2AORE-X1True Wireless Earphones

X1 X1 Q： Why only one side have sound or have two same earbuds in Bluetooth list A： Please reset the earbuds by holding the pair button on the case for 15S till the Red flash, Keep holding it untill red and blue flash. The reset is complete. Q:仅单耳出声或蓝牙搜索出两个相同设备名 A：TWS左右耳配对，长按对码键15s至红灯闪烁； 20s后红蓝灯交替闪后即可配对设备 Q:僅單耳出聲或藍牙搜索出兩個相同設備名 A：TWS左右耳配對，長按對碼鍵15s至紅燈閃爍； 20s後紅藍燈交替閃後即可配對設備 Q : 한쪽 이어폰만 소리가 나거나 Bluetooth가 두 개의 동일한 장치를 검색합니다 A : 리셋을 위하여 빨간색 표시등이 깜박일 때까지 페어링 버튼을 15초 동안 길게 누릅니다. 빨간색과 파란색 표시등이 번갈아 깜박일 때까지 누르면 리셋이 완료됩니다 “FLYDIGI Cyberfox X1” New Generation Flydigi Foxspeed™ Low Latency Technology. Real Latency-Insensitive Wireless Sound Experience 第三代飞智Foxspeed™低延迟技术， 真·有线级无感延迟体验 第三代飛智Foxspeed™低延遲技術， 真·有線級無感延遲體驗 새로운 세대의 Flydigi Foxspeed™저지연 기술. 실제 유선 수준의 지연 없는 사운드 제공 连接其他设备 打开耳机盒，长按对码键3s直到指示灯红蓝交 替闪烁，前往“蓝牙”设置并选取“FLYDIGI Cyberfox X1”。 連線其他裝置 打開耳機盒,長按對碼鍵3s直到指示燈紅藍交 替閃爍,前往“藍牙”設定並選取“FLYDIGI Cyberfox X1”。 Connection to Other Devices Open earphone case and long press “connect button” for 3 seconds until you see an alternation of blue and red blinks. Then go to bluetooth setting-Blue- tooth-Choose "FLYDIGI Cyberfox X1" X1 X1 X1 X1 기타 기기 연결 이어폰 박스를 열고 코드 키를 3초 동안 누르면 표시등이 빨간색과 파란색으로 번갈아 깜박입니다. 풀린 후 "블루투스"설정으로 이동하여"FLYDIGI Cyberfox X1"을 선택하십시오. X1 X1 X1 Download Flydigi Game Center 下载飞智游戏厅APP Subscribe To Our WeChat 关注飞智微信公众号 FAQ This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequence energy and, if not installed and used in accordance with the instructions,may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.if this equipmemt does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an autlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The devicecan be used in portable exposure condition without restrictio

SCS-F019:ConfidentialityRequestLetterPage 1 of 3 Rev7.0 775MontagueExpressway Milpitas,CA95035 Tel:408-526-1188 Fax:408-526-1088 Email:[email protected] Website:https://www.cps.bureauveritas.com/ Confidentiality RequestLetter ReasonforAmendment(current/obsolete) RevisionHistory ApprovedDate FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 AddingCFR2.459(obsolete)1.02.0August–11-2008 Updatedcompanytemplate&Addedtext box(obsolete) 2.03.0Jan-31-2012 AddedICconfidentialityletterform (obsolete) 3.04.0March-26-2015 CorrectionstoSTCform.Addedreference toKDB(obsolete) 4.05.0Nov-19-2015 Updatedcompanylogo(current)5.06.0Jun-26-2019 UpdatedReferencesandContactInfo6.07.0Aug-30-2020 SCS-F019:ConfidentialityRequestLetterPage 2 of 3 Rev7.0 ShanghaiFlydigiElectronicsTechnologyCo.,Ltd. (2021-05-25) To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046-1609 Cc: BureauVeritasConsumerProductsServicesInc. 775MontagueExpressway Milpitas,CA95035 Subject:ConfidentialityRequestforFCCID:2AORE-X1 PursuanttoCFR47sections0.457and0.459,werespectfullyrequestpermanentconfidentialtreatmentofthe followingExhibitsaccompanyingthisapplicationbeheldconfidential: TypeofConfidentialityRequestedExhibit ShortTermPermanentBlockDiagram ShortTermExternalPhotos ShortTermPermanent i InternalPhotos ShortTermPermanentOperationalDescription/TheoryofOperation ShortTermPermanentPartsList ShortTermPermanentTune-UpProcedure ShortTermPermanentSchematics ShortTermTestSetupPhotos ShortTermPermanent i User’sManual Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. PermanentConfidentiality: Theapplicantrequeststheexhibitslistedaboveaspermanentlyconfidentialbepermanentlywithheldfrom publicreviewduetomaterialsthatcontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic. Short-TermConfidentiality: Toavoidprematurereleaseofsensitiveinformationpriortomarketingorreleaseoftheproducttothepublic,the applicantrequeststhefollowingdocumentscontainedinthiscertificationapplicationbetemporarilywithheld frompublicdisclosureforaninitialperiodof45or180days;orforaspecifieddateofnottoexceed 180daysfromtheGrantDate Theapplicantunderstandsthatdisclosureofthisapplicationandallaccompanyingdocumentationwillnotbe madebeforethedateoftheGrantforthisapplication. Sincerely, SCS-F019:ConfidentialityRequestLetterPage 3 of 3 Rev7.0 ShuiqingHuang InternationalTradeManger ShanghaiFlydigiElectronicsTechnologyCo.,Ltd. Rm1108,No.258GuoxiaRd,YangpuDistrict,Shanghai,China i PermanentconfidentialitymayberequestedinaccordancewithFCCKDB726920

型号：FLYDIGI Cyberfox X1 额定容量：500mAh 1.85Wh 输入：5V=2A 输出：5A=0.16A 中国制造 CMIIT ID：2020DP5376 FCC ID：2AORE-X1 上海飞智电子科技有限公司 2.4mm 6.6mm 2.1mm 9.0mm Label location

ANT

RFEXPOSUREEVALUATION EUTSpecification EUTTrueWirelessEarphones ModelNumberFLYDIGICyberfoxX1 FCCID2AORE-X1 Antennagain(Max)0dBi OperationFrequencyBR+EDR:2402-2480MHz BLE:2402-2480MHz InputRatingDC3.7VBattery ClassificationPer StipulatedTestStandard §15.247(i),§2.1093 ModulationGFSK Max.outputpowerBR+EDR:1.39dBm(0.0014W) BLE:-2.46dBm(0.0006W) TestRequirement: Accordingto§15.247(i)and§1.1307(b)(1),systemsoperatingunderthe provisionsofthissectionshallbeoperatedinamannerthatensuresthatthe publicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis 5mm. BR+EDRDSS: BLEDTS: AccordingtoKDB447498,nostand-alonerequiredforBTantenna,andno simultaneousSARmeasurementisrequired. Transmit Frequency (MHz) Mode Measured Power (dBm) Tuneup Power (dBm) Maxtuneup power(dBm) Calculation Result 1-g SAR 2402GFSK-4.69-5±1-40.1233983 2440GFSK-2.73-3±1-20.1971713 2480GFSK-1.21 -1 ± 1 00.3149603 2402 π/4-DQ PSK -2.36 -2 ± 1 -10.2462073 2440 π/4-DQ PSK -0.41 0±110.3933743 2480 π/4-DQ PSK 1.37 1±120.4991813 24028DPSK-2.39-2±1-10.2462073 24408DPSK-0.380±110.3933743 24808DPSK1.39 1 ± 1 20.4991813 ransmit Frequency (MHz) Mode Measured Power (dBm) Tuneup Power (dBm) Maxtuneup power(dBm) Calculation Result 1-g SAR 2402GFSK-4.18-4±1-30.1553563 2440GFSK-3.57-3±1-20.1971713 2480GFSK-2.46-2±1-10.2501733 Signature: AlanHe Date:2021-05-25

Report No.: EA21040504F01001 1 of 80 TRF No. FCC Part 15.247/A Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF True Wireless Earphones Model No.: FLYDIGI Cyberfox X1 Trademark: Flydigi FCC ID: 2AORE-X1 Report No.: EA21040504F01001 Issue Date: May 26, 2021 Prepared for Shanghai Flydigi Electronics Technology Co., Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China Prepared by Dong Guan Anci Electronic Technology Co., Ltd. 1-2 Floor, Building A, No.11, Headquarters 2 Road, Songshan, Lake Hi-tech Industrial Development Zone, Dongguan City, evelopment Zone, Dongguan City, Guangdong Pr., China. This report shall not be reproduced, except in full, without the written approval of Dong Guan Anci Electronic Technology Co., Ltd. Report No.: EA21040504F01001 2 of 80 TRF No.: FCC 15.209/A Rev. 1.0 VERIFICATION OF COMPLIANCE Applicant: Shanghai Flydigi Electronics Technology Co., Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China Manufacturer: Shanghai Flydigi Electronics Technology Co., Ltd. Rm 1108, No.258 Guoxia Rd, Yangpu District, Shanghai, China Product Description: True Wireless Earphones Trade Mark: Flydigi Model Number: FLYDIGI Cyberfox X1 We hereby certify that: The above equipment was tested by Dong Guan Anci Electronic Technology Co., Ltd.The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2020). Date of Test : May 19, 2021 to May 25, 2021 Prepared by : Tomas Yang/Supervisor Reviewer & Authorized Signer : Alan He/Manager Report No.: EA21040504F01001 3 of 80 TRF No.: FCC 15.209/A Rev. 1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / EA21040504F01001 Report No.: EA21040504F01001 4 of 80 TRF No.: FCC 15.209/A Rev. 1.0 Table of Contents 1. GENERAL INFORMATION ......................................................................................................... 6 1.1 PRODUCT DESCRIPTION ............................................................................................................................. 6 1.2 TEST METHODOLOGY ................................................................................................................................. 6 1.3 TEST FACILITY ............................................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION............................................................................................... 8 2.1EUT CONFIGURATION ................................................................................................................................. 8 2.2 EUT EXERCISE..................................................................................................................................... 8 2.3 TEST PROCEDURE..................................................................................................................................... 8 2.4CONFIGURATION OF TESTED SYSTEM ........................................................................................................ 9 3. SUMMARY OF TEST RESULTS ................................................................................................. 10 4. DESCRIPTION OF TEST MODES .............................................................................................. 11 5. TEST SYSTEM UNCERTAINTY .................................................................................................. 12 6. CONDUCTED EMISSIONS TEST ............................................................................................... 13 6.1MEASUREMENT PROCEDURE: ................................................................................................................... 13 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ......................................................................... 13 6.3MEASUREMENT EQUIPMENT USED: .......................................................................................................... 13 6.4 MEASUREMENT RESULT: .......................................................................................................................... 14 7. RADIATED EMISSION TEST ....................................................................................................... 15 7.1MEASUREMENT PROCEDURE .................................................................................................................... 15 7.2TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .......................................................................... 17 7.3 MEASUREMENT EQUIPMENT USED: ......................................................................................................... 18 7.4 RADIATED EMISSION LIMIT ....................................................................................................................... 19 7.5 MEASUREMENT RESULT ......................................................................................................................... 20 7.5 RADIATED MEASUREMENT PHOTOS: ....................................................................................................... 28 8. CHANNEL SEPARATION TEST ................................................................................................. 29 8.1MEASUREMENT PROCEDURE .................................................................................................................... 29 8.2TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .......................................................................... 29 8.3 MEASUREMENT EQUIPMENT USED: ....................................................................................................…
