2APX7K60Smart phone
KRIPTO MOBILE CORPORATION
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Apr 21, 2023
- Application Purpose
- Original Equipment
- Date of Application
- Apr 21, 2023
- Equipment Note
- Smart phone
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- KRIPTO MOBILE CORPORATION
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Attestation Statements
KRIPTO MOBILE CORPORATION 7640 NW 25TH ST STE 101 MIAMI Florida United States The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-4-18 U.S. Agent Designation KRIPTO MOBILE CORPORATION acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID:2APX7K60): Name and company of U.S. agent: KRIPTO MOBILE CORPORATION Physical U.S. address of agent: 7640 NW 25TH ST STE 101, MIAMI, FL 33122, United States FRN of U.S. agent: 0027561588 Email address of U.S. agent: [email protected] KRIPTO MOBILE CORPORATION acknowledges their obligation to accept service of process on behalf of KRIPTO MOBILE CORPORATION . KRIPTO MOBILE CORPORATION accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). KRIPTO MOBILE CORPORATION 7640 NW 25TH ST STE 101 MIAMI Florida United States The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC. Sincerely, Signature RENATO TAVARES SOFTWARE MANAGER KRIPTO MOBILE CORPORATION Signature RENATO TAVARES SOFTWARE MANAGER KRIPTO MOBILE CORPORATION 48_[model] US_Agent_2.911(d)(7) - U, V03
Cover Letter(s)
Sincerely, Name/Title： RENATO TAVARES/SOFTWARE MANAGER Company: KRIPTO MOBILE CORPORATION Address: 7640 NW 25TH ST STE 101 MIAMI Florida United States Phone: +1 305 499 3333 Fax: +1 786 693 8098 E-Mail: [email protected]
External Photos
Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 4 EXTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 4 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 4 Fig.5 Fig.6 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 4 Fig.7 Fig.8
ID Label/Location Info
Label Location: FCC ID: 2APX7K60
Internal Photos
Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 4 INTERIOR PHOTOGRAPHS OF EUT Fig.1 Fig.2 WiFi/Bluetooth /FM/GNSS antenna LTE/WCDMA /GSM Main antenna LTE diversity antenna Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 4 Fig.3 Fig.4 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 4 Fig.5 Fig.6 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 4 of 4 Fig.7 Fig.8
RF Exposure Info
!! " !#$ %# &'()*+,$ ! )$ ! - %./-0 10/2 $ !#''/ 3- 3-%% /!0%$ 4- 0 !3 3 . -" 2 -.)%-/- $1- 0 5%-/- $ $.0 %! $ - 0 36 !3!0/%!-3 /- (7- %1/!) /-0 !#8 +9:** 1!';9 <=>?@<ABC<A36 #-#CB=<DE>FABCGC><?=B BHIFEDJ=B)@BKA-@E>KBL*M,<NBFGB0=BO>KCB/EHIEF *M*P+1!. 0 (7/0 <=>?@<A>EFC<AB8+*:&+:*+*' QQR STUVUTWXYZ[\]^_ QW` VaVTbVcb WXdddQW RVQ R IBGKBEeAIB Ee@<H?@<FC<FCAIB<HH@BC>A<A>EF@BeB@BFHBK>KD@EI>?>ABCe@Ef<Fg@BD@ECGHA>EF# hijjkl mnTYSWQop XU`R Y XUYUn p UnWSVXSR YobUY RWpVXVQQR STU Sqrq [sT bStRWc QVbTcRVUTWX` R WRp SVUruvwoYTXxUn yzt qU YUc XQnw WRoY dTUnVruvqrq Y{YU pWXb{mn U YUR YobUYQWa R Sc{VQQR STUVUTWXVR URVQ Vcb UWUn zXU RXVUTWXVb{YU pW |XTUY}z~ !3 !0/ (7>B=C1@E?B <=>?@<A>EF/BDE@A Ref : ACR.41.6.23.BES.A !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ M" _LNKOGJN ` O" aG!N OLR" R"S R"I Q] # bcdef ghi jiklmino pnlnqd uF"Kv"I Q] # bcdef ghi jiklmino pnlnqd wSSRJX"I Q] xnll jyhznml gn{ydnzyd| }mdizyd uLHOJM"R ^ M" `GHORGQLOGJN # g~j klkl jz jiklyoyq| y gz HHL" ^ M" ` O" YJIGVGK OGJNH bcdef ghi lmzmno don Ref: ACR.41.6.23.BES.A 2/10/2023 2/10/2023 2/10/2023 2/10/2023 !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ _`ab cdef ghi jfkelbi _hbfamiakd ^ ndfop qdkfroiakd sssssssssssssssssssssssssssssssssssssssssssssssssssssss t uohlfrdi uivke t^ wadofaix ssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss t dhaia`aix sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss tt wkyf _ibiakd warai sssssssssssssssssssssssssssssssssssssssssssssssssssss t qhkifkmx sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss t^ kldeofx bi ssssssssssssssssssssssssssssssssssssssssssssssssssssssssss uohlfrdi cdbfioadix z opa{foiakd uohlfrdi hlpih z ^ dhaia`aix ad oaf ssssssssssssssssssssssssssssssssssssssssssssssssssssssssss z wadofaix ssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss | t dhaia`aix ad pa}lae ssssssssssssssssssssssssssssssssssssssssssssssssssssssss ~ qhkifkmx sssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssssss z wahi k }lamrdi ^ Ref: ACR.41.6.23.BES.A !"# $%&& '()*+,-(./01233324255267892:;;<=.0>6>;/1 ?@AB( CD EFGH IJKLM"NO HF PP NJO Q" R"SRJILK"IT "UK"SO GN VLPP JR GN S ROT WGOFJLO OF" WRGOO"N SSRJX P JV YZ[\ EF" GNVJRM OGJN KJNO GN"I F"R"GN GH OJ Q" LH"I J NP] VJR OF" SLRSJH" VJR WFGKF GO GH HLQMGOO"I NI GH NJO OJ Q" R"P" H"I GN WFJP" JR S RO WGOFJLO WRGOO"N SSRJX P JV YZ[\ ^ _ ` abcdeb fghbi jbkl mnop qrs tut mt vu qv wv xm yt uz{|zp}|~~ u u ~oz | ~ yt y~|p} {o}o{ { | w~|{pr z{ y~ o}z{p q~ mos z} {{p}~ mos u mos u mos u ` x vwtuqvt ¡¢ £ ¤¥¦§ ̈ ©ª«¬¦ ª¦ ¬®¥§ ̄ ¥° zpp~z{p } } v v ±² z{ w ³m ² m }z{z~ ́μ¶· ̧ ^ ¹ YZ[ º»Y»¼½¾ ¿JHGM"ORGK À VG"PI RJQ" y~ x{} x{} v{ono|z mos uzÁo | Á}~{z oz }~ ² y~ qos Á}~{z moz }~ mo}z{p }{ os s~ Á}~ o}r  ` à q v v ±² z{ w ³m ² m }z{z~ s~no ~p { s~zp}op ~ } s~ pzo~z}o{Ä o{p|o{ } s~~ z{p pz~zp}~o}op o{}~} z{ } r op } z }o~ zp} pzo~z}o{ z|~ {} s~~ } } ~ {}o{ }z{z~ xv vqÅ q nz|z}o{ } o{z~o}r z { o{ ~ szp |o{ } zn|oÄ s~~ o{ z s~ s } pn~ } ~z{ ÆÇ } ÆÇ vqvvqÅ q {o}ono}r zp}~ } }~ os ~ }~ o{ |o{ z } }s pzo~z}o{ } zo~ z { }o| o |z}o{ o|o |o{ zn|o z |}o{ o{ } }z{z~ Ref: ACR.41.6.23.BES.…
Text truncated - open the document above for the full version.
RF Exposure Info
! "#$% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^ _`_ _a bc ded fghijk lmn o pqfkff qgj rslmnltnr utvwxn tyzxt{msr vt tt m| nxuv}r zrn vt r~rs{ wl}xnlsxvm {lrzt{msr bc v}}vxm {lrzt{msr t utvt{n sv wtx~ s cls sc utvnz|s |v{u}xr xsc sc vt {msxvmn rslmnltnr j b db bc nxuv} zrn vt r~rs{ wl}xnlsxvm {lrzt{msr lmn |c|r {zrs clw l tsztm }vrr v ig n vt sst bc tsztm }vrr {lrzt{ms rcl}} utvt{n llxmrs l }xyzxn x}}n }ls uclmsv{ xsc sc uclm sv{ |vmrstz|sn lr vzs}xmn xm sc vt {msxvmn rslmnltnr nxt|s {scvn xr zrn xsc l msvt lml} ~rt lmn xsr |l}xtlsxvm xs vsc xsc l wl}xn d jgk |l}xtlsxvm d db bc ded fghijk lmn o pqfkff qgj rslmnltnr ru|x~ sc {|clmx|l} |v{uvmmsr lmn nx{mrxv |~ lmn uclmsv{ rc}} scx|mrr numnms bc srs m|c {u}v~r l {{ uclmsv{ rc}} scx|mrr sctvt sc nxuv}r rv}n vt zr xsc sc srs m|c |v{u}~ xsc sc tyzxt{msr rs vtsc vt l {{ uclmsv{ rc}} scx|mrr nxt|s {scvn xr zrn xsc l d jgk |l}xtlsn |l}xut _`_ ` ¡ }} zm|tslxmsxr }xrsn }v tut rms lm ¢ulmnn zm|tslxms~ ¢utrrn ls luutv¢x{ls}~ sc hk£ |vmxnm| }w} zrxm l |vwtl l|s vt v ¤ stl|l} sv sc dmstmlsxvml}}~ ||usn ¥zxnr sv lrzt{ms m|tslxms~ kj b bc v}}vxm zm|tslxmsxr luu}~ sv sc tsztm }vrr {lrzt{ms ¦§ ̈©§ª«¬ ®ª ̄ °±®ª ̄§ ̄ `ª«§¦²®³ª²¬ ́ª §²©¦ª ́μμ ggifggg¶ gg d k qd d b bc v}}vxm zm|tslxmsxr luu}~ sv sc nx{mrxvm {lrzt{msr §ª·² ̧ ¹ºº» °±®ª ̄§ ̄ `ª«§¦²®³ª²¬ ́ª §ª·² ̧ g i ¼gg gg {{ ¼gg i kg g {{ k¼ ½dqbd b bc zxn}xmr vzs}xmn xm sc ded fghijk lmn o pqfkff qgj rslmnltnr t v}}vn sv mtls sc {lrzt{ms zm|tslxms~ vt wl}xnlsxvm {lrzt{msr ! "#$% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^_` abcdef gh_`ifi j`^fkl_m`ln o p oq r s t ou p oq r s t v wjw j xo yz{ |} {~ ~{ { ~ |z~ kfdf`^n w fldk` b i fdmkfef`l i ehfi_`^f ouu xq u oq o x yz{ |} {~ ~{ { }~ |z~ kfdf`^n w fldk` b i fdmkfef`l i ehfi_`^f ouu u u u u ! "#$% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^_ `abcd ec`b cfb ghijkilmn opq r ss t ss u ss hijkvhiu wixykhiu hijkvhiu wixykhiu hijkvhiu wixykhiu z{{ |}{~{ ~ }{~{ ~ ~z ~ |{ }{~{ ~ ~ ~ ~z ~ { ~{ ~ {{~{ ~ ~z ~ z ~{ ~ ~ ~ z~ ~ {{ |~{ ~ z~z ~ z~ ~ |{ ~ ~ ~ ~ z~ ~ {{ ~} ~ {~{ ~ z~ ~ |{ ~{ ~ |~ ~ z~ ~ { ~} ~ |}~ ~ z~ ~ {{ }~{ ~ ~ |~ ~ |~ { z~ ~ z~ {{ ~{ ~ z~ ~ z~ ~ { ~z ~ z~ ~ z~ ~ }{{{ |~ ~ z ~ ~ z~ ~ }{{ ~{ ~ z~ ~ z~ ~ }z{{ ~ ~ z}~ ~ z~ ~ }|{ ~ ~ z{~| ~ z~ ~ }{{ |~ ~ }~ ~ z~ ~ z{{{ |~ ~ }~{ ~ z~ ~ zz{{ z{{ z ~{ ~ }~| ~ z~ ~ z {{ z|~ ~ }~| ~ z~ ~ z{{ |}{{ |{{ |{{ cc ^ e^^^ e ¡ ¢ ¢ £ ¤¡ ¢ ¥ ¦ ¤¡ ¥ ¡ ¡ ¢ ¡ ¦ ¦ ¡ §¢ ¡ ¢ ¢ £ ¤¡ ¥ §¢ ¤¡ ̈ © ¤¡ ¦¡¢¦ ¡¢ ¡ ¡ ª ̈ ¤¡ £ ¤¡ ¡ £¡© £¡¡ ¡ ¤¡ ̈ © ¤¡ ¥ ¦ ¤ ¡ ¡¥ ¡ ¡ ¤¡ ̈ © ¡¤ ¢¦ ¡ ¤¡ ¦ £ ¦ ¡ £¡¡ ¢¦ ¡ ¤¡ ! "#$% &'()*+,'-./01222131441567819::;<-:.0 0'='>'?@' 2A)B*' CD EFGH IJKLM NO HF PP NJO Q R SRJILK IT UK SO GN VLPP JR GN S ROT WGOFJLO OF WRGOO N SSRJX P JV YZ[\ EF GNVJRM OGJN KJNO GN I F R GN GH OJ Q LH I JNP] VJR OF SLRSJH VJR WFGKF GO GH HLQMGOO I NI GH NJO OJ Q R P H I GN WFJP JR S RO WGOFJLO WRGOO N SSRJX P JV YZ[\ ^_ `a bcdeca f efgh ijklmknop qrs tkuvwxyk zkj{xwwxyxwp | j }~ nmowxyxwp | { j…
Text truncated - open the document above for the full version.
RF Exposure Info
The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China SAR TEST REPORT Product Name: Smart phone Model Name: K60 FCC ID: 2APX7K60 Issued For : KRIPTO MOBILE CORPORATION 7640 NW 25TH ST STE 101, MIAMI, FL 33122 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23C021HA01 Sample Received Date: Mar. 14, 2023 Date of Test: Mar. 16, 2023~ Mar. 28, 2023 Date of Issue: Apr. 04, 2023 Max. SAR (1g): Head:0.718 W/kg Body: 0.851 W/kg Report No.: LGT23C021HA01 Page 2 of 112 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 7 1.3 Test Factory 7 2. Test Standards and Limits 8 3. SAR Measurement System 9 3.1 Definition of Specific Absorption Rate (SAR) 9 3.2 SAR System 9 4. Tissue Simulating Liquids 12 4.1 Simulating Liquids Parameter Check 12 5. SAR System Validation 14 5.1 Validation System 14 5.2 Validation Result 15 6. SAR Evaluation Procedures 16 7. EUT Antenna Location Sketch 17 7.1 SAR test exclusion consider table 18 8. EUT Test Position 23 8.1 Define Two Imaginary Lines on the Handset 23 8.2 Hotspot mode exposure position condition 24 9. Uncertainty 25 9.1 Measurement Uncertainty 25 9.2 System validation uncertainty 26 10. Conducted Power Measurement 27 10.1 Test Result: 27 11. EUT and Test Setup Photo 57 11.1 EUT Photos 57 11.2 Setup Photos 60 12. SAR Result Summary 66 12.1 Head SAR 66 12.2 Body-worn and Hotspot SAR 69 13. Equipment List 75 Appendix A. System Validation Plots 76 Appendix B. SAR Test Plots 88 Appendix C. Probe Calibration and Dipole Calibration Report 112 Report No.: LGT23C021HA01 Page 3 of 112 Revision History Rev. Issue Date Contents 00 Apr. 04, 2023 Initial Issue Report No.: LGT23C021HA01 Page 4 of 112 TEST REPORT CERTIFICATION Applicant KRIPTO MOBILE CORPORATION Address 7640 NW 25TH ST STE 101, MIAMI, FL 33122 Manufacture HuaYueShiTong Software Technology Co.,Ltd Address Room 703-704, Building B, Phase 1, WankeYuncheng Innovation Valley, Xili Street, Nanshan District, Shenzhen Product Name Smart phone Trademark KRIP Model Name K60 Sample number LGT2303019 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Zane Shan Engineer Vita Li Manager Report No.: LGT23C021HA01 Page 5 of 112 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Smart phone Trademark KRIP Model Name K60 Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled IMEI IMEI 1: 359058075452164 IMEI 2: 359058075452172 Hardware Version TH106S V1.0 Software Version KRIP_K60_EN_13_HW1_V001_20230307 Frequency Range GSM 850: 824 MHz ~ 849 MHz PCS 1900: 1850 MHz ~ 1910 MHz WCDMA Band II: 1850 MHz ~ 1910 MHz WCDMA Band V: 824 MHz ~ 849 MHz LTE Band 2:1850 MHz ~1910MHz LTE Band 4:1710 MHz ~1755MHz LTE Band 5:824 MHz ~ 849MHz LTE Band 7:2500 MHz ~ 2570MHz LTE Band 12:699 MHz ~716MHz LTE Band 17:704 MHz ~ 716MHz WLAN 802.11b/g/n20: 2412 MHz ~ 2462 MHz Bluetooth: 2402 MHz ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Head:0mm Body Worn and Hotspot:10mm Mode Head (W/ kg) Body Worn and Hotspot (W/ kg) GSM 850 0.168 0.280 PCS 1900 0.188 0.272 WCDMA Band II 0.616 0.652 WCDMA Band V 0.174 0.221 Report No.: LGT23C021HA01 Page 6 of 112 LTE Band 2 0.718 0.405 LTE Band 4 0.420 0.447 LTE Band 5 0.139 0.215 LTE Band 7 0.365 0.851 LTE Band 12 0.066 0.122 LTE Band 17 0.107 0.148 2.4G WLAN 0.161 0.090 Bluetooth 0.068 0.047 1-g Sum SAR 0.879 0.941 Battery Rated Voltage:3.85V Capacity:4800mAh Description test modes SIM 1 and SIM 2 is a chipset unit and tested as single chipset, SIM 1 is used to tested Operating Mode: GSM: GSM Voice; GPRS/EGPRS Class 12 WCDMA: RMC, HSDPA, HSUPA Release 6 LTE: QPSK, 16QAM 2.4G WLAN: 802.11b(DSSS): CCK, DQPSK, DBPSK 802.11g(OFDM): BPSK, QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK, QPSK,16-QAM,64-QAM Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification GSM/WCDMA/LTE: Internal Antenna Bluetooth: Internal Antenna WLAN: Internal Antenna Operating Mode Maximum continuous output SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot trans mitting at the same time Hotspot Mode Support DTM Mode Not Support Report No.: LGT23C021HA01 Page 7 of 112 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate FCC Registration No.: 746540 A2LA Certificate No.: 6727.01 IC Registration No.: CN0136 Report No.: LGT23C021HA01 Page 8 of 112 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std.…
Text truncated - open the document above for the full version.
Test Report
ShenZhen Huaxinwei communication technology Co.,Ltd. Antenna test report 2 The customer name Hua Yue Shi Tong Project Name N62F NO. project Detailed above 1 spectrum GSM850/900/1800/1900+WCDMA-B1/2/5/8+LTE-B2/3/4/5/7/8/12/17/28+ GPS/WIFI/BT 2 Project type The mobile phone 3 Antenna space area 4 Feed point type 5 The sensitivity 6 Type of antenna 7 The length of the PCB board 8 note Debugging prototype RF Zhang Jun 13430515055 [email protected] 3 1、 Test system and test equipment System Brand: MVG(SATIMO) measurement features: gain • pattern beamwidth cross polarization resolution sidelobe level 3D cavity reflectance at any polarization cavity reflectance (line or arc) antenna efficiency TRP, TIS, EIRP and EIS. Frequency band: StarLab 6 GHZ - 650 MHZ to 6 GHZ Link antenna The object under test Test Equipment Antenna position WWAN LB antenna GPS/WIFI/BT antenna diversity antenna WWAN M&H antenna Efficient ( 2G+3G+4G+2.4G-WiFi /BT) PEAK GAIN 2G: Frequency range dBi GSM850 824~894Mhz -0.71 GSM900 880~960Mhz -1.05 DCS1800 1710~1880Mhz 0.63 PCS1900 1850~1990Mhz 0.81 3G: W1 1920~2170Mhz 0.92 W2 1850~1990Mhz 0.81 W5 824~894Mhz -0.71 W8 880~960Mhz -1.05 4G: LTE-B2 1850~1990Mhz 0.81 LTE-B3 1710~1880Mhz 0.63 LTE-B4 1710~2155Mhz 0.92 LTE-B5 824~894Mhz -0.71 LTE-B7 2500~2690Mhz 1.12 LTE-B8 880~960Mhz -1.05 LTE-B12 698~746Mhz -1.42 LTE-B17 704~746Mhz -1.42 LTE-B28 708~798Mhz -1.42 WIFI 2400~2500Mhz 2.08dBi BT 2400~2500Mhz 2.08dBi Efficient ( GSM850+W5+LTE-B5 824~894MHz ） Efficient ( GSM900+W8+LTE-B8 880~960MHz ） Efficient ( GSM1800+LTE-B3 1710~1880 MHz） Efficient ( GSM1900+W2+LTE-B2 1850~1990 MHz ） Efficient (W1+LTE-B4 1710~2170MHz ） Efficient ( LTE-B7 2500~2690MHz ） Efficient (LTE-B12/17/28 698~798 MHz ） Efficient (2.4GWIFI/BT) Master antenna specifications GPS/WIFI/BT Specifications Diversity antenna specifications
Test Report
Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 1 of 43 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: Smart phone Trade Mark: KRIP Test Model: K60 FCC ID: 2APX7K60 Environmental Conditions Temperature: 23.8°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Anna Hu Supervised by: Hugo Chen NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.942 2401.541 2402.483 --- --- 2441 0.939 2440.541 2441.480 --- --- 2480 0.939 2479.547 2480.486 --- --- 2DH5 Ant1 2402 1.293 2401.364 2402.657 --- --- 2441 1.317 2440.343 2441.660 --- --- 2480 1.311 2479.346 2480.657 --- --- 3DH5 Ant1 2402 1.335 2401.331 2402.666 --- --- 2441 1.278 2440.352 2441.630 --- --- 2480 1.272 2479.358 2480.630 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 2 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 3 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 4 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 5 of 43 Appendix B: Occupied Channel Bandwidth Test Result TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.85527 2401.5722 2402.4275 --- --- 2441 0.83857 2440.5801 2441.4187 --- --- 2480 0.85550 2479.5689 2480.4244 --- --- 2DH5 Ant1 2402 1.1970 2401.4054 2402.6024 --- --- 2441 1.1898 2440.4080 2441.5978 --- --- 2480 1.1956 2479.4039 2480.5995 --- --- 3DH5 Ant1 2402 1.2014 2401.3942 2402.5956 --- --- 2441 1.1938 2440.4000 2441.5938 --- --- 2480 1.2041 2479.3909 2480.5950 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 6 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 7 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 8 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 9 of 43 Appendix C: Maximum Peak conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant1 2402 7.47 ≤30.00 PASS 2441 7.25 ≤30.00 PASS 2480 4.85 ≤30.00 PASS 2DH5 Ant1 2402 7.63 ≤20.97 PASS 2441 8.48 ≤20.97 PASS 2480 5.9 ≤20.97 PASS 3DH5 Ant1 2402 7.82 ≤20.97 PASS 2441 8.79 ≤20.97 PASS 2480 6.16 ≤20.97 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 10 of 43 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 11 of 43 2DH5_Ant1_2402 2DH5_Ant1_2441 2DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 12 of 43 3DH5_Ant1_2402 3DH5_Ant1_2441 3DH5_Ant1_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 13 of 43 Appendix D: Carrier frequency separation Test Result TestMode Antenna Channel Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 1.014 ≥0.942 PASS 2DH5 Ant1 Hop 1.11 ≥0.878 PASS 3DH5 Ant1 Hop 1.134 ≥0.890 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 14 of 43 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 15 of 43 Appendix E: Time of occupancy Test Result TestMode Antenna Channel BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.894 110 0.318 ≤0.4 PASS 2DH5 Ant1 Hop 2.883 90 0.259 ≤0.4 PASS 3DH5 Ant1 Hop 2.882 110 0.317 ≤0.4 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 16 of 43 Test Graphs DH5_Ant1_Hop DH5_Ant1_Hop 2DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 17 of 43 2DH5_Ant1_Hop 3DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 18 of 43 Appendix F: Number of hopping channels Test Result TestMode Antenna Channel Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 19 of 43 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 20 of 43 Appendix G: Band edge measurements Test Result TestMode Antenna ChName Channel RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 7.21 -49.25 ≤-12.79 PASS High 2480 4.67 -48.03 ≤-15.33 PASS Low Hop_2402 6.68 -50.24 ≤-13.32 PASS High Hop_2480 4.99 -48.57 ≤-15.01 PASS 2DH5 Ant1 Low 2402 5.54 -43.37 ≤-14.46 PASS High 2480 3.85 -47.87 ≤-16.15 PASS Low Hop_2402 2.53 -49.67 ≤-17.47 PASS High Hop_2480 2.86 -49.16 ≤-17.14 PASS 3DH5 Ant1 Low 2402 5.74 -42.25 ≤-14.27 PASS High 2480 3.66 -48.75 ≤-16.34 PASS Low Hop_2402 1.96 -50.45 ≤-18.04 PASS High Hop_2480 3.33 -48.77 ≤-16.67 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 21 of 43 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 22 of 43 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 2DH5_Ant1_High_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 23 of 43 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480 3DH5_Ant1_Low_2402 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 24 of 43 3DH5_Ant1_High_2480 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Repo…
Text truncated - open the document above for the full version.
Test Report
Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2APX7K60 Report No.: TZ230304140-E1 Page 40 of 43 Test Graphs DH5_An…
Text truncated - open the document above for the full version.
Contact Information
Applicant
RENATO TAVARES
Test Firm
Shenzhen Tongzhou Testing Co., LTDAndy Zhang
[email protected]+86-755-32902198
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 7.60 mW |
