2APRB-WNVR-FWR8G1Wireless Network Video Recorder

Step 6: Adding your Cameras Step 8: microSD Card Setup Step 7: Testing your CamerasEnsure you test the connection and functionality of each camera you connect before you mount them. Check for signal strength in the desired placement location and adjust the placement if needed. 1. Insert the microSD card into the slot at the bottom of the hub. 2. Within the Night Owl app, go to the hub settings to quickly format the microSD card. The hub can accommodate a 2.5” internal SATA HDD (Hard Disk Drive) for increased storage. You can purchase a compatible HDD from Night Owl. To install: (a) unplug the wireless hub’s power supply, (b) remove the top cover on the hub, (c) pull out the HDD tray, (d) put the HDD in the tray, (e) secure the HDD using the screws and screw holes, (f) reinsert the HDD tray into the hub and replace the top cover, (g) reconnect the wireless hub’s power supply, and (h) go to the hub settings in the app to quickly format the HDD.IMPORTANT: If both a microSD Card and HDD are inserted, the hub will default all recordings to the HDD. HDD size is limited to 2.5” and cannot support SSDs. 11 Hard Disk Drive Storage (Optional) To view and access your hub from a TV or monitor, simply connect an HDMI cable (not included) from the hub to your TV or monitor. You can use the app to adjust the layout. TV or Monitor Viewing (Optional) Transfer Recordings to a USB Drive You can easily transfer your recordings to a USB drive for long-term storage or sharing. To do this:1. ΖQVHUWD86%ȵDVKGULYHLQWRWKH86%SRUWRQWKHrear of the hub. 2. Go to the hub settings within the app to transfer the selected recordings. IMPORTANT: Hub supports up to USB 2.0 with FAT32 ȴOHV\VWHP Factory ResetMaintenance Tips Resetting the hub to factory default will erase all settings and require you to set up the hub all over again. We recommend this as a last resort. To perform, simply hold the reset button down for 3 seconds. Troubleshooting Hub Not Connecting to Wi-Fi: • Ensure the Wi-Fi network is working by checking other devices. • Verify that you entered the correct Wi-Fi password. • Restart the hub and try reconnecting.Devices Not Pairing with Hub: • Check if the devices are compatible with the hub. • Ensure devices are within range of the hub. • Restart both the hub and the devices, then attempt to pair again.Firmware Update Issues: • Ensure the hub is connected to the Internet.ȏ'RQRWXQSOXJWKHKXEGXULQJDQXSGDWHDȵDVKLQJ blue and red light means it is correctly upgrading ȴUPZDUH • If the update fails, restart the hub, and try again.Loss of Connection or Poor Signal: • Avoid placing the hub near metal objects or electronic devices that can cause interference. • Move the hub to a more central location in your home. 12 13 14 15 16 17 18 19 This hub is compatible with multiple Night Owl Wi-Fi devices. When you choose to add a new camera, the app will ask you what type and walk you through the setup steps. However, you can also scan the QR code below for more in-depth step-by-step instructions. Need Help? For more help, please follow the steps below to access your Series support page:1. Please visit: Support.NightOwlSP.com 2. Enter FWR8 into the Search bar or scan the QR Code QSG-FWR8 4-240509 FCC RADIATION NORMFCCThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.FCC Compliance Statement These limits are designed to provide reasonable protection against frequency interference in residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed or used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in television reception, ZKLFKFDQEHGHWHUPLQHGE\WXUQLQJWKHHTXLSPHQWR΍DQGRQ7KH XVHULVHQFRXUDJHG to try and correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and the receiver. ȏ&RQQHFWWKHHTXLSPHQWLQWRDQRXWOHWRQDFLUFXLWGL΍HUHQWIU RPWKDWWRZKLFKWKH receiver is connected.• Consult the dealer or an experienced radio/TV technician for help.CAUTION!The Federal Communications Commission warns the user that changes or PRGLȴFDWLRQVWRWKHXQLWQRWH[SUHVVO\DSSURYHGE\WKHSDUW\UH VSRQVLEOHIRU compliance could void the user’s authority to operate the equipment. This equipment should be installed and operated with a minimum distance of 8 inches between the radiator and your body. LED Status Lights LED Status Hub Status Powered ON but NOT paired to the appPowered ON and paired to the app&RQȴJXULQJQHWZRUNDQGadding cameraNetworking failedFirmware is being updated Solid RED Solid BLUE Quickly Flashing BLUE Slowly Flashing BLUE Flashing RED and BLUE Reset SYNC HDMI LAN USB DC12V Reset SYNC HDMI LAN USB DC12V Reset SYNC HDMI LAN USB DC12V HDD Tray Supports a 2.5” Hard Drive HDD Tray Supports a 2.5” Hard Drive HDMI Blue LED Status Reset SYNC HDMI LAN USB DC12V Red LED Status 1.2.3.4. Regular Firmware Updates:ȏ.HHSWKHKXEȴUPZDUHXSWRGDWHIRUVHFXULW\DQG performance improvements. • Turn on automatic updates if available.Physical Maintenance: • Dust the hub periodically to ensure proper ventilation. • Keep the hub in a dry, temperature-controlled environment.Regular Checkups: • Periodically check the status of connected devices. 1.2.3. GND Quick Setup Guide Let’s get started What’s Included 2 Hub Details 3 Pre-Setup Checklist To ensure you do not experience any issues getting your hub and cameras connected, please do the following:1. Verify your home Wi-Fi network is working. 2. Make sure you have your network’s name and password. 3. Place the hub in a central location within range o…

Text truncated - open the document above for the full version.

FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of Adapter FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT

FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Appendix IID Label Appendix II ID Label Location

FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 9 Internal of EUT Photo 10 Internal of EUT BT&2.4G WIFI &5G WIFI Antenna 2.4G WIFI Antenna1 2.4G WIFI Antenna2 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 11 Internal of EUT Photo 12 Appearance of PCB FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Photo 15 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202403-0339-1 Page: 1 of 4 TB-RF-073-3.0 1/F., Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 Maximum Permissible Exposure Evaluation FCC ID: 2APRB-WNVR-FWR8G1 1. Client Information Applicant : Guangdong Juan Intelligent Technology Joint Stock Co., Ltd. Address : THE FIRST AND SECOND FLOORS OF BUILDING 2 (PLANT NO.2), WEST SIDE OF SHANXI VILLAGE, DASHI STREET, PANYU DISTRICT, GUANGZHOU, China Manufacturer : Guangdong Juan Intelligent Technology Joint Stock Co., Ltd. Address : THE FIRST AND SECOND FLOORS OF BUILDING 2 (PLANT NO.2), WEST SIDE OF SHANXI VILLAGE, DASHI STREET, PANYU DISTRICT, GUANGZHOU, China 2. General Description of EUT EUT Name : Wireless Network Video Recorder Models No. : WNVR-FWR8G1-8, WNVR-FWR8G1-81, WNVR-FWR8G1-8-VT4, FWR8-64GB-B43L, FWR8-64GB-F43L, FWR8-64GB-F83L, FWR8-64GB-B44L, WM-FWR8G64-B43L Model Difference : All these models are identical in the same PCB, layout and electrical circuit, the only difference is Different camera to ship with. Sample ID : HC-C-202403-0339-01-01-1#&HC-C-202403-0339-01-01-2# Operation Frequency: (REALTEK 8192FC) 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz Product Description : Operation Frequency: (AIC8800D40L) Bluetooth LE V5.4: 2402MHz~2480MHz 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11ax(HE20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz 802.11ax(HE40): 2422MHz~2452MHz U-NII-1: 5180MHz~5240MHz U-NII-2A: 5260MHz~5320MHz U-NII-2C: 5500MHz~5700MHz U-NII-3: 5745MHz~5825MHz Power Rating : Adapter(CS-1202000) INPUT: 100-240V~50/60Hz 1.5A max OUTPUT: DC 12V/2A Software Version : V1.0.8 Hardware Version : V300P Connecting I/O Port(S) : Please refer to the User's Manual Remark : the MPE report used the EUT-2(HC-C-202403-0339-01-01-2#). Report No.: TBR-C-202403-0339-1 Page: 2 of 4 TB-RF-074-1.0 MPE Calculations 1. Antenna Gain: REALTEK 8192FC Antenna Gain(dBi) Antenna Brand Model Name Type Ant.1 Ant.2 2.4G WIFI N/A N/A PCB 4.61 5.06 AIC8800D40L Antenna Brand Model Name Type Antenna Gain(dBi) Bluetooth LE 3.23 2.4G WIFI 3.23 U-NII-1 4.57 U-NII-2A 5.04 U-NII-2C 5.37 U-NII-3 N/A N/A FPC 5.30 2. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 3. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 4. Simultaneous transmission MPE Considerations According to KDB447498: All transmitters and antennas in the host must be either evaluated for MPE compliance, by measurement or computational modeling, or qualify for the standalone MPE test exclusion in section 7.1. Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. This means that: ∑ of MPE ratios ≤ 1.0 Report No.: TBR-C-202403-0339-1 Page: 3 of 4 TB-RF-074-1.0 5. Standalone MPE Evaluation: Worst Maximum MPE Result(REALTEK 8192FC) Mode N TX Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/cm 2 ) [S] 802.11g 1 15.78 15±1 16 4.61 20 0.02289 Note: N TX = Number of Transmit Antennas RF Output power specifies that Maximum Conducted Peak Output Power. Worst Maximum MPE Result(REALTEK 8192FC) Mode N TX Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/cm 2 ) [S] 802.11g 2 15.95 15±1 16 5.06 20 0.02539 Note: N TX = Number of Transmit Antennas RF Output power specifies that Maximum Conducted Peak Output Power. Worst Maximum MPE Result(AIC8800D40L) Mode N TX Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/cm 2 ) [S] Bluetooth LE 6.643 6±1 7 3.23 20 0.00209 2.4G WIFI 17.00 17±1 18 3.23 20 0.02640 U-NII-1 16.81 16±1 17 4.57 20 0.02855 U-NII-2A 17.05 17±1 18 5.04 20 0.04006 U-NII-2C 16.32 16±1 17 5.37 20 0.03433 U-NII-3 1 16.81 16±1 17 5.30 20 0.03378 Note: NTX= Number of Transmit Antennas RF Output power specifies that Maximum Conducted Peak Output Power. Remark: 1. Output power including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 4. Only the worst power was evaluated for each wireless function Report No.: TBR-C-202403-0339-1 Page: 4 of 4 TB-RF-074-1.0 6. Conclusion: As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure (MPE), Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 7. Summary simultaneous transmission information The sample supports two antennas for Bluetooth and WLAN. The Bluetooth and WLAN can transmit simultaneous. The Bluetooth and WLAN with two different Antenna. According to KDB447498 for Transmitters used in mobile exposure conditions for simultaneous transmission operations; ∑ of MPE ratios ≤ 1.0 8. Summary simultaneous transmission results Antenna1(REALTEK 8192FC) + Antenna2(REALTEK 8192FC) + Antenna1(AIC8800D40L) Maximum Simultaneous transmission MPE Ratios is 0.02289+0.02539+0.04006=0.08834≤1.0 9. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. -----END OF THE REPORT-----

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 1 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 RF Test Data for 2.4G WiFi (Conducted Measurements) General Description of EUT Product Name: Wireless Network Video Recorder Test Model: WNVR-FWR8G1-8 Sample ID: HC-C-202403-0339-01-01-2# Environmental Conditions Temperature: 23.8°C Relative Humidity: 48% Test Voltage: AC 120V Test Engineer: ZKN zhou Note: For a more detailed features description, please refer to the report TBR-C-202403-0339-3 The report only show the worst case data. Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 2 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Contents 1. Duty Cycle ..........................................................................................................................................................................................3 2. Maximum Conducted Output Power ..............................................................................................................................................10 3. -6dB Bandwidth ...............................................................................................................................................................................11 4. Occupied Channel Bandwidth ........................................................................................................................................................24 5. Maximum Power Spectral Density Level .......................................................................................................................................37 6. Band Edge ........................................................................................................................................................................................50 7. Conducted RF Spurious Emission ................................................................................................................................................67 8. Restrict Band ...................................................................................................................................................................................92 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 3 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 1. Duty Cycle Condition Mode Frequency (MHz) Antenna Duty Cycle (%) Correction Factor (dB) 1/T (kHz) NVNT b 2412 Sum 98.73 0.06 0.08 NVNT b 2437 Sum 98.96 0.05 0.08 NVNT b 2462 Sum 99.04 0.04 0.08 NVNT g 2412 Sum 98.10 0.08 0.49 NVNT g 2437 Sum 97.17 0.12 0.49 NVNT g 2462 Sum 92.41 0.34 0.48 NVNT n(HT20) 2412 Sum 94.61 0.24 0.52 NVNT n(HT20) 2437 Sum 97.96 0.09 0.52 NVNT n(HT20) 2462 Sum 95.05 0.22 0.52 NVNT n(HT40) 2422 Sum 95.00 0.22 1.05 NVNT n(HT40) 2437 Sum 90.38 0.44 1.06 NVNT n(HT40) 2452 Sum 92.23 0.35 1.05 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 4 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Test Graphs Duty Cycle NVNT b 2412MHz Sum Duty Cycle NVNT b 2437MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 5 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Duty Cycle NVNT b 2462MHz Sum Duty Cycle NVNT g 2412MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 6 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Duty Cycle NVNT g 2437MHz Sum Duty Cycle NVNT g 2462MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 7 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Duty Cycle NVNT n(HT20) 2412MHz Sum Duty Cycle NVNT n(HT20) 2437MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 8 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Duty Cycle NVNT n(HT20) 2462MHz Sum Duty Cycle NVNT n(HT40) 2422MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 9 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Duty Cycle NVNT n(HT40) 2437MHz Sum Duty Cycle NVNT n(HT40) 2452MHz Sum Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 10 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 2. Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT b 2412 Ant1 12.04 30 Pass NVNT b 2412 Ant2 11.74 30 Pass NVNT b 2412 Sum 14.903 28.15 Pass NVNT b 2437 Ant1 15.26 30 Pass NVNT b 2437 Ant2 15.37 30 Pass NVNT b 2437 Sum 18.326 28.15 Pass NVNT b 2462 Ant1 10.5 30 Pass NVNT b 2462 Ant2 10.4 30 Pass NVNT b 2462 Sum 13.461 28.15 Pass NVNT g 2412 Ant1 8.33 30 Pass NVNT g 2412 Ant2 8.63 30 Pass NVNT g 2412 Sum 11.493 28.15 Pass NVNT g 2437 Ant1 15.78 30 P…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 19 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT20) 2437MHz Ant1 -6dB Bandwidth NVNT n(HT20) 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 20 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT20) 2462MHz Ant1 -6dB Bandwidth NVNT n(HT20) 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 21 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT40) 2422MHz Ant1 -6dB Bandwidth NVNT n(HT40) 2422MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 22 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT40) 2437MHz Ant1 -6dB Bandwidth NVNT n(HT40) 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 23 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 -6dB Bandwidth NVNT n(HT40) 2452MHz Ant1 -6dB Bandwidth NVNT n(HT40) 2452MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 24 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 4. Occupied Channel Bandwidth Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) NVNT b 2412 Ant1 15.033 NVNT b 2412 Ant2 15.076 NVNT b 2437 Ant1 15.043 NVNT b 2437 Ant2 15.11 NVNT b 2462 Ant1 14.934 NVNT b 2462 Ant2 14.985 NVNT g 2412 Ant1 16.578 NVNT g 2412 Ant2 16.637 NVNT g 2437 Ant1 16.748 NVNT g 2437 Ant2 17.49 NVNT g 2462 Ant1 16.571 NVNT g 2462 Ant2 16.638 NVNT n(HT20) 2412 Ant1 17.635 NVNT n(HT20) 2412 Ant2 17.679 NVNT n(HT20) 2437 Ant1 17.749 NVNT n(HT20) 2437 Ant2 17.977 NVNT n(HT20) 2462 Ant1 17.651 NVNT n(HT20) 2462 Ant2 17.678 NVNT n(HT40) 2422 Ant1 35.892 NVNT n(HT40) 2422 Ant2 35.945 NVNT n(HT40) 2437 Ant1 36.021 NVNT n(HT40) 2437 Ant2 36.235 NVNT n(HT40) 2452 Ant1 35.864 NVNT n(HT40) 2452 Ant2 35.955 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 25 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Test Graphs OBW NVNT b 2412MHz Ant1 OBW NVNT b 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 26 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT b 2437MHz Ant1 OBW NVNT b 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 27 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT b 2462MHz Ant1 OBW NVNT b 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 28 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT g 2412MHz Ant1 OBW NVNT g 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 29 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT g 2437MHz Ant1 OBW NVNT g 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 30 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT g 2462MHz Ant1 OBW NVNT g 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 31 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT20) 2412MHz Ant1 OBW NVNT n(HT20) 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 32 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT20) 2437MHz Ant1 OBW NVNT n(HT20) 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 33 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT20) 2462MHz Ant1 OBW NVNT n(HT20) 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 34 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT40) 2422MHz Ant1 OBW NVNT n(HT40) 2422MHz Ant2

Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 35 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT40) 2437MHz Ant1 OBW NVNT n(HT40) 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 36 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 OBW NVNT n(HT40) 2452MHz Ant1 OBW NVNT n(HT40) 2452MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 37 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 5. Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Max PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT b 2412 Ant1 -19.302 8 Pass NVNT b 2412 Ant2 -20.071 8 Pass NVNT b 2412 Sum -16.659 6.15 Pass NVNT b 2437 Ant1 -14.856 8 Pass NVNT b 2437 Ant2 -15.711 8 Pass NVNT b 2437 Sum -12.252 6.15 Pass NVNT b 2462 Ant1 -21.27 8 Pass NVNT b 2462 Ant2 -20.517 8 Pass NVNT b 2462 Sum -17.867 6.15 Pass NVNT g 2412 Ant1 -24.679 8 Pass NVNT g 2412 Ant2 -25.034 8 Pass NVNT g 2412 Sum -21.843 6.15 Pass NVNT g 2437 Ant1 -17.732 8 Pass NVNT g 2437 Ant2 -17.237 8 Pass NVNT g 2437 Sum -14.467 6.15 Pass NVNT g 2462 Ant1 -25.853 8 Pass NVNT g 2462 Ant2 -26.284 8 Pass NVNT g 2462 Sum -23.053 6.15 Pass NVNT n(HT20) 2412 Ant1 -25.331 8 Pass NVNT n(HT20) 2412 Ant2 -25.384 8 Pass NVNT n(HT20) 2412 Sum -22.347 6.15 Pass NVNT n(HT20) 2437 Ant1 -18.358 8 Pass NVNT n(HT20) 2437 Ant2 -17.644 8 Pass NVNT n(HT20) 2437 Sum -14.976 6.15 Pass NVNT n(HT20) 2462 Ant1 -26.152 8 Pass NVNT n(HT20) 2462 Ant2 -26.841 8 Pass NVNT n(HT20) 2462 Sum -23.473 6.15 Pass NVNT n(HT40) 2422 Ant1 -29.547 8 Pass NVNT n(HT40) 2422 Ant2 -29.285 8 Pass NVNT n(HT40) 2422 Sum -26.404 6.15 Pass NVNT n(HT40) 2437 Ant1 -21.732 8 Pass NVNT n(HT40) 2437 Ant2 -21.455 8 Pass NVNT n(HT40) 2437 Sum -18.581 6.15 Pass NVNT n(HT40) 2452 Ant1 -29.919 8 Pass NVNT n(HT40) 2452 Ant2 -30.379 8 Pass NVNT n(HT40) 2452 Sum -27.133 6.15 Pass Note： The EUT incorporates a MIMO function. Physically, the EUT provides two antennas for transmitting and receiving. When ANT.1(4.61dBi) and ANT. 2(5.06dBi) transmitting simultaneously, so the Directional Gain= 7.85dBi＞6dBi. So PSD out = PSD limit -(G TX -6)]=(8-1.85)dBm =6.15dBm Directional Gain=10 log[(10^G1/20 + 10^G2/20 + ... + 10GN/20)^2/NANT] The Duty Cycle Factor is compensated in the graph. Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 38 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 Test Graphs PSD NVNT b 2412MHz Ant1 PSD NVNT b 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 39 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT b 2437MHz Ant1 PSD NVNT b 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 40 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT b 2462MHz Ant1 PSD NVNT b 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 41 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT g 2412MHz Ant1 PSD NVNT g 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 42 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT g 2437MHz Ant1 PSD NVNT g 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 43 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT g 2462MHz Ant1 PSD NVNT g 2462MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 44 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT n(HT20) 2412MHz Ant1 PSD NVNT n(HT20) 2412MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report No.: TBR-C-202403-0339-3 Page: 45 of 111 FCC ID: 2APRB-WNVR-FWR8G1 TB-RF-074-1.0 PSD NVNT n(HT20) 2437MHz Ant1 PSD NVNT n(HT20) 2437MHz Ant2 Shenzhen Toby Technology Co., Ltd. Http://www.tobylab.cn Add：1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China. Report…
