2AORE-B7XFlydigi Mobile Phone Cooling Fan B7X

【B7X
English
User
Manual
】Flydigi
Mobile
Phone
Cooling
Fan
B7X
Flydigi
Mobile
Phone
Cooling
Fan
B7X
User
Manual
Mount
Magnetic
sheet
(*Skip
this
step
if
there
is
magnetic
function
to
your
phone
(iPhone
12/13/14/15
serials))
1.Clean
up
your
device
before
applying.
2.Make
sure
that
the
transparent
plastic
sheet
handle
is
facting
the
phone
charging
port.
3.Attach
magnetic
sheet
to
protective
film.
Set
it
aside
for
1
hour
before
use.
Mount
Cooling
Fan
1.First
to
use:
The
default
mode
is
the
Smart
FrequencyConversion
mode.
Notice:
5V
2A
or
higher
charger
output
is
required.
2.Power
Switch:
Click
can
control
the
cooling
fan
on
and
off
Download
Feizhi
Game
Center
Smart
Frequency
Conversion
Cooling
fan
will
auto
adjust
cooling
power
for
safe
use
of
your
phone.
It
is
recommended
to
use
a
20W
or
above
power
charger,
otherwise
the
maximum
power
cannot
be
activated
Fixed
power
Cooling
fan
will
auto
adjust
cooling
power
for
safe
use
of
your
phone.
It
is
recommended
to
use
a
20W
or
above
power
charger,
otherwise
the
maximum
power
can
not
be
activated
Q&A
Q1:
Is
it
necessary
to
pair
with
a
charger
without
power
of
27W
and
above?
A1:
In
order
to
active
maximum
power,
we
recommend
to
pair
with.
Q2:
Why
does
the
Cooling
fan
suddenly
stop
working?
A2:
When
the
temperature
of
the
product
is
too
high,
the
automatic
protection
mechanism
will
be
triggered,
which
will
automatically
stop
working.
Please
put
it
in
a
cool
place
and
make
sure
before
restarting.
Q3:Does
B7X
have
battery
inside?
Flydigi
Mobile
Cooling
Fan
B7X
doesn't
have
battery
inside
does
not
support
battery
charging
Notes
1.Please
make
sure
you
read
through
all
safety
information
betfore
using
device.
2.Do
not
insert
fingers
or
foreign
objects
into
or
block
the
air
inlet
to
avoid
damage
or
overheating
of
the
product.Please
do
not
block
the
air
inlet
to
avoid
damage
or
overheating
of
the
device
3.Warning:
This
device
contains
magnets
that
may
interfer
with
functioning
of
implantable
medical
devices
or
personal
medical
devices,
such
as
pacemakers,
cochlear
iimplants,
hearing
aids,
etc.
It
is
suggested
that
a
distance
of
15cm
or
above
be
kept
between
the
said
medical
devices
and
B7X.
FCC
Statement
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • Connect the equipment into an autlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-03-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AORE-B7X ) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-03-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: 2AORE-B7X) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

Attestation Statements (2024-1-5) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (GC: 2AORE) (Shanghai Flydigi Electronics Technology Co., Ltd. ), the undersigned, hereby authorize (Wilson Tech Service LLC) to act as our designated U.S. agent for service of process, (Shanghai Flydigi Electronics Technology Co., Ltd.) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Wilson Tech Service LLC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Shanghai Flydigi Electronics Technology Co., Ltd. Contact Name: Xiang Gao Address: Rm1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. FRN: 0027133024 Telephone No: 13537659630 Email: [email protected] Signature [Xiang Gao] U.S. Agent Information: Company Name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US FRN: 0033402033 Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] Signature [Wilson Cheung]

Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-03-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-03-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Flydigi Mobile Phone Cooling Fan B7X /Model: B7X /FCC ID: 2AORE-B7X) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram ,Operational Description,Schematics ) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.
