1 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interferencewill not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: .Reorient or relocate the receiving antenna. .Increase the separation between the equipment and receiver. .Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. .Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. RF Exposure Information The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected.
LeadingPlusElectronicCo.,Ltd Theinformationprovidedin thisletteris basedon thereferencedrulepartsof Title47 of theCFRas wellas KDB986446D01. Anexpirationdateforthisletterdoesnotexist.In casetheU.S.agentchanges,thegranteeis obligatedto notifytheFCCwithin30 daysvia thegrantingTCB. FederalCommunicationsCommission Authorizationand EvaluationDivision EquipmentAuthorizationBranch 7435 OaklandMills Road Columbia,MD 21046 7/27/23 U.S. AgentDesignation LeadingPlusElectronicCo.,Ltdacknowledgestheir consentfor the followingcontactlocatedin the UnitedStatesto act as their agent for serviceof processfor the equipmentfor whichauthorizationis sought(FCC ID: 2APTY-QIS10): Nameand companyof U.S. agent:Tim Payne,FCC US Agent,LLC PhysicalU.S. addressof agent:3722 IllinoisAvenue,Saint Charles,IL, 60174,USA FRN of U.S. agent:0033402884 Email addressof U.S. agent:[email protected] FCC US Agent,LLCacknowledgestheir obligationto acceptserviceof processon behalfof LeadingPlusElectronicCo.,Ltd. LeadingPlusElectronicCo.,Ltdwith theFRN 0027524008acceptsits obligationto maintainan agent for serviceof processin the UnitedStatesfor no less than one year after either the granteehas permanentlyterminatedall marketingand importationof the applicableequipmentwithinthe U.S., or the conclusionof any Commission-relatedadministrativeor judicialproceedinginvolvingthe equipment,whicheveris later. By signingthis form, we confirmthe aboveand that we are awareof the applicationrequirements listed under § 2.911(d)(7). Sincerely, Signature JessieChen Manager LeadingPlusElectronicCo.,Ltd Signature Tim Payne Manager FCC US Agent,LLC 48_[model] US_Agent_2.911(d)(7)-U, V04
Page 1 of 5 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. EUT Constructional Details External EUT Photo Photo 1 Photo 2 Page 2 of 5 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 3 Photo 4 Page 3 of 5 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 5 Photo 6 Page 4 of 5 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 7 Photo 8 Page 5 of 5 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 9 ---The End---
Label Product Name:Wireless Charger Model No:MI-QIS10-199M FCC ID: 2APTY-QIS10
Page 1 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. EUT Constructional Details Internal EUT Photo Photo 1 Photo 2 Page 2 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 3 Photo 4 Antenna Antenna Antenna Page 3 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 5 Photo 6 Page 4 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 7 Photo 8 Page 5 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 9 Photo 10 Page 6 of 6 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Photo 11 Photo 12 ------End------
Page 1 of 7 FCC ID: 2APTY-QIS10 RF Exposure Evaluation 1 Measuring Standard KDB 680106 RF Exposure Wireless Charging Apps v03r01 2 Requirements According to the item 5 of KDB 680106 v03r01: Inductive wireless power transfer applications that meet all of the following requirements are excluded from submitting an RF exposure evaluation. (1) Power transfer frequency is less than 1MHz. (2) Output power from each primary coil is less than or equal to 15 watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. (4) Client device is placed directly in contact with the transmitter. (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Remark: Meet all the above requirements. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Page 2 of 7 FCC ID: 2APTY-QIS10 3 Test Setup 4 Test Procedure 1) The RF exposure test was performed in anechoic chamber. 2) The measurement probe was placed at test distance (15 cm from all sides and 20 cm from the top) which is between the edge of the charger and the geometric center of probe. 3) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. 4) The EUT was measured according to the dictates of KDB 680106 D01v03. Remark:The EUT’s test position A, B, C, D and E is valid for the E and H field measurements. 5 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Test Mode Description Mode 1 AC Adapter + EUT + Mobile phone+ Earphone+ Watch Record Mode 2 AC Adapter + EUT + Mobile phone+ Earphone Pre-tested Mode 3 AC Adapter + EUT + Mobile phone+Watch Pre-tested Mode 4 AC Adapter + EUT + Earphone +Watch Pre-tested Mode 5 AC Adapter + EUT + Mobile phone Pre-tested Mode 6 AC Adapter + EUT + Earphone Pre-tested Mode 7 AC Adapter + EUT + Watch Pre-tested Mode 8 Test the EUT in idle mode. Pre-tested Note: 1. All test modes were pre-tested, but we only recorded the worst case in this report. 2. Unfolded and folded mode were tested, but we only recorded the worst case. Page 3 of 7 FCC ID: 2APTY-QIS10 6 Peripheral List 7 Test Instruments list Test Equipment Manufacturer Model No. SN. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) Electric and Magnetic Field Analyzer Narda EHP-200A 180ZX10505 21.06.2022 20.06.2024 8 Test Result E-Filed Strength at 15 cm from the edges surrounding the EUT (V/m) Unit Test mode TM1 Test Position A Test Position B Test Position C Test Position D Test Position E 50% Limits (V/m) Limits (V/m) Unfolded mode Folded Mode V/m Phone port 90.21 101.25 95.46 94.59 89.30 307 614 V/m Earphone port 83.76 82.82 81.47 83.90 82.99 307 614 V/m Watch port 62.48 66.95 62.38 63.84 64.53 307 614 H-Filed Strength at 15 cm from the edges surrounding the EUT (A/m) Unit Test mode TM1 Test Position A Test Position B Test Position C Test Position D Test Position E 50% Limits (A/m) Limits (A/m) Unfolded mode Folded Mode A/m Phone port 0.213 0.243 0.287 0.211 0.215 0.815 1.63 A/m Earphone port 0.108 0.151 0.203 0.134 0.177 0.815 1.63 A/m Watch port 0.181 0.119 0.277 0.191 0.135 0.815 1.63 N o. Equipment Manufacturer Model No. Serial No. Power cord signal cable 1 Adapter HNT HNT-QC530 N/A N/A N/A 2 Mobile lphone XIAOMI MI 11 N/A N/A N/A 3 Airpod Apple Airpod 3 N/A N/A N/A 4 Watch Apple S6 N/A N/A N/A Page 4 of 7 FCC ID: 2APTY-QIS10 H-Filed Strength at 20 cm from the top of the EUT (A/m) Unit Test mode TM1 Test Position E 50% Limits (A/m) Limits (A/m) Folded Mode A/m Phone port 0.191 0.815 1.63 A/m Earphone port 0.170 0.815 1.63 A/m Watch port 0.165 0.815 1.63 Note: All test modes were pre-tested, but we only recorded the worst case in this report. Page 5 of 7 FCC ID: 2APTY-QIS10 9 Test Setup photo Test Position A-15cm from the edge of EUT to the geometric center of the probe Test Position B-15cm from the edge of EUT to the geometric center of the probe Page 6 of 7 FCC ID: 2APTY-QIS10 Test Position C-15cm from the edge of EUT to the geometric center of the probe Test Position D-15cm from the edge of EUT to the geometric center of the probe Page 7 of 7 FCC ID: 2APTY-QIS10 Test Position E-15cm from the edge of EUT to the geometric center of the probe Test Position E-20cm from the edge of EUT to the geometric center of the probe ***End of report***
Page 1 of 26 Report No.: AIT23070718FW1 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling Third Street, Jitigang, Huangjiang,Dongguan, Guangdong, China. FCC TEST REPORT Client Information: Applicant: LeadingPlus Electronic Co.,Ltd Applicant add.: RM337,3/F B Block,JieMeiKang Creative Industry Park, Donghuan 2nd Road No.57,Longhua Dist.,Shenzhen China Manufacturer: LeadingPlus Electronic Co.,Ltd Manufacturer add.: RM337,3/F B Block,JieMeiKang Creative Industry Park, Donghuan 2nd Road No.57,Longhua Dist.,Shenzhen China Product Information: Product Name: Wireless Charger Model No.: MI-QIS10-199M, LP-WL07, LP-WC01, LP-WC02, LP-WC06, LP-WC12 Brand Name: N/A FCC ID: 2APTY-QIS10 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Prepared By: Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang,Dongguan, Guangdong, China Tel.: +86-769-8202 0499 Fax.: +86-769-8202 0495 Date of Receipt: July 07, 2023 Date of Test: July 07, 2023~ July 10, 2023 Date of Issue: July 11, 2023 Test Result: Pass This device described above has been tested by Dongguan Yaxu (AiT) Technology Limited and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Note: This report shall not be reproduced except in full, without the written approval of Dongguan Yaxu (AiT) Technology Limited, this document may be altered or revised by Dongguan Yaxu (AiT) Technology Limited, personal only, and shall be noted in the revision of the document. This test report must not be used by the client to claim product endorsement. Reviewed by: Approved by: Simba Huang Seal.chen Page 2 of 26 Report No.: AIT23070718FW1 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling Third Street, Jitigang, Huangjiang,Dongguan, Guangdong, China. 1 Contents Page COVER PAGE 1 CONTENTS ........................................................................................................................................................... 2 2 TEST SUMMARY .................................................................................................................................................. 5 2.1 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 5 2.2 MEASUREMENT UNCERTAINTY ............................................................................................................................ 5 3 TEST FACILITY ..................................................................................................................................................... 6 3.1 DEVIATION FROM STANDARD ............................................................................................................................... 6 3.2 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 6 3.3 TEST LOCATION ................................................................................................................................................. 6 4 GENERAL INFORMATION ................................................................................................................................... 7 4.1 EUT TEST MODE ............................................................................................................................................... 8 4.2 DESCRIPTION OF TEST SETUP............................................................................................................................. 8 4.3 PERIPHERAL LIST ............................................................................................................................................... 9 4.4 EUT PERIPHERAL LIST ....................................................................................................................................... 9 5 EQUIPMENTS LIST FOR ALL TEST ITEMS ..................................................................................................... 10 6 CONDUCTED EMISSION TEST ......................................................................................................................... 11 6.1 CONDUCTED EMISSION MEASUREMENT ................................................................................................ 11 6.2 POWER LINE CONDUCTED EMISSION LIMITS ........................................................................................... 11 6.3 TEST PROCEDURE ...................................................................................................................................... 11 6.4 DEVIATION FROM TEST STANDARD ......................................................................................................... 11 6.5 TEST SETUP ................................................................................................................................................. 12 6.6 EUT OPERATING CONDITIONS .................................................................................................................. 12 6.7 TEST RESULT .................................................................................................................................................. 13 7 RADIATED EMISSION MEASUREMENT .......................................................................................................... 15 7.1 RADIATED EMISSION LIMITS .............................................................................................................................. 15 7.2 ANECHOIC CHAMBER TEST SETUP DIAGRAM ..................................................................................................... 16 7.3 TEST PROCEDURE ........................................................................................................................................... 16 7.4 DEVIATION FROM TEST STANDARD ..........................................…
Text truncated - open the document above for the full version.
Fine Page 1 of 3 SPECIFICATION FOR APPROVAL CUSTOMER: Dongguan Jufu Electronics Co., LTD Operation frequency: 113kHz-205kHz FINE P/N: G43.5 Double slot -6.5UH single coil 0.08*24P*2*10TS DESC: Φ43.5MMX5.0MMX0.6MM PC95 Material DATE: 2023/3/23 Version: A.0 PREPARED BY CHECKED BY APPROVED BY CUSTOMER APPROVE Dongguan Jufu Electronics Co., LTD Factory address: Sukeng village, Changping Town, Dongguan City TEL:0769-36820766 FAX:0769-84526500 E-mail:[email protected] Version Change History Fine Page 2 of 3 SPECIFICATION DESC: Φ20.5x40-6.5uH-0.15x18-15mm- Rev:A.0 客戶CUST: XXX 客户料号CUST P/N: 一、DIMENSION:(mm) A 38.50±1.5 Rev. Before Change After Change Change Date Approved By A.0 New issue ---- 2023/07/04 Zhou Wentao Fine Page 3 of 3 二、SCHEMATIC DIAGRAM: B 20.5±0.5 C 1.25 Max D 15±2 E 4±2 F 43.5±1 G 10.0 ref H 1.6 Max I 5.3 ref Note: 1. Cross out wire; 2. Wrap 8mm(ref) width high-temperature adhesive paper 1-2Ts around the outlet position; 3. The coil is attached to the circular hard magnetic disc with groove, the magnetic disc size is 43.5±1mm, the inner hole is 5.3mm, and the thickness is 0.6 ±0.2mm. 三、Winding Specification: NO. TERMINAL WIRE Turns Winding Direction 1 S F Enamelled wire 0.08*24*2 10Ts CCW 四、ELECTRICAL CHARACTERISTICS: TEMPERATURE:25±10°C, RELATIVE HUMIDITY:65±20% NO. ITEM TERMINAL SPECIFICATION TEST FREQUENCY TEST EQUIPMENTS 1 IND. S-F 3.8uH ±20% Individual coil 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.3uH ±10% Magnetic sheet 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤50mΩ LCZ METER 502B PREPARED BY/DATE CHECKED BY/DATE 2023/03/23 2023/07/4
Letter of acceptance Customer name: Customer Material Number: Our model: YZ-G25-6.4UH-2750GS-7MM Working frequency: 300kHz-350kHz Datelanded: 2023/7/18 Supplier: Draw Audit approval CUSTOMER APPROVAL: PASS FALL acknowledge Notes Dongguan Jierith Technology Co., LTD Tel: Fax: Add: customer name Customer Material Number model number edition Birthdate YZ-G25-6.4UH-2750GS-7MM A0 2023.7.18 一、Plane structure: Unit :MM 二、Product Parameter: Foot position Radial sawing Cycles Reserve note 1 - 2 0.08*24P 12 Hot air stranding wire 三、Technical requirements: 1. Fix the end of the wire to prevent loose and broken wires 2.According to customer requirements, the long thread is cut and tinned, and the tinning depth is 2±1MM 3.Point the appropriate white glue on the soft magnetic sheet, paste the coil, and ensure that the product surface is clean and tidy in the process 4. The soft magnetic sheet used is with round holes, without damage 審 核 A C G K J I H M F L A B C D E F H I J 7.6±0.05 1.8±0.05 2±1 15±0.2 20.7±0.3 21±0.2 23.5±0.3 25±0.2 2.5±0.1 2.4±0.1 中柱高度 K 磁铁 1 2 1 2 7±1 L B D E 7.7±0.05 13.5±0.2 G M 5. Additional process (according to customer requirements) : Install 7.6x1.8mm magnet in the middle round hole of the finished product and attach 16mm round double-sided tape on the back of the finished product, after packaging 四、Electrical parameter: 1.Inductance value, Q value: PIN 1 — 2 = 6.4uH ±0.2UH Q value (before magnet installation) ≥35 (after magnet installation) ≥25 The above inductance values are based on Quanhua 1062A instrument, 10KHZ/0.3Vrms as the standard or equivalent instrument. Q value is based on Quanhua 1062A instrument, 100KHZ/0.3Vrms as standard or equivalent instrument 我司型號 五、BOM: Serial number Name Material Supplier Notes 1 Hot air stranding wire 0.08X24P Weihan or equivalent 2 Magnetic plate G25 pressure casting Tiantong or equivalent 3 Tin High temperature environmental protection Thousand Islands or equivalent 4 White glue BY882 Moon or equivalent 5 Strong magnetic 7.6*2*2750±50GS United win or equivalent Additional processes, according to customer requirements 6 Double-sided adhesive Diameter ø16mm Honghui or d white 审核
Page 1 of 2 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Test Setup Photo Radiated Emission Page 2 of 2 FCC ID: 2APTY-QIS10 Dongguan Yaxu (AiT) Technology Limited No.22, Jinqianling 3rd Street, Jitigang, Huangjiang, Dongguan, Guangdong, China. Conducted Emission ------End------
