0/27 All product specifications are subject to change without notice CBSD Outdoor Small Cell T99B226 User Manual 1/27 All product specifications are subject to change without notice 1. Introduction ................................................................................................ 2 2. HW installation guide and specifications ......................................................... 3 3. Private Network Solution ............................................................................ 12 3.1 Configuration Overview .............................................................................. 12 3.1.1 Basic Setting ............................................................................................... 13 3.1.2 Advanced Setting ........................................................................................ 14 3.1.2.1 Cell Configuration ..................................................................................... 14 3.1.2.2 Rem Configuration .................................................................................... 15 3.1.2.3 Gateway Configuration ............................................................................. 16 3.2 Sniffer ........................................................................................................ 16 3.3 Syslog ........................................................................................................ 16 3.4 Alarm ........................................................................................................ 17 3.5 Diagnostic .................................................................................................. 17 4. Warranty and compliance ........................................................................... 18 5. Frequently Asked Questions ........................................................................ 19 6. Troubleshooting.......................................................................................... 25 2/27 All product specifications are subject to change without notice 1. Introduction A compact, high output power, resilient CBRS (Citizens Broadband Radio Service) complied LTE Small Cell is presented in Fig1.1. The device is water and dust- proof (IP65) and can be pole mounted, which makes it suitable to be deployed in a dense factory area, both indoors and outdoors. Figure 1.1 T99B226 overview The LTE CA technology deployed in this outdoor small cell is complied with specification defined by IEEE 3GPP Alliance. The small cell has four LTE and one GPS antenna ports and is powered through 56 VDC PoE. Its LTE interface operates in CBRS band and supports SAS, Spectrum Access System. By using GPS Timing synchronization, handover between various small cells can be achieved. This is essential for scenarios that need quick switches between base stations, such as AGV (Automatic Guide Vehicle) for factory automation. 3/27 All product specifications are subject to change without notice 2. HW installation guide and specifications This section describes HW overview of the Outdoor Small Cell-T99B226 Connectors and Interfaces As shown below in fig 2.1, T99B226 consists of four N-type cable connectors (LTE antenna #1,2,3,4) on the bottom side of the device for LTE antennas and an ethernet RJ45 port for power. There are four bolt holes on the back side of the device so that it can be pole mounted onto a factory pole by using a mounting bracket. The SMA connector on the back side of the device can be used to connect to GPS antenna and provide 3.3V DC power to it. Figure 2.1 T99B226 Ports and Connectors LTE Antenna #1 (Ant2-Main) LTE Antenna #2 (Ant2-Div) RJ45 GPS Antenna LTE Antenna #3 (Ant1-Main) LTE Antenna #4 (Ant1-Div) Vent valve Bracket screw 4/27 All product specifications are subject to change without notice Cable routing and installation guide While installing, the device should have a clear view towards potential user transmitters and not obstructed by nearby trees or buildings. Once you pick an ideal installation spot, place the mast bracket and wrap it around the mast, clamp the bracket and device together by tightening screws through bolt holes on the back of device and the bracket. LTE antenna wires need to be pulled from the N-Type connectors on device along four bracket arms to four antennas on each corner as shown in figure2.2 and the running wires can be fixed onto bracket arms using bracket ties. It is the best practice to keep antenna rods perpendicular to bracket branches and make sure four antennas are evenly distributed in four corners. Figure 2.2 T99B226 cables top view LTE Antenna #3 LTE Antenna #4 Cable routing on Bracket LTE Antenna #1 LTE Antenna #2 5/27 All product specifications are subject to change without notice Moreover, the GPS antenna needs to be positioned at a place where GPS reception is solid, and the wire connecting GPS antenna to the device needs to be attached to the pole to ensure the stability of the connection during non-ideal weather conditions. Power for T99B226 is provided by connecting the power to a POE (power on Ethernet) adapter and through the waterproof ethernet cable to the ethernet port next to the antenna ports as shown in fig2.3. For the same reasons, the wires need to be attached to the pole firmly and the waterproof ethernet port is complied with IP65 regulations which makes it resilient to outdoors conditions. Figure 2.3 T99B226 assemble front view Installation bracket guide. Total overview: Cable tie LTE Antenna GPS Antenna 5VDC output for supporting 5 V A c t i v e GPS Antenna LTE Antenna PoE adaptor 6/27 All product specifications are subject to change without notice Assembly Step1: Bracket base and housing assemble: 7/27 All product specifications are subject to change without notice Assembly Step3: Antenna holder assemble: Assembly Step4: Antenna holder and bracket assemble: 8/27 All product specifications are subject to change without notice Assembly Step5: Fix the bracket on pole: As…
