2AQ8LTREKC2Temperature Data logger with Bluetooth

Parsyl Trek Tab User Guide 2021 TrekTab The Android App The Web Application Gateway Safety and Certification 1 The Trek Tab Product Sheet Basic specifications of Trek Tab device User Guide Shipments Configuration Settings 2 The Trek Tab Product Overview Sensors Temperature Normal Operating Range-30°C to +55°C Sensing Range-30°C to +70°C Accuracy±0.3°C to ±0.4°C Resolution0.01°C CalibrationNIST Traceable, ISO/IEC 17025 certified Enclosures Dimensions51mm x 26mm x 5.3mm Weight9g Battery100 days of active logging at 0°C, 24-month shelflife at 20°C MaterialPolycarbonate + ABS Humidity0% - 95% RH (Storage, Operating, Transport) Ingress Protection IP67-rated. Water and dust resistant. Status Indicators Bright LED lights indicate status of device and monitoring. Wireless Connectivity Bluetooth Low Energy (BLE) 5.0 - 2.4GHz, Class 2. Warranty The product is covered by a one year warranty in theevent of any component failure not caused by mechanical damage. 3 The Trek Tab User Guide Status button, LED Display The Trek Tab LED display utilizes indicator lightsin green or red in varying patterns to indicate status. The center LED indicates the recording status. A flashinggreen LED after a single short button press indicates that the Trek Tab is actively recording. The left [✔] LED indicates with a flashing green LEDafter a single short button press that the Trek Tab has not experienced conditions that exceedany of the threshold alarm settings. If the button is pressed while the TrekTab is actively recording,the [✔] LED will flash in sequence after the center LED flashing green. The right [✖] LED indicates with a flashing red LEDafter a single short button press when the Trek Tab has experienced at least one instance ofconditions exceeding at least one of the threshold alarm settings. If the button is pressedwhile the Trek Tab is actively recording, the right [✖] LED will flash in sequence after the centerLED flashing green. Shipments To activate the Trek Tab device to track a shipment,press and hold the ‘Push’ button for 3-seconds until the center LED flashes green. Dependingon your shipping profile settings, there may be a delay after the unit is activated until itbegins recording. To stop recording, press and hold the ‘Push’ buttonuntil the center LED flashes red.Note:The Trek Tab is intended to be a single use device. Oncerecording has been stopped it cannot be restarted. 4 To conserve battery power, after the Trek Tab has stopped recording, it will stop BLE advertising after prolonged periods without user interaction. Users can re-initiate BLE advertisements from this low-power state with a single short press ofthe ‘Push’ button. Data Transfer In order to access the data recorded on the Trek Tab,it will need to be offloaded by aGatewayor theParsyl Mobile App. To offload data with the app,start bylogging inor selectingTransfer Data. To view the Trek Tab data and analyze findings, loginto theParsyl Web Applicationand select the appropriate Shipment from the list within yourCompany to view the details. 5 The Trek Tab Configuration Settings Excursions An excursion is defined as any time spent outsideof “expected ranges” when monitoring your products. Excursion thresholds are defined by yourspecific needs and set by creating upper and lower limits of temperature. Options for excursions Within our excursion settings, you have two optionsfor tracking the excursions recorded by our Treks: ● Cumulativeexcursions will sum all of the time yourTrek Tab records values outside the predetermined range, even if those values temporarilyenter back into normal range during the Trek Tab’s journey. Optionally, the TrekTab can be reset once the alarm has been breached or the device has been turned off. ● Continuousexcursions occur only when the readingsfrom your Trek are outside the predetermined range, continuously, for a specifiedamount of time. The timer becomes reset upon detecting that readings have returned to“normal” or “expected” ranges. Alerts The Trek Tab can be configured to display and recordvarying alert “levels” given certain values and threshold conditions. There are three (optional) severity levels that canbe customized to your preferred workflow and procedure requirements: ● Info:normal, or expected recordings for data pointslogged by the Trek Tab. ● Warning:“concerning” recordings for data points loggedby the Trek Tab. ● Alarm:“high-level of concern” recordings for datapoints logged by the Trek Tab. Note:Only alarm and normal conditions are indicatedby the LEDs of the TrekTab. Warning conditions are accessible by means of mobile and webinterfaces. Customizations Within each alert type, the behavior requested wheneach severity threshold is met can be customized to your desire. Settings that are customizablefor displaying alarms on the Trek Tab include: ● Alarm threshold settings ● Logging start delay Please note that no action is required from the userto ensure uninterrupted use of the device during electromagnetic disturbance. 6 The Android App User Guide Getting Started Shipments Settings 7 The Android App User Guide Getting Started Before you begin, you must have a Parsyl account withappropriate permissions to access the Android App experience for your company’s Parsyl account. Download the Parsyl Android App from the Google Playstore,here. Once the download is complete, open the Parsyl Appfrom your Android phone. Log in by entering your email address or phone numberand entering the login code we send you. 8 Shipments The Shipments section of the Android app is reservedfor the monitoring and analyzing of shipment data recorded by the Trek Tab during itsjourney. Trek Details Screen Upon scanning the QR code of a Trek Tab, from theShipments section within the Mobile App, you will be taken to the Trek Details screen. This screen provides an example of the details ofthe shipment including at least one time-temperature limit violation for each alarm typeincluding the first time-temperature-violation o…

Text truncated - open the document above for the full version.

Date (06/15/2021) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Dear Sir or Madam, We, Parsyl Inc. 2825 Larimer Street, Denver CO 80205 USA hereby authorize Matt Zhang from TUV SUD Certification and testing (China) Co., Ltd. Guangzhou Branch, address is 5F, Communication Building, 163 Pingyun Rd, Huangpu West Ave. Guangzhou 510656 P. R. China, phone is +86 (0) 20 3815 3243, to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Type of equipment: Temperature Data logger Model name: TREKC2 FCC ID: 2AQ8LTREKC2 This authorization expires on 06/15/2022. Sincerely, Company Officer: Murat Erdogan Telephone Number: +1 5038587599 Email: [email protected]

Date (06/15/2021) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2AQ8LTREKC2 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Parsyl Inc. hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics PCB & Components list Block Diagrams Operating instruction The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Murat Erdogan Telephone Number: +1 5038587599 Email: [email protected]

Project No: Rev.: 00 Date: Page: 1 of 3 Telephone : +86 20 38320668 Telefax : +86 20 38320478 http://www.tuv-sud.cn TÜ V SÜ D Certification and Testing (China) Co., Ltd. Guangzhou Branch, TÜ V SÜ D Group 5F, Communication Building, 163 Pingyun Rd, Huangpu Ave. West, Guangzhou, 501656, P.R.China Photo Documentation Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Project No: Rev.: 00 Date: Page: 2 of 3 Telephone : +86 20 38320668 Telefax : +86 20 38320478 http://www.tuv-sud.cn TÜ V SÜ D Certification and Testing (China) Co., Ltd. Guangzhou Branch, TÜ V SÜ D Group 5F, Communication Building, 163 Pingyun Rd, Huangpu Ave. West, Guangzhou, 501656, P.R.China Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Project No: Rev.: 00 Date: Page: 3 of 3 Telephone : +86 20 38320668 Telefax : +86 20 38320478 http://www.tuv-sud.cn TÜ V SÜ D Certification and Testing (China) Co., Ltd. Guangzhou Branch, TÜ V SÜ D Group 5F, Communication Building, 163 Pingyun Rd, Huangpu Ave. West, Guangzhou, 501656, P.R.China Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Details of: General view of product View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom

Project No: Rev.: 00 Date: Page: 1 of 2 Telephone : +86 20 38320668 Telefax : +86 20 38320478 http://www.tuv-sud.cn TÜ V SÜ D Certification and Testing (China) Co., Ltd. Guangzhou Branch, TÜ V SÜ D Group 5F, Communication Building, 163 Pingyun Rd, Huangpu Ave. West, Guangzhou, 501656, P.R.China Photo Documentation Details of: View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Details of: View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom Bluetooth antenna Project No: Rev.: 00 Date: Page: 2 of 2 Telephone : +86 20 38320668 Telefax : +86 20 38320478 http://www.tuv-sud.cn TÜ V SÜ D Certification and Testing (China) Co., Ltd. Guangzhou Branch, TÜ V SÜ D Group 5F, Communication Building, 163 Pingyun Rd, Huangpu Ave. West, Guangzhou, 501656, P.R.China Details of: View: [ ] general [ ] front [ ] rear [ ] right [ ] left [ ] top [ ] bottom

Report Number: 64.790.20.05491.01-S Page 1 of 1 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F, Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 RF exposure Estimation Applicant: Parsyl Inc. Address: 2825 Larimer Street, Denver CO 80205 USA FCC ID: 2AQ8LTREKC2 1. Product information EUT is a Temperature Data logger, 2.4GHz Bluetooth technology was used for communicating. 2. Limit and Guidelines on Exposure to Electromagnetic Fields According to§15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D01 Mobile Portable RF Exposure v06, no SAR required if power is lower than the flowing threshold: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation25 • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 3. Calculation method [(max. power of` channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 Maximum output power: -1.49dBm = 0.71mW Distance = 5 mm f = 2.402 GHz [0.71/5] * SQRT(2.402) = 0.22 0.22 ≤ 3.0 Therefore, excluded from SAR testing. TUV SUD China, Guangzhou Branch Reviewed by: Prepared By: Peter Jia Matt Zhang Date: 2021-06-11 Date: 2021-06-11

Report Number: 64.790.21.02220.01 Page 1 of 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 FCC- TEST REPORT Report Number : 64.790.21.02220.01 Date of Issue: June 11, 2021 Model : TREKC2 Product Type : Temperature Data logger Applicant : Parsyl Inc. Manufacturer : Parsyl Inc. Address : 2825 Larimer Street, Denver CO 80205 USA Test Result : ◼ Positive  Negative Total pages including Appendices : 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 64.790.21.02220.01 Page 2 of 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 1 Table of Contents 1 Table of Contents ................................................................................................................................................................ 2 2 Details about the Test Laboratory ..................................................................................................................................... 3 3 Description of the Equipment under Test ........................................................................................................................ 4 4 Summary of Test Standards .............................................................................................................................................. 5 5 Summary of Test Results ................................................................................................................................................... 6 6 General Remarks ................................................................................................................................................................ 7 7 Test Setups .......................................................................................................................................................................... 8 8 Systems test configuration ................................................................................................................................................. 9 9 Technical Requirement .................................................................................................................................................... 10 9.1 Conducted Emission ................................................................................................................................................ 10 9.2 Conducted peak output power................................................................................................................................ 11 9.3 6dB bandwidth and 99% Occupied Bandwidth......................................................................................................... 13 9.4 Power spectral density ............................................................................................................................................. 17 9.5 Spurious RF conducted emissions ........................................................................................................................ 19 9.6 Band edge ................................................................................................................................................................. 23 9.7 Spurious radiated emissions for transmitter ......................................................................................................... 25 10 Test Equipment List ...................................................................................................................................................... 28 11 System Measurement Uncertainty ............................................................................................................................. 29 Report Number: 64.790.21.02220.01 Page 3 of 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 0478 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China FCC Registration Number: 514049 IC Registration Number: 10320A Telephone: 86 755 8828 6998 Fax: 86 755 828 5299 Report Number: 64.790.21.02220.01 Page 4 of 29 TÜV SÜD Certification and Testing (China) Co., Ltd. Guangzhou Branch 5F,Communication Building,163 Pingyun Rd, Huangpu Ave. West Guangzhou, P.R.China TEL: +86 20 3832 0668 FAX: +86 20 3832 04…
