User Guide EYES 8 - 1 - 01. Product Diagram USB-C Data Port x 1 USB 3.0 Hub Port x 3 microSD Card Reader x 1 SD Card Reader x 1 15W Super-Fast Charging Pad LED Indicator Tray Type-C Port to Power Type-C Port to Connect to Computer USB-C to USB-A Data Cable USB-C to USB-A Charging Cable USB-C to USB-A Converter Adapter Model POUT-02001 Size W 563mm x L 200mm x H 57mm Weight1,340g Material E0 MDF, ABS, TPE Rated Power Input5V 3A / 9V 2A / 12V 1.5A (Max) Rated Power Output Wireless Charging Pad: 5W / 7.5W / 10W / 15W (Max) Port 1-6: Power source from USB-C to USB-A input Total Power24W Operating Temperature-0°C ~ 40°C Storage Temperature-10°C ~ 50°C - 2 - 02. What is in the box? USER Guide 03. Instructions for use ① Connect the included ‘USB-C to USB-A Charging Cable’ to the device. ② Connect the other side of ‘USB-C to USB-A Charging Cable’ to an available fast charge adapter. To ensuring fast charging, you should use a fast charge adapter instead of charging through your computer. (*For best performance, please connect the included charging cable to the most appropriate fast charging adapter supporting QC3.0 or above) ③ Simply place your device on the charging area of this fast wireless charger. Wireless charging will begin in seconds. ① Connect the included ‘USB-C to USB-A Data Cable’ to the device. ② Connect the other side of ‘USB-C to USB-A Data Cable’ to an available USB port on your PC. (*To connect with USB-C port on your PC, please use the included ‘USB-C to USB-A Converter Adapter’) ③ The operating system should detect the hub and card reader immediately and automatically install it. ④ Connect your device(s) to the corresponding USB-C port (Port 1), USB 3.0 ports (Port 2, 3, 4) and microSD&SD slots. USB-C to USB-A Data Cable x 1USB-C to USB-A Power CableMonitor Stand x 1USB-C to USB-A Converter Adapter ① ② Wireless Charging ③①② USB HUBs ③ Port 1 Port 2,3,4 micro SD SD - 3 - 04. GOOD TO KNOW • USB-C Port (Port 1) is for data transfer only. • The computer will automatically install the driver at the first time when connecting to the Hub. Please wait for approximately five seconds to allow the installation to complete automatically. • To operate the product smoothly, please make sure that both the cables and adapter are completely plugged in when using the product. • In order to enjoy the super speed of 5Gbps, your PC host and OS must fully support USB 3.0; otherwise it can only reach the speed of USB 2.0 standard. • To prevent damage to the contents of the USB/memory/media card, please ensure you are following the correct procedure for removing storage from the operating system you are using. • In a Windows® operating environment, when the USB/memory/media card is first connected, the Safely Remove Hardware icon will appear. Right-click on the icon, and select Safely Remove Hardware. When the Safely Remove Hardware window appears, select USB Mass Storage Device, then click on Stop. This will, in turn, open the Stop a Hardware Device window. Select the USB Mass Storage Device again, and click on OK, then wait for the operating system to notify you that it can now be safely removed. • In a MAC OS operating environment, the added memory cards will appear on the desktop as disk drives. To safely remove the indicated drive(s), simply click and drag the icon to the Trash. Please read this manual before using the device to ensure safe and proper use. Images may differ in appearance from the actual product. Content is subject to change without prior notice. Appearances and specifications are subject to change without prior notice. Failure to comply with safety warnings and regulations can cause serious injury, property damage or death. This monitor stand securely supports up to 9 kg (20 lbs). Do not place any monitors and devices heavier than the recommended weight limit. Do not use the device for anything other than its intended use. Your device may mal - function. Do not insert the device or supplied accessories into the eyes, ears, or mouth. Doing so m a y cause suffocation or serious injuries. Do not bite or suck the device. Doing so may damage the device or result in an explosion or fire. Children or animals can choke on small parts. If children use the device, make sure that they use the device properly. The device can be used in locations with an ambient temperature of 0°C to 40°C. You can store the device at an ambient temperature of -10°C to 50°C. Using or storing the device outside of the recommended temperature ranges may damage to the device or reduce the device lifespan. Do not use damaged power cords or plugs, or loose electrical sockets. Unsecured connections can cause electric shock or fire. Use manufacturer-supplied power cable, data cable, and converter adapter. Using other cable and adapter may shorten the life of your device or cause the device to malfunction. They may also cause a fire or cause the devise to explode. Protect the device from damage. Avoid exposing your device to very cold or very hot temperatures. Extreme temperatures can damage the device and reduce the capacity and life of your device. Keep your device dry. Humidity and liquids may damage the parts or electronic circuits in your device. Do not turn on your device if it is wet. There may be some events such as wireless charging begins after 4-5 seconds even though your device is positioned on a charging area properly. It is a normal situation that magnetic field is transferring between a charging pad and a mobile de - vice. Do not drop or cause an impact to the device. Handle and dispose of the device with care. Never d i spose of the device in a fire. Never place the device on or in heating devices, such as microwave ovens, stoves, or radiators. The device may explode when overheated. Follow all local regulations when disposing of used device. Never crush or puncture the device. Do not disassemble, modify, or repair your device. Any changes or modifications to your device can void your manufacturer’s w…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 BROS & COMPANY INC. (March 25, 2020) To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ BROS & COMPANY INC. _____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AQIS-POUT-02001 Product Description: EYES8 Model: POUT-02001 Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 BROS & COMPANY INC. (March 25, 2020) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AQIS-POUT-02001 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected] SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 BROS & COMPANY INC. (March 25, 2020) To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AQIS-POUT-02001 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of / / not to exceed 180 days from the Grant Date. See KDB 726920. User Manual Internal Photos Test Setup photos External Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected]

Page 1 of 1 IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The FCC ID shall be permanently affixed in the rear side of the equipment Authorized Person - Print Name: KIYEOL PARK / CEO Date: March 25, 2020 Signature: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID : 2AQIS-POUT-02001

Coil Antenna

Page 1 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION COMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-203-RWD-066 AGR No. : A19DA-366R1 Applicant : BROS&COMPANY INC. Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Manufacturer : BROS&COMPANY INC. Address :A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Type of Equipment : EYES8 FCC ID. : 2AQIS-POUT-02001 Model Name : POUT-02001 Serial number : N/A Total page of Report : 12 pages (including this page) Date of Incoming : January 02, 2020 Date of issue : March 25, 2020 SUMMARY The equipment complies with the regulation; FCC CFR 47 PART 1.1310 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Reviewed by: Approved by: Ha-Ram Lee / Manager Jae-Ho Lee / General Manager ONETECH Corp. ONETECH Corp. Page 2 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................ 5 2.1 PRODUCT DESCRIPTION ................................................................................................................................................. 5 2.2 MODEL DIFFERENCES.................................................................................................................................................... 5 3. EUT MODIFICATIONS .................................................................................................................... 5 4. RADIO FREQUENCY EXPOSURE ................................................................................................ 6 4.1 ENVIRONMENTAL EVALUATION AND EXPOSURE LIMIT ................................................................................................ 6 Page 3 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Issue Report No. Issued Date Revisions Effect Section OT-203-RWD-066 March 25, 2020 Initial Release All Page 4 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : BROS&COMPANY INC. Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Contact Person : KIYEOL PARK / CEO Telephone No. : +82-31-286-8646 FCC ID : 2AQIS-POUT-02001 Model Name : POUT-02001 Serial Number : N/A Date : March 25, 2020 EQUIPMENT CLASS DCD – Part 15 Low Power Transmitter Below 1 705 kHz KIND OF EQUIPMENT EYES8 THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2013 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC CFR 47 PART 1.1310 MODIFICATIONS ON THE EQUIPMENT TO ACHIEVE COMPLIANCE No FINAL TEST WAS CONDUCTED ON 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximum emission levels emanating from equipment are within the compliance requirements. Page 5 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 2. GENERAL INFORMATION 2.1 Product Description The BROS&COMPANY INC., Model: POUT-02001 (referred to as the EUT in this report) is an EYES8. Product specification information described herein was obtained from product data sheet or user’s manual. DEVICE TYPE Wireless Charger OPERATING FREQUENCY 111 kHz ~ 205 kHz RATED RF OUTPUT POWER 54.0 dBμV/m ANTENNA TYPE Coil Antenna MODULATION ASK RATED SUPPLY VOLTAGE DC 5.0 V, DC 9.0 V, DC 12.0 V 2.2 Model Differences -. None 3. EUT MODIFICATIONS -. None Page 6 of 12 Report No.: OT-203-RWD-066 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 4. RADIO FREQUENCY EXPOSURE 4.1 Environmental evaluation and exposure limit According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of FCC part 2.1093 of this chapter Frequency Range [MHz] Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [mW/cm 2 ] Average Time [minutes] (A) Limits for Occupational / Control Exposures 0.3 – 3.0 614 1.63 *(100) 6 3.0 – 30 1 842/f 4.89/f *(900/f 2) 6 30 – 300 …
