2APNR-GM500U1GLTE Module

Hardware Development Guide Version: V1.0 Date: 2020-11-20 LTE Module Series GM500-U 1G_A Website: www.gosuncnwelink.com E-mail: [email protected] All Rights reserved, No Spreading without GOSUNCN PermissionI GM500-U1G_A Hardware Development Guide Revision History Version Date Description 1.0 2020-11-20 1 st released version All Rights reserved, No Spreading without GOSUNCN PermissionII GM500-U1G_A Hardware Development Guide About This Document A. Application Range This document is the Product Technical Specification for the GM500-U1G_AGSM/WCDMA/LTE-FDD module. It defines the high level product features and illustrates the interface for these features. This document is intended to cover the hardware aspects of the product, including electrical and mechanical. B. Reading Note The symbols below are the reading notes you should pay attention on: : WARNING or ATTENTION : NOTE or REMARK C. Purpose This document provides the hardware solutions and development fundamentals for a product with the module. By reading this document, the user can have an overall knowledge of the module and a clear understanding of the technical parameters. With this document, the user can successfully fulfill the application and development of wireless Internet product or equipment. Besides the product features and technical parameters, this document also provides the product reliability tests and related testing standards, RF performance indexes and a guide on the design of user circuits, to provide the user with a complete design reference. NOTE: To ensure the module manufacturing and welding quality, do as the chapter 7 of Manufacturing Guide in this document. The force on the squeegee should be adjusted so as to produce a clean stencil surface on a single pass and ensure the module soldering quality. D. Abbreviations Table below is a list of abbreviations involved in this document, as well as the English full names. Abbreviations Full Name 3GPP Third Generation Partnership Project AP Another name of DTE CHAP Challenge Handshake Authentication Protocol CE European Conformity CMOS Complementary Metal Oxide Semiconductor DCE Data Communication Equipment DL Downlink DTE Data Terminal Equipment EIA Electronic Industries Association EMC Electromagnetic Compatibility ESD Electro-Static discharge ESR Equivalent Series Resistance FDD Frequency Division Duplex GPIO General-purpose I/O LCC Leadless Chip Carrier All Rights reserved, No Spreading without GOSUNCN PermissionIII GM500-U1G_A Hardware Development Guide LDO Low-Dropout LED Light Emitting Diode LTE Long Term Evolution ME Mobile Equipment MO Mobile Origination Call MT Mobile Termination Call MSB Most Significant Bit PC Personal Computer PCB Printed Circuit Board PDA Personal Digital Assistant PDU Protocol Data Unit PAP Password Authentication Protocol PPP Point to Point Protocol RTC Real Time Clock SMS Short Messaging Service SMT Surface Mount Technology SPI Serial Peripheral Interface TBD To Be Determined TCP Transmission Control Protocol TIS Total Isotropic Sensitivity TRP Total Radiated Power TVS Transient Voltage Suppressor UART Universal Asynchronous Receiver-Transmitter UDP User Datagram Protocol UL Up Link USB Universal Serial Bus USIM Universal Subscriber Identity Module URC Unsolicited result code VIH Logic High level of input voltage VIL Logic Low level of input voltage VOH Logic High level of output voltage VOL Logic Low level of output voltage All Rights reserved, No Spreading without GOSUNCN PermissionIV GM500-U1G_A Hardware Development Guide Safety Information The following safety precautions must be observed during all phases of the operation, such as usage, service or repair of any cellular terminal or mobile incorporating ME3610 module. Manufacturers of the cellular terminal should send the following safety information to users and operating personnel and to incorporate these guidelines into all manuals supplied with the product. If not so, GOSUNCN does not take on any liability for customer failure to comply with these precautions. Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a mobile while driving (even with a hands free kit) cause distraction and can lead to an accident. You must comply with laws and regulations restricting the use of wireless devices while driving. Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it switched off. The operation of wireless appliances in an aircraft is forbidden to prevent interference with communication systems. Consult the airline staff about the use of wireless devices on boarding the aircraft, if your device offers a Airplane Mode which must be enabled prior to boarding an aircraft. Switch off your wireless device when in hospitals or clinics or other health care facilities. These requests are designed to prevent possible interference with sensitive medical equipment. GSM cellular terminals or mobiles operate over radio frequency signal and cellular network and cannot be guaranteed to connect in all conditions, for example no mobile fee or an invalid SIM card. While you are in this condition and need emergent help, please remember using emergency call. In order to make or receive call, the cellular terminal or mobile must be switched on and in a service area with adequate cellular signal strength. Your cellular terminal or mobile contains a transmitter and receiver. When it is on, it receives and transmits radio frequency energy. RF interference can occur if it is used close to TV set, radio, computer or other electric equipment. In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other cellular terminals. Areas with potentially explosive atmospheres including fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles such as grain, dust or metal powders. All Rights res…
