2AP2N-MAGQOOMagnetic Wireless Charger

FCC Statement : This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.Caution: Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.The device has been evaluated to meet general RF exposure requirement.The distance between user and products should be no less than 20cm.

January 21, 2021 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N–MAGQOO Product Name: Magnetic Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co.,LTD Address 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen,China Tel 0086-0755-23696752 Fax / Email [email protected]

FCC ID: 2AP2N–MAGQOO

4.5cm 2.5cm Label Location FCC ID: 2AP2N–MAGQOO Shenzhen Esorun Technology Co.,LTD Product name: Magnetic Wireless Charger Model No.: MagQoo This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AP2N–MAGQOO ANT

FCC TEST REPORT FCC ID: 2AP2N–MAGQOO On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo Prepared for : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2012157-C01-R04 Date of Receipt : December 22, 2020 Date of Test : December 22, 2020–January 20, 2021 Date of Report : January 20, 2021 Version Number : V0 Page 2 of 15 Report No.: A2012157-C01-R04 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. EUT Description ....................................................................................... 6 2.1. Description of Device (EUT) ............................................................................................................. 6 2.2. Accessories of Device (EUT) ........................................................................................................... 8 2.3. Tested Supporting System Details .................................................................................................. 8 2.4. Block Diagram of Connection between EUT and Simulators ....................................................... 8 2.5. Description of Test Modes ............................................................................................................... 8 2.6. Test Conditions ................................................................................................................................. 8 2.7. Test Facility ........................................................................................................................................ 9 2.8. Measurement Uncertainty ................................................................................................................ 9 3. Test Results and Measurement Data ................................................... 10 3.1. RF Exposure Test ............................................................................................................................ 10 4. Photos of test setup .............................................................................. 13 5. Photographs of EUT .............................................................................. 15 Page 3 of 15 Report No.: A2012157-C01-R04 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Manufacturer : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: January 20, 2021 Page 4 of 15 Report No.: A2012157-C01-R04 Revision History Revision Issue Date Revisions Revised By V0 January 20, 2021 Initial released Issue Lucas Pang Page 5 of 15 Report No.: A2012157-C01-R04 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 15 Report No.: A2012157-C01-R04 2. EUT Description 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo DIFF. : N/A Trademark : ESORUN Power supply : Input : 5V ⎓2A, 9V ⎓2A, 12V ⎓2A Wireless Output : 5V ⎓1A(5W), 9V ⎓0.83A(7.5W), 9V ⎓1.12A(10W), 9V ⎓1.67A(15W) Operation frequency : 112~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi (This value is supplied by applicant). Software version : V3.0 Hardware version : V1.0 Intend use environment : Residential, commercial and light industrial environment Page 7 of 15 Report No.: A2012157-C01-R04 Conditions requirement Answers Power transfer frequency is less than 1 MHz. After measuring the product the transfer frequency is 0.112-0.205KHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 10 watts The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. The transfer system includes only single primary. Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter. Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only. The aggregate H-field strengths at …

Text truncated - open the document above for the full version.

FCC TEST REPORT FCC ID: 2AP2N–MAGQOO On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo Prepared for : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2012157-C01-R03 Date of Receipt : December 22, 2020 Date of Test : December 22, 2020–January 20, 2021 Date of Report : January 20, 2021 Version Number : V0 Page 2 of 30 Report No.: A2012157-C01-R03 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. General Information ................................................................................. 6 2.1. Description of Device (EUT) ............................................................................................................. 6 2.2. Accessories of Device (EUT) ........................................................................................................... 7 2.3. Tested Supporting System Details .................................................................................................. 7 2.4. Block Diagram of Connection between EUT and Simulators ....................................................... 7 2.5. Description of Test Modes ............................................................................................................... 7 2.6. Test Conditions ................................................................................................................................. 7 2.7. Test Facility ........................................................................................................................................ 8 2.8. Measurement Uncertainty ................................................................................................................ 8 2.9. Test Equipment List .......................................................................................................................... 9 3. Test Results and Measurement Data ................................................... 10 3.1. Conducted Emission ....................................................................................................................... 10 3.2. Radiated Spurious Emission Measurement ................................................................................. 13 3.3. Test Specification ............................................................................................................................ 21 4. Photos of Test Setup ............................................................................. 23 5. Photographs of EUT .............................................................................. 25 Page 3 of 30 Report No.: A2012157-C01-R03 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Manufacturer : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: January 20, 2021 Page 4 of 30 Report No.: A2012157-C01-R03 Revision History Revision Issue Date Revisions Revised By V0 January 20, 2021 Initial released Issue Lucas Pang Page 5 of 30 Report No.: A2012157-C01-R03 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 30 Report No.: A2012157-C01-R03 2. General Information 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo DIFF. : N/A Trademark : ESORUN Power supply : Input : 5V ⎓2A, 9V ⎓2A,12V ⎓2A Wireless Output : 5V ⎓1A(5W), 9V ⎓0.83A(7.5W), 9V ⎓1.12A(10W), 9V ⎓1.67A(15W) Operation frequency : 112~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi (This value is supplied by applicant). Software version : V3.0 Hardware version : V1.0 Connector cable loss : 0.5dB (This value is supplied by applicant). Intend use environment : Residential, commercial and light industrial environment Page 7 of 30 Report No.: A2012157-C01-R03 2.2. Accessories of Device (EUT) Accessories1 : / Manufacturer : / Model : / Ratings : / 2.3. Tested Supporting System Details No. Description Manufacturer Model Serial Number Certification 1 Wireless load -- -- -- -- 2 Adapter -- HNFCQ3024UU -- -- 2.4. Block Diagr…

Text truncated - open the document above for the full version.

FCC ID: 2AP2N–MAGQOO Radiated Emission Conducted Emission
