2APJQKG865WIfi Trail Camera

This is the newest scouting camera which is designed for activity and is resistant against water and snow. It is equipped with built-in infrared sensor, so that it can be triggered accurately by heat sources, then take high quality pictures or videos. Please refer to the notes below to ensure that you are completely satisfied with this product. Contents Highly Recommended by Outdoor Explorers - WIFI Wildlife Scouting CamInstruction Book 1 KEEPTIME 2 3 4 5 6 7 7 8 9-12 13-24 25 26-27 28 Features/Quick Start Note before use View Drawings Camera Overview Standard Accessories Power Supply SD Card Operational Modes Setting WIFI Function Mounting and Positioning Specification Warranty Card Quick Start 2 KEEPTIME ※ Move the latch and open the camera case ※ Load 8 lithium AA(non-rechargeable) or alkaline AA batteries ※ Insert the SD card ※ Switch to the SETUP Mode. ※ Press " UP/DOWN " key to select Video/camera Mode ※ Press " MENU " key to setting camera function ※ Switch to the ON Mode ※ Close the case and position the camera for using Features 1.Wifi funcation, you can preview, download, delete, take photo/video, change settings, check battery and memory capacity in APP. 2.During day, sharp and clear images and during night, clear black and white image. 3.Impressively quick trigger time 0.4S. 4.Lockable and password protection. 5.Extremely low power consumption in standby operation providing extremely long operation times. 1. When setting camera parameters, please put camera in Setup mode. 2. To replace the battery, SD card, firstly turn camera to OFF mode. 3. Color of Indicator 1) When camera is updating firmware, indicator light flashes green. 2) The indicator light flashes red when it is turned on or ready for operation. 3) low battery, the indicator light flashes blue. 4) long standby time, the indicator flashes purple. 5. Batteries need to use dry batteries, do not use rechargeable batteries. 6. When the SD card is inserted into camera, make sure that the SD card is not in lock state. 7. When using an external power supply, make sure that voltage is6V. 8. Please take out the battery to avoid leakage of the battery if camera is not used for a long time. 9. Camera can not be directly immersed in water, can not be placed in the environment of strong acid and alkali. 10. Don't use your fingers to press the Fresnel lens. 11. Keep the lens and battery compartment clean. 12. Do not use sharp hard objects to scratch screen. 3 KEEPTIME Notes Before Use View Drawings 4 KEEPTIME Camera Overview 5 KEEPTIME DC port load batteryDisplay screen Latch PIR Sensor DC in jack Lens IR LED LED indicator Standard Accessories 1× Case 1× Manual 1×Belt1× USB Other Accessories (not included) 1×Security Case 1×External battery connection wire 1×solar panel 1×Cradle Head 6 KEEPTIME Power Supply After opening the latch on the right side of the camera, you will see that it has 8 battery slots. Please use 8 lithium AA or alkaline AA batteries. Please be sure to insert each battery with correct polarity (negative or “flat”end against the long spring of each battery slot). SD Card Insert the SD card before beginning to operate the camera. SD card is supported up to maximum 64GB capacity. 64GB 7 KEEPTIME ●「ON」Mode In the ON mode you can check and change the settings of the cam with the help of built-in LCD. Moving the power switch to the ON position will turn on the LCD display and you will see an information screen as below. The cam has two basic operational modes: 「OFF」, 「ON」 ● 「OFF 」Mode When cam is in OFF mode, you can do the following: • Replacing the SD card or batteries • Connecting cam with other device by USB port It will occur a little of power consumption under OFF mode. If you won't use it for a long time, please take batteries off. 5M 1080P 00000/00888 00:00:00 Camera Mode SD Card Battery Level Video Mode Image Resolution of Photos Taken Video Resolution Available Video Recording Time KEEPTIME 2020/11/18 13:15:452020/11/18 13:15:45 8 Operational Modes KEEPTIME Setting Mode:Photo, Video, Photo+Video PIR Interval: Defaulted 30seconds, optional from 10seconds to 60minutes. The camera won't record any image or videos during the selected interval. PIR Sensitivity:High, Medium, Low IR LED:Auto, Super fine, Economy Time Lapse: Off/ON(ptioanl from 5seconds to 24hours) When selected on, the camera will take photo/video automatically in the selected time interval no matter the PIR sensor has detected a motion or not. Note: In this mode, PIR function still working, camera would take photo/video in the iterval time when PIR sensor detect a motion. Working Time: off/on When select ON mode, camera only active within a certain time. eg: Set start time to 17:35 and end time to 7:25, the camera will be operational from 5:35pm of the current day until 7:25 am of the next day. Camera won't be triggered and won't take any photos/videos outside thie period. 9 KEEPTIME Setting Image Size:2M, 3M, 5M(Recomend), 8M Picture Number: 1-10 photos. Select the number of photos to be taken in succesion.( Available on Photo mode) Shutter speed:1/30,1/20, 1/15 Video Size:360P,480P, 720P, 1080P,1296P Video Length: 5-180 seconds Specify the duration of a video recording when the camera is triggered automatically. Video's recording period won't be limited in Setup mode. Video Sound:on/off 10 KEEPTIME Setting Language:English,French,Spanish, Portuguese, German,Italian, simplified Chinese,Chinese Traditional, Russian, Japanese. Default Setting:Press “OK” to reset the camera to default setting. Format:Press”OK” to format the SD card, all file will be delected by formating. Date/Time: Set day and time Time Format: 24H/12H Date Stamp:On/Off Select “ON” to print the date, time, temperature, battery state and camera's name Camera Name:KW865WF The name can be a combination of 10 digits, 26 big letters and 26 small letters. Password Setting: off/on Select “On” will enter a four digit password to prtect your camera against unauthorised access. This passwor…

Text truncated - open the document above for the full version.

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Date: 2021-03-10 Dear Sir/Madam, We, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: WIfi Trail Camera Model No.: KG865, KG866, KW865, KW866, KW867, OM865, KG867 FCC ID: 2APJQKG865 Sincerely, Name/Title： KAM LAU/Manager Company: KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address: FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Phone: (86) 15017967565 Fax: (86) 755-83996051 E-Mail: [email protected] Stop

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/03/10 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: Model No.: KG865, KG866, KW865, KW866, KW867, OM865, KG867 FCC ID: 2APJQKG865 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： KAM LAU/Manager Company: KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address: FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Phone: (86) 15017967565 Fax: (86) 755-83996051 E-Mail: [email protected] Stop

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Date: 2021-03-10 FCC ID: 2APJQKG865 Model Number: KG865 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD, declare that this EUT (FCC ID: 2APJQKG865) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： KAM LAU/Manager Company: KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address: FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Phone: (86) 15017967565 Fax: (86) 755-83996051 E-Mail: [email protected] Stop

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong,Kowloon,HongKong Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/03/10 To whom it may concern: We, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2APJQKG865 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： KAM LAU/Manager Company: KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address: FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Phone: (86) 15017967565 Fax: (86) 755-83996051 E-Mail: [email protected] Stop

FCC ID: 2APJQKG865 FCC ID: 2APJQKG865 FCC ID: 2APJQKG865

FCC ID: 2APJQKG865 WIfi Trail Camera Model No.: KG865 FCC ID : 2APJQKG865 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2APJQKG865 FCC ID: 2APJQKG865 WIFI ANT BT ANT FCC ID: 2APJQKG865

RF Exposure evaluation FCC ID: 2APJQKG865 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information KG865 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Antenna type and antenna number Operate frequency band Maximum antenna gain BT ANT / PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 2.4GWIFI ANT / FPC Antenna 2.4GHz – 2.5 GHz 2.0 dBi 5. Conducted power [2.4GHz WIFI] Mode Channel Frequency Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 18.96 6 2437 18.75 11 2462 18.81 IEEE 802.11g 1 2412 16.21 6 2437 17.85 11 2462 17.98 IEEE 802.11n HT20 1 2412 17.32 6 2437 17.50 11 2462 17.47 [2.4GHz BLE] Mode Channel Frequency Peak Conducted Output Power (dBm) BLE 00 2402 -3.87 19 2440 -4.74 39 2480 -5.18 6. Manufacturing Tolerance 2.4GHz WLAN Frequency (MHz) IEEE 802.11b (Peak) 2412 2437 2462 Target (dBm) 18.0 18.0 18.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11g (Peak) 2412 2437 2462 Target (dBm) 17.0 17.0 17.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) IEEE 802.11n HT20 (Peak) 2412 2437 2462 Target (dBm) 17.0 17.0 17.0 Tolerance ± (dB) 1.0 1.0 1.0 2.4GHz BLE Frequency (MHz) GFSK (Peak) 2402 2440 2480 Target (dBm) -4.50 -4.50 -4.50 Tolerance ± (dB) 1.0 1.0 1.0 7. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of WIFI antenna is 2.0dBi, the gain of BT antenna is 0dBi.the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW WIFI 19.0 79.43282347 2.00 1.584893 0.025058 1.0000 BLE -3.50 0.446683592 0.00 1.00000 0.000089 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Summary simultaneous transmission results The sample supports 2 antennas for 2.4G WLAN and BT. The BT antenna and WLAN antenna can transmit simultaneous. According to KDB447498 for Transmitters used in mobile exposure conditions for simultaneous transmission operations; ∑ of MPE ratios ≤ 1.0 BLE and WIFI for simultaneous transmission MPE BLE (mW/cm 2 ) MPE wifi (mW/cm 2 ) ∑MPE ratios Limit Results 0.000089 0.025058 0.025147 1.0 PASS 9. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20210309017-1-1 2APJQKG865 Compiled by ( position+printed name+signature) . : File administrators Jimmy Wang Supervised by ( position+printed name+signature) . : Test Engineer Aaron Tan Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Jan.30, 2021 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address ............................................ : FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : WIfi Trail Camera Trade Mark ....................................... : N/A Manufacturer .................................... : HuaRui Technology(ShenZhen)CO.,Ltd Model/Type reference ...................... : KG865 Listed Models .................................. : KG866, KW865, KW866, KW867, OM865, KG867 Modulation Type ............................... : CCK/DSSS/ OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 6V From Battery and DC 5V From external circuit Result ............................................... : PASS Report No.: GTS20210309017-1-1 Page 2 of 38 T E S T R E P O R T Equipment under Test : WIfi Trail Camera Model /Type : KG865 Listed Models : KG866, KW865, KW866, KW867, OM865, KG867 Applicant : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address : FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong,Kowloon,HongKong Manufacturer : HuaRui Technology(ShenZhen)CO.,Ltd Address : 401,building 3,No.32,Dafu Road,Zhangge community,Fucheng street,Longhua District,Shenzhen Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210309017-1-1 Page 3 of 38 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Conducted Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 32 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 33 6 P H O T O S O F T H E E U T ........................................................... 34 Report No.: GTS20210309017-1-1 Page 4 of 38 1 TES T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20210309017-1-1 Page 5 of 38 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jan. 24, 2021 Testing commenced on : Jan. 24, 2021 Testing concluded on : Mar. 09, 2021 2.2 Product Description Product Name: WIfi Trail Camera Model/Type reference: KG865 Power supply: DC 6V From Battery and DC 5V From external circuit Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS20210309017-1-1-1#(Engineer sample), GTS20210309017-1-1-2#(Normal sample) Software version: V1.0 Hardware version: V1.0 WIFI : Supported type: 802.11b/802.11g/802.11n(H20) Modulation: 802.11b: DSSS 802.11g/802.11n(H20): OFDM Operation frequency: 802.11b/802.11g/802.11n(H20): 2412MHz~2462MHz Channel number: 802.11b/802.11g/802.11n(H20): 11 Channel separation: 5MHz Antenna type: FPC antenna Antenna gain: 2.00 dBi 2.3 Equipment Under Test Power supply …

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20210309017-1-2 2APJQKG865 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Mar. 09, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address ............................................ : FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: WIfi Trail Camera Trade Mark ....................................... : N/A Manufacturer .................................... : HuaRui Technology(ShenZhen)CO.,Ltd Model/Type reference....................... : KG865 Listed Models .................................. : KG866, KW865, KW866, KW867, OM865, KG867 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 6V From Battery and DC 5V From external circuit Result................................................ : PASS Report No.: GTS20210309017-1-2 Page 2 of 29 T E S T R E P O R T Equipment under Test : WIfi Trail Camera Model /Type : KG865 Listed Models : KG866, KW865, KW866, KW867, OM865, KG867 Applicant : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address : FlatD,8/F.,Successlnd.Bld G.,No.17SheungHeiSt.,SanPoKong, Kowloon,HongKong Manufacturer : HuaRui Technology(ShenZhen)CO.,Ltd Address : 401,building 3,No.32,Dafu Road,Zhangge community,Fucheng street,Longhua District,Shenzhen Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210309017-1-2 Page 3 of 29 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emissions and Band Edge 13 4.3 Maximum Peak Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 22 4.6 Out-of-band Emissions 24 4.7 Antenna Requirement 27 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 28 6 P H O T O S O F T H E E U T ........................................................... 29 Report No.: GTS20210309017-1-2 Page 4 of 29 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20210309017-1-2 Page 5 of 29 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jan. 24, 2021 Testing commenced on : Jan. 24, 2021 Testing concluded on : Mar. 09, 2021 2.2 Product Description Product Description: WIfi Trail Camera Model/Type reference: KG865 Power supply: DC 6V From Battery and DC 5V From external circuit Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A Testing sample ID： GTS20210309017-1-1-1#(Engineer sample), GTS20210309017-1-1-2#(Normal sample) Software version: V1.0 Hardware version: V1.0 Bluetooth BLE Supported type: Bluetooth low Energy Modulation: GFSK Operation frequency: 2402MHz to 2480MHz Channel number: 40 Channel separation: 2 MHz Antenna type: PCB antenna Antenna gain: 0.0 dBi 2.3 Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 6V From Battery and DC 5V From external circuit 2.4 Short description of the Equipment under Test (EUT) Th…

Text truncated - open the document above for the full version.

FCC ID: 2APJQKG865 _______________________________________________________________________________________________ 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2APJQKG865 _______________________________________________________________________________________________ 1.2. Photo of Conducted testing Measurement Fig. 3
