2APTY-LP-UN-313-2UV Sterilizer with Wireless Charger

Multi-funcion UV Sterilizer User Guide Technical Specifications UV sterilizing power: 2W*2 Type-C input:9V/2A 5V/2A USB output: Wireless output: Weight:354g 5V/2A 5V/2A Sterilize： Mobile phone, iPod, Mp3 player, Wireless earphones, Watches, Keys, Jewelries etc. What’s in the box Type-C USB Cable UV Sterilizer UV Sterilizer Overview 1 2 3 4 9 5 UV lamp LED indicators LED display/Button USB output port Type-C input port 6 7 8 Buzzer Lid Infrared sensor Wireless charging 1 2 3 4 6 8 5 7 9 ①Plug in Type-C cable, connect UV sterilizer to an adapter. Put your phone inside, press the Button to turn on the UV lamps. How to Use 1. UV Sterilizing Open ③After 15 minutes, UV lamps automatically turn off, buzzer will “Beep”disinfection process completed. When you open the lid, infrared sensor switch will detect it, UV lamps will automatically turn off.. When you close the lid, UV lamps will turn on again. Note: Close 2. Wireless Charging Put your phone in UV sterilizer, it will wireless charge your phone. 1. Wireless charge only supports Qi-enabled phone. Qi-enabled phoneNOT Qi-enabled phone Note: 2. Quick wireless charge only works with 9V/2A output adapter (not supplied). 9V/2A 5V/2A 5V/1A 3. Put your phone in the center of UV sterilizer. Please note wireless charge may not work on phones with thick case on. 4. If there are metal units between the phone and UV sanitizer, UV sanitizer will detect them, the green LED indicator will flash, please take out metal units. Quick charge Standard charge 3. USB Charging Plug in another charging cable, charge other phones or devices. Note: If the output power of adapter is too low, sterilizing, wireless charging and USB charging will not work at the same time. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE： This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF exposure compliance statement: This device has been evaluated to meet the general RF exposure requirement Warranty certificate Client’s name : Contact number : Username : Correspondence address: Email address: Product information :

Leadingplus Electronic Co., Ltd Agent Authorization Company: Leadingplus Electronic Co., Ltd Address: RM337, 3/F B Block, JieMeiKang Creative Industry Park, Donghuan 2nd Road No.57, Longhua Dist., Shenzhen, China Product Name: UV Sterilizer with Wireless Charger Model Number(s): LP-UN-313-2, LP-UN-313, LP-UN-313-1, LP-UN-313-3, LP- UN-313-4 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: Jun. 22, 2020Signature: Name: Jessie chen Title:manager Company: Leadingplus Electronic Co., Ltd

Leadingplus Electronic Co., Ltd Model Confirmation Letter We, Leadingplus Electronic Co., Ltd , certify the product: UV Sterilizer with Wireless Charger , Model No.: LP-UN-313-2, LP-UN-313, LP-UN-313-1, LP- UN-313-3, LP-UN-313-4 All models have the same functionality, software and electronics, only the color and model names may differ. Test sample model: LP-UN-313-2 Signiture: Grantee Contact: Jessie chen Company Name: Leadingplus Electronic Co., Ltd Date: Jun. 22, 2020

Leadingplus Electronic Co., Ltd Date: Jun. 22, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2APTY-LP-UN-313-2 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jessie chen Title: manager

External photos

UV Sterilizer with Wireless Charger MODEL: LP‐UN‐313‐2 FCC ID: 2APTY‐LP‐UN‐313‐2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. SIZE:50*25mm

Internal photos Wireless antenna

Page 1 of 8 Report No.: HK2006181454-2E FCC TEST REPORT Test report On Behalf of Leadingplus Electronic Co., Ltd For UV Sterilizer with Wireless Charger Model No.: LP-UN-313-2 FCC ID: 2APTY-LP-UN-313-2 Prepared for : Leadingplus Electronic Co., Ltd RM337, 3/F B Block, JieMeiKang Creative Industry Park, Donghuan 2nd Road No.57, Longhua Dist., Shenzhen, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Jun. 08, 2020 ~ Jun. 19, 2020 Date of Report: Jun. 19, 2020 Report Number: HK2006181454-2E Page 2 of 8 Report No.: HK2006181454-2E Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 119.1 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1 Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 All emissions,radiated(<30M)(9KHz-30MHz) ±2.45dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 8 Report No.: HK2006181454-2E 2.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Broadband Field Meter NARDA NBM-550 - Dec. 27, 2018 Dec. 26, 2019 Magnetic Field Meter NARDA ELT-400 1 – 400kHz Dec. 27, 2018 Dec. 26, 2019 Magnetic Probe NARDA HF-3061 300kHz – 30MHz Dec. 27, 2018 Dec. 26, 2019 Magnetic Probe NARDA HF-0191 27 – 1000MHz Dec. 27, 2018 Dec. 26, 2019 Broadband Field Meter NARDA NBM-550 - Dec. 27, 2018 Dec. 26, 2019 Electric Field Meter COMBINOVA EFM 200 5Hz – 400kHz Dec. 27, 2018 Dec. 26, 2019 E-Field Probe NARDA EF-0391 100kHz – 3GHz Dec. 27, 2018 Dec. 26, 2019 E-Field Probe NARDA EF-6091 100MHz – 60GHz Dec. 27, 2018 Dec. 26, 2019 NOTE: 1. The calibration interval of the above test instruments is 12 months . Page 4 of 8 Report No.: HK2006181454-2E 3. MAXIMUM PERMISSIBLE EXPOSURE 3.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03 Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 0.815A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 8 Report No.: HK2006181454-2E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 TEST SETUP 4.2 RESULT OF MAXIMUM PERMISSIBLE EXPOSURE Page 6 of 8 Report No.: HK2006181454-2E For Full load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.1191 2.08 1.57 1.31 2.11 1.78 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.1191 0.67 0.75 0.78 0.64 0.66 1.63 For Half Load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.1191 1.78 1.85 0.75 1.62 1.81 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.1191 0.71 0.80 0.74 0.69 0.68 1.63 Page 7 of 8 Report No.: HK2006181454-2E For No load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.1191 2.18 1.25 1.29 1.72 1.66 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.1191 0.67 0.38 0.57 0.76 0.81 1.63 Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03, section 5, b). The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface …
