Flydigi Apex6 Pro Haptics Elite Controller User Manual Force Adjustable Joystick Instruction 1 Lift the D-pad straight up to remove it. 2 Remove the magnetic cover from the gap of the grip, and take out the force adjustment paddle from the right side of the controller. 3 Adjust the joystick tension by rotating the screw on the right side of the joystick using the djustment paddle. Connect Your Controller Pull the reel switch of the controller to ON, then press and hold the to open the menu on the screen, where you can configure the controller mode and button settings. Connect to a PC Open the on-screen menu, select [Connect] - [PC), and connect the computer and the controller using a dongle or a cable. If the controller is not used for a period of time, it will automatically enter sleep mode. Press the to wake up the controller. You can modify the sleep timeout in the Flydigi Space Station. Re-pairingMore Connect Connect OKBack Connect to a Switch Adjust the controller to Switch mode, click on the controllers icon on the home page of your Nintendo Switch, and go to [Change Grip/Order]. The controller will automatically pair and connect. Connect to an Android/iOS device 1. Scan the QR code to download and install the Flydigi Game Center app. 2. Enter Flydigi Game Center - Peripheral Management and click on "Add Device". Follow the instructions provided in the game hall to connect the controller. A B B A X Y Y X SELECT - START + Home Screenshot Switch At Switch mode, the button-to-key mapping is as follows Specifications Platform PC Switch Android iOS Dongle/Cable/BT Switch Flashplay/Native Native Mode Win 10 and above Switch Android 10 and above iOS 14 and above System Requirement Wireless RF: NearLink, BT 5.0 Operating Distance: Less than 10 meters Battery Information: Rechargeable lithium-ion battery, battery capacity 1500mAh, charging time 3-4 hours, charging voltage 5V, charging current 1000mA Operating Current: Current less than 100mA during use (default light, excluding motors and force feedback triggers), current less than 0.1mA in standby mode Temperature Range: Use and store between -10°C and 50°C. Native Mode: This mode is suitable for games that natively support controllers. Flashplay mode: This mode is suitable for mobile games that do not support controllers. It requires the use of the Flydigi Game Hall app as a companion. Appearance Fn Button Logo Button Adjustable RGB Lighting Turbo Button Charging Contacts Detachable D-pad FORCEFLEX Alloy Joystick Detachable Top Cover Force adjustment paddle Full-color Interactive Screen Power SwitchRear Buttons Rear Button Slot FORCEADAPT Triggers Concealed Holder Slot Adjustable RGB Lighting Replaceable Light Panels L3 LMRM R3 Usage of Turbo button Functions Enable/Disable button rapid fire *Turbo button function is off by default and can be enabled in Flydigi Space Station + button to be set Key Combinations Hotkeys Functions Wake up the controller Enter the screen menu Press the button Press and hold the button for 1 second Re-pair the donglePress and hold + for 3 seconds Key Combinations Switch controller's preset + A/B/X/Y（corresponding to preset 1/2/3/4) Restore factory settingsPress and hold + + for 3 seconds *The Preset Switching function is off by default and can be enabled in Flydigi Space Station FAQ Q: The controller BT cannot connect? A: In the screen menu - Connect, click Re-pairing. The controller will display "Pairing" at this time. Open the device's BT settings and reconnect. Q: Dongle connection signal is unstable. (delay/disconnect etc) A: If there are many 2.4GHz signals in the vicinity, it may cause interference. It is recommended to use a USB extension cable between the dongle and the computer to enhance the signal. Q: Are the trigger/joystick data abnormal? A: You can contact official customer service to get the controller calibration method. The name and content of harmful substances in the product This form has been prepared in accordance with the provisions of SJ/T 11364 Indicates that the content of the hazardous substance in all homogeneous materials of this part is within the limit specified in GB/T 26572-2011 Require the following Indicates that the content of the hazardous substance in at least one homogeneous material of the component exceeds the provisions of GB/T 26572-2011 The limited requirements Part Name Toxic or Hazardous Substances and Elements PbHgCdCrPBBPBDE PCB Board Shell Packaging Wire Polymer battery Silicone Small structural parts such as metal and tape FCC Statement 1. This device complies with Part 15 of the FCC Rules. Opeeration is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including inteerference that maycause undesired operation. 2.Changes or modifications not expressly approved by the party respoonsible for compliance could void the user's authority to operate the equipment Note:This equipment has been tested and found to compbly with the limits for a class Bdigital device, pursuant to Part 15 of the FCC Rules. These linhits are designed to providereasonable protection against harmful interference in a ressidential installation This equipment generates uses and can radiate radio frequerncy energy and,if not installed and used in accordance with the instruuctions,may cause harmful interference to radio communications. However,there is rno guarantee that interference will not occur in a particular installation.if thisequipmemt does cause harmful interference to radio or television reception, whichcan be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one on more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receivver. Connect the equipment into an outlet on a circuit different fromthat to which the Consult the dealer or an experienced radio/TV technician …

Text truncated - open the document above for the full version.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-07-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AORE-K6P) [ Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-07-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AORE-K6P) [ Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-07-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2026-07-21 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR ( EUT Name: Flydigi Apex6 Pro Haptics Elite Controller /Model: Apex6 Pro /FCC ID: 2AORE-K6P) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram, Operational Description, Schematics) required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd.

External

42.23¡ã

Internal 2.4G Custom Antenna BT/BLE Antenna

RF EXPOSURE EVALUATION EUT Specification EUT Flydigi Apex6 Pro Haptics Elite Controller Model Number Apex6 Pro FCC ID 2AORE-K6P Antenna gain (Max) BR+EDR: 2.43dBi BLE: 2.43dBi 802.15.4: 2.03 dBi Operation Frequency BR+EDR: 2402-2480MHz 802.15.4: 2405-2475 MHz Rating DC 5V/1A MAX Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation BR+EDR: GFSK, π/4-DQPSK, 8DPSK 802.15.4: GFSK Max. output power BR+EDR: -3.62dBm(0.4345mW) BLE: -0.34 dBm(0.9247mW) 802.15.4: 4.33dBm(2.7102mW) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BLE: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2480 BLE 2M -0.34 0±1 1 0.499181 3 802.15.4: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2475 GFSK 4.33 4±1 5 0.994994 3 According to KDB 447498, no simultaneous SAR measurement is required. Signature: Alan He Date: 2026-7-17

深圳市深探智能科技有限公司 第 1 页 共 6 页 Test Specification 客户Customer： 项目型号Project Model： 频段Frequency Band：BT 2400-2500MHz 版本号Version Number：V1.1 天线安装尺寸图 Antenna Dimension ANT-L ANT-R 深圳市深探智能科技有限公司 第 2 页 共 6 页 一、微波暗室的测试原理图 Test Schematic 二、无源测试数据 Passive Test Data S参数图S-parameter Plot ANT-L 深圳市深探智能科技有限公司 第 3 页 共 6 页 S11参数数据 S11 Parameter Data Freq/MHz 2400 2450 2500 VSWR ANT-L 1.40 1.03 1.66 ANT-R 1.61 1.14 1.67 ANT-R 深圳市深探智能科技有限公司 第 4 页 共 6 页 Gain&Efficiency Frequency (MHz) ANT-L ANT-R Gain (dBi) Efficiency (%) Gain (dBi) Efficiency (%) 2400 1.16 43.19 2.03 44.63 2410 1.08 44.29 1.65 45.40 2420 1.15 43.79 1.19 45.17 2430 1.23 43.10 1.78 46.80 2440 1.03 44.28 1.52 46.56 2450 1.49 44.25 1.15 46.86 2460 1.72 45.79 0.89 45.97 2470 2.43 46.54 1.11 46.48 2480 2.19 46.75 0.40 45.94 2490 2.49 45.13 0.41 45.54 2500 2.23 44.53 0.91 44.97 深圳市深探智能科技有限公司 第 5 页 共 6 页 天线方向图 Antenna Radiation Pattern ANT-L 2400MHz 3D-3Dback-E1-E2-H 2450MHz 3D-3Dback-E1-E2-H 2500MHz 3D-3Dback-E1-E2-H ANT-R 2400MHz 3D-3Dback-E1-E2-H 2450MHz 3D-3Dback-E1-E2-H 深圳市深探智能科技有限公司 第 6 页 共 6 页 2500MHz 3D-3Dback-E1-E2-H 深探智能科技有限公司 20260508

Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT 2.4G 2405 Ant1 100 0 0 NVNT 2.4G 2436 Ant1 100 0 0 NVNT 2.4G 2475 Ant1 100 0 0 2 / 22 Duty Cycle NVNT 2.4G 2405MHz Ant1 Duty Cycle NVNT 2.4G 2436MHz Ant1 3 / 22 Duty Cycle NVNT 2.4G 2475MHz Ant1 4 / 22 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit Conducted(dBm) Verdict NVNT 2.4G 2405 Ant1 3.92 30 Pass NVNT 2.4G 2436 Ant1 4.29 30 Pass NVNT 2.4G 2475 Ant1 4.33 30 Pass 5 / 22 Peak Power NVNT 2.4G 2405MHz Ant1 Peak Power NVNT 2.4G 2436MHz Ant1 6 / 22 Peak Power NVNT 2.4G 2475MHz Ant1 7 / 22 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT 2.4G 2405 Ant1 0.669 0.5 Pass NVNT 2.4G 2436 Ant1 0.648 0.5 Pass NVNT 2.4G 2475 Ant1 0.6512 0.5 Pass 8 / 22 -6dB Bandwidth NVNT 2.4G 2405MHz Ant1 -6dB Bandwidth NVNT 2.4G 2436MHz Ant1 9 / 22 -6dB Bandwidth NVNT 2.4G 2475MHz Ant1 10 / 22 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT 2.4G 2405 Ant1 1.023 NVNT 2.4G 2436 Ant1 1.0178 NVNT 2.4G 2475 Ant1 1.0116 11 / 22 OBW NVNT 2.4G 2405MHz Ant1 OBW NVNT 2.4G 2436MHz Ant1 12 / 22 OBW NVNT 2.4G 2475MHz Ant1 13 / 22 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT 2.4G 2405 Ant1 -5.73 8 Pass NVNT 2.4G 2436 Ant1 -6.04 8 Pass NVNT 2.4G 2475 Ant1 -5.24 8 Pass 14 / 22 PSD NVNT 2.4G 2405MHz Ant1 PSD NVNT 2.4G 2436MHz Ant1 15 / 22 PSD NVNT 2.4G 2475MHz Ant1 16 / 22 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 2.4G 2405 Ant1 -61.98 -20 Pass NVNT 2.4G 2475 Ant1 -62.16 -20 Pass 17 / 22 Band Edge NVNT 2.4G 2405MHz Ant1 Ref Band Edge NVNT 2.4G 2405MHz Ant1 Emission 18 / 22 Band Edge NVNT 2.4G 2475MHz Ant1 Ref Band Edge NVNT 2.4G 2475MHz Ant1 Emission 19 / 22 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT 2.4G 2405 Ant1 -43.57 -20 Pass NVNT 2.4G 2436 Ant1 -43.68 -20 Pass NVNT 2.4G 2475 Ant1 -44.5 -20 Pass 20 / 22 Tx. Spurious NVNT 2.4G 2405MHz Ant1 Ref Tx. Spurious NVNT 2.4G 2405MHz Ant1 Emission 21 / 22 Tx. Spurious NVNT 2.4G 2436MHz Ant1 Ref Tx. Spurious NVNT 2.4G 2436MHz Ant1 Emission 22 / 22 Tx. Spurious NVNT 2.4G 2475MHz Ant1 Ref Tx. Spurious NVNT 2.4G 2475MHz Ant1 Emission

Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT BLE 1M 2402 Ant1 85.2 0.7 0.47 NVNT BLE 1M 2440 Ant1 85.2 0.7 0.47 NVNT BLE 1M 2480 Ant1 85 0.71 0.47 NVNT BLE 2M 2402 Ant1 43 3.67 0.93 NVNT BLE 2M 2440 Ant1 43 3.67 0.93 NVNT BLE 2M 2480 Ant1 43 3.67 0.93 2 / 32 Duty Cycle NVNT BLE 1M 2402MHz Ant1 Duty Cycle NVNT BLE 1M 2440MHz Ant1 3 / 32 Duty Cycle NVNT BLE 1M 2480MHz Ant1 Duty Cycle NVNT BLE 2M 2402MHz Ant1 4 / 32 Duty Cycle NVNT BLE 2M 2440MHz Ant1 Duty Cycle NVNT BLE 2M 2480MHz Ant1 5 / 32 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit Conducted(dBm) Verdict NVNT BLE 1M 2402 Ant1 -2.02 30 Pass NVNT BLE 1M 2440 Ant1 -1.23 30 Pass NVNT BLE 1M 2480 Ant1 -0.45 30 Pass NVNT BLE 2M 2402 Ant1 -1.97 30 Pass NVNT BLE 2M 2440 Ant1 -1.15 30 Pass NVNT BLE 2M 2480 Ant1 -0.34 30 Pass 6 / 32 Peak Power NVNT BLE 1M 2402MHz Ant1 Peak Power NVNT BLE 1M 2440MHz Ant1 7 / 32 Peak Power NVNT BLE 1M 2480MHz Ant1 Peak Power NVNT BLE 2M 2402MHz Ant1 8 / 32 Peak Power NVNT BLE 2M 2440MHz Ant1 Peak Power NVNT BLE 2M 2480MHz Ant1 9 / 32 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.6607 0.5 Pass NVNT BLE 1M 2440 Ant1 0.6543 0.5 Pass NVNT BLE 1M 2480 Ant1 0.7083 0.5 Pass NVNT BLE 2M 2402 Ant1 1.214 0.5 Pass NVNT BLE 2M 2440 Ant1 1.109 0.5 Pass NVNT BLE 2M 2480 Ant1 1.163 0.5 Pass 10 / 32 -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 11 / 32 -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2402MHz Ant1 12 / 32 -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2480MHz Ant1 13 / 32 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1M 2402 Ant1 1.0349 NVNT BLE 1M 2440 Ant1 1.0366 NVNT BLE 1M 2480 Ant1 1.0397 NVNT BLE 2M 2402 Ant1 2.0721 NVNT BLE 2M 2440 Ant1 2.0683 NVNT BLE 2M 2480 Ant1 2.0744 14 / 32 OBW NVNT BLE 1M 2402MHz Ant1 OBW NVNT BLE 1M 2440MHz Ant1 15 / 32 OBW NVNT BLE 1M 2480MHz Ant1 OBW NVNT BLE 2M 2402MHz Ant1 16 / 32 OBW NVNT BLE 2M 2440MHz Ant1 OBW NVNT BLE 2M 2480MHz Ant1 17 / 32 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -18.05 8 Pass NVNT BLE 1M 2440 Ant1 -17.22 8 Pass NVNT BLE 1M 2480 Ant1 -16.64 8 Pass NVNT BLE 2M 2402 Ant1 -21.4 8 Pass NVNT BLE 2M 2440 Ant1 -20.68 8 Pass NVNT BLE 2M 2480 Ant1 -19.82 8 Pass 18 / 32 PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 19 / 32 PSD NVNT BLE 1M 2480MHz Ant1 PSD NVNT BLE 2M 2402MHz Ant1 20 / 32 PSD NVNT BLE 2M 2440MHz Ant1 PSD NVNT BLE 2M 2480MHz Ant1 21 / 32 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -43.43 -20 Pass NVNT BLE 1M 2480 Ant1 -46.25 -20 Pass NVNT BLE 2M 2402 Ant1 -33.71 -20 Pass NVNT BLE 2M 2480 Ant1 -45.55 -20 Pass 22 / 32 Band Edge NVNT BLE 1M 2402MHz Ant1 Ref Band Edge NVNT BLE 1M 2402MHz Ant1 Emission 23 / 32 Band Edge NVNT BLE 1M 2480MHz Ant1 Ref Band Edge NVNT BLE 1M 2480MHz Ant1 Emission 24 / 32 Band Edge NVNT BLE 2M 2402MHz Ant1 Ref Band Edge NVNT BLE 2M 2402MHz Ant1 Emission 25 / 32 Band Edge NVNT BLE 2M 2480MHz Ant1 Ref Band Edge NVNT BLE 2M 2480MHz Ant1 Emission 26 / 32 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -44.23 -20 Pass NVNT BLE 1M 2440 Ant1 -41.54 -20 Pass NVNT BLE 1M 2480 Ant1 -41.73 -20 Pass NVNT BLE 2M 2402 Ant1 -44.28 -20 Pass NVNT BLE 2M 2440 Ant1 -44.71 -20 Pass NVNT BLE 2M 2480 Ant1 -44.11 -20 Pass 27 / 32 Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Emission 28 / 32 Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Emission 29 / 32 Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Emission 30 / 32 Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Emission 31 / 32 Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Emission 32 / 32 Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Emission
