2APRB-X104G CAMERA

Camera Instructions QUICK START GUIDE Download “Eseecloud” client site Use your mobile phone to scan the QR code below to download and install "Eseecloud", and follow the APP prompts to complete user registration. Download "Eseecloud" APP Add device Step 1: Please connect the device to the power supply to ensure that the device is powered on normally; Step 2: Log in to the "Eseecloud" APP, turn on the Bluetooth function of the mobile phone, and click the "+" add button on the interface to enter the automatic search device interface; Step 1: Please connect the device to the power supply to ensure that the device is powered on normally; Step 2: On the automatic search interface, click "Scan to add" to enter the scan code interface; Step 3: Scan the QR code on the device body, and add the device according to the interface guidance. (1). WIFI Camera: (2). 4G Camera: 1.If you cannot find the QR code on the device body, please choose other adding methods according to the device type: (1).Insert the SIM card or connect the network cable to use the device, please click "Manual Add", enter the device ID to add the device; (2).For the device used to connect to the router WiFi, please click "Camera scan code to add" or "Camera hots pot add" to add the device according to the interface guidance; 2.If the location where you install the camera cannot be connected to the Internet, please click the "WiFi Connection" button in the upper right corner of the WiFi selection interface, and switch to "Direct Connection" in the pop-up window. Note: The local direct connection needs to be connected to the camera's own WiFi to preview the camera screen normally, it cannot be viewed remotely. This manual is only a guide for related products and may differ from the actual product, please refer to the actual product. Due to product version upgrade or other needs, this manual may be updated without further notice! Interface description This manual is suitable for various types of cameras. (The appearance of the same series of products may be different, the details are subject to the purchase and receipt. This manual is only for the installation guidance of the same series of equipment, and the installation method of the same series of products is the same) DC power supply One click call Indicator light Lens 7 6 4 8 5 2 3 10 Reset button Microphone SD card slot SIM card slot 1. Pan-Tilt Camera Series 1. Pan-tilt Camera Series 2. Cube Camera 5. Q40 Dome Camera Series 5. Q40 Dome Camera Series 5 1IPUPTFOTJUJWF 9 Infrared&Spot light Lens 4 Mic 1 SD card slot 3 Reset button 2 DC power supply 7 5 4 9 3 MIC Lens Spot light SD card slot SIM card slot 6 Indicator light 2 Reset button 10 11 Alarm Lamp   Photosensitive Infrared&Spot light Microphone Lens   SD card slot SIM card slot  Reset button Mounting bracket 13 WIFI Camera 4G Camera Installation and placement Table placement Place on a desk or table. Ceiling installation 1. Insert the expansion plug into the ceiling and fix the bracketbase to the ceiling with screws; 2. Install the device on the bracket. wall plug Screws wall plug Screws Ceiling Ceiling Ceiling Ceiling Ceiling Ceiling installation Wall installation This product supports two installation methods: Ceiling and wall mounting. 1).Tape the mounting guide sticker to the location you want to drill holes for your camera,and insert the wall plug into the hole. 2).Align the holes of camera bracket with the plug in the wall,and then tighten the screws.
wall plug Screws Mounting the camera with screws Mounting the camera with screws A hole for tail cable to pass through A hole for tail cable to pass through 2 Reset button 7 DC power supply 3. Bullet Camera Series Lens 4 4. Q20 Dome Camera Series 2 Reset button 7 6 Network port and indicator light 5 Mic 3 10 SD card slot SIM card slot 9 Infrared&Spot light DC power supply Lens 4 About this product 2 7 6 Reset button DC power supply Network port and indicator light 3 SD card slot Before adding the device, please confirm the status of the device ’s WIFI / 4G dial switch. When the dial switch is set to the side near the 4G card slot, it is 4G configuration mode; when the dial switch is set to be away from the 4G card slot, it is WIFI Configuration mode. Tip: Switching the dial switch status needs to be performed when the device is powered off. WiFi mode is optional. Switch near to 4G SIM card slot. Camera in 4G mode Switch far away from 4G SIM card slot. Camera in Wi-Fi mode Reset switchWi-FI mode 4G mode SIM card TF card (*SIM card direction) (*TF card direction) Before operating this unit,please read these instructions carefully,and save them for future use. Note: For iOS system, it requires iOS 9.0 version or above.For Android,Android 5.1 or above. Step 3: Select the device you need to add, click the "Add" button on the right, and follow the interface guidance to add the device; Note: If you do not find the device you want to add after waiting 10s on the Bluetooth search interface, please click "Scan to add" below to scan the QR code on the device body to add the device. Note: Table placement Place on a desk or table. The bracket can be stretched and retracted. Wall installation wall wall wall wall 2. Cube camera Series 3M glue Fix the base of the cube camera with 3M glue (glass and other smooth surfaces) on the other side or fix the screws(brick wall, etc.) on the wall with mounting sticker, fix the hanging hole of the base of the cube camera with the screws, and then adjust the angle. base mounting guide sticker 1. Select a suitable wall bracket, install the bracket to the wall, and then fix the camera to the bracket; 2. Tighten the vertical and horizontal adjustment screws to adjust the camera to the desired monitoring scene, and then tighten the adjustment screws to complete the installation. 3. Bullet Camera Series Mounting bracket Mounting the camera wall plug Screws Ceiling wall Wall installation Ceiling installation 1).Use the camera positioning paper t…

Text truncated - open the document above for the full version.

FCC ID: 2APRB-X10 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of adapter

FCC ID: 2APRB-X10 TB-RF-074-1.0 Appendix IID Label Size for the label: 30mm X 30mm 4G CAMERA FCC ID:2APRB-X10 Model:X10 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. FCC ID: 2APRB-X10 TB-RF-074-1.0 Appendix II ID Label Location

FCC ID: 2APRB-X10 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 5 Internal of EUT Photo 6 Internal of EUT FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo 7 Internal of EUT Photo 8 Internal of EUT 4G Antenna Fake Antenna FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo 9 Appearance of PCB Photo 10 Appearance of PCB FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TBR-C-202405-0316-221 Page: 1 of 34 TB-RF-074-1.0 1/F.,Building 6, Rundongsheng Industrial Zone, Longzhu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Part 15B Test Report FCC ID:2APRB-X10 Report No. : TBR-C-202405-0316-221 Applicant : Guangdong Juan Intelligent Technology Joint Stock Co., Ltd. Equipment Under Test (EUT) EUT Name : 4G CAMERA Model No. : X10 Series Model No. : X20 Brand Name : JUANCLOUD Sample ID : HC-C-202405-0316-04-01# Receipt Date : 2024-06-13 Test Date : 2024-06-13 to 2024-06-28 Issue Date : 2024-06-28 Standards : FCC 47 CFR Part 15 Subpart B Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above The EUT technically complies with the FCC requirements. Test By : Marvin Guo Reviewed By : Camille Li Approved By : Ivan Su This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TBR-C-202405-0316-221 Page: 2 of 34 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 REVISION HISTORY ............................................................................................................................. 3 1. GENERAL INFORMATION ...................................................................................................... 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Block Diagram Showing The Configuration of System Tested..................................... 5 1.4 Description of Support Units .............................................................................................. 5 1.5 Description of Test Mode .................................................................................................... 6 1.6 Test standards ...................................................................................................................... 6 1.7 Test Facility ........................................................................................................................... 7 1.8 Measurement Uncertainty .................................................................................................. 7 2. TEST SOFTWARE ..................................................................................................................... 8 3. TEST SUMMARY ....................................................................................................................... 8 4. TEST EQUIPMENT USED AND TEST SITE ........................................................................ 8 5. LABEL REQUIREMENTS & STATEMENT REQUIREMENTS ......................................... 9 6. CONDUCTED EMISSION TEST ........................................................................................... 10 6.1 Test Standard and Limit .................................................................................................... 10 6.2 Test Setup ........................................................................................................................... 10 6.3 Test Procedure ................................................................................................................... 11 6.4 Deviation From Test Standard ......................................................................................... 11 6.5 EUT Operating Mode ........................................................................................................ 11 6.6 Test Data ............................................................................................................................. 11 7. RADIATED EMISSION TEST ................................................................................................ 12 7.1 Test Standard and Limit .................................................................................................... 12 7.2 Test Setup ........................................................................................................................... 13 7.3 Test Procedure ................................................................................................................... 13 7.4 Deviation From Test Standard ......................................................................................... 14 7.5 EUT Operating Mode ........................................................................................................ 14 7.6 Test Data ............................................................................................................................. 14 8. PHOTOGRAPHS - CONSTRUCTIONAL DETAILS .......................................................... 15 9. PHOTOGRAPHS - TEST SETUP ......................................................................................... 25 ATTACHMENT A-- CONDUCTED EMISSION DATA (AC MAINS) ........................................... 27 ATTACHMENT A--RADIATED EMISSION TEST DATA ............................................................. 29 Report No.: TBR-C-202405-0316-221 Page: 3 of 34 TB-RF-074-1.0 Revision History Report No. Version Description Issued Date TBR-C-202405-0316-221 Rev.01 Initial issue of report 2024-06-28 Report No.: TBR-C-202405-0316-221 Page: 4 of 34 TB-RF-074-1.0 1. General Information 1.1 Client Information Applicant : Guangdong Juan Intelligent Technology Joint Stock Co., Ltd. Address : THE FIRST AND SECOND FLOORS OF BUILDING 2 (PLANT NO.2), WEST SIDE OF SHANXI VILLAGE, DASHI STREET, PANYU DISTRICT, GUANGZHOU, Chi…

Text truncated - open the document above for the full version.

FCC ID: 2APRB-X10 TB-RF-074-1.0 Appendix V EUT Test Photographs Photo of Setup for Radiated Emission (Below 1 GHz)-X10 Photo of Setup for Radiated Emission (Below 1 GHz)-X20 FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo of Setup for Radiated Emission (Above 1 GHz)-X10 Photo of Setup for Conducted Emission-X10 FCC ID: 2APRB-X10 TB-RF-074-1.0 Photo of Setup for Radiated Emission (Above 1 GHz)-X10 -----END OF REPORT-----
