2AORE-FP3Flydigi Direwolf 3 Gaming Controller, Direwolf 3 Gaming Controller Mechanical Edition

Customizable FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • Connect the equipment into an autlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-09-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AORE-FP3 ) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Shanghai Flydigi Electronics Technology Co.,Ltd. 2024-09-25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: 2AORE-FP3) [Shanghai Flydigi Electronics Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Xiang Gao Quality supervisor Shanghai Flydigi Electronics Technology Co.,Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China.

Attestation Statements (2024-1-5) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (GC: 2AORE) (Shanghai Flydigi Electronics Technology Co., Ltd. ), the undersigned, hereby authorize (Wilson Tech Service LLC) to act as our designated U.S. agent for service of process, (Shanghai Flydigi Electronics Technology Co., Ltd.) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (Wilson Tech Service LLC) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Shanghai Flydigi Electronics Technology Co., Ltd. Contact Name: Xiang Gao Address: Rm1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. FRN: 0027133024 Telephone No: 13537659630 Email: [email protected] Signature [Xiang Gao] U.S. Agent Information: Company Name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US FRN: 0033402033 Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] Signature [Wilson Cheung]

External

Internal BR + EDR Antenna BLE Antenna

RF EXPOSURE EVALUATION EUT Specification EUT Flydigi Direwolf 3 Gaming Controller, Direwolf 3 Gaming Controller Mechanical Edition Model Number Direwolf 3 FCC ID 2AORE-FP3 Antenna gain (Max) 0dBi Operation Frequency 2402-2480MHz Rating 5V1A Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation BLE: GFSK BR+EDR: GFSK, π/4-DQPSK, 8DPSK Max. output power BR+EDR: 3.32dBm(2.148W) BLE: 2.96dBm(1.977mW) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BR+EDR: Transmit Frequency (MHz) Mode Measur ed Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK 1.42 1±1 2 0.491 3 2441 GFSK 2.09 2±1 3 0.623 3 2480 GFSK 2.24 2±1 3 0.628 3 2402 π/4-DQPSK 2.28 2±1 3 0.618 3 2441 π/4-DQPSK 2.89 3±1 4 0.785 3 2480 π/4-DQPSK 2.99 3±1 4 0.791 3 2402 8DPSK 2.62 3±1 4 0.779 3 2441 8DPSK 3.21 3±1 4 0.785 3 2480 8DPSK 3.32 3±1 4 0.791 3 BLE: Transmit Frequency (MHz) Mode Measured Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK（1M） 2.43 2±1 3 0.491 3 2440 GFSK（1M） 2.52 3±1 4 0.785 3 2480 GFSK（1M） 2.96 3±1 4 0.791 3 2402 GFSK（2M） 1.55 2±1 3 0.618 3 2440 GFSK（2M） 1.76 2±1 3 0.623 3 2480 GFSK（2M） 2.27 2±1 3 0.628 3 According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Shawn Wen Date: 2024-09-23

-天线性能测试规格书- DocNo. Rev. Page 1 / 13 FP3 天 线 性 能 测 试 规 格 书 -天线性能测试规格书- DocNo. Rev. Page 2 / 13 APPlications ※BluetoothHomeRF ※ISMband2.4GHzapplications 1.Dimensions 2.Specifications numberItemSpecifications 1WorkingCentralFrequency2441MHz 2BandWidth(2402-2480)MHz 3Gain0dBi 4VSWR≤2.0 5AntennatypePCB antenna -天线性能测试规格书- DocNo. Rev. Page 3 / 13 6AzimuthBeamwidthOmni‐directional 7Impedance50欧姆 8ModulationmodeGFSK 3.仪器测试、软件仿真参数 ①VSWR Mkr1:2397MHz1.47Mkr2:2450MHz1.51Mkr3:2482MHz1.59 ②SmithChar Mkr1:2397MHz73.4Mkr2:2450MHz62.7Mkr3:2482MHz66.8 -天线性能测试规格书- DocNo. Rev. Page 4 / 13 ③ReturnLoss Mkr1:2397MHz-15Mkr2:2450MHz-18Mkr3:2482MHz-16 -天线性能测试规格书- DocNo. Rev. Page 5 / 13 ④SmithChar仿真 Mkr1:2400MHz1.234Mkr2:2500MHz1.051Mkr3:2600MHz1.322 -天线性能测试规格书- DocNo. Rev. Page 6 / 13 ⑤ReturnLoss仿真 Mkr1:2400MHz-19.59Mkr2:2450MHz-27.70Mkr3:2500MHz-31.97 Mkr4:2550MHz-21.83 -天线性能测试规格书- DocNo. Rev. Page 7 / 13 ` ⑥Phase仿真 Mkr1:2400MHz-54.89Mkr2:2500MHz-82.03Mkr3:2600MHz-102.6 -天线性能测试规格书- DocNo. Rev. Page 8 / 13 4.RadiationPattems XY-plane -天线性能测试规格书- DocNo. Rev. Page 9 / 13 XZ-plane -天线性能测试规格书- DocNo. Rev. Page 10 / 13 YZ-plane -天线性能测试规格书- DocNo. Rev. Page 11 / 13 3D辐射场型图 -天线性能测试规格书- DocNo. Rev. Page 12 / 13 -天线性能测试规格书- DocNo. Rev. Page 13 / 13

1 / 32 Appendix B Duty Cycle Condition Mode Frequency (MHz) Antenna On Time (ms) Period (ms) Duty Cycle (%) Correction Factor (dB) 1/T (kHz) Final settingFor VBW (kHz) NVNT BLE 1M 2402 Ant1 0 0 100 0 0 1 NVNT BLE 1M 2440 Ant1 0 0 100 0 0 1 NVNT BLE 1M 2480 Ant1 0 0 100 0 0 1 NVNT BLE 2M 2402 Ant1 0 0 100 0 0 1 NVNT BLE 2M 2440 Ant1 0 0 100 0 0 1 NVNT BLE 2M 2480 Ant1 0 0 100 0 0 1 2 / 32 Test Graphs Duty Cycle NVNT BLE 1M 2402MHz Ant1 Duty Cycle NVNT BLE 1M 2440MHz Ant1 3 / 32 Duty Cycle NVNT BLE 1M 2480MHz Ant1 Duty Cycle NVNT BLE 2M 2402MHz Ant1 4 / 32 Duty Cycle NVNT BLE 2M 2440MHz Ant1 Duty Cycle NVNT BLE 2M 2480MHz Ant1 5 / 32 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant1 2.43 0 2.43 30 Pass NVNT BLE 1M 2440 Ant1 2.52 0 2.52 30 Pass NVNT BLE 1M 2480 Ant1 2.96 0 2.96 30 Pass NVNT BLE 2M 2402 Ant1 1.55 0 1.55 30 Pass NVNT BLE 2M 2440 Ant1 1.76 0 1.76 30 Pass NVNT BLE 2M 2480 Ant1 2.27 0 2.27 30 Pass 6 / 32 Test Graphs Power NVNT BLE 1M 2402MHz Ant1 Power NVNT BLE 1M 2440MHz Ant1 7 / 32 Power NVNT BLE 1M 2480MHz Ant1 Power NVNT BLE 2M 2402MHz Ant1 8 / 32 Power NVNT BLE 2M 2440MHz Ant1 Power NVNT BLE 2M 2480MHz Ant1 9 / 32 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.68 0.5 Pass NVNT BLE 1M 2440 Ant1 0.66 0.5 Pass NVNT BLE 1M 2480 Ant1 0.67 0.5 Pass NVNT BLE 2M 2402 Ant1 1.35 0.5 Pass NVNT BLE 2M 2440 Ant1 1.28 0.5 Pass NVNT BLE 2M 2480 Ant1 1.39 0.5 Pass 10 / 32 Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 11 / 32 -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2402MHz Ant1 12 / 32 -6dB Bandwidth NVNT BLE 2M 2440MHz Ant1 -6dB Bandwidth NVNT BLE 2M 2480MHz Ant1 13 / 32 Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT BLE 1M 2402 Ant1 1.023 NVNT BLE 1M 2440 Ant1 1.024 NVNT BLE 1M 2480 Ant1 1.026 NVNT BLE 2M 2402 Ant1 2.029 NVNT BLE 2M 2440 Ant1 2.039 NVNT BLE 2M 2480 Ant1 2.05 14 / 32 Test Graphs OBW NVNT BLE 1M 2402MHz Ant1 OBW NVNT BLE 1M 2440MHz Ant1 15 / 32 OBW NVNT BLE 1M 2480MHz Ant1 OBW NVNT BLE 2M 2402MHz Ant1 16 / 32 OBW NVNT BLE 2M 2440MHz Ant1 OBW NVNT BLE 2M 2480MHz Ant1 17 / 32 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Duty Factor (dB) Total PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -9.13 0 -9.13 8 Pass NVNT BLE 1M 2440 Ant1 -10.12 0 -10.12 8 Pass NVNT BLE 1M 2480 Ant1 -10.07 0 -10.07 8 Pass NVNT BLE 2M 2402 Ant1 -14.03 0 -14.03 8 Pass NVNT BLE 2M 2440 Ant1 -13.59 0 -13.59 8 Pass NVNT BLE 2M 2480 Ant1 -10.55 0 -10.55 8 Pass 18 / 32 Test Graphs PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 19 / 32 PSD NVNT BLE 1M 2480MHz Ant1 PSD NVNT BLE 2M 2402MHz Ant1 20 / 32 PSD NVNT BLE 2M 2440MHz Ant1 PSD NVNT BLE 2M 2480MHz Ant1 21 / 32 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -56.65 -20 Pass NVNT BLE 1M 2480 Ant1 -57.5 -20 Pass NVNT BLE 2M 2402 Ant1 -35.87 -20 Pass NVNT BLE 2M 2480 Ant1 -56.54 -20 Pass 22 / 32 Test Graphs Band Edge NVNT BLE 1M 2402MHz Ant1 Ref Band Edge NVNT BLE 1M 2402MHz Ant1 Emission 23 / 32 Band Edge NVNT BLE 1M 2480MHz Ant1 Ref Band Edge NVNT BLE 1M 2480MHz Ant1 Emission 24 / 32 Band Edge NVNT BLE 2M 2402MHz Ant1 Ref Band Edge NVNT BLE 2M 2402MHz Ant1 Emission 25 / 32 Band Edge NVNT BLE 2M 2480MHz Ant1 Ref Band Edge NVNT BLE 2M 2480MHz Ant1 Emission 26 / 32 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -45.21 -20 Pass NVNT BLE 1M 2440 Ant1 -44.79 -20 Pass NVNT BLE 1M 2480 Ant1 -46.89 -20 Pass NVNT BLE 2M 2402 Ant1 -46.53 -20 Pass NVNT BLE 2M 2440 Ant1 -45.31 -20 Pass NVNT BLE 2M 2480 Ant1 -46.64 -20 Pass 27 / 32 Test Graphs Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2402MHz Ant1 Emission 28 / 32 Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2440MHz Ant1 Emission 29 / 32 Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 1M 2480MHz Ant1 Emission 30 / 32 Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2402MHz Ant1 Emission 31 / 32 Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2440MHz Ant1 Emission 32 / 32 Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Ref Tx. Spurious NVNT BLE 2M 2480MHz Ant1 Emission

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-08-25 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For Flydigi Direwolf 3 Gaming Controller, Direwolf 3 Gaming Controller Mechanical Edition MODEL NUMBER: Direwolf 3 REPORT NUMBER: E04A24080983F00302 ISSUE DATE: September 21, 2024 FCC ID: 2AORE-FP3 Prepared for Shanghai Flydigi Electronics Technology Co., Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report shall not be reproduced, except in full, without the written approval of Guangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A24080983F00302 Page 2 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 September 21, 2024 Initial Issue REPORT NO.: E04A24080983F00302 Page 3 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. Summary of Test Results Test Item Clause Limit/Requirement Result Antenna Requirement N/A FCC Part 15.203/15.247 (c) Pass AC Power Line Conducted Emission ANSI C63.10-2013, Clause 6.2 FCC Part 15.207 Pass Conducted Output Power ANSI C63.10-2013, Clause 11.9.1.3 FCC Part 15.247 (b)(3) Pass 6dB Bandwidth ANSI C63.10-2013, Clause 11.8.1 FCC Part 15.247 (a)(2) Pass Power Spectral Density ANSI C63.10-2013, Clause 11.10.2 FCC Part 15.247 (e) Pass Conducted Band edge and spurious emission ANSI C63.10-2013, Clause 11.11 FCC Part 15.247(d) Pass Radiated Band edge and Spurious Emission ANSI C63.10-2013, Clause 11.11 & Clause 11.12 FCC Part 15.247 (d) FCC Part 15.205/15.209 Pass Duty Cycle ANSI C63.10-2013, Clause 11.6 None; for reporting purposes only. Pass *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A24080983F00302 Page 4 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. CHANNEL LIST ........................................................................................................ 8 5.3. Maximum Conducted Output Power .......................................................................... 9 5.4. TEST CHANNEL CONFIGURATION ........................................................................ 9 5.5. THE WORSE CASE POWER SETTING PARAMETER ............................................ 9 5.6. DESCRIPTION OF AVAILABLE ANTENNAS ........................................................... 9 5.7. SUPPORT UNITS FOR SYSTEM TEST ................................................................. 10 5.8. SETUP DIAGRAM .................................................................................................. 10 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 11 7. ANTENNA PORT TEST RESULTS ..................................................................................... 13 7.1. Conducted Output Power ........................................................................................ 13 7.2. 6dB Bandwidth and 99% Occupied Bandwidth ....................................................... 14 7.3. Power Spectral Density ........................................................................................... 16 7.4. Conducted Band edge and spurious emission ........................................................ 17 7.5. Duty Cycle .............................................................................................................. 19 8. RADIATED TEST RESULTS ............................................................................................... 20 9. ANTENNA REQUIREMENT ................................................................................................ 37 10. AC POWER LINE CONDUCTED EMISSION ......................................................... 38 11. TEST DATA ............................................................................................................ 41 APPENDIX: PHOTOGRAPHS OF TEST CONFIGURATION ..................................................... 42 APPENDIX: PHOTOGRAPHS OF THE EUT .............................................................................. 43 REPORT NO.: E04A24080983F00302 Page 5 of 43 TRF No.: 04-E001-0B Global Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Shanghai Flydigi Electronics Technology Co.,Ltd. Address: Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China. Manufacturer Information Company Name: SHENZHEN KING CHUANG TECH & ELECTRONIC CO.,LTD Address: 58 Guangtian Road, Luotian Neighbour, Yanluo Street, Baoan District, Shenzhen, China (Postal Code 518127) EUT Information Product Description: Flydigi Direwolf 3 Gaming Controller, Direwolf 3 Gaming Controller …
