2AQ68W6RD2201Indoor Wireless Gateway

Indoor Wireless Gateway Model • W6R-D220-101 Physical • Dimensions: 220 x 220 x 48.5 mm • Weight: 630 g • PoE Input: Standard PoE 802.3at • DC Input: 12V • Power consumption: < 30W • Mounting: Kit included celling mount of the CPE Environmental • Operating Temperature: 0º C to 40º C • Storage Temperature: 0º C to 75º C • Humidity: Operating 10~90%; Storage 5~95% Wi-Fi • Radio Access: WIFI alliance 802.11ax standard • Frequency Band: 2.4G and 5G • Maximum Throughput: 1800 Mbps User Interfaces • Data Interface: 1 x RJ45, Gigabit Ethernet, 802.3at PoE Device Management • Wi-Fi Management System Industry Standards • IEEE IEEE 802.11ax IEEE 802.3at PoE Package Contents • Indoor wireless gateway • Celling Mounting Kit Installation Connector and Interface, WAN port is the PoE port. Hook Gateway onto the ceiling mount pic 1 pic 2 Pic 3 Network access The indoor ap WAN is configured as Ethernet with DHCP client through the PoE connectivity. In the installation environment, there is no extra configuration is needed if a DHCP server is available through Ethernet connection. Since the indoor ap is control by the Wi-Fi management system, server IP must be configured before installation, use Laptop to connect to device via Wi-Fi or LAN port then go to Wi-Fi management page to input to proper IP address, press Enter than everything is ready, once device get online, Wi-Fi management system will know it. The default IP address of the Indoor AP is 192.168.1.100 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

HON LIN Technology Co., Ltd. 11F, No.32, Jihu Rd., Neihu Dist., Taipei City 114, Taiwan R.O.C. TEL: + 886 2 2267 6511 FAX: + 886 2 2267 6512 Date: 2022/7/12 FCC ID: 2AQ68W6RD2201 To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics / Block Diagram Operational Description Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Nancy Lin / Associate Manager Tel: + 886 2 2267 6511 Fax: + 886 2 2267 6512 E-mail: [email protected]

HON LIN Technology Co., Ltd. 11F, No.32, Jihu Rd., Neihu Dist., Taipei City 114, Taiwan R.O.C. TEL: + 886 2 2267 6511 FAX: + 886 2 2267 6512 Date: 2022/7/12 FCC ID: 2AQ68W6RD2201 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, Nancy Lin / Associate Manager Tel: + 886 2 2267 6511 Fax: + 886 2 2267 6512 E-mail: [email protected]

HON LIN Technology Co., Ltd. 11F, No.32, Jihu Rd., Neihu Dist., Taipei City 114, Taiwan R.O.C. TEL: + 886 2 2267 6511 FAX: + 886 2 2267 6512 Date: 2022/7/12 FCC ID: 2AQ68W6RD2201 AUTHORIZATION LETTER To Whom It May Concern: HON LIN Technology Co., Ltd. hereby authorizes Amanda Wu of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu of BV CPS Taoyuan on HON LIN Technology Co., Ltd.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Nancy Lin / Associate Manager Tel: + 886 2 2267 6511 Fax: + 886 2 2267 6512 E-mail: [email protected]

Reference No.:BHQC-WTW-P22060178_Ext Page 1/4 CONSTRUCTION PHOTOS OF EUT Reference No.:BHQC-WTW-P22060178_Ext Page 2/4 Reference No.:BHQC-WTW-P22060178_Ext Page 3/4 Reference No.:BHQC-WTW-P22060178_Ext Page 4/4

Label LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. EUT Bottom

Reference No.:BHQC-WTW-P22060178_Int Page 1/13 CONSTRUCTION PHOTOS OF EUT Reference No.:BHQC-WTW-P22060178_Int Page 2/13 Reference No.:BHQC-WTW-P22060178_Int Page 3/13 Reference No.:BHQC-WTW-P22060178_Int Page 4/13 Reference No.:BHQC-WTW-P22060178_Int Page 5/13 Reference No.:BHQC-WTW-P22060178_Int Page 6/13 Reference No.:BHQC-WTW-P22060178_Int Page 7/13 Reference No.:BHQC-WTW-P22060178_Int Page 8/13 Reference No.:BHQC-WTW-P22060178_Int Page 9/13 Reference No.:BHQC-WTW-P22060178_Int Page 10/13 Reference No.:BHQC-WTW-P22060178_Int Page 11/13 Reference No.:BHQC-WTW-P22060178_Int Page 12/13 Reference No.:BHQC-WTW-P22060178_Int Page 13/13

Report No.: MFBHQC-WTW-P22060178 Page No. 1 / 10 Report Format Version: 7.1.0 RF EXPOSURE REPORT CERTIFICATE OF CONFORMITY FCC Rule Part: FCC Part 2 (Section 2.1091 & 2.1093) Report No.: MFBHQC-WTW-P22060178 FCC ID: 2AQ68W6RD2201 Model No.: W6R-D220-101 Received Date: 2022/6/6 Test Date: 2022/7/20 Issued Date: 2022/7/28 Applicant: HON LIN Technology Co., Ltd. Address: 11F, No.32, Jihu Rd., Neihu Dist., Taipei City 114, Taiwan R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 Approved by: , Date: 2022/7/28 May Chen / Manager This test report consists of 10 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Vivian Huang / Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBHQC-WTW-P22060178 Page No. 2 / 10 Report Format Version: 7.1.0 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Applicable RF Exposure Limit .................................................................................................................................. 5 3 Applicable Evaluation Criteria .................................................................................................................................. 6 4 Test Results ................................................................................................................................................................ 8 5 Conclusion .................................................................................................................................................................. 9 6 Information of the Testing Laboratories ................................................................................................................ 10 Report No.: MFBHQC-WTW-P22060178 Page No. 3 / 10 Report Format Version: 7.1.0 Release Control Record Issue No. Description Date Issued MFBHQC-WTW-P22060178 Original release. 2022/7/28 Report No.: MFBHQC-WTW-P22060178 Page No. 4 / 10 Report Format Version: 7.1.0 1 Certificate Product: Indoor Wireless Gateway Brand: Hon Lin Test Model: W6R-D220-101 Sample Status: Engineering sample Applicant: HON LIN Technology Co., Ltd. Test Date: 2022/7/20 FCC Rule Part: FCC Part 2 (Section 2.1091 & 2.1093) Standard: KDB 447498 D04 Interim General RF Exposure Guidance v01 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Report No.: MFBHQC-WTW-P22060178 Page No. 5 / 10 Report Format Version: 7.1.0 2 Applicable RF Exposure Limit § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatialaverage SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, averaged over any 10 grams of tissue (defined as a ti…

Text truncated - open the document above for the full version.

INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-01-287 DOCUMENT ENS000156280 SPEC REV. NO. P1 PAGE 1 OF 4 Embedded Dual-Band Antenna for WA-P-LB-01-287 1. Explanation of part number： (1) (2) (3) (4) (5) (1) Product Type：Wireless Antenna (2) Material： PCB (3) Frequency：2400-2500、5150-5850 MHz (4) Coaxial Cable Type：White Cable (5) Suffix：287 2. Electrical Specification ： Those specifications were specially defined for IDL755 model Dual-Band Antenna, and all characteristics were measured under the model’s handset testing jig. 2-1. Frequency Band： Frequency Band MHz WiFi 2400-2500、5150-5850 MHz 2-2. Impedance： 50 ohm nominal 2-3. Matching circuit ： None W A P L B 0 1 2 8 7 INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-01-287 DOCUMENT ENS000156280 SPEC REV. NO. P1 PAGE 2 OF 4 2-4. VSWR： 2-5. Efficiency： INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-01-287 DOCUMENT ENS000156280 SPEC REV. NO. P1 PAGE 3 OF 4 3. Antenna Drawing： The appearance of the antenna is according to drawing Figure . 3-1-1 Drawing Rev.P0 Figure 3-1-1. ITEM DESCRIPTION MATERIAL SPECIFICATION QUANTITY UNIT SUPPLIER UL NO. 1 PCB L45*W28.4*T0.8mm 1 PCS N/A N/A 2 Cable 1.13LLS,White 1 PCS HA0008 E318898 3 Tube Transparent 1 PCS HA0059 N/A 4 Connector IPEX MHF I-PEX Equivalent(compatible) 1 PCS HA0063 E213445 INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-01-287 DOCUMENT ENS000156280 SPEC REV. NO. P1 PAGE 4 OF 4 4. Connector Specification：

INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-883 DOCUMENT ENS000156290 SPEC REV. NO. P1 PAGE 1 OF 4 Embedded Dual-Band Antenna for WA-P-LB-02-883 1. Explanation of part number： (1) (2) (3) (4) (5) (1) Product Type：Wireless Antenna (2) Material： PCB (3) Frequency：2400-2500、5150-5850 MHz (4) Coaxial Cable Type：Black Cable (5) Suffix：883 2. Electrical Specification ： Those specifications were specially defined for IDL755 model Dual-Band Antenna, and all characteristics were measured under the model’s handset testing jig. 2-1. Frequency Band： Frequency Band MHz WiFi 2400-2500、5150-5850 MHz 2-2. Impedance： 50 ohm nominal 2-3. Matching circuit ： None W A P L B 0 2 8 8 3 INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-883 DOCUMENT ENS000156290 SPEC REV. NO. P1 PAGE 2 OF 4 2-4. VSWR： 2-5. Efficiency： INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-883 DOCUMENT ENS000156290 SPEC REV. NO. P1 PAGE 3 OF 4 3. Antenna Drawing ： The appearance of the antenna is according to drawing Figure . 3-1-1 Drawing Rev.P0 Figure 3-1-1. ITEM DESCRIPTION MATERIAL SPECIFICATION QUANTITY UNIT SUPPLIER UL NO. 1 PCB L45*W28.5*T0.8mm 1 PCS N/A N/A 2 Cable 1.13LLS,White 1 PCS HA0008 E318898 3 Tube Transparent 1 PCS HA0059 N/A 4 Connector IPEX MHF I-PEX Equivalent(compatible) 1 PCS HA0063 E213445 INPAQ TECHNOLOGY CO., LTD 2021/09/28 `UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：涂正憲 CHECKED BY：鄭榮謀 DESIGNED BY：黃健育 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-883 DOCUMENT ENS000156290 SPEC REV. NO. P1 PAGE 4 OF 4 4. Connector Specification：

Reference No.: BHQC-WTW-P22060178_TSup Page 1/5 PHOTOGRAPHS OF THE TEST CONFIGURATION AC Power Conducted Emissions Reference No.: BHQC-WTW-P22060178_TSup Page 2/5 Unwanted Emissions below 1 GHz Reference No.: BHQC-WTW-P22060178_TSup Page 3/5 Reference No.: BHQC-WTW-P22060178_TSup Page 4/5 Unwanted Emissions above 1 GHz Reference No.: BHQC-WTW-P22060178_TSup Page 5/5
