SLT779 QuickStartGuide GettingStarted： ThankyouforchoosingthePortable4G Router Note: ThisUserGuideprovidesthebasic operationsoftheSLT779. Deviceoverview 1.Menubutton 2.SignalandRoamingstatusicon 3.Networkmodeicon 4.Wi-Fisignalicon 5.Unreadmessageicon 6.Batteryicon 7.PowerButton 8.MicroUSBPort 9.Batterycover 10.Thepointofremovingthebackcover. Displaylayout&icons IconDescription SignalandRoamingstatus icon Networkmodeicon Dataflowicon Wi-Fisignalandnumberof accessusers Thenumberofunread message ， maximumis100 Batterycapacityicon,if batterycapacityislower than25%,thisiconisred. DataStatistics,used/total WPSstatusindicator Downloadandupload DataSpeed InstallingtheSIMCard FollowingtheinstructiontoinstallyourSIM card: 1.RemovetheSIMcardfromtheoutercard, beingcarefulnottotouchthegoldcontacts. 2.Turnthepoweroff.Removethebattery coverandtakethebatteryout.Locatethe SIMcardslot.Holdthecardsothewriting onthebackofthecardisfacingyouandthe goldcontactpointsareproperlyaligned withtheSIMcardslot. 3.InserttheSIMcardintotheslotuntilitis fullyinserted. Note: DonotremoveSIMcardwhenthedeviceis poweredonsincethismaydamagethecard andthedevice. DonotbendorscratchyourSIMcard.Avoid exposingyourSIMcardtostaticelectricity, waterordirt. InsertingandChargingthe Battery 1.Removethebatterycoverandalignthe batterycontactswiththeterminalsinthe batterycompartmentasshown.Pushthe batterydownuntilitclicksintoplace. 2.Placethebatterycoveroverthebattery compartmentandpressitdownwarduntilit clicksintoplace. 3.Yourdevicecomeswithacharger.Tocharge: Plugoneendofthechargerintoanelectrical outletandtheotherendintothedevice’s MicroUSBPort. RemovingtheSIMCard 1.Turnthepoweroff.Removethebattery coverandtakeoutthebattery. 2.GentlyremovetheSIMcardfromtheSIM cardslot SettingupWi-Ficonnection 1. Press and hold the “power” button for 3 secondsuntilthewelcomelogoisdisplayed ontheLCD,andWi-Fiison. 2.Useyourterminaltosearchthewireless network connection with the Wi-Fi’s SSID of “4G-MiFi-2.4GHz_XXXX”or “5G-MiFi_ 5GHz_XXXX” and click “Connect”. If the security mechanism is applied, you need to enter the correct PASSWORD. 3. The default password is the last 8 digits of IMEI.original password123456. Note:XXXX is the last 4 digits of device MAC Address. Youcanalsofindthelabelforthedefault SSIDandPASSWORDwhenyouremovethe backcover. YoucanalsofindthedefaultSSIDand PasswordintheWIFIInfopageofSLT779 screenoncethedeviceispoweredon. SettingupyourWPS IfyourterminalsupportWPS,youdonothave toinputthepasswordmanuallyonceyour WPShasbeensetup. TouseWPSpleasefollowthesesteps: 1.EnableWPSintheWebUIthrough Settings->Wireless->WLANSettings->WPS 2.Press“Menu”buttononthedevicetoselect “WPSActive”pageontheLCD 3.Press“Power”buttontoactiveWPS function ThenyoucanenabletheWPSfunctiononyour terminaltoconnectthehotspot. LoggingintotheDeviceManagement website 1.Makesureyourdeviceisconnectedtothe SLT779viaWi-FiorMicro-USBcable. 2.Openabrowseronyourcomputerorother connecteddevice,andinput http://192.168.1.1orhttp://device.WebUI intotheaddressbar. 3.Enteryourusernameandpassword,and click“LogIn”.Theadministratorhasthe righttocheckandmodifyconfiguration permissions. Note:Thedefaultusernameisadmin;the defaultpasswordisadmin. Youcanalsofindthelabelfordefaultlogin usernameandpasswordprintedonthedevice labelbyremovingthebackcoverandbattery. HowtochangetheSSID&Password 1.Whileyourcomputerorotherdevice terminalisconnectedtothehotspot,login tohttp://192.168.1.1or http://device.WebUIinaninternetbrowser usingthedefaultusernameandpassword. 2.IntheWebUI,SelectSettings>Wireless> WLANSettings,thenyouwillsee“Wi-Fi Name(SSID)”and“Password”.Deletethe oldnameandpasswordandenteryournew nameandpassword. 3.Select“Apply”button,waitforthescreento display“Success”,andthenlogout. 4.Waitforthecomputerorotherdevice terminalscreentodisplaytheWi-Fiicon. Thismeansthewirelessnetworkconnection wassuccessful. RestoreFactorySettings IfyouareuncertainofwhichWi-Fisettingsyou haveconfiguredorchanged,youcanrestore thefactorydefaultsthatcomewiththedevice toreconfigurethedeviceWi-Fisetting. 1.LogintoDeviceManagementintheWebUI torestoreyourhotspottoitsfactorydefault settings. 2.Onthehotspot,pressandhold“Reset” buttonfor5seconds,andthedevicewill restartwithrestoredfactorydefault settings. Note:Resettingwilldeleteallofthedevice’s user-definedWi-Fisettingsandrestoreall settingstofactorydefaultvalues. Trouble-shooting Ifyouarehavingtroublewithdevice,hereare afewtroubleshootingtips: 1.Ifthedeviceisnotresponsive,restartitby pressthe“Power”buttonforabout5 secondstoshowthe“Reboot”selection, andthenclickit.Orpressandholdthe “Power”buttonfor8secondstorestartit directly. 2.Ifrestartingthedevicedoesnotsolvethe issue,tryrestoringthedevicetoitsdefault factorysettings. Q&A Q:WhatdoIdoifIseetheSSIDbutfailedto connect? A:1Checkifthepasswordyouenteredisthe correctone. 2CheckifWPSsecurityisenabledonyourPC.If so,checkthedevicetoseeifitisexpectingaWPS actionfromyourPC. Q:WhattodoifthereisNoservice? A:Thepossiblereasonsareanunstablenetwork signalorahardwareproblem. Youcantrythefollowingsolutions: 1.Ifyouareinsideabuildingorneara structurethatmaybeblockingthesignal,change thepositionorlocationofthedevice.Forexample, trymovingthedeviceclosetoawindow. 2.Checkthehardwareforanyloosepartsor damage. Q:WhattodoifIforgotmyWi-Fipassword? A:1.youcanfindtheWi-FipasswordintheWi-Fi InfopageontheLCD. 2.youcanalsoresetthedevicetofactorydefaults bypresstheresetbuttonfor5seconds.Thedefault passwordisthelast8digitsofyourdeviceIMEI whichisalsolistedontheSSIDlabelundertheback coverofthedevice. Q:Dataconnectionfailed. A:Youhavenonetworkcoverage.Trymoving locationuntilyougetgoodreception. Q:Themodemcannotconnecttotheinternetwhen overseas A:youcancheckifthedataroamingfunctionis enabledintheDeviceSettingpageontheLCD. Makesureyouhaveinternationalroamingenabled onyourplan.Youcancontactyourserviceprovider beforeyougooverseastoenableroaming. . TotheOwner •Someelectronicdevices,suchastheelectronic systemofvehicles,aresusceptibleto electromagneticinterferencesentbyyour …

Text truncated - open the document above for the full version.

一、制造商信息ManufacturerInformation 制造商：深圳祥博一科技有限公司 Manufacturer：ShenzhenXiangboyiTechnologyCo.Ltd 地址：广东省深圳市龙华区油松路95号油松文创园文成楼1楼 Address：1/F,WenchengBuilding,PinusTabulaeformisCulturalInnovation Park,95YousongRoad,LonghuaDistrict,ShenzhenCity,Guangdong Province 二、天线样品及天线类型Antennasampleandantennatype 主天线mainantenna天线类型TypeofantennaLDS 分集天线天线类型LDSDiversityantennaantennatypeLDS WiFiANT0antennatypeFPC WiFiANT1antennatypeFPC 三、天线方向图Antennapattern Pleaserefertotheattachment. 四、天线增益Antennagain WiFiunit 2.4G2dBi 5G3dBi 2G&3Gunit B50.6dBi LTE(4G)unit B21.5dBi B41.5dBi B50.6dBi B120.5dBi B130.5dBi B251.5dBi B260.5dBi B412.5dBi B661.5dBi B710.5dBi LTEB2/4/25/66Gain:1.5dBi LTEB12/13/26/71Gain:0.5dBi LTEB5Gain:0.6dBi LTEB41Gain:2.5dBi 2.4GWIFI2dBi 5GWIFI3dBi

MeiG Smart Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022/08/24 Subject; Request for Confidentiality FCC ID: 2APJ4-SLT779 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune up procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Xinwei Lou Title: HW test Leader Email: [email protected] X

LetterofAuthorization Company:MeiGSmartTechnologyCo.,Ltd Address:2ndFloor,OfficeBuilding,No.5LingxiaRoad,Fenghuang,Fuyong Street,Bao'anDistrict,Shenzhen,China ProductName:MiFi ModelNumber:SLT779 FCCIdentifier:2APJ4-SLT779 WeauthorizeMiCOMLabsInc,575BoulderCourt,Pleasanton,California 94566,USA,toactonourbehalfonallmattersconcerningtheabove namedequipment. AnyindividualwithinMiCOMLabsisauthorizedtoactonourbehalfand takeactionontheapplication. WedeclarethatMiCOMLabsInc,575BoulderCourt,Pleasanton,California 94566,USA,isallowedtoforwardallinformationrelatedtotheapproval projecttotheFederalCommunicationCommissionandtodiscussany issuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Name: XinweiLouDate:2022-08-23 Title:HWtestLeader Signatureofapplicant:

MeiGSmartTechnologyCo.,Ltd Date:2022-08-24 FCCID:2APJ4-SLT779 ModelNumber:SLT779 To: FederalCommunicationCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21048 ToWhomItMayConcern, We,MeiGSmartTechnologyCo.,LtddeclarethatthisEUT(FCCID: 2APJ4-SLT779)willconductFCCcompliancetesting,theSDOCpart recognizedtestlab(ShenzhenNTEKTestingTechnologyCo., Ltd.(ShenZhenLab.). 1/F,BuildingE,FendaSciencePark,SanweiCommunity,XixiangStreet Bao’anDistrict,Shenzhen518126P.R.China) Pleasecontactmeifyouhaveanyquestion. Sincerely, (Signed) Name/Title:XinweiLou/HWtestLeader Company:MeiGSmartTechnologyCo.,Ltd Address:2ndFloor,OfficeBuilding,No.5LingxiaRoad,Fenghuang,Fuyong Street,Bao'anDistrict,Shenzhen,China

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 1# Photo 14 1# Photo 15 1# Photo 16 1# Photo 17 1# Photo 18 2# Photo 19 2# Photo 20 2# Photo 21 2# Photo 22 WIFI ANT0 WIFI ANT1 4G AUX ANT 3/4G MAIN ANT Photo 23 Photo 24

Page 1 of 245 Report No.: S22080805001001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093), ANSI/IEEE C95.1-1992 and IEEE Std 1528-2013 Product Name： MiFi Brand Name： MEIGLink Model Name： SLT779 Family Model： N/A Report No.： S22080805001001 FCC ID： 2APJ4-SLT779 Prepared for MeiG Smart Technology Co., Ltd 2nd Floor, Office Building,No.5 Lingxia Road, Fenghuang, Fuyong Street, Bao'an District, Shenzhen, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao'an District, Shenzhen 518126 P.R.China. Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 245 Report No.: S22080805001001 TEST RESULT CERTIFICATION Applicant’s name ................. : MeiG Smart Technology Co., Ltd Address .................................. : 2nd Floor, Office Building,No.5 Lingxia Road, Fenghuang, Fuyong Street, Bao'an District, Shenzhen, China Manufacturer's Name .......... : MeiG Smart Technology Co., Ltd Address .................................. : 2nd Floor, Office Building,No.5 Lingxia Road, Fenghuang, Fuyong Street, Bao'an District, Shenzhen, China Product description Product name ........................ : MiFi Brand Name ......................... : MEIGLink Model and/or type reference : SLT779 Family Model ......................... : N/A Standards ............................. : FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093) and ANSI/IEEE C95.1-1992. The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Test Sample Number ............................. : S220808050001 Date of Test Date (s) of performance of tests .............. : Aug. 09, 2022 ~ Aug. 18, 2022 Date of Issue ........................................... : Aug. 19, 2022 Test Result ............................................... : Pass Prepared By (Test Engineer) : (Jacob Chen) Approved By (Lab Manager) : (Alex Li) Page 3 of 245 Report No.: S22080805001001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Aug. 19, 2022 Jacob Chen Page 4 of 245 Report No.: S22080805001001 TABLE OF CONTENTS 1. General Information ............................................................................................ 6 1.1. RF exposure limits .................................................................................... 6 1.2. Statement of Compliance ........................................................................ 7 1.3. EUT Description ....................................................................................... 7 1.4. Test specification(s) .................................................................................. 9 1.5. Ambient Condition ................................................................................... 9 2. SAR Measurement System ................................................................................. 10 2.1. SATIMO SAR Measurement Set-up Diagram .......................................... 10 2.2. Robot ..................................................................................................... 11 2.3. E-Field Probe .......................................................................................... 12 2.3.1. E-Field Probe Calibration ................................................................. 12 2.4. SAM phantoms ...................................................................................... 13 2.4.1. Technical Data .................................................................................. 14 2.5. Device Holder ........................................................................................ 15 2.6. Test Equipment List ................................................................................ 16 3. SAR Measurement Procedures .......................................................................... 18 3.1. Power Reference ................................................................................... 18 3.2. Area scan & Zoom scan .......................................................................... 18 3.3. Description of interpolation/extrapolation scheme .............................. 20 3.4. Volumetric Scan ..................................................................................... 20 3.5. Power Drift ............................................................................................ 20 4. System Verification Procedure .......................................................................... 21 4.1. Tissue Verification ................................................................................. 21 4.1.1. Tissue Dielectric Parameter Check Results ...................................... 22 4.2. System Verification Procedure .............................................................. 23 4.2.1. System Verification Results .............................................................. 24 5. SAR Measurement variability and uncertainty .................................................. 25 5.1. SAR measurement variability ................................................................. 25 5.2. SAR measurement uncertainty .....................................…

Text truncated - open the document above for the full version.

Report No.: S22080803502003 Page 1 of 9 1 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict WCDMA Band5 4132 826.4 22.69 PASS WCDMA Band5 4182 836.4 22.68 PASS WCDMA Band5 4233 846.6 22.60 PASS 2 Peak-to-Average Ratio Band Channel Frequency (MHz) Result (dB) high Limit (dB) Verdict WCDMA Band5 4132 826.4 3.57 13 PASS WCDMA Band5 4182 836.4 3.47 13 PASS WCDMA Band5 4233 846.6 3.84 13 PASS WCDMA Band5 Channel=4132 Report No.: S22080803502003 Page 2 of 9 WCDMA Band5 Channel=4182 WCDMA Band5 Channel=4233 Report No.: S22080803502003 Page 3 of 9 3 Occupied bandwidth Band Channel Frequency (MHz) 99% OBW (kHz) -26dB EBW (kHz) Verdict WCDMA Band5 4132 826.4 4142.141 4677.382 PASS WCDMA Band5 4182 836.4 4126.594 4701.735 PASS WCDMA Band5 4233 846.6 4131.270 4651.165 PASS WCDMA Band5 Channel=4132 Report No.: S22080803502003 Page 4 of 9 WCDMA Band5 Channel=4233 WCDMA Band5 Channel=4182 Report No.: S22080803502003 Page 5 of 9 4 Band edge Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict WCDMA Band5 4132 826.4 824.00 -20.32 -13 PASS WCDMA Band5 4233 846.6 849.14 -20.02 -13 PASS WCDMA Band5 Channel=4233 Report No.: S22080803502003 Page 6 of 9 WCDMA Band5 Channel=4132 Report No.: S22080803502003 Page 7 of 9 5 Out-of-band emissions Band Channel Frequency (MHz) Spur Freq (MHz) Spur Level (dBm) Limit (dBm) Verdict WCDMA Band5 4132 826.4 7547.13 -29.96 -13 PASS WCDMA Band5 4182 836.4 3250.81 -30.02 -13 PASS WCDMA Band5 4233 846.6 3151.61 -30.05 -13 PASS WCDMA Band5 Channel=4132 Report No.: S22080803502003 Page 8 of 9 WCDMA Band5 Channel=4182 WCDMA Band5 Channel=4233 Report No.: S22080803502003 Page 9 of 9 6 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict HSDPA Band5 Subtest1 4132 826.4 21.74 PASS HSDPA Band5 Subtest2 4132 826.4 21.73 PASS HSDPA Band5 Subtest3 4132 826.4 20.62 PASS HSDPA Band5 Subtest4 4132 826.4 20.65 PASS HSDPA Band5 Subtest1 4182 836.4 21.73 PASS HSDPA Band5 Subtest2 4182 836.4 21.60 PASS HSDPA Band5 Subtest3 4182 836.4 20.83 PASS HSDPA Band5 Subtest4 4182 836.4 20.57 PASS HSDPA Band5 Subtest1 4233 846.6 21.62 PASS HSDPA Band5 Subtest2 4233 846.6 21.48 PASS HSDPA Band5 Subtest3 4233 846.6 20.59 PASS HSDPA Band5 Subtest4 4233 846.6 20.42 PASS 7 Conducted output power Band Channel Frequency (MHz) Power (dBm) Verdict HSUPA Band5 Subtest1 4132 826.4 21.07 PASS HSUPA Band5 Subtest2 4132 826.4 21.84 PASS HSUPA Band5 Subtest3 4132 826.4 21.43 PASS HSUPA Band5 Subtest4 4132 826.4 21.90 PASS HSUPA Band5 Subtest5 4132 826.4 21.20 PASS HSUPA Band5 Subtest1 4182 836.4 21.04 PASS HSUPA Band5 Subtest2 4182 836.4 21.71 PASS HSUPA Band5 Subtest3 4182 836.4 21.28 PASS HSUPA Band5 Subtest4 4182 836.4 21.58 PASS HSUPA Band5 Subtest5 4182 836.4 21.07 PASS HSUPA Band5 Subtest1 4233 846.6 20.93 PASS HSUPA Band5 Subtest2 4233 846.6 21.58 PASS HSUPA Band5 Subtest3 4233 846.6 21.21 PASS HSUPA Band5 Subtest4 4233 846.6 21.32 PASS HSUPA Band5 Subtest5 4233 846.6 21.20 PASS
