2AP2N-WA02iWatch wireless charger

Apple Watch Charger-LED Usage P6 12 Standby mode Charging mode Green light on Green light breathing Watch charging indicator P15 Wireless charging for Apple Watch Please remove the case of watch charger and inserted it into the corresponding position of charging dock. P16 Wireless charging for Apple Watch Please make sure your Apple Watch is corresponded to the area of the wireless charger for Apple Watch. It will automatically detect the Apple Watch and charge it. Note: This product is only available for Apple Watch. If Samsung watch, it's not compatible. Apple Watch Charger-Product Structure P5 Wireless Charging Area for Apple Watch Apple Watch Charger Case Type-C Input Watch Charging Indicator 1 2 3 4 P16 P15 2 1 3 4 P6 Apple Watch Charger-Specifications Type C Input Output 5V/1A 2W This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.

September 14, 2022 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AP2N-WA02 Product Name: iWatch wireless charger Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co.,LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

September 14, 2022 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building i, No.2, Lixin Road, Fuyong Street, Bao’an District, 518103, Shenzhen, Guangdong, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Esorun Technology Co.,LTD Address: Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen ( applicant name and address). Signature: Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co.,LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected]

Differences Description We S Shenzhen Esorun Technology Co.,LTD state: Product name: iWatch wireless charger Model: WA02, WM01 All model’s the function, software and electric circuit are the same, except the model numbers and appearance color difference. 2022-9-21 Name Zhang Yi Position Deputy General Manager Company Name Shenzhen Esorun Technology Co.,LTD Address Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Tel 0086-0755-23696752 Fax / Email [email protected] (Signature)

FCC ID: 2AP2N-WA02 FCC ID: 2AP2N-WA02 FCC ID: 2AP2N-WA02 FCC ID: 2AP2N-WA02

2cm 1cm Label Location FCC ID: 2AP2N-WA02 Shenzhen Esorun Technology Co.,LTD

FCC ID: 2AP2N-WA02 ANT2 FCC ID: 2AP2N-WA02 FCC ID: 2AP2N-WA02

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-WA02 On Behalf of Shenzhen Esorun Technology Co.,LTD iWatch wireless charger Model No.: WA02, WM01 Prepared for : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2207165-C03-R06 Date of Receipt : July 18, 2022 Date of Test : July 18, 2022–August 18, 2022 Date of Report : August 18, 2022 Version Number : V0 Page 2 of 37 Report No.: A2207165-C03-R06 TABLE OF CONTENTS Description Page 1. Test Result Summary ................................................................................................................................ 5 2. EUT Description ......................................................................................................................................... 6 2.1. Description of Device (EUT) ................................................................................................................ 6 2.2. Accessories of Device (EUT) .............................................................................................................. 8 2.3. Tested Supporting System Details ...................................................................................................... 8 2.4. Block Diagram of Connection between EUT and Simulators.............................................................. 8 2.5. Description of Test Modes................................................................................................................... 8 2.6. Test Conditions ................................................................................................................................... 8 2.7. Test Facility ......................................................................................................................................... 9 2.8. Measurement Uncertainty ................................................................................................................... 9 3. Test Results and Measurement Data ..................................................................................................... 10 3.1. RF Exposure Test ............................................................................................................................. 10 3.1.1. Test Specification ....................................................................................................... 10 3.1.2. Test Instruments ........................................................................................................ 11 3.1.3. Test data ..................................................................................................................... 11 4. Photos of test setup ................................................................................................................................ 27 5. Photographs of EUT ................................................................................................................................ 37 Page 3 of 37 Report No.: A2207165-C03-R06 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : iWatch wireless charger (A) Model No. : WA02, WM01 (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Yannis Wen Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...... .......................: August 18, 2022 Page 4 of 37 Report No.: A2207165-C03-R06 Revision History Revision Issue Date Revisions Revised By V0 August 18, 2022 Initial released Issue Yannis Wen Page 5 of 37 Report No.: A2207165-C03-R06 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 37 Report No.: A2207165-C03-R06 2. EUT Description 2.1. Description of Device (EUT) EUT Name : iWatch wireless charger Model No. : WA02, WM01 DIFF. : There is no difference between the models except the model name. So all the test were performed on the model WA02. Trademark : ESORUN Power supply : Power from adapter EUT information : Input : 5V ⎓ 1A Output :2W Operation frequency : 325KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 0dBi (This value is supplie…

Text truncated - open the document above for the full version.

ALPHA's reports is using a digital certificate that is trusted on Adobe's official server. If there is no digital certificate or the digital certificate shows damaged in your report. Please do not accept the report. E-mail: [email protected] Tel: 4008300895 Website: http://www.a-lab.cn/certificate FCC TEST REPORT FCC ID: 2AP2N-WA02 On Behalf of Shenzhen Esorun Technology Co.,LTD iWatch wireless charger Model No.: WA02, WM01 Prepared for : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2207165-C03-R05 Date of Receipt : July 18, 2022 Date of Test : July 18, 2022–August 18, 2022 Date of Report : August 18, 2022 Version Number : V0 Page 2 of 30 Report No.: A2207165-C03-R05 TABLE OF CONTENTS Description Page 1. Test Result Summary ............................................................................................................................... 5 2. General Information .................................................................................................................................. 6 2.1. Description of Device (EUT) ............................................................................................................. 6 2.2. Accessories of Device (EUT) ............................................................................................................ 7 2.3. Tested Supporting System Details ................................................................................................... 7 2.4. Block Diagram of Connection between EUT and Simulators ........................................................... 7 2.5. Description of Test Modes ................................................................................................................ 7 2.6. Test Conditions ................................................................................................................................. 7 2.7. Test Facility ....................................................................................................................................... 8 2.8. Measurement Uncertainty................................................................................................................. 8 2.9. Test Equipment List .......................................................................................................................... 9 3. Test Results and Measurement Data .................................................................................................... 10 3.1. Conducted Emission ....................................................................................................................... 10 3.1.1. Test Specification ............................................................................................................... 10 3.1.2. Test Data ............................................................................................................................ 11 3.2. Radiated Spurious Emission Measurement ................................................................................... 14 3.2.1. Test Specification ............................................................................................................... 14 3.2.2. Test Data ............................................................................................................................ 17 3.3. Test Specification ........................................................................................................................... 23 3.3.1. Test Data ............................................................................................................................ 24 4. Photos of Test Setup .............................................................................................................................. 25 5. Photographs of EUT ............................................................................................................................... 27 Page 3 of 30 Report No.: A2207165-C03-R05 TEST REPORT DECLARATION Applicant : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen Manufacturer : Shenzhen Esorun Technology Co.,LTD Address : Room 226, Building A, B, C, Zone B, Yuanfen Industrial Zone, Taoyuan Community, Dalang Street, Longhua District, Shenzhen EUT Description : iWatch wireless charger (A) Model No. : WA02, WM01 (B) Trademark : ESORUN Measurement Standard Used: FCC CFR Title 47 Part 15 Subpart C Section 15.209 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness of test. Also, this report shows that the EUT is technically compliant with the FCC CFR Title 47 Part 15 Subpart C Section 15.209 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Yannis Wen Project Engineer Approved by (name + signature).......: Jack Xu Project Manager Date of issue...... .......................: August 18, 2022 Page 4 of 30 Report No.: A2207165-C03-R05 Revision History Revision Issue Date Revisions Revised By V0 August 18, 2022 Initial released Issue Yannis Wen Page 5 of 30 Report No.: A2207165-C03-R05 1. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line C…

Text truncated - open the document above for the full version.

Fine Page 1 of 3 承 認 書 SPECIFICATION FOR APPROVAL 客 戶： CUSTOMER: 深圳一讯达科技有限公司 客 戶 料 號： CUST P/N: 10.0110.1207 松 岛 料 號： FINE P/N: 手表发射线圈6.8UH 0.08*24P*11TS 産 品 型 號： DESC: 日 期： DATE: 2021/08/18 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 黄燕铭 宁元安 黄锦华 深圳市松岛科技有限公司 工廠地址：深圳市光明新区红星村第四工业区9栋7楼 TEL：0755-36820766 FAX：0755-84526500 E-mail：[email protected] Fine Page 2 of 3 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2018/03/09 黄锦华 Fine Page 3 of 3 SPECIFICATION 産 品 型 號： DESC 苹果发射线圈15*21.5-6.8UH 版本 Rev：A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 25±1 B 23.6±0.5 C 21.5±0.5 D 14.5±0.3 E 7.7±0.05 F 3±2 H 20±2 注： 1.交叉出线; 2.出线位置缠mm(ref)宽度高 温胶纸Ts; 3.线圈贴圆形硬磁片两端带 缺口，磁片尺寸25±1mm,内孔 7.7mm,厚度为2.8±0.2mm。 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 漆包线0.08*24P 11Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.1uH ±20%单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.8 uH ±20%单独线圈 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤110mΩ 100KHz/1.0V LCZ METER 502B 4 Q S-F ≤32 100KHz/1.0V LCZ METER 502B 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE 黄燕铭2021/08/18 黄锦华2021/08/18

FCC ID: 2AP2N-WA02 Radiated Emission FCC ID: 2AP2N-WA02 Conducted Emission
