Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 169 | 27 | 3.46 GHz - 3.53 GHz | 584.80 mW | 27M8W7D | 2.5
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesOutput power listed is conducted. Single Modular Approval for mobile RF Exposure condition. The module antenna(s) must be installed to meet the RF exposure compliance separation distance of 20 cm and any additional testing and authorization process as required. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. Approved for OEM integration only. The grantee must provide OEM integrators, or end-users if marketed directly to end-users, with installation and operating instructions for satisfying FCC multi-transmitter product guidelines. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end-user has no manual instructions to remove or install the device. This transmitter must be installed and operated so as to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures, or as evaluated in this filing.
This device supports LTE of 1.4, 3, 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Bands 2, 4, 25 and 66; LTE of 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Bands 7 and 71; LTE of 1.4, 3, 5 and 10 MHz bandwidth modes for FDD LTE Bands 5 and 12; LTE of 5 and 10 MHz bandwidth modes for FDD LTE Bands 13, 14, 17 and 30; LTE of 1.4, 3, 5, 10 and 15 MHz bandwidth modes for FDD LTE Band 26; and LTE of 5, 10, 15 and 20 MHz bandwidth modes for TDD LTE Bands 38, 41 and 42. Certification of LTE band 42 operations is limited to the 3.45 GHz segment under Part 27.5(o). This device also supports LTE uplink carrier aggregation: 2C/5B/7C/38C/41C/42C/43C/66B/66C, and Inter Band CA combinations: NR n5+n78 and NR n78+n5.
This device also supports Frequency Range 1 5G NR modes of 5, 10, 15, and 20 MHz bandwidth for FDD Bands n2, n5, n26 and n71; 5, 10 and 15 MHz bandwidth for FDD Bands n12 and n70; 5, 10, 15, 20, 25, 30 and 40 MHz bandwidth for FDD Bands n7 and n25; 5, 10, 15, 20, 30 and 40 MHz bandwidth for FDD Band n66; 5, and 10 MHz bandwidth modes for FDD Bands n13, n14 and n30; 10, 15, 20, 30 and 40 MHz bandwidth modes for TDD Band n38; 20, 30, 40, 50, 60, 70, 80, 90 and 100 MHz bandwidth modes for TDD Band n41; and 10, 15, 20, 30, 40, 50, 60, 70, 80, 90 and 100 MHz bandwidth modes for TDD Bands n77 and n78. Certification of 3GPP 5G NR band n77/n78 operations is limited to the 3.45 GHz segment under Part 27.5(o) and the 3.7 GHz segment under Part 27.5(m). This device also supports LTE uplink carrier aggregation: NR n5+n78 and NR n78+n5. Frequency Range 1 5G NR ENDC modes: LTE Band 4+NR n7; LTE Band 26+NR n25; LTE Band 2+ NR n48; LTE Band 5+ NR n48; LTE Band 13+ NR n48; and LTE Band 66+ NR n48; n2 + LTE Band 4/5/7/12/13/14/30/66/71; n5 + LTE Band 2/7/30/66; n7 + LTE Band 5/12/13; n12 + LTE Band 2/7/30/66; n14 + LTE Band 2/30/66;n25 + LTE Band 7/12/13/66;n30 + LTE Band 2/5/12/14/66;n38 + LTE Band 2/4/5/12/66/71; n41 + LTE Band 2/4/5/12/25/26/66; n66 + LTE Band 2/5/7/12/13/14/30/71; n71 + LTE Band 2/7/66; n77 + LTE Band 2/5/7/12/13/14/25/30/41/66/71; n78 + LTE Band 2/4/5/7/12/25/26/38/41/66/71. This device contains functions that are not operational in U.S. Territories; this filing is applicable only for U.S. operations.
