2APJQ-WC30895VCovert Wireless Trail Camera

WC30‐V Covert Scouting Camera Instruction Manual 1 Table of Contents Quick Start Guide ................................................................................................................................................................... 3 What You Will Need to Set Up Your Camera ........................................................................................................................ 4 Installing the Batteries ....................................................................................................................................................... 4 Installing the SD Card ......................................................................................................................................................... 4 Camera Button Control Diagram ........................................................................................................................................... 4 Button and Switch Functions ................................................................................................................................................. 5 Understanding Main Screen Information .............................................................................................................................. 5 SET UP SCREENS............................................................................................................................... ....................................... 6 Set Clock.............................................................................................................................................................................. 6 Mode ................................................................................................................................................................................... 6 Image Size ........................................................................................................................................................................... 6 Capture Number ................................................................................................................................................................. 6 Image Format ..................................................................................................................................................................... 6 Video Size............................................................................................................................................................................ 6 Video Length ....................................................................................................................................................................... 6 Camera Name ..................................................................................................................................................................... 6 Trigger Switch ..................................................................................................................................................................... 6 Interval ................................................................................................................................................................................ 6 Work Period ........................................................................................................................................................................ 7 Time Lapse .......................................................................................................................................................................... 7 Night Image ........................................................................................................................................................................ 7 Sensor Level ........................................................................................................................................................................ 7 Password ............................................................................................................................................................................. 7 Overwrite ............................................................................................................................................................................ 8 Wireless .............................................................................................................................................................................. 8 Send Mode .......................................................................................................................................................................... 8 Format................................................................................................................................................................................. 8 Default ................................................................................................................................................................................ 8 Tricks and Tips on Field Setup ................................................................................................................................................ 8 Covert Scouting Cameras Warranty....................................................................................................................................... 9 Covert Warranty Policy and Procedure ............................................................................................................................. 9 Covert International Warranty Policy and Procedure ...................................................................................................... 9 2 Congratulations on your purchase of the WC30‐A/WC30‐V Covert Scouting Camera! We truly value your business and will continue to provide you top quality customer service sho…

Text truncated - open the document above for the full version.

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Date: 2021-03-23 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: To Whom It May Concern: This letter is to statement that WC30-V, CT895V / Covert Wireless Trail Camera. has been tested according to FCC Part 15B by Waltek Testing Group Co., Ltd. (Test Report No.: WTD21D02012819E). And the SDOC file, meetting the requirements of the FCC regulations, would been provided when the device is sold by the responsible party in US. The service will not be sold until the SDOC is provided. If the sale does not have an SDOC, all responsibility is the responsibility of the applicant. Sincerely, Signature [KAM LAU] [Business manager] [KEEPWAY INDUSTRIAL(ASIA)CO.,LTD] 2APJQ-WC30895V

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Date: Mar. 23, 2021 Federal Communications Commission Authorization and Evaluation Division Co nfidentiality Request regarding application for certification of FCC ID: 2APJQ-WC30895V Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf Part List Part Placement Schematics PCB Layout Schematics Tune-up Procedure Part List.pdf Part Placement Schematics.pdf PCB Layout Schematics.pdf Tune-up Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Signature KAM LAU / Business manager Typed name and Title

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FCC ID: POWER OF ATTORNEY Date: Mar. 23, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on Mar. 22, 2022. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Signature KAM LAU / Business manager Typed name and Title 2APJQ-WC30895V

KEEPWAY INDUSTRIAL(ASIA)CO.,LTD FCC ID: Date: 3/23/2021 Subject: authorization for adding family models To whom it May concern, Statement We would like to confirm the product Covert Wireless Trail Camera with models WC30-V, CT895V are same in all respects. Only the model names are different for different market requirement. Yours sincerely, [signature] [KAM LAU] [Business manager] [KEEPWAY INDUSTRIAL(ASIA)CO.,LTD] 2APJQ-WC30895V

Appendix- WC30-V -Photos Page 1 of 5 Photographs –Constructional Details EUT – External View Model WC30-V FCC ID: 2APJQ-WC30895V Appendix- WC30-V -Photos Page 2 of 5 Appendix- WC30-V -Photos Page 3 of 5 Appendix- WC30-V -Photos Page 4 of 5 Appendix- WC30-V -Photos Page 5 of 5 LTE ANT.

39.7mm 25.7mm

Appendix- WC30-V -Photos Page 1 of 8 Photographs –Constructional Details EUT – Internal View Model WC30-V FCC ID: 2APJQ-WC30895V Appendix- WC30-V -Photos Page 2 of 8 Appendix- WC30-V -Photos Page 3 of 8 Appendix- WC30-V -Photos Page 4 of 8 Appendix- WC30-V -Photos Page 5 of 8 Appendix- WC30-V -Photos Page 6 of 8 Appendix- WC30-V -Photos Page 7 of 8 Appendix- WC30-V -Photos Page 8 of 8

Waltek Testing Group Co., Ltd. http://www.waltek.com.cn TEST REPORT Referen ce No. .................... : WTD21D02012814W002 FCC ID ................................ : 2APJQ-WC30895V Applicant ............................ : KEEPWAY INDUSTRIAL(ASIA)CO.,LTD Address .............................. : Flat D, 8/F., Successlnd.Bld G., No.17, SheungHeiSt., SanPoKong, Kowloon ,Hongkong Manufacturer .................... : HUARUI TECHNOLOGY(SHENZHEN)CO.,LTD Address .............................. : 401, building 3, No.32, Dafu Road,Zhangge community, Fuchen g street, Lo nghua District, Shenzhen, China Product ............................... : Covert Wireless Trail Camera Model(s). ............................ : WC30-V, CT895V Standards........................... : FCC 1.1307 Date of Receipt sample .... : 2021-02-24 Date of Test ....................... : 2021-02-25 to 2021-03-10 Date of Issue ...................... : 2021-03-11 Test Result ......................... : Pass Remarks: The re sults shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group Co., Ltd. Address: No. 77, Houjie Section, Guantai Road, Houjie Town, Dongguan City, Guangdong, China Tel: +86-769-2267 6998 Fax: +86-769-2267 6828 Compiled by: Approved by: Levi Xiao / Project Engineer Daniel Liu / Designated Reviewer Reference No.: WTD21D02012814W002 Page 2 of 7 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................................ 2 3 REVISION HISTORY ............................................................................................................................................ 3 4 GENERAL INFORMATION .................................................................................................................................. 4 4.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................................ 4 4.2 DETAILS OF E.U.T. ......................................................................................................................................... 4 4.3 TEST FACILITY ................................................................................................................................................. 4 5 TEST SUMMARY .................................................................................................................................................. 5 6 RF EXPOSURE ...................................................................................................................................................... 6 6.1 REQUIREMENTS ............................................................................................................................................... 6 6.2 THE PROCEDURES / LIMIT ................................................................................................................................ 6 6.3 MPE CALCULATION METHOD ......................................................................................................................... 7 Reference No.: WTD21D02012814W002 Page 3 of 7 3 Revision History Test report No. Date of Receipt sample Date of Test Date of Issue Purpose Comment Approved WTD21D02012 814W002 2021-02-24 2021-02-25 to 2021-03-10 2021-03-11 original - Valid Reference No.: WTD21D02012814W002 Page 4 of 7 4 General Information 4.1 General Description of E.U.T. Product: Covert Wireless Trail Camera Model(s): WC30-V, CT895V Model Description: Only the model name is different，So choose the model WC30-V for testing LTE Band(s): FDD Band 4/13 Hardware Version: KT895MV08 Software Version: CT895VNC2Lx146018 Highest frequency (Exclude Radio): 26MHz Storage Location: Internal Storage 4.2 Details of E.U.T. Operation Frequency: LTE Band 4: 1710~1755MHz LTE Band 13: 777~787MHz Type of Modulation: QPSK, 16QAM Antenna installation: External antenna with RP-SMA connector Antenna Gain: LTE Band 4: 1.0dBi LTE Band 13: 1.0dBi Ratings: DC 9V 4.3 Test Facility The test facility has a test site registered with the following organizations: ISED CAB identifier: CN0013. Test Firm Registration No.: 7760A. Waltek Testing Group Co., Ltd. Has been registered and fully described in a report filed with the Industry Canada. The acceptance letter from the Industry Canada is maintained in our files. Registration number 7760A, October 15, 2016. FCC Designation No.: CN1201. Test Firm Registration No.: 523476. Waltek Testing Group Co., Ltd. EMC Laboratory `has been registered and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Registration number 523476, September 10, 2019. Reference No.: WTD21D02012814W002 Page 5 of 7 5 Test Summary Test Items Test Requirement Result Maximum Permissible Exposure (Exposure of Humans to RF Fields) 1.1307(b)(1) PASS Reference No.: WTD21D02012814W002 Page 6 of 7 6 RF Exposure Test Requirement: FCC Part 1.1307 Test Mode: The EUT work in test mode(Tx). 6.1 Requirements Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. 6.2 The procedures / limit FCC Part 1.1307: (A) Limits for Occupational / Controlled Exp…

Text truncated - open the document above for the full version.

Page 1 of 58 Annex E. LTE Band Edge Page 2 of 58 1. LTE_Band13 1.1. LTE Band Edge(NTNV)(Subtest:1, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-24.03 Pass 784 Page 3 of 58 1.2. LTE Band Edge(NTNV)(Subtest:2, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-50.73 Pass 784 Page 4 of 58 1.3. LTE Band Edge(NTNV)(Subtest:3, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 773.028-41.49 Pass 784 Page 5 of 58 1.4. LTE Band Edge(NTNV)(Subtest:4, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-27.27 Pass 784 Page 6 of 58 1.5. LTE Band Edge(NTNV)(Subtest:5, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.962-36.81 Pass 784 Page 7 of 58 1.6. LTE Band Edge(NTNV)(Subtest:6, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-40.81 Pass 784 Page 8 of 58 1.7. LTE Band Edge(NTNV)(Subtest:7, Channel:23205, Bandwidth:5, Modulation:QPSK, RB Number: 25, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-31.26 Pass 784 Page 9 of 58 1.8. LTE Band Edge(NTNV)(Subtest:8, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-26.09 Pass 784 Page 10 of 58 1.9. LTE Band Edge(NTNV)(Subtest:9, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-51.54 Pass 784 Page 11 of 58 1.10. LTE Band Edge(NTNV)(Subtest:10, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 773.003-40.4 Pass 784 Page 12 of 58 1.11. LTE Band Edge(NTNV)(Subtest:11, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 12, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-28.88 Pass 784 Page 13 of 58 1.12. LTE Band Edge(NTNV)(Subtest:12, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 12, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-38.96 Pass 784 Page 14 of 58 1.13. LTE Band Edge(NTNV)(Subtest:13, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 12, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-42.95 Pass 784 Page 15 of 58 1.14. LTE Band Edge(NTNV)(Subtest:14, Channel:23205, Bandwidth:5, Modulation:Q16, RB Number: 25, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 777 20 0.051 RMS 776.987-32.97 Pass 784 Page 16 of 58 1.15. LTE Band Edge(NTNV)(Subtest:15, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 790.946-36.19 Pass 784 Page 17 of 58 1.16. LTE Band Edge(NTNV)(Subtest:16, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.013-48.54 Pass 784 Page 18 of 58 1.17. LTE Band Edge(NTNV)(Subtest:17, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.013-22.06 Pass 784 Page 19 of 58 1.18. LTE Band Edge(NTNV)(Subtest:18, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.013-37.93 Pass 784 Page 20 of 58 1.19. LTE Band Edge(NTNV)(Subtest:19, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.038-29.05 Pass 784 Page 21 of 58 1.20. LTE Band Edge(NTNV)(Subtest:20, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 12, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.013-23.4 Pass 784 Page 22 of 58 1.21. LTE Band Edge(NTNV)(Subtest:21, Channel:23255, Bandwidth:5, Modulation:QPSK, RB Number: 25, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 787.013-26.64 Pass 784 Page 23 of 58 1.22. LTE Band Edge(NTNV)(Subtest:22, Channel:23255, Bandwidth:5, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 787 20 0.051 RMS 790.946-36.97 Pass 784 Page 24 of 58 1.23. LTE Band Edge(NTNV)(Subtest:23…

Text truncated - open the document above for the full version.

Page 1 of 170 Annex E. LTE Band Edge Page 2 of 170 1. LTE_Band4 1.1. LTE Band Edge(NTNV)(Subtest:1, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.989-25.7 Pass 2666 Page 3 of 170 1.2. LTE Band Edge(NTNV)(Subtest:2, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.959-48.34 Pass 2666 Page 4 of 170 1.3. LTE Band Edge(NTNV)(Subtest:3, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.448-48.82 Pass 2666 Page 5 of 170 1.4. LTE Band Edge(NTNV)(Subtest:4, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-26.49 Pass 2666 Page 6 of 170 1.5. LTE Band Edge(NTNV)(Subtest:5, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-34.7 Pass 2666 Page 7 of 170 1.6. LTE Band Edge(NTNV)(Subtest:6, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-40.12 Pass 2666 Page 8 of 170 1.7. LTE Band Edge(NTNV)(Subtest:7, Channel:19957, Bandwidth:1.4, Modulation:QPSK, RB Number: 6, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-31.59 Pass 2666 Page 9 of 170 1.8. LTE Band Edge(NTNV)(Subtest:8, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-29.82 Pass 2666 Page 10 of 170 1.9. LTE Band Edge(NTNV)(Subtest:9, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.966-48.44 Pass 2666 Page 11 of 170 1.10. LTE Band Edge(NTNV)(Subtest:10, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.336-49.3 Pass 2666 Page 12 of 170 1.11. LTE Band Edge(NTNV)(Subtest:11, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 3, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-24.19 Pass 2666 Page 13 of 170 1.12. LTE Band Edge(NTNV)(Subtest:12, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 3, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.989-38.07 Pass 2666 Page 14 of 170 1.13. LTE Band Edge(NTNV)(Subtest:13, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 3, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.996-41.48 Pass 2666 Page 15 of 170 1.14. LTE Band Edge(NTNV)(Subtest:14, Channel:19957, Bandwidth:1.4, Modulation:Q16, RB Number: 6, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1710 20 0.015 RMS 1709.981-33.74 Pass 2666 Page 16 of 170 1.15. LTE Band Edge(NTNV)(Subtest:15, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.702-47.33 Pass 2666 Page 17 of 170 1.16. LTE Band Edge(NTNV)(Subtest:16, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.026-42.38 Pass 2666 Page 18 of 170 1.17. LTE Band Edge(NTNV)(Subtest:17, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.004-23.42 Pass 2666 Page 19 of 170 1.18. LTE Band Edge(NTNV)(Subtest:18, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.184-37.69 Pass 2666 Page 20 of 170 1.19. LTE Band Edge(NTNV)(Subtest:19, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.079-24.01 Pass 2666 Page 21 of 170 1.20. LTE Band Edge(NTNV)(Subtest:20, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 3, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.026-20.58 Pass 2666 Page 22 of 170 1.21. LTE Band Edge(NTNV)(Subtest:21, Channel:20393, Bandwidth:1.4, Modulation:QPSK, RB Number: 6, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 20 0.015 RMS 1755.019-28.12 Pass 2666 Page 23 of 170 1.22. LTE Band Edge(NTNV)(Subtest:22, Channel:20393, Bandwidth:1.4, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power …

Text truncated - open the document above for the full version.

Page 102 of 170 1.101. LTE Band Edge(NTNV)(Subtest:101, Channel:20350, Bandwidth:10, Modulation:QPSK, RB Number: 1, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1755-31.46 Pass 601 Page 103 of 170 1.102. LTE Band Edge(NTNV)(Subtest:102, Channel:20350, Bandwidth:10, Modulation:QPSK, RB Number: 25, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1755.05-38.87 Pass 601 Page 104 of 170 1.103. LTE Band Edge(NTNV)(Subtest:103, Channel:20350, Bandwidth:10, Modulation:QPSK, RB Number: 25, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1755.05-35.33 Pass 601 Page 105 of 170 1.104. LTE Band Edge(NTNV)(Subtest:104, Channel:20350, Bandwidth:10, Modulation:QPSK, RB Number: 25, RB Position:HIGH) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1755-29.16 Pass 601 Page 106 of 170 1.105. LTE Band Edge(NTNV)(Subtest:105, Channel:20350, Bandwidth:10, Modulation:QPSK, RB Number: 50, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1755.15-32.27 Pass 601 Page 107 of 170 1.106. LTE Band Edge(NTNV)(Subtest:106, Channel:20350, Bandwidth:10, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep Point 1755 30 0.1 RMS 1763.25-44.68 Pass 601 Page 108 of 170 1.107. LTE Band Edge(NTNV)(Subtest:107, Channel:20350, Bandwidth:10, Modulation:Q16, RB Number: 1, RB Position:MID) Center Frequency (MHz) Span (MHz) RBW (MHz) Detector Frequency (MHz) Power (dBm) Verdict Sweep…
