2APJQ-CC02XXInterceptor Solar, Interceptor Pro, Interceptor

1 Interceptor Solar Covert Scouting Camera Instruction Manual 2 TABLE OF CONTENTS Quick Start Guide .............................................. 5 What You Will Need to Setup the Camera .......... 6 Button and Front Case Diagram ......................... 8 Button and Switch Function...................................8 Understanding the Main Screen Info ............. 12 Me nu Screens.........................................................13 Solar Function.........................................................19 Tricks and Tips/Troubleshooting ...................... 20 Covert Scouting Cameras Warranty ................. 22 3 Congratulations on your purchase of The Interceptor Solar Covert Scouting Camera! We truly value your business and will continue to provide you with top quality customer service should you ever need help with any of our products. Check out our other products on our website at: www.covertscoutingcameras.com COVERT SCOUTING CAMERAS 101 Main St. Superior WI 54880 Technical Support www.feradyne.com/contact Customer Service Phone: (270) 743-1515 4 Downloading the Mobile App Search “Covert Wireless” in your Google Play Store or Apple App Store. Accessing the Web Portal: Open your web browser to: www.covert-wireless.com Accessing the Billing Site: Open your web browser to: https://secure.covert- wireless.com 5 Quick Start Guide 1. Install 8AA batteries or the Interceptor Lithium Battery Tray and up to a 64GB SD card. 2. Find the QR code by clicking the menu button then selecting registration on the first page. 3. In your covert app hit the “+” button on the main covert. 4. Scan the QR code and follow the prompts to add the camera to your account. To Manually Enter Camera Information 1. Open you web browser to https://secure.covert- wireless.com 2. Select the type of plan you would like to add 3. Enter IMEI found on the sticker inside the camera door and the ICCID found on the SIM card. 4. Follow the prompts to select your rate plan, enter your personal/billing information and complete your purchase. 6 What You Will Need to Setup the Camera: - 8 AA Batteries/Covert Lithium Battery Tray - 1 SD Card (Up to 64GB) Installing the Batteries The Interceptor Solar functions on 8 AA batteries or the Interceptor Lithium Battery Tray. To install, click the eject button, slide the battery tray out of the bottom of the unit, and slide each battery into its appropriate slot. Make sure to pay attention to the positive and negative terminal directions which are molded into the front of the battery sleeve. Installing the SD Card Prior to powering up the camera, install a Covert SD card into the slot on the right side of the camera. Push the card in until it clicks, then release. To remove, repeat that process, the card will pop out enough to remove. You can use any size SD card up to 64GB. Please see page 17 for instructions for formatting your SD card. 7 Quick Set Up 1. Install batteries and SD card 2. Add the camera to your Covert Wireless Plan. (See Quick Start Guide) 3. Switch the camera to ON 4. Press Menu, and select your desired settings 5. Mount the camera in your desired location. 6. Leave the camera in the ON position and it will start taking pictures 8 Button and Front Case Diagram ON/OFF Switch SD Card Slot Arrow and OK Buttons Set-Up Screen Battery Tray Eject Button Sim Card Slot Menu Button 9 Button and Switch Function ON/OFF Two Position Switch • OFF Position – The unit will remain OFF as long as the switch is in this position. • ON Position – When the switch is in this position, you will be able to set up your preferred settings in the camera menu. Once your desired settings are chosen, the camera will turn on after sitting idle for 10 seconds. You will see a 10s countdown after which your camera will turn on and begin taking pictures. If the countdown starts and you are not finished setting up your camera, you can hit any button to access the menu and stop the countdown. 10 Button Functions • Arrow Keys – You will use these keys to scroll through the menu, change the settings for your camera, and take a photo or video. o Take Image – to take an image using the arrow keys, simply press the down arrow key and your camera will take a picture. When connected, the camera will automatically upload this manual photo to the app. o Take Video – when in video mode, click the down arrow key and your camera will begin to take a video click the down arrow key again to end the video. • OK Button –You will use this button to select your preferred settings for your camera and view the images stored on your SD card. o To View Images – click the OK button 1 time while in the main screen. Click it again to go back to the main screen. 11 • Menu Button – The menu button, located above the arrow keys, is used to access your camera settings, and delete images stored on your SD card. o To Delete – a fter clicking OK to view your images, click Menu, and it will give you the option to delete that image. 12 Understanding the Main Screen Info When you go to set up your camera you will come to the main screen (pictured below) before you head into your settings. Battery Life Megapixel & Video Setting Cell Reception Date & Time SD Card Storage Connection Status GPS Connection SD Card Status 13 Menu Screens The menu screen is divided into four screens, which you can switch between at the top of the screen with the left or right arrow keys. Screen 1: Camera Registration - Here is where you find the QR code used to add your camera to your covert wireless plan. - In the app click “+” in the bottom right corner of the screen and scan the QR code shown on your camera screen. Image Size - Select your megapixel size: 4, 16 or 32. Capture Number - Select the number of images you would like the camera to take each time it is triggered. Options of 1-9. Video Size - Select your video quality: 720, 1080, 2560. - The higher the number, the greater the quality. 14 Video Length - Select how long of a video you would li…

Text truncated - open the document above for the full version.

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Date: June 17, 2024 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2APJQ-CC02XX Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description PCB Layout PCB Part Placement BOM Tune-up Procedure Schematics.pdf Block Diagram.pdf Operational Description.pdf PCB Layout.pdf PCB Part Placement.pdf BOM.pdf Tune-up Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Signature KAM LAU / Business manager Typed name and Title

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FCC ID: 2APJQ-CC02XX Date: 7/31/2024 Subject: authorization for adding family models To whom it May concern, Statement We would like to confirm the product Interceptor Solar, Interceptor Pro, Interceptor with models Interceptor Solar CC0234, Interceptor Pro CC0227, Interceptor CC0210 are same in RF circuit. Only the model names, solar battery, display screen are different for different market requirement. The product Interceptor Solar with model Interceptor Solar CC0234 have solar battery and display screen. The product Interceptor Pro with model Interceptor Pro CC0227 have display screen without solar battery. The product Interceptor with model Interceptor CC0210 have no solar battery and display screen. Yours sincerely, KAM LAU Business manager KEEPWAY INDUSTRIAL(ASIA)CO.,LTD

Appendix-Interceptor Solar CC0234-Photos Page 3 of 19 2. Photographs –Constructional Details 2.1. EUT – External View FCC ID: 2APJQ-CC02XX Model: Interceptor Solar CC0234 ANT Appendix-Interceptor Solar CC0234-Photos Page 4 of 19 Appendix-Interceptor Solar CC0234-Photos Page 5 of 19 Appendix-Interceptor Solar CC0234-Photos Page 6 of 19 Appendix-Interceptor Solar CC0234-Photos Page 7 of 19 Appendix-Interceptor Solar CC0234-Photos Page 8 of 19

Appendix-Interceptor Solar CC0234-Photos Page 9 of 19 Appendix-Interceptor Solar CC0234-Photos Page 10 of 19 Model: Interceptor CC0210

Label and Label Location

Appendix-Interceptor Solar CC0234-Photos Page 11 of 19 2.2. EUT – Internal View FCC ID: 2APJQ-CC02XX Appendix-Interceptor Solar CC0234-Photos Page 12 of 19 Appendix-Interceptor Solar CC0234-Photos Page 13 of 19 Appendix-Interceptor Solar CC0234-Photos Page 14 of 19 Appendix-Interceptor Solar CC0234-Photos Page 15 of 19

Appendix-Interceptor Solar CC0234-Photos Page 16 of 19 Appendix-Interceptor Solar CC0234-Photos Page 17 of 19 Appendix-Interceptor Solar CC0234-Photos Page 18 of 19 Appendix-Interceptor Solar CC0234-Photos Page 19 of 19

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 9 TEST REPORT Referen ce No. .................... : WTD24D06131645W004 FCC ID ................................ : 2APJQ-CC02XX Applicant ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address .............................. : Flat D,8/F.,Successlnd.Bld G.,No.17 SheungHeiSt., SanPoKong, Kowloon, Hongkong, China Manufacturer .................... : HuaRui Technology(ShenZhen)CO.,Ltd Address .............................. : 401, Building 3, No.32, Dafu Road, Zhangge Community, Fucheng Street, Longhua District, Shenzhen, China Product ............................... : Interceptor Solar, Interceptor Pro, Interceptor Model(s). ............................ : Interceptor Solar CC0234, Interceptor Pro CC0227, Interceptor CC0210 Standards........................... : FCC 47CFR Part 2 Subpart J Section 2.1091 Date of Receipt sample .... : 2024-06-11 Date of Test ....................... : 2024-06-12 to 2024-08-22 Date of Issue ...................... : 2024-09-27 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD24D06131645W004 Page 2 of 9 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2. Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2. CONTENTS ............................................................................................................................................... 2 3. REVISION HISTORY ................................................................................................................................. 3 4. GENERAL INFORMATION ....................................................................................................................... 4 4.1. GENERAL DESCRIPTION OF E.U.T.................................................................................................... 4 4.2. DETAILS OF E.U.T. ......................................................................................................................... 4 4.3. TEST FACILITY ................................................................................................................................ 6 4.4. SUBCONTRACTED ........................................................................................................................... 6 4.5. ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 6 5. TEST SUMMARY ...................................................................................................................................... 7 6. RF EXPOSURE ......................................................................................................................................... 8 6.1. REQUIREMENTS .............................................................................................................................. 8 6.2. THE PROCEDURES / LIMIT ................................................................................................................ 8 6.3. MPE CALCULATION METHOD........................................................................................................... 9 6.4. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ................................................................... 9 Reference No.: WTD24D06131645W004 Page 3 of 9 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 3. Revision History Test Report No. Date of Receipt Sample Date of Test Date of Issue Purpose CommentApproved WTD24D06131645W004 2024-06-11 2024-06-12 to 2024-08-22 2024-09-27Original - Valid Reference No.: WTD24D06131645W004 Page 4 of 9 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 4. General Information 4.1. General Description of E.U.T. Product: Interceptor Solar, Interceptor Pro, Interceptor Model(s): Interceptor Solar CC0234, Interceptor Pro CC0227, Interceptor CC0210 Model Description: Only the product name, model names, solar battery, display screen are different for different market requirement. The product Interceptor Solar with model Interceptor Solar CC0234 have solar battery and display screen. The product Interceptor Pro with model Interceptor Pro CC0227 have display screen without solar battery. The product Interceptor with model Interceptor CC0210 have no solar battery and display screen. The test sample model was Interceptor Solar CC0234. Test Sample No.: 1-1/1 WCDMA Band(s): FDD Band II/IV/V LTE Band(s): FDD Band 2/4/5/12/13/25/26 Hardware Version: Interceptor Solar CC0234: KT899MV04H Interceptor Pro CC0227: KT899MV04M Interceptor CC0210: KT899MV04L Software Version: Interceptor Solar CC0234: CC0234K2C2F2X2921087 Interceptor Pro CC0227: CC0227K2C2F2X2921079 Interceptor CC0210: CC0210K2NLF2X2915084 4.2. Details of E.U.T. Operation Frequency: WCDMA Band II: 1850~1910MHz WCDMA Band V: 824~849MHz WCDMA Band IV:1710~1755MHz LTE Band 2: 1850~1910MHz LTE Band 4: 1710~1755MHz LTE Band 5: 824~849MHz LTE Band 12: 699~716MHz LTE Band 13: 777~787MHz LTE Band 25 1850~1915MHz LTE Band 26(Part 90): 814~824MHz LTE Band 26(Part 22): 824~849MHz Max. RF output power: WCDMA Band II: 22.83dBm WCDMA Band V: 22.91dBm WCDMA Band IV: 22.54dBm LTE Band 2: 23.25dBm LTE Band 4: 23.09dBm LTE Band 5: 23.86dBm LTE Band 12: 23.86dBm LTE Band 13: 23.41dBm LTE Band 25: 23.22dBm LTE Band 26(Part 90): 23.16dBm Reference No.…

Text truncated - open the document above for the full version.

Product No.: Y0HRY00A0AA Version: 1.0 Date: 2024-04-12 Product Name: 4G External Antenna Main Specification: Frequency Range: 700-960MHz, 1710-2690MHz Size: 209.23 × 42.0 × 13.0 mm Efficiency: Max. 81% Comply with RoHS Environmental Standards IP65 Quectel Antenna Specification Y0HRY00A0AA 1 / 8 1 Specifications Test status: Free space - single antenna 1.1. Electrical properties 1.2. Mechanical and Environmental Characteristics Electrical Specifications Frequency Range 700-960MHz, 1710-2690MHz Impedance 50 Ω Polarization mode Linear polarization Radiation pattern Omnidirectional VSWR ≤ 5.1 Peak Gain ≤ 3.5 dBi Mechanical Antenna Size 209.23 × 42.0 × 13.0 mm Housing Material & Color PC/ABS & Black Connector Type RP-SMA-Male Weight about 40.17 g Installation Type Nut locking Environment Operating Temperature -40 °C to +85 °C Storage Temperature -40 °C to +85 °C Waterproof Level IP65 Comply with Environmental Standards RoHS 2 / 8 2 Drawing Y0HRY00A0AA 3 / 8 3 Detailed Performance Parameters 3.1. S Parameter Test 3.1.1. VSWR 1 2 3 4 5 6 7 8 9 10 500700900 1100130015001700190021002300250027002900 VSWR Frequency(MHz) VSWR Free Space VSWR F (MHz) 600 630 710 830 900 960 1440 1710 1740 1880 VSWR - - 1.8 2.4 2.4 2.2 - 1.8 1.9 1.3 F (MHz) 1950 2140 2350 2450 2600 2690 4700 5000 5500 6000 VSWR 1.2 1.1 2.4 3.8 5.1 4.5 - - - - Y0HRY00A0AA 4 / 8 3.2. Radiation Performance Test 3.2.1. Efficiency 0 10 20 30 40 50 60 70 80 90 100 700750800850900950 100017101760181018601910196020102060211021602210226023102360241024602510256026102660 Efficiency(%) Frequency(MHz) Efficiency Free Space Efficiency (%) F (MHz) 600 630 710 830 900 960 1440 1710 1740 1880 Efficiency(%) - - 81.0 61.2 53.6 49.0 - 62.2 66.4 71.6 F (MHz) 1950 2140 2350 2450 2600 2690 4700 5000 5500 6000 Efficiency(%) 76.9 78.5 67.0 51.0 41.4 43.9 - - - - Y0HRY00A0AA 5 / 8 3.2.2. Peak Gain -2 -1 0 1 2 3 4 700750800850900950 100017101760181018601910196020102060211021602210226023102360241024602510256026102660 Peak Gain(dBi) Frequency(MHz) Peak Gain Free Space Peak Gain (dBi) F (MHz) 600 630 710 830 900 960 1440 1710 1740 1880 Peak Gain (dBi) - - 0.6 0.2 0.6 1.2 - 1.5 1.6 2.2 F (MHz) 1950 2140 2350 2450 2600 2690 4700 5000 5500 6000 Peak Gain (dBi) 2.2 3.3 3.1 1.3 1.4 1.8 - - - - Y0HRY00A0AA 6 / 8 3.2.3. 2D Radiation Pattern ⚫ ⚫ Test status: Free space - single antenna Test Lab: SZ-S-1 710 MHz 830 MHz Z X Y × Y0HRY00A0AA 7 / 8 900 MHz 1740 MHz 1880 MHz 1950 MHz 2140 MHz 2350 MHz Y0HRY00A0AA 8 / 8 2450 MHz 2600 MHz Y0HRY00A0AA

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 58 TEST REPORT Referen ce No. .................... : WTD24D06131645W002 FCC ID ................................ : 2APJQ-CC02XX Applicant ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address .............................. : Flat D,8/F.,Successlnd.Bld G.,No.17 SheungHeiSt., SanPoKong, Kowloon, Hongkong, China Manufacturer .................... : HuaRui Technology(ShenZhen)CO.,Ltd Address .............................. : 401, Building 3, No.32, Dafu Road, Zhangge Community, Fucheng Street, Longhua District, Shenzhen, China Product ............................... : Interceptor Solar, Interceptor Pro, Interceptor Model(s). ............................ : Interceptor Solar CC0234, Interceptor Pro CC0227, Interceptor CC0210 Standards........................... : FCC CFR47 Part 22 Subpart H FCC CFR47 Part 24 Subpart E FCC CFR47 Part 27 Subpart L Date of Receipt sample .... : 2024-06-11 Date of Test ....................... : 2024-06-12 to 2024-06-26 Date of Issue ...................... : 2024-09-27 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD24D06131645W002 Page 2 of 58 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 3 4 GENERAL INFORMATION ....................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF E.U.T. ...................................................................................................... 4 4.2 DETAILS OF E.U.T. .............................................................................................................................. 4 4.3 TEST MODE ........................................................................................................................................ 5 4.4 TEST FACILITY .................................................................................................................................... 5 5 TEST SUMMARY ...................................................................................................................................... 6 6 EQUIPMENT USED DURING TEST ......................................................................................................... 7 6.1 EQUIPMENTS LIST ............................................................................................................................... 7 6.2 MEASUREMENT UNCERTAINTY ............................................................................................................. 8 7 RF OUTPUT POWER................................................................................................................................ 9 7.1 EUT OPERATION ................................................................................................................................. 9 7.2 TEST PROCEDURE ............................................................................................................................... 9 7.3 TEST RESULT .................................................................................................................................... 10 8 PEAK-TO-AVERAGE RATIO ................................................................................................................. 14 8.1 EUT OPERATION ............................................................................................................................... 14 8.2 TEST PROCEDURE ............................................................................................................................. 14 8.3 TEST RESULT .................................................................................................................................... 15 9 BANDWIDTH ........................................................................................................................................... 17 9.1 EUT OPERATION ............................................................................................................................... 17 9.2 TEST PROCEDURE ............................................................................................................................. 17 9.3 TEST RESULT .................................................................................................................................... 18 10 SPURIOUS EMISSIONS AT ANTENNA TERMINALS .......................................................................... 26 10.1 EUT OPERATION .......................................................................................................................... 26 10.2 TEST PROCEDURE ........................................................................................................................ 26 10.3 TEST RESULT ............................................................................................................................... 27 11 SPURIOUS RADIATED EMISSIONS ..............…

Text truncated - open the document above for the full version.

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn Page 1 of 124 TEST REPORT Re ference No. .................... : WTD24D06131645W003 FCC ID ................................ : 2APJQ-CC02XX Applicant ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address .............................. : Flat D,8/F.,Successlnd.Bld G.,No.17 SheungHeiSt., SanPoKong, Kowloon, Hongkong, China Manufacturer .................... : HuaRui Technology(ShenZhen)CO.,Ltd Address .............................. : 401, Building 3, No.32, Dafu Road, Zhangge Community, Fucheng Street, Longhua District, Shenzhen, China Product ............................... : Interceptor Solar, Interceptor Pro, Interceptor Model(s). ............................ : Interceptor Solar CC0234, Interceptor Pro CC0227, Interceptor CC0210 Standards........................... : FCC CFR47 Part 22 Subpart H FCC CFR47 Part 24 Subpart E FCC CFR47 Part 27 FCC CFR47 Part 90 Date of Receipt sample .... : 2024-06-11 Date of Test ....................... : 2024-06-12 to 2024-08-22 Date of Issue ...................... : 2024-09-27 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Ford Wang / Project Engineer Deval Qin / Designated Reviewer Reference No.: WTD24D06131645W003 Page 2 of 124 Waltek Testing Group Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................... 2 3 REVISION HISTORY ................................................................................................................................. 4 4 GENERAL INFORMATION ....................................................................................................................... 5 4.1 GENERAL DESCRIPTION OF E.U.T. ...................................................................................................... 5 4.2 DETAILS OF E.U.T. .............................................................................................................................. 5 4.3 TEST MODE ........................................................................................................................................ 7 4.4 TEST FACILITY .................................................................................................................................... 9 5 TEST SUMMARY .................................................................................................................................... 10 6 EQUIPMENT USED DURING TEST ....................................................................................................... 11 6.1 EQUIPMENTS LIST ............................................................................................................................. 11 6.2 MEASUREMENT UNCERTAINTY ........................................................................................................... 12 7 RF OUTPUT POWER.............................................................................................................................. 13 7.1 EUT OPERATION ............................................................................................................................... 13 7.2 TEST PROCEDURE ............................................................................................................................. 13 7.3 TEST RESULT .................................................................................................................................... 14 8 PEAK-TO-AVERAGE RATIO ................................................................................................................. 70 8.1 EUT OPERATION ............................................................................................................................... 70 8.2 TEST PROCEDURE ............................................................................................................................. 70 8.3 TEST RESULT .................................................................................................................................... 70 9 BANDWIDTH ........................................................................................................................................... 71 9.1 EUT OPERATION ............................................................................................................................... 71 9.2 TEST PROCEDURE ............................................................................................................................. 71 9.3 TEST RESULT .................................................................................................................................... 71 10 SPURIOUS EMISSIONS AT ANTENNA TERMINALS .......................................................................... 72 10.1 EUT OPERATION .......................................................................................................................... 72 10.2 TEST PROCEDURE ........................................................................................................................ 72 10.3 TEST RESULT ............................................................................................................................... 72 11 SPURIOUS RADIATED EMISSIONS ............…

Text truncated - open the document above for the full version.

Reference No.: WTD24D06131645W003 LTE_Band2 Page 1 of 170 Annex E. LTE Band Edge Reference No.: WTD24D06131645W003 LTE_Band2 Page 2 of 170 1. LTE_Band2 1.1. LTE Band Edge(NTNV)(Subtest:1, Channel:18607, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep P…
