2AP2N-MAGQOO-ASMagnetic Wireless Charger

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.

January 10, 2023 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N-MAGQOO-AS Product Name: Magnetic Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date: 2023.01.09 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

January 10, 2023 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Esorun Technology Co., LTD. Address: Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen (applicant name and address). Date: 2023.01.09 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

FCC ID: 2AP2N-MAGQOO-AS

4.0cm*1.0 cm Label Location FCC ID: 2AP2N-MAGQOO-AS

FCC ID: 2AP2N-MAGQOO-AS ANT

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-MAGQOO-AS On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo AS Prepared for : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2212151-C01-R08 Date of Receipt : December 20, 2022 Date of Test : December 20, 2022-January 3, 2023 Date of Report : January 4, 2023 Version Number : V0 Page 2 of 14 Report No.: A2212151-C01-R08 TABLE OF CONTENTS Description Page 1. Test Result Summary ................................................................................................................................ 5 2. EUT Description ......................................................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup ................................................................................................................................ 13 Page 3 of 14 Report No.: A2212151-C01-R08 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo AS (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue................................: January 4, 2023 Page 4 of 14 Report No.: A2212151-C01-R08 Revision History Revision Issue Date Revisions Revised By V0 January 4, 2023 Initial released Issue Lucas Pang Page 5 of 14 Report No.: A2212151-C01-R08 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 5. Decision rules for the conclusion of this test report: decision by actual test data without considering measurement uncertainty. Page 6 of 14 Report No.: A2212151-C01-R08 2. EUT Description 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo AS DIFF. : N/A Trademark : ESORUN Power supply : Input: 5V⎓2A, 9V⎓2.22A Wireless Output: 5W, 7.5W, 10W, 15W Radio Technology : Wireless power transmission systems Operation frequency : 115-205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.0 Page 7 of 14 Report No.: A2212151-C01-R08 Conditions requirement Answers Power transfer frequency is less than 1MHz. After measuring the product the transfer frequency is 115-205KHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 15 watts The system may consist of more than one s…

Text truncated - open the document above for the full version.

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-MAGQOO-AS On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo AS Prepared for : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2212151-C01-R07 Date of Receipt : December 20, 2022 Date of Test : December 20, 2022-January 3, 2023 Date of Report : January 4, 2023 Version Number : V0 Page 2 of 32 Report No.: A2212151-C01-R07 TABLE OF CONTENTS Description Page 1. Test Result Summary ................................................................................................................................ 5 2. General Information ................................................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 7 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 7 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 7 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 7 2.6. TEST CONDITIONS ................................................................................................................................. 7 2.7. TEST FACILITY ...................................................................................................................................... 8 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 8 2.9. TEST EQUIPMENT LIST ........................................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. CONDUCTED EMISSION ........................................................................................................................ 10 3.2. RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................... 14 3.3. TEST SPECIFICATION ........................................................................................................................... 23 4. Photos of test setup ................................................................................................................................ 25 5. Photographs of EUT ................................................................................................................................ 27 Page 3 of 32 Report No.: A2212151-C01-R07 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co., LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo AS (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...................................: January 4, 2023 Page 4 of 32 Report No.: A2212151-C01-R07 Revision History Revision Issue Date Revisions Revised By V0 January 4, 2023 Initial released Issue Lucas Pang Page 5 of 32 Report No.: A2212151-C01-R07 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 5. Decision rules for the conclusion of this test report: decision by actual test data without considering measurement uncertainty. Page 6 of 32 Report No.: A2212151-C01-R07 2. General Information 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo AS DIFF. : N/A Trademark : ESORUN Power supply : Input: 5V⎓2A, 9V⎓2.22A Wireless Ou…

Text truncated - open the document above for the full version.

深圳市三盛创电子科技有限公司 承 認 書 客 戶： CUSTOMER: 深圳市一讯达电子科技有限公司 客 戶 料 號： CUST P/N: 三盛创 料 號： FINE P/N: 磁吸线圈-6.5UH 单线圈0.08*24P*10TS 産 品 型 號： DESC: Φ43.5MMX5.3MMX0.8MM开槽 日 期： DATE: 2022.03.05 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 林素玲 安帅印 安帅印 深圳市三盛创电子科技有限公司 工廠地址：深圳市光明新区玉塘街道玉泉东路9号 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2022.03.05 安帅印 SPECIFICATION 産 品 型 號： DESC Φ20.5x42-6.5uH-0.08x24P*2-15mm 版本 Rev：A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 43.5±0.5 B 42±0.5 C 20.5±0.5 D 5.3±0.5 E 3±2 S 15±2 注： 1.交叉出线; 2.出线位置缠8mm(ref)宽度高 温胶纸1-2Ts; 3.线圈贴圆形硬磁片带槽，磁 片尺寸43.5±0.5mm,内孔 5.3mm,厚度为0.8±0.1mm。 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 热风线0.08*24P 10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8uH ±10%单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.5uH ±10%加磁片 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤43mΩ 100KHz/1.0V LCZ METER 502B 4 Q S-F ≥75 100KHz/1.0V LCZ METER 502B 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 林素玲2022.03.05 安帅印2022.03.05

FCC ID: 2AP2N-MAGQOO-AS Radiated Emission Conducted Emission
