2APJ4-SLM770A4G LTE Module

SLM770A Module Hardware Design Manual 美格智能技术股份有限公司 1/75 SLM770A Module Hardware Design Manual Controlled Version Number: V1.3 Release Date: 2023/12 SLM770A Module Hardware Design Manual MeiG Smart Technology Co., Ltd 77/77 Important Notice Copyright Notice All rights reserved. MeiG Smart Technology Co., Ltd This manual and all its contents are owned by MeiG Smart Technology Co., Ltd and protected by Chinese laws and relevant copyright laws in applicable international conventions. Without the written authorization of MeiG Smart Technology Co., Ltd, no one may copy, disseminate, distribute, modify or use part or all of this manual in any form, and the offenders will be held responsible according to law. Statement of No Guarantee MeiG Smart Technology Co., Ltd makes no representations or guarantees, either express or implied, for any contents in this document, and assumes no responsibility for the merchantability and fitness for a particular purpose or any indirect, extraordinary or consequential losses. Confidentiality Claim The information contained in this document (including any annexes) is confidential. The recipient understands that the document obtained by him is confidential and shall not be used for any purpose other than the stated purpose, and he shall not disclose this document to any third party. Disclaimer The company assumes no responsibility for property damage or personal injury caused by customers' improper operation. Customers are requested to develop corresponding products according to the technical specifications and reference designs in the manual. Before the disclaimer, the company has the right to change the contents of this manual according to the needs of technological development, and the version is subject to change without further notice. SLM770A Module Hardware Design Manual MeiG Smart Technology Co., Ltd 77/77 Revision History No. Version Date Reason for Revision 1 V1.0 2022-03-30 Created version 2 V1.1 2022-10-21 Modify 3.5.1, 3.6, 3.7, 3.8, 3.12, 6.4 chapter description 3 V1.2 2023-11-29 1. Modify the ADC power domain 2. Modify the RTS and CTS pin descriptions 3. Add the description of PCM interfaces 4. Add audio pin description 4 V1.3 2023-12-14 1. Add the SLM770A-SC model description 2. Improve the description of analog audio 3. Delete the RF reference circuit SLM770A Module Hardware Design Manual MeiG Smart Technology Co., Ltd 77/77 Contents Important Notice ....................................................................................................................................... 2 Revision History ....................................................................................................................................... 3 Contents .................................................................................................................................................... 4 Table Index ................................................................................................................................................ 6 Figure Index .............................................................................................................................................. 7 1 Introduction ....................................................................................................................................... 8 1.1 Safety Information .................................................................................................................... 9 1.2 Purpose .................................................................................................................................. 10 1.3 Content List ............................................................................................................................. 10 2 Product Overview ........................................................................................................................... 11 2.1 Basic Description ..................................................................................................................... 11 2.2 Main Performance .................................................................................................................. 13 2.3 Functional diagram ....................................................................................... 错误!未定义书签。 3 Application Interface ...................................................................................................................... 16 3.1 Basic Description .................................................................................................................... 16 3.2 LCC Card Interface Definition ................................................................................................ 17 3.3 Pin Description........................................................................................................................ 17 3.4 Module Operating Mode ......................................................................................................... 24 3.5 Power Saving.......................................................................................................................... 26 3.5.1 Sleep Mode .................................................................................................................. 26 3.5.2 Flight Mode ................................................................................................................... 26 3.6 Power Supply Design ............................................................................................................. 27 3.6.1 Power Supply Pins ....................................................................................................... 27 3.6.2 Decrease Voltage Drop ................................................................................................ 27 3.6.3 Reference Design for Power Supply ............................................................................ 30 3.6.4 VDD_EXT Voltage Output .…

Text truncated - open the document above for the full version.

TIANHENG CONSULTING, LLC 392 Andover Street, Wilmington, MA 01887, United States Phone: +1 (617) 997-4010Email:[email protected] Supplier's Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Manufacturer: Company Name: MeiG Smart Technology Co., Ltd Address: 2nd Floor, Office Building,No.5 Lingxia Road, Fenghuang,Fuyong Street, Bao 'an District,Shenzhen, China Contact Person: Name: Xinwei Lou Phone: +86-21-54278676 U.S. Responsible Party: TianHeng Consulting, LLC 392 Andover Street Wilmington, MA 01887, United States Contact Person: Hualing Dong Phone: +1-617- 997-4010 Email: [email protected] Product Name: 4G LTE Module Model Number(s): SLM770A We hereby declare that the equipment bearing the product name and model number specified above was tested conforming to the FCC Rules and Regulations Title 47 Part 15 Subpart B and the most accurate measurement standards. We confirm that the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commission’s requirements. This Declaration is valid until (expiry date): For the product life time. Signature: Signed by: Hualing Dong Date: May 7, 2024

Rev 1/26/2023 MeiG Smart Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-04-29 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2APJ4-SLM770A [MeiG Smart Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Xinwei Lou (Applicant printed name) Rev 1/26/2023 MeiG Smart Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-04-29 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2APJ4-SLM770A [MeiG Smart Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Xinwei Lou (Applicant printed name)

MeiG Smart Technology Co., Ltd Declaration of Authorization We Name: MeiG Smart Technology Co., Ltd Address: 2nd Floor,Office Building,No.5 LingxiaRoad,Fenghuang,Fuyong Street,Bao'an District,Shenzhen, China Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3,Jinshagang 1st Road, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification of the following product(s) and signing all the related documents including 731 forms: Product description: 4G LTE Module Type designation: SLM770A Trademark: MEIGLink FCC ID: 2APJ4-SLM770A on our behalf. Date:2024-04-29 City: Shenzhen Name: Xinwei Lou Function: HW test Leader Signature:

MeiG Smart Technology Co., Ltd Date: 2024-04-29 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2APJ4-SLM770A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description Bill(s) of Material The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ----- Xinwei Lou --------- Grantee Contact’s Signature MeiG Smart Technology Co., Ltd

MeiG Smart Technology Co., Ltd Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: 2APJ4-SLM770A Items to be covered by Single modular transmitters. Answer from applicant 1. The modular transmitter must have its own RF shielding. YES, Please refer to External Photos. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Yes, it is fulfilled. The EUT has buffered data inputs to insure compliance with Part 15 requirements under conditions of excessive data rates or over modulation.Please see the Schematics exhibit. 3. The modular transmitter must have its own power supply regulation. YES, the modular has its own power supply regulation. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(b)(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). YES, it is Dipole antenna. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes, the module is tested in a stand-alone configuration as the test photos show. 6. The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number in accordance with 15.212 (a)(1)(vi)(A) / (B). YES, please refer to the exhibition label sample for this module. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. YES, please refer to the user manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 1.1310, 2.1091, 2.1093, and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. YES, RF exposure statement is attached in the user manual. Note: A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with the requirements above. Name and surname of applicant (or authorized representative): Xinwei Lou Date: 2024-04-29 Signature: ___

Project No.: 2402C072 Page 2 of 6 Project No.: 2402C072 Page 3 of 6 WWAN Main Ant. WWAN Div. Ant.

VER REMARK DATE 名称 Title 尺寸 Dimension 公差 Tolerance 制作 Drawn mm 0 ~ 30 30 ~ 60 > 60 Angle ±0.1 ±0.15 ±0.2 ±1° 1 : 1 日期 Date 料号 Part No. 图号 DWG No. 项目 Project 日期 Date 比例 Scale 审核 Checked 单位 Unit Made in China IMEI: XXXXXXXXXXXXXXX FCC ID: 2APJ4-SLM770A SN: XXXXXXXXXXXXXXXXXXX SA SLM770A MeiG Smart Technology Co.,LTD SLM770A-镭雕稿件 770AHSAA A 30 27

Project No.: 2402C072 Page 4 of 6 Project No.: 2402C072 Page 5 of 6 Project No.: 2402C072 Page 6 of 6

Report No.: BTL-FCCP-4-2402C072 Page 1 of 4 FCC Radio Test Report FCC ID: 2APJ4-SLM770A This report concerns: Original Grant Project No. : 2402C072 Equipment : 4G LTE Module Brand Name : MEIGLink Test Model : SLM770A Series Model : N/A Applicant : MeiG Smart Technology Co., Ltd Address : 2nd Floor,Office Building,No.5 LingxiaRoad,Fenghuang,Fuyong Street,Bao'an District,Shenzhen,China Manufacturer : MeiG Smart Technology Co., Ltd Address : 2nd Floor,Office Building,No.5 LingxiaRoad,Fenghuang,Fuyong Street,Bao'an District,Shenzhen,China Date of Receipt : Feb. 07, 2024 Date of Test : Feb. 18, 2024 ~ Apr. 29 2024 Issued Date : Apr. 30, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024020714 and SSL2024020715 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Edward Li Approved by : Steven Lu Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-4-2402C072 Page 2 of 4 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-4-2402C072 R00 Original Report. Apr. 30, 2024 Valid Report No.: BTL-FCCP-4-2402C072 Page 3 of 4 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For Part 22: Manufacturer P/N Antenna Type Connector Gain (dBi) Note ShenZhen VLG Wireless TECHNOLOGY CO,.LTD 45-V1497-057-01 Dipole SMA -1.1 GSM 850 -1.1 WCDMA Band V -1.1 LTE Band 5 For Part 24: Manufacturer P/N Antenna Type Connector Gain (dBi) Note ShenZhen VLG Wireless TECHNOLOGY CO,.LTD 45-V1497-057-01 Dipole SMA -1.1 PCS 1900 -1.1 WCDMA Band II -1.1 LTE Band 2 For Part 27: Manufacturer P/N Antenna Type Connector Gain (dBi) Note ShenZhen VLG Wireless TECHNOLOGY CO,.LTD 45-V1497-057-01 Dipole SMA -1.5 WCDMA Band IV -1.5 LTE Band 4 1.9 LTE Band 7 0.2 LTE Band 40 (2305-2315MHz) 0.4 LTE Band 40 (2350-2355MHz) -1.4 LTE Band 66 Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-4-2402C072 Page 4 of 4 2. TEST RESULTS For GSM: Band Frequency (MHz) Max. Tune up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Te s t Result GSM 850 824.2 33.5 -1.1 0.7762 1737.80 0.3457 0.5495 Complies PCS 1900 1850.2 31.5 -1.1 0.7762 1096.48 0.2181 1.0000 Complies For WCDMA: Band Frequency (MHz) Max. Tune up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Te s t Result WCDMA Band II 1852.4 25 -1.1 0.7762 245.47 0.0488 1.0000 Complies WCDMA Band IV 1712.4 25 -1.5 0.7079 223.87 0.0445 1.0000 Complies WCDMA Band V 826.4 25 -1.1 0.7762 245.47 0.0488 0.5509 Complies For LTE: Band Frequency (MHz) Max. Tune up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/ cm 2 ) Power Density Limit (mW/ cm 2 ) Te s t Result Band 2 1850.7 25.7 -1.1 0.7762 288.40 0.0574 1.2338 Complies Band 4 1710.7 25.7 -1.5 0.7079 263.03 0.0523 1.0000 Complies Band 5 824.7 25.7 -1.1 0.7762 288.40 0.0574 0.5498 Complies Band 7 2502.5 25.7 1.9 1.5488 575.44 0.1145 1.0000 Complies Band 40 (2305-2315 MHz) 2307.5 25.7 0.2 1.0471 389.05 0.0774 1.0000 Complies Band 40 (2350-2355 MHz) 2352.5 25.7 0.4 1.0965 407.38 0.0810 1.0000 Complies Band 66 1710.7 25.7 -1.4 0.7244 269.15 0.0535 1.0000 Complies Note: The calculated distance is 20 cm. End of Test Report

Report No.: BTL-FCCP-1-2402C072 Page 1 of 75 FCC Radio Test Report FCC ID: 2APJ4-SLM770A Thi s report concerns: Original Grant Project No. : 2402C072 Equipment : 4G LTE Module Brand Name : MEIGLink Test Model : SLM770A Series Model : N/A Applicant : MeiG Smart Technology Co., Ltd Address : 2nd Floor,Office Building,No.5 LingxiaRoad,Fenghuang,Fuyong Street,Bao'an District,Shenzhen,China Manufacturer : MeiG Smart Technology Co., Ltd Address : 2nd Floor,Office Building,No.5 LingxiaRoad,Fenghuang,Fuyong Street,Bao'an District,Shenzhen,China Date of Receipt : Feb. 07, 2024 Date of Test : Feb. 18, 2024 ~ Apr. 28, 2024 Issued Date : Apr. 30, 2024 Report Version : R00 Test Sample : Engineering Sample No.: SSL2024020714 and SSL2024020717 for radiated, SSL2024020714 and SSL2024020715 for conducted. Standard(s) : 47 CFR FCC Part 22 Subpart H 47 CFR FCC Part 2 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Edward Li Approved by : Steven Lu Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China. Te l : +86-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-1-2402C072 Page 2 of 75 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2402C072 Page 3 of 75 Table of Contents Page REPORT ISSUED HISTORY 5 1 . APPLICABLE STANDARDS 6 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 2.3 TEST ENVIRONMENT CONDITIONS 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 11 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATIONOFSYSTEMTESTED 13 2.4 DESCRIPTION OF SUPPORT UNITS 13 4 . TEST RESULT 14 4.1 OUTPUT POWER MEASUREMENT 14 4.1.1 LIMIT 14 4.1.2 TEST PROCEDURE 14 4.1.3 TEST SETUP LAYOUT 14 4.1.4 TEST DEVIATION 14 4.1.5 TEST RESULTS 14 4.2 OCCUPIED BANDWIDTH MEASUREMENT 15 4.2.1 TEST PROCEDURE 15 4.2.2 TEST SETUP LAYOUT 15 4.2.3 TEST DEVIATION 15 4.2.4 TEST RESULTS 15 4.3 CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 16 4.3.1 LIMIT 16 4.3.2 TEST PROCEDURES 16 4.3.3 TEST SETUP LAYOUT 16 4.3.4 TEST DEVIATION 16 4.3.5 TEST RESULTS 16 4.4 RADIATED SPURIOUS EMISSIONS MEASUREMENT 17 4.4.1 LIMIT 17 4.4.2 TEST PROCEDURES 17 4.4.3 TEST SETUP LAYOUT 18 4.4.4 TEST DEVIATION 19 4.4.5 TEST RESULTS (9KHZ TO 30MHZ) 19 4.4.6 TEST RESULTS (30MHZ TO 1000MHZ) 19 4.4.7 TEST RESULTS (ABOVE 1000MHZ) 19 Report No.: BTL-FCCP-1-2402C072 Page 4 of 75 Table of Contents Page 4.5 BAND EDGE MEASUREMENT 20 4.5.1 LIMIT 20 4.5.2 TEST PROCEDURES 20 4.5.3 TEST SETUP LAYOUT 20 4.5.4 TEST DEVIATION 20 4.5.5 TEST RESULTS 20 4.6 PEAK TO AVERAGE RATIO MEASUREMENT 21 4.6.1 LIMIT 21 4.6.2 TEST PROCEDURES 21 4.6.3 TEST SETUP LAYOUT 21 4.6.4 TEST DEVIATION 21 4.6.5 TEST RESULTS 21 4.7 FREQUENCY STABILITY MEASUREMENT 22 4.7.1 LIMIT 22 4.7.2 TEST PROCEDURES 22 4.7.3 TEST SETUP LAYOUT 22 4.7.4 TEST DEVIATION 22 4.7.5 TEST RESULTS 22 4. LIST OF MEASUREMENT EQUIPMENTS 23 5. EUT TEST PHOTO 25 APPENDIX A - OUTPUT POWER 28 APPENDIX B - OCCUPIED BANDWIDTH 35 APPENDIX C - CONDUCTED SPURIOUS EMISSIONS 43 APPENDIX D - RADIATED SPURIOUS EMISSIONS (9KHZ TO 30MHZ) 47 APPENDIX E - RADIATED SPURIOUS EMISSIONS (30MHZ TO 1000MHZ) 49 APPENDIX F - RADIATED SPURIOUS EMISSIONS (ABOVE 1000MHZ) 53 APPENDIX G - BAND EDGE 57 APPENDIX H - PEAK TO AVERAGE RATIO 64 APPENDIX I - FREQUENCY STABILITY 72 Report No.: BTL-FCCP-1-2402C072 Page 5 of 75 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-1-2402C072 R00 Original Report. Apr. 30, 2024 Valid Report No.: BTL-FCCP-1-2402C072 Page 6 of 75 1. APPLICABLE STANDARDS According to the specifications of the manufacturer, the EUT must comply with the requirements of the following standards: ANSI C63.26-2015 The following reference test guidance is not within the scope of accreditation of A2LA: FCC KDB 971168 D01 Power Meas License Digital Systems v03r01 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 22 Subpart H & Part 2 Standard(s) Sec…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2402C072 Page 44 of 75 GSM850_GSM_CH190 Spectrum Plot GSM850_EDGE_CH190 Spectrum Plot Report No.: BTL-FCCP-1-2402C072 Page 45 of 75 WCDMA Band V_WCDMA_CH4182 Spectrum Plot Report No.: BTL-FCCP-1-2402C072 Page 46 of 75 LTE Band 5_1.4MHz_CH20525 Spectrum Plot LTE Band 5_5MHz_CH20525 Spectrum Plot LTE Band 5_10M_CH20525 Spectrum Plot Report No.: BTL-FCCP-1-2402C072 Page 47 of 75 APPENDIX D - RADIATED SPURIOUS EMISSIONS (9KHZ TO 30MHZ) Report No.: BTL-FCCP-1-2402C072 Page 48 of 75 Test Mode : TX Mode Ant 0° Test Mode : TX Mode Ant 0° Test Mode : TX Mode Ant 90° Test Mode : TX Mode Ant 90° Report No.: BTL-FCCP-1-2402C072 Page 49 of 75 APPENDIX E - RADIATED SPURIOUS EMISSIONS (30MHZ TO 1000MHZ) Report No.: BTL-FCCP-1-2402C072 Page 50 of 75 Test Mode : GSM850_TX CH190_GSM Vertical Test Mode : GSM850_TX CH190_GSM Horizontal Test Mode : WCDMA Band V_TX CH4182 Vertical Test Mode : WCDMA Band V_TX CH4182 Horizontal Report No.: BTL-FCCP-1-2402C072 Page 51 of 75 Test Mode : LTE Band 5_TX CH20525_1.4MHz Vertical Test Mode : LTE Band 5_TX CH20525_1.4MHz Horizontal Test Mode : LTE Band 5_TX CH20525_5MHz Vertical Test Mode : LTE Band 5_TX CH20525_5MHz Horizontal Report No.: BTL-FCCP-1-2402C072 Page 52 of 75 Test Mode : LTE Band 5_TX CH20525_10MHz Vertical Test Mode : LTE Band 5_TX CH20525_10MHz Horizontal Report No.: BTL-FCCP-1-2402C072 Page 53 of 75 APPENDIX F - RADIATED SPURIOUS EMISSIONS (ABOVE 1000MHZ) Report No.: BTL-FCCP-1-2402C072 Page 54 of 75 Test Mode : GSM850_TX CH190_GSM Vertical Test Mode : GSM850_TX CH190_GSM Horizontal Test Mode : WCDMA Band V_TX CH4182 Vertical Test Mode : WCDMA Band V_TX CH4182 Horizontal Report No.: BTL-FCCP-1-2402C072 Page 55 of 75 Test Mode : LTE Band 5_TX CH20525_1.4MHz Vertical Test Mode : LTE Band 5_TX CH20525_1.4MHz Horizontal Test Mode : LTE Band 5_TX CH20525_5MHz Vertical Test Mode : LTE Band 5_TX CH20525_5MHz Horizontal Report No.: BTL-FCCP-1-2402C072 Page 56 of 75 Test Mode : LTE Band 5_TX CH20525_10MHz Vertical Test Mode : LTE Band 5_TX CH20525_10MHz Horizontal Report No.: BTL-FCCP-1-2402C072 Page 57 of 75 APPENDIX G - BAND EDGE Report No.: BTL-FCCP-1-2402C072 Page 58 of 75 GSM850_GSM Spectrum Plot Channel 128 Channel 251 GSM850_EDGE Spectrum Plot Channel 128 Channel 251 Report No.: BTL-FCCP-1-2402C072 Page 59 of 75 WCDMA Band V_WCDMA Spectrum Plot Channel 4132 Channel 4233 Report No.: BTL-FCCP-1-2402C072 Page 60 of 75 LTE Band 5_1.4MHz Spectrum Plot 1RB#0 1RB#5 Channel 20407 Channel 20643 6RB#0 Channel 20407 Channel 20643 Report No.: BTL-FCCP-1-2402C072 Page 61 of 75 LTE Band 5_3MHz Spectrum Plot 1RB#0 1RB#14 Channel 20415 Channel 20635 15RB#0 Channel 20415 Channel 20635 Report No.: BTL-FCCP-1-2402C072 Page 62 of 75 LTE Band 5_5MHz Spectrum Plot 1RB#0 1RB#24 Channel 20425 Channel 20625 25RB#0 Channel 20425 Channel 20625 Report No.: BTL-FCCP-1-2402C072 Page 63 of 75 LTE Band 5_10MHz Spectrum Plot 1RB#0 1RB#49 Channel 20450 Channel 20600 50RB#0 Channel 20450 Channel 20600 Report No.: BTL-FCCP-1-2402C072 Page 64 of 75 APPENDIX H - PEAK TO AVERAGE RATIO Report No.: BTL-FCCP-1-2402C072 Page 65 of 75 GSM 850_GSM Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 128 824.2 2.62 13 Pass 190 836.6 2.62 13 Pass 251 848.8 2.62 13 Pass Spectrum Plot 128 190 251 Report No.: BTL-FCCP-1-2402C072 Page 66 of 75 GSM 850_EDGE Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 128 824.2 8.03 13 Pass 190 836.6 7.74 13 Pass 251 848.8 7.21 13 Pass Spectrum Plot 128 190 251 Report No.: BTL-FCCP-1-2402C072 Page 67 of 75 WCDMA Band V_WCDMA Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 4132 826.4 3.03 13 Pass 4182 836.4 2.95 13 Pass 4233 846.6 3.01 13 Pass Spectrum Plot 4132 4182 4233 Report No.: BTL-FCCP-1-2402C072 Page 68 of 75 LTE Band 5_1.4MHz Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 16QAM 20407 824.7 5.14 5.68 13 Pass 20525 836.5 4.90 5.69 13 Pass 20643 848.3 5.20 5.79 13 Pass Spectrum Plot QPSK-20407 QPSK-20525 QPSK-20643 16QAM-20407 16QAM-20525 16QAM-20643 Report No.: BTL-FCCP-1-2402C072 Page 69 of 75 LTE Band 5_3MHz Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 16QAM 20415 825.5 5.24 5.78 13 Pass 20525 836.5 5.05 5.73 13 Pass 20635 847.5 5.34 6.15 13 Pass Spectrum Plot QPSK-20415 QPSK-20525 QPSK-20635 16QAM-20415 16QAM-20525 16QAM-20635

Report No.: BTL-FCCP-1-2402C072 Page 70 of 75 LTE Band 5_5MHz Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 16QAM 20425 826.5 5.23 6.00 13 Pass 20525 836.5 4.99 5.78 13 Pass 20625 846.5 5.46 6.29 13 Pass Spectrum Plot QPSK-20425 QPSK-20525 QPSK-20625 16QAM-20425 16QAM-20525 16QAM-20625 Report No.: BTL-FCCP-1-2402C072 Page 71 of 75 LTE Band 5_10MHz Channel Frequency (MHz) Peak To Average Ratio (dB) Max. Limit (dB) Result QPSK 16QAM 20450 829.0 5.27 6.15 13 Pass 20525 836.5 5.24 6.34 13 Pass 20600 844.0 5.15 5.74 13 Pass Spectrum Plot QPSK-20450 QPSK-20525 QPSK-20600 16QAM-20450 16QAM-20525 16QAM-20600 Report No.: BTL-FCCP-1-2402C072 Page 72 of 75 APPENDIX I - FREQUENCY STABILITY Report No.: BTL-FCCP-1-2402C072 Page 73 of 75 Test Mode GSM850_CH190 Frequency error versus temperature and supply voltage Temperature (°C) Frequency error (Hz) ppm Limit 50 -23.99 -0.03 ±2.5ppm 40 -25.89 -0.03 30 -21.57 -0.03 20 -23.18 -0.03 10 -22.37 -0.03 0 -17.76 -0.02 −10 -25.8 -0.03 −20 -22.37 -0.03 −30 -22.96 -0.03 Minimum voltage -28.83 -0.03 Maximum voltage -27.02 -0.03 Nominal voltage -19.34 -0.02 Note: Nominal voltage= 3.8V, Maximum voltage= 4.2V, Minimum voltage= 3.3V. Report No.: BTL-FCCP-1-2402C072 Page 74 of 75 Test Mode WCDMA Band V_C…

Text truncated - open the document above for the full version.
