2AP2N-MAGHOLDC02Magnet Wireless Charging Car Mount

Wireless Magnetic Vehicle Charger Manual Model: Maghold C02 Note:For best performance and safety, please read this manual carefully before using the product. Magnet Circle Nut Air Vent Clamp Wireless Charging Area LED Indicator 1. Connect the Air Vent Clamp to the Devices; .Unscrew the nut .Place the nut around ball head,insert into socket .Tighten nut clockwise 2.Attach clamp to the car vent Press the button to unlock the air vent clamp; entry and release to grip the air vent 3.Connect power to the charger Use the USB-C to C cable packed in the box to connect the device and the car charger. Tips:When using this product, please make sure that the product is connected to the power.To achieve fast charging,QC2.0/3.0 car charger is required. 4.Charging your iPhone Please fit the product with the back of your iPhone, it will charge your iPhone automatically via the built-in magnetic wireless charger,Max Output to be 15W. Note: Under normal charging conditions, the charger and mobile phone could be slightly hot; the temperature may rise if the mobile phone is working while charging (such as playing video). Please stop charging your phone when the charger is over-heating. Our product will automatically stop charging when over-heating. Please try it again when it’s cooling down 5. Indicators Status Standby:White Light On WirelessCharging:White Light Breathing Fully Charged:White Light Breathing FOD: Red & White Blinks Overtemp.Protection: Red Light Blinks Over Voltage Protection:Red Light Blinks Short Circuit Protection:Red Light Blinks Over Current Protection:Red Light Blinks Precautions Please carefully handle your charger and accessories,the following recommendations will help you effectively use the warranty service. Please keep the equipment dry.Rain,moisture and various liquidmay contain minerals that will corrode the circuit. If the equipment is wet, please dry the product as soon aspossible oruse a soft clothto wipe it clean.losing the data stored due to emagnetization. When charging,please select the regular 5V/2A,9V/2A chargers.Do not use any damaged chargers. Please do not attempt to charge the equipment with exposed or case broken,and do not charge the equipment that are incompatible with this product. Do not storethe equipment in a cold place. Otherwise, if temperature rises to normal temperature, moisture will pent up inside it and damage the electric appliance. Do not attempt to open the equipment, unauthorized dis-assembly or modification will damage equipment or related wireless charging functions. Donot throw, apor shake the equipment; rough handling of the equipment will damage the internal circuit board and the mechanical structure. Use the clean and moist soft cloth to clean the surface of the equipment.Donot use or store the equipment in dusty or dirty places. Some components of this product are magnetic and metal materials may be adsorbed onto this product.Please donot use bank cards,credit cards or any other items with magnetic near the product so as to avoid losing the data stored due to demagnetization. Fits Below Supports(NotIncluded) Ball Diameter:16.8±0.3mm Specifications: Input:5V 2A, 9V 2A, 12V 2A Wireless Output:5W, 7.5W,10W,15W Cable Length: 1M USB C TO C CABLE Dimension:60*2.5mm Wha’s Inthebox: Charger X 1 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.

July 15, 2022 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu , (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Esorun Technology Co., LTD. Address: Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen, China (applicant name and address). Date: July 15, 2022 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen, China Tel 0086-0755-23696752 Fax / Email [email protected]

July 15, 2022 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N-MAGHOLDC02 Product Name: Magnet Wireless Charging Car Mount Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date: July 15, 2022 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen, China Tel 0086-0755-23696752 Fax / Email [email protected]

FCC ID: 2AP2N-MAGHOLDC02

3.5cm*0.5 cm Label Location FCC ID: 2AP2N-MAGHOLDC02

FCC ID: 2AP2N-MAGHOLDC02 ANT

FCC TEST REPORT FCC ID: 2AP2N-MAGHOLDC02 On Behalf of Shenzhen Esorun Technology Co., LTD Magnet Wireless Charging Car Mount Model No.: Maghold C02 Prepared for : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2205162-C01-R07 Date of Receipt : May 26, 2022 Date of Test : May 27, 2022-June 9, 2022 Date of Report : June 9, 2022 Version Number : V0 Page 2 of 14 Report No.: A2205162-C01-R07 TABLE OF CONTENTS 1. Test Result Summary ................................................................................................................................ 5 2. EUT Description ......................................................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup ................................................................................................................................ 13 Page 3 of 14 Report No.: A2205162-C01-R07 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : Magnet Wireless Charging Car Mount (A) Model No. : Maghold C02 (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: June 9, 2022 Page 4 of 14 Report No.: A2205162-C01-R07 Revision History Revision Issue Date Revisions Revised By V0 June 9, 2022 Initial released Issue Lucas Pang Page 5 of 14 Report No.: A2205162-C01-R07 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 5. Decision rules for the conclusion of this test report: decision by actual test data without considering measurement uncertainty. Page 6 of 14 Report No.: A2205162-C01-R07 2. EUT Description 2.1. Description of Device (EUT) EUT Name : Magnet Wireless Charging Car Mount Model No. : Maghold C02 DIFF. : N/A Trademark : ESORUN Power supply : Input : 5V⎓2A, 9V⎓2A, 12V⎓2A Wireless output : 5W, 7.5W, 10W, 15W Operation frequency : 115~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.0 Page 7 of 14 Report No.: A2205162-C01-R07 Conditions requirement Answers Power transfer frequency is less than 1MHz. After measuring the product the transfer frequency is 115-205KHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 15 watts The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system includes only single primary. Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter. Mobile exposure conditi…
