2APNR-GM500U1G1LTE Module

Hardware Development Guide Version: V1.0 Date: 2020-11-20 LTE Module Series GM500-U 1G Website: www.gosuncnwelink.com E-mail: [email protected] All Rights reserved, No Spreading without GOSUNCN PermissionI GM500-U1G Hardware Development Guide Revision History Version Date Description 1.0 2020-11-20 1 st released version All Rights reserved, No Spreading without GOSUNCN PermissionII GM500-U1G Hardware Development Guide About This Document A. Application Range This document is the Product Technical Specification for the GM500-U1G_AGSM/WCDMA/LTE-FDD module. It defines the high level product features and illustrates the interface for these features. This document is intended to cover the hardware aspects of the product, including electrical and mechanical. B. Reading Note The symbols below are the reading notes you should pay attention on: : WARNING or ATTENTION : NOTE or REMARK C. Purpose This document provides the hardware solutions and development fundamentals for a product with the module. By reading this document, the user can have an overall knowledge of the module and a clear understanding of the technical parameters. With this document, the user can successfully fulfill the application and development of wireless Internet product or equipment. Besides the product features and technical parameters, this document also provides the product reliability tests and related testing standards, RF performance indexes and a guide on the design of user circuits, to provide the user with a complete design reference. NOTE: To ensure the module manufacturing and welding quality, do as the chapter 7 of Manufacturing Guide in this document. The force on the squeegee should be adjusted so as to produce a clean stencil surface on a single pass and ensure the module soldering quality. D. Abbreviations Table below is a list of abbreviations involved in this document, as well as the English full names. Abbreviations Full Name 3GPP Third Generation Partnership Project AP Another name of DTE CHAP Challenge Handshake Authentication Protocol CE European Conformity CMOS Complementary Metal Oxide Semiconductor DCE Data Communication Equipment DL Downlink DTE Data Terminal Equipment EIA Electronic Industries Association EMC Electromagnetic Compatibility ESD Electro-Static discharge ESR Equivalent Series Resistance FDD Frequency Division Duplex GPIO General-purpose I/O LCC Leadless Chip Carrier All Rights reserved, No Spreading without GOSUNCN PermissionIII GM500-U1G Hardware Development Guide LDO Low-Dropout LED Light Emitting Diode LTE Long Term Evolution ME Mobile Equipment MO Mobile Origination Call MT Mobile Termination Call MSB Most Significant Bit PC Personal Computer PCB Printed Circuit Board PDA Personal Digital Assistant PDU Protocol Data Unit PAP Password Authentication Protocol PPP Point to Point Protocol RTC Real Time Clock SMS Short Messaging Service SMT Surface Mount Technology SPI Serial Peripheral Interface TBD To Be Determined TCP Transmission Control Protocol TIS Total Isotropic Sensitivity TRP Total Radiated Power TVS Transient Voltage Suppressor UART Universal Asynchronous Receiver-Transmitter UDP User Datagram Protocol UL Up Link USB Universal Serial Bus USIM Universal Subscriber Identity Module URC Unsolicited result code VIH Logic High level of input voltage VIL Logic Low level of input voltage VOH Logic High level of output voltage VOL Logic Low level of output voltage All Rights reserved, No Spreading without GOSUNCN PermissionIV GM500-U1G Hardware Development Guide Safety Information The following safety precautions must be observed during all phases of the operation, such as usage, service or repair of any cellular terminal or mobile incorporating ME3610 module. Manufacturers of the cellular terminal should send the following safety information to users and operating personnel and to incorporate these guidelines into all manuals supplied with the product. If not so, GOSUNCN does not take on any liability for customer failure to comply with these precautions. Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a mobile while driving (even with a hands free kit) cause distraction and can lead to an accident. You must comply with laws and regulations restricting the use of wireless devices while driving. Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it switched off. The operation of wireless appliances in an aircraft is forbidden to prevent interference with communication systems. Consult the airline staff about the use of wireless devices on boarding the aircraft, if your device offers a Airplane Mode which must be enabled prior to boarding an aircraft. Switch off your wireless device when in hospitals or clinics or other health care facilities. These requests are designed to prevent possible interference with sensitive medical equipment. GSM cellular terminals or mobiles operate over radio frequency signal and cellular network and cannot be guaranteed to connect in all conditions, for example no mobile fee or an invalid SIM card. While you are in this condition and need emergent help, please remember using emergency call. In order to make or receive call, the cellular terminal or mobile must be switched on and in a service area with adequate cellular signal strength. Your cellular terminal or mobile contains a transmitter and receiver. When it is on, it receives and transmits radio frequency energy. RF interference can occur if it is used close to TV set, radio, computer or other electric equipment. In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other cellular terminals. Areas with potentially explosive atmospheres including fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles such as grain, dust or metal powders. All Rights reserved, No …

Text truncated - open the document above for the full version.

Applicant/Grantee Gosuncn Technology Group Co., Ltd. /2APNR FCC ID: 2APNR-GM500U1G1 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio portion of this module is shielded, please see exhibition external photos. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The module has buffer modulation/data inputs. Y 3 The modular transmitter must have its own power supply regulation. The module has its own power supply regulation. Please see the schem.pdf Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The requirements of antenna connector and spurious emission have been fulfilled. Please refer to the Test Report exhibition. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Please refer to the Setup Photo exhibition for the stand-alone test configuration. Y equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The Module will be labeled with its own FCC ID, and the instruction on the labeling rule of the end product has been stated in the User Manual of this module. Please refer to the Label and User Manual exhibition. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The required FCC rule has been fulfilled and all the instructions for maintaining compliance have been clearly stated in the User Manual. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Y _________________________________ Contact Person: Xiaoting Chen E-mail: [email protected]

Rev. 1/1/03 Gosuncn Technology Group Co.,Ltd. Date: August 18, 2022 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2APNR-GM500U1G1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Parts List Operation Description Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________________ Contact: Xiaoting Chen E-mail: [email protected]

Gosuncn Technology Group Co.,Ltd. Date: August 18, 2022 Power of Attorney To whom it may concern, Please be notified that I, Xiaoting Chen, have designated Jim Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jim Tsai in Sporton International Inc. on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C 862. This authorization is limited to the product of as following: FCC ID: 2APNR-GM500U1G1 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, Contact: Xiaoting Chen E-mail: [email protected]

1/1 Gosuncn Technology Group Co.,Ltd. Date: August 18, 2022 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : 2APNR-GM500U1G1 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, Public Notice DA 04-1705 of the Commission’s policy and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos  Internal Photos  Test set-up photos  Users Manual The application contains technical information, which Gosuncn Technology Group Co.,Ltd. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Contact: Xiaoting Chen E-mail: [email protected]

Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 1 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 720510 1. External Photograph of EUT Mode 1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 2 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 3 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Mode 2 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 4 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1

IMEI: XXXXXXXXXXXXXXX S/N: XXXXXXXXXXXX MADE IN CHINA Gosuncn Technology Group Co., Ltd. LTE Module FCC ID: 2APNR-GM500U1G1 Model:GM500-U1G

Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 5 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 720510 2. Internal Photograph of EUT WWAN Diversity Antenna Port WWAN Main Antenna Port Mode 1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 6 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 7 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 8 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 9 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 10 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 11 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 12 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 13 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 14 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 15 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 16 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Mode 2 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 17 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 18 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 19 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 20 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 21 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Photographs of EUT Report No.: EP272912 Brand Name: GOSUNCN; Model Name: GM500-U1G Sporton International Inc.(Shenzhen) Page Number : 22 of 22 TEL : 86-755-8637-9589 Report Issued Date : Aug. 30, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1

Sporton International Inc. (ShenZhen) Page Number : 1 of 20 TEL : 86-755-8637-9589 Report Issued Date : Aug. 26, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Report Template No.: BU5-FC15B Version 3.0 FCC Test Report Report No. : FC272912 FCC Test Report APPLICANT : Gosuncn Technology Group Co., Ltd. EQUIPMENT : LTE Module BRAND NAME : GOSUNCN MODEL NAME : GM500-U1G FCC ID : 2APNR-GM500U1G1 STANDARD : 47 CFR Part 15 Subpart B CLASSIFICATION : Certification TEST DATE(S) : Aug. 09, 2022 ~ Aug. 12, 2022 We, Sporton International Inc. (Shenzhen), would like to declare that the tested sample has been evaluated in accordance with the test procedures given in ANSI C63.4-2014 and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Shenzhen), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (ShenZhen) 1/F, 2/F, Bldg 5, Shiling Industrial Zone, Xinwei Village, Xili, Nanshan, Shenzhen, 518055 People’s Republic of China Sporton International Inc. (ShenZhen) Page Number : 2 of 20 TEL : 86-755-8637-9589 Report Issued Date : Aug. 26, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Report Template No.: BU5-FC15B Version 3.0 FCC Test Report Report No. : FC272912 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1. GENERAL DESCRIPTION .......................................................................................................................... 5 1.1. Applicant ............................................................................................................................................ 5 1.2. Manufacturer ..................................................................................................................................... 5 1.3. Product Feature of Equipment Under Test ....................................................................................... 5 1.4. Product Specification of Equipment Under Test ............................................................................... 6 1.5. Modification of EUT ........................................................................................................................... 6 1.6. Test Location ..................................................................................................................................... 7 1.7. Test Software .................................................................................................................................... 7 1.8. Applicable Standards ........................................................................................................................ 7 2. TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1. Test Mode ......................................................................................................................................... 8 2.2. Connection Diagram of Test System ................................................................................................ 9 2.3. Support Unit used in test configuration and system .......................................................................... 9 2.4. EUT Operation Test Setup ................................................................................................................ 9 3. TEST RESULT ........................................................................................................................................... 10 3.1. Test of AC Conducted Emission Measurement .............................................................................. 10 3.2. Test of Radiated Emission Measurement ....................................................................................... 14 4. LIST OF MEASURING EQUIPMENT ........................................................................................................ 19 5. UNCERTAINTY OF EVALUATION ........................................................................................................... 20 APPENDIX A. SETUP PHOTOGRAPHS Sporton International Inc. (ShenZhen) Page Number : 3 of 20 TEL : 86-755-8637-9589 Report Issued Date : Aug. 26, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Report Template No.: BU5-FC15B Version 3.0 FCC Test Report Report No. : FC272912 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FC272912 Rev. 01 Initial issue of report Aug. 26, 2022 Sporton International Inc. (ShenZhen) Page Number : 4 of 20 TEL : 86-755-8637-9589 Report Issued Date : Aug. 26, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2APNR-GM500U1G1 Report Template No.: BU5-FC15B Version 3.0 FCC Test Report Report No. : FC272912 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 15.107 AC Conducted Emission < 15.107 limits PASS Under limit 12.31 dB at 0.150 MHz 3.2 15.109 Radiated Emission < 15.109 limits PASS Under limit 11.39 dB at 30.000 MHz Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Sporton International Inc. (ShenZhen) Page Number : 5 of 20 TEL : 86-755-8637-9589 Report Issued Date : Aug. 26, 2022 FAX : 86-755-8637-9595 Report Version : Rev. 01…

Text truncated - open the document above for the full version.

Sporton International Inc. (ShenZhen) Page Number : A1 of A2 TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC ID : 2APNR-GM500U1G1 FCC Test Report Report No. : FC272912 Appendix A. Setup Photographs <Conducted Emission> Mode 1 Sporton International Inc. (ShenZhen) Page Number : A2 of A2 TEL : 86-755-8637-9589 FAX : 86-755-8637-9595 FCC ID : 2APNR-GM500U1G1 FCC Test Report Report No. : FC272912 <Radiated Emission> Mode 1 LF HF
