2AP2N-SUPERWireless Charger

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.

Shenzhen Esorun Technology Co., LTD Covered Equipment Certification Attestation Letter 2/13/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AP2N-SUPER Shenzhen Esorun Technology Co., LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Shenzhen Esorun Technology Co., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Zhang Yi Title: Deputy General Manager Company Name: Shenzhen Esorun Technology Co., LTD Date: 2/13/2023

* the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. JOC Australia Inc U.S. Agent Designation for Service of Process - Certification Attestation Letter 2/14/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AP2N-SUPER Per section 2.911(d)(7) of the FCC rules,Shenzhen Esorun Technology Co., LTD(“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 18351 Colima Road Ste 585 Rowland Heights,California, 91748 United States of America Agent name: William.Jones Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Printed name: Zhang Yi Title: Deputy General Manager Company Name: Shenzhen Esorun Technology Co., LTD Date: 2/14/2023 Signed: Printed name: Benjamin Smith Title: Vice President Company Name: JOC Australia Inc Date: 2/14/2023

Differences Description We Shenzhen Esorun Technology Co., LTD state: FCC ID: 2AP2N-SUPER Product name: Wireless Charger Model: Super P, Super Z All model’s the function, software and electric circuit are the same, only to different guest with the appearance, shape and model name. Signature: Date: 2023.01.09 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

January 9, 2023 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Esorun Technology Co., LTD. Address: Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen (applicant name and address). Date: 2023.01.09 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

January 9, 2023 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N-SUPER Product Name: Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date: 2023.01.09 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

FCC ID: 2AP2N-SUPER Super P Super Z

3.0cm*1.0 cm Label Location FCC ID: 2AP2N-SUPER

FCC ID: 2AP2N-SUPER ANT

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-SUPER On Behalf of Shenzhen Esorun Technology Co., LTD Wireless Charger Model No.: Super P, Super Z Prepared for : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2212151-C01-R06 Date of Receipt : December 20, 2022 Date of Test : December 20, 2022-January 3, 2023 Date of Report : January 4, 2023 Version Number : V0 Page 2 of 14 Report No.: A2212151-C01-R06 TABLE OF CONTENTS Description Page 1. Test Result Summary ................................................................................................................................ 5 2. EUT Description ......................................................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup ................................................................................................................................ 13 Page 3 of 14 Report No.: A2212151-C01-R06 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : Wireless Charger (A) Model No. : Super P, Super Z (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue................................: January 4, 2023 Page 4 of 14 Report No.: A2212151-C01-R06 Revision History Revision Issue Date Revisions Revised By V0 January 4, 2023 Initial released Issue Lucas Pang Page 5 of 14 Report No.: A2212151-C01-R06 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 5. Decision rules for the conclusion of this test report: decision by actual test data without considering measurement uncertainty. Page 6 of 14 Report No.: A2212151-C01-R06 2. EUT Description 2.1. Description of Device (EUT) EUT Name : Wireless Charger Model No. : Super P, Super Z DIFF. : There is no difference between the models except the appearance color. So all the test were performed on the model Super P. Trademark : ESORUN Power supply : Input: 5V⎓2A, 9V⎓2.22A Wireless Output: 5W, 7.5W, 10W, 15W Radio Technology : Wireless power transmission systems Operation frequency : 115-205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.1 Page 7 of 14 Report No.: A2212151-C01-R06 Conditions requirement Answers Power transfer frequency is less than 1MHz. After measuring the product the transfer frequency is 115-205KHz Output power from each primary coil is less than or equal to 15 watts.…

Text truncated - open the document above for the full version.

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-SUPER On Behalf of Shenzhen Esorun Technology Co., LTD Wireless Charger Model No.: Super P, Super Z Prepared for : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2212151-C01-R05 Date of Receipt : December 20, 2022 Date of Test : December 20, 2022-January 3, 2023 Date of Report : January 4, 2023 Version Number : V0 Page 2 of 32 Report No.: A2212151-C01-R05 TABLE OF CONTENTS Description Page 1. Test Result Summary ................................................................................................................................ 5 2. General Information ................................................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 7 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 7 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 7 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 7 2.6. TEST CONDITIONS ................................................................................................................................. 7 2.7. TEST FACILITY ...................................................................................................................................... 8 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 8 2.9. TEST EQUIPMENT LIST ........................................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. CONDUCTED EMISSION ........................................................................................................................ 10 3.2. RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................... 14 3.3. TEST SPECIFICATION ........................................................................................................................... 23 4. Photos of test setup ................................................................................................................................ 25 5. Photographs of EUT ................................................................................................................................ 27 Page 3 of 32 Report No.: A2212151-C01-R05 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : Wireless Charger (A) Model No. : Super P, Super Z (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...................................: January 4, 2023 Page 4 of 32 Report No.: A2212151-C01-R05 Revision History Revision Issue Date Revisions Revised By V0 January 4, 2023 Initial released Issue Lucas Pang Page 5 of 32 Report No.: A2212151-C01-R05 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 5. Decision rules for the conclusion of this test report: decision by actual test data without considering measurement uncertainty. Page 6 of 32 Report No.: A2212151-C01-R05 2. General Information 2.1. Description of Device (EUT) EUT Name : Wireless Charger Model No. : Super P, Super Z DIFF. : There is no difference between the models except the appearance color. So all the …

Text truncated - open the document above for the full version.

Fine Page 1 of 3 承 認 書 SPECIFICATION FOR APPROVAL 客 戶： CUSTOMER: 深圳市一讯达科技有限公司 客 戶 料 號： CUST P/N: 10-0110-0522 松 岛 料 號： FINE P/N: G511-6.3UH 单线圈0.08*105P*10TS 産 品 型 號： DESC: Φ50MMX5.0MMX1.0MM开槽 日 期： DATE: 2020/04/10 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 黄燕铭 黄燕铭 黄锦华 深圳市松岛科技有限公司 工廠地址：深圳市光明新区红星村第四工业区9栋7楼 TEL：0755-36820766 FAX：0755-84526500 E-mail：[email protected] Fine Page 2 of 3 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2018/04/24 黄锦华 Fine Page 3 of 3 SPECIFICATION 産 品 型 號： DESC Φ20.5x43-6.3uH-0.08x105-5mm/15mm 版本 Rev：A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 50±1 B 43±1 C 20.5±1 D 15+2 E 5+2 F 3±2 注： 1.交叉出线; 2.出线位置缠8mm(ref)宽度高 温胶纸1-2Ts; 3.线圈贴圆形硬磁片带槽，磁 片尺寸50±1mm,内孔5.3mm, 厚度为1.0±0.2mm。 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 丝包线0.08*105P 10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8uH ±20%单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.3uH ±10%加磁片 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤45mΩ 100KHz/1.0V LCZ METER 502B 4 Q值 S-F ≥75mΩ 100KHz/1.0V LCZ METER 502B 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 黄燕铭2020/04/10 黄锦华2020/04/10

FCC ID: 2AP2N-SUPER Radiated Emission Conducted Emission
