2AP2N-MAGQOOASMagnetic Wireless Charger

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The distance between user and products should be no less than 15cm.

May 10, 2021 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N-MAGQOOAS Product Name: Magnetic Wireless Charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Date: May 10, 2021 Signatory Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co., LTD Address 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Tel 0086-0755-23696752 Fax / Email [email protected]

FCC ID: 2AP2N-MAGQOOAS

2.5cm*1.0 cm Label Location FCC ID: 2AP2N-MAGQOOAS Magnetic Wireless Charger Model No.: MagQoo AS

FCC ID: 2AP2N-MAGQOOAS ANT

FCC TEST REPORT FCC ID: 2AP2N-MAGQOOAS On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo AS Prepared for : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2104124-C01-R05 Date of Receipt : April 22, 2021 Date of Test : April 23, 2021-April 29, 2021 Date of Report : April 29, 2021 Version Number : V0 Page 2 of 13 Report No.: A2104124-C01-R05 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. EUT Description ....................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup .............................................................................. 13 Page 3 of 13 Report No.: A2104124-C01-R05 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Manufacturer : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo AS (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: April 29, 2021 Page 4 of 13 Report No.: A2104124-C01-R05 Revision History Revision Issue Date Revisions Revised By V0 April 29, 2021 Initial released Issue Lucas Pang Page 5 of 13 Report No.: A2104124-C01-R05 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 13 Report No.: A2104124-C01-R05 2. EUT Description 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo AS DIFF. : N/A Trademark : ESORUN Power supply : Type-C Input : DC 5V/2A, DC 9V/2A, DC 12V/2A Wireless Output : DC 5V/1A(5W), 9V/0.83A(7.5W), 9V/1.12A(10W), 9V/1.67A(15W) Operation frequency : 125~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.0 Page 7 of 13 Report No.: A2104124-C01-R05 Conditions requirement Answers Power transfer frequency is less than 1 MHz. After measuring the product the transfer frequency is 125-205KHz Output power from each primary coil is less than or equal to 15 watts. After measuring the product the each primary coil power is 15 watts The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system includes only single primary. Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter. Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only. The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. After meas…

Text truncated - open the document above for the full version.

FCC TEST REPORT FCC ID: 2AP2N-MAGQOOAS On Behalf of Shenzhen Esorun Technology Co., LTD Magnetic Wireless Charger Model No.: MagQoo AS Prepared for : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2104124-C01-R04 Date of Receipt : April 22, 2021 Date of Test : April 23, 2021-April 29, 2021 Date of Report : April 29, 2021 Version Number : V0 Page 2 of 30 Report No.: A2104124-C01-R04 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. General Information ................................................................................. 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 7 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 7 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 7 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 7 2.6. TEST CONDITIONS ................................................................................................................................. 7 2.7. TEST FACILITY ...................................................................................................................................... 8 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 8 2.9. TEST EQUIPMENT LIST ........................................................................................................................... 9 3. Test Results and Measurement Data ................................................... 11 3.1. CONDUCTED EMISSION ........................................................................................................................ 11 3.2. RADIATED SPURIOUS EMISSION MEASUREMENT ................................................................................... 14 3.3. TEST SPECIFICATION ........................................................................................................................... 21 4. Photos of test setup .............................................................................. 23 5. Photographs of EUT .............................................................................. 25 Page 3 of 30 Report No.: A2104124-C01-R04 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China Manufacturer : Shenzhen Esorun Technology Co., LTD Address : 101, Dormitory Building, No. 1215, Guihua Community Guanguang Road, Guanlan Street, Longhua District, Shenzhen, China EUT Description : Magnetic Wireless Charger (A) Model No. : MagQoo AS (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: April 29, 2021 Page 4 of 30 Report No.: A2104124-C01-R04 Revision History Revision Issue Date Revisions Revised By V0 April 29, 2021 Initial released Issue Lucas Pang Page 5 of 30 Report No.: A2104124-C01-R04 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Spurious Emission §15.209(a)(f) PASS Occupied Bandwidth §15.215 (c) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 30 Report No.: A2104124-C01-R04 2. General Information 2.1. Description of Device (EUT) EUT Name : Magnetic Wireless Charger Model No. : MagQoo AS DIFF. : / Trademark : ESORUN Power supply : Type-C Input : DC 5V/2A, DC 9V/2A, DC 12V/2A Wireless Output : DC 5V/1A(5W), 9V/0.83A(7.5W), 9V/1.12A(10W), 9V/1.67A(15W) Operation frequency : 125~205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi(This value is supplied by applicant). Connector cable loss : 0.5dB (This value is supplied by applicant). Software version : V1.0 Hardware version : V1.0 Page 7 of 30 Report No.: A2104124-C01-R04 2.2. Accessories of Device (EUT) Accessories1 : / Manufacturer : / Model : / Ratings : / 2.3. Tested Supporting System Details No. Description Manufacturer Model Serial Number Certification or SDOC 1 Adapter -- -- -- -- 2 Load -- -- -- -- 2.4. Block Diagram of connection between EUT and simulators 2.5. Description of Test Modes Channel F…

Text truncated - open the document above for the full version.

FCC ID: 2AP2N-MAGQOOAS Radiated Emission Conducted Emission
