the full version.

Setup Photographs Radiated Band edge and Spurious Emission Radiated Band edge and Spurious Emission Page 2 of 2 AC Power Line Conducted Emission
