2AQIS-POUT-02201HANDS3 SPLIT

User Guide HANDS 3 SPLIT 190702_HANDS 3 SPLIT_guide.indd 12019-07-03 오전 11:21:02 - 1 - 01. Specification ModelPOUT-02201 Size (Mouse Pad) 240x215mm (Charging Pad) 100x215mm (Total) 340x215mm Weight (Mouse Pad) 235g (Charging Pad) 115g (Total) 350g MaterialPC-ABS, PU, Magnet Rated Power InputDC 5V 2A / 9V 2A / 12V 2A Rated Power Output5W / 7.5W / 10W / 15W Frequency111-150 KHz (*China: 110~190 KHz) Operating Temperature0°C ~ 35°C Storage Temperature-20°C ~ 70°C Input Charging Area Area for Mouse Fast Charging Cable 190702_HANDS 3 SPLIT_guide.indd 22019-07-03 오전 11:21:02 - 2 - 02. What is in the box? Mouse Pad x 1Detachable Fast Wireless Charging Pad x 1 User Guide USB-C Type Fast Charging Cable x 1 190702_HANDS 3 SPLIT_guide.indd 32019-07-03 오전 11:21:02 - 3 - 03. Instructions for use 1. Connect the included fast charging USB cable to the device. 2. Connect the other side of fast charg - ing USB cable to an available fast charge adapter. To ensuring fast charging, you should use a fast charge adapter (QC2.0 or QC3.0) instead of charging through your computer. 3. Simply place your device on charging area of this fast wireless charger. Wireless charging will begin in seconds. Pad position for right-handed Vertical pad positionSeperate use of mouse pad and chanrging pad Pad position for left-handed * Examples of Efficient Usage 190702_HANDS 3 SPLIT_guide.indd 42019-07-03 오전 11:21:02 - 4 - 04. Warning Please read this manual before using the device to ensure safe and proper use. Images may differ in appearance from the actual product. Content is subject to change without prior notice. Appearances and specifications are subject to change without prior notice. Failure to comply with safety warnings and regula- tions can cause serious injury, property damage or death. Do not use the device for anything other than its intended use. Your device may malfunction. Do not insert the device or supplied accessories into the eyes, ears, or mouth. Doing so may cause suffocation or serious injuries. Do not bite or suck the device. Doing so may damage the device or result in an explosion or fire. Children or animals can choke on small parts. If children use the device, make sure that they use the device properly. Do not use damaged power cords or plugs, or loose electrical sockets. Unsecured connections can cause electric shock or fire. Use manufactur- er-approved charging cable, accessories, and supplies. Using generic chargers may shorten the life of your device or cause the device to malfunction. They may also cause a fire or cause the battery to explode. Do not store your device near magnetic fields. Your device may malfunction. Magnetic stripe cards, including credit cards, phone cards, passbooks, and boarding passes, may be damaged by magnetic fields. Protect the device and charger from damage. Avoid expos- ing your device to very cold or very hot temperatures. Extreme temperatures can damage the device and reduce the charging capacity and life of your device. Nev- er use a damaged charger or battery. 190702_HANDS 3 SPLIT_guide.indd 52019-07-03 오전 11:21:03 - 5 - 05. Caution Do not use or store your device in areas with high concentrations of dust or air- borne materials. Dust or foreign materials can cause your device to malfunction and may result in fire or electric shock. Prevent the multipurpose jack and the small end of the charger from contact with conductive materials, such as liquids, dust, metal powders, and pencil leads. Conductive materials may cause a short circuit or corrosion of the terminals, which may result in an explosion or fire. Keep your device dry. Humidity and liquids may damage the parts or electronic cir- cuits in your device. Do not turn on your device if it is wet. Do not drop or cause an impact to the charger or the device. Handle and dispose of the device and charger with care. Never dispose of the device in a fire. Never place the device on or in heating devices, such as microwave ovens, stoves, or radiators. The device may explode when overheated. Follow all local regulations when disposing of used device. Never crush or puncture the device. Do not disassemble, modify, or repair your device. Any changes or modifications to your device can void your manufacturer’s warranty. If your device needs servicing, take your device to a Service Center. Do not use your device with the back cover removed. Doing so may result in damage or malfunction. Do not drop your device or cause impacts to your device. Your device may be damaged or may malfunction. If bent or de- formed, your device may be damaged or parts may malfunction. Do not touch the device, power cords, plugs, or the electric socket with wet hands or other wet body parts. Doing so may cause electric shock. Do not pull the power cord excessively when disconnecting it. Doing so may cause electric shock or fire. Do not bend or damage the power cord. Doing so may cause electric shock or fire. Do not use your device outdoor during a thunderstorm. Doing so may result in electric shock or device malfunction. Turn off the device in potentially explosive environments. Turn off your device in potentially explosive environments instead of removing the battery. Always comply with regulations, instructions and signs in potentially explosive environments. Do not use your device at refueling points (petrol stations), near fuels or chemicals, or in blasting areas. Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the device, its parts, or accessories. 190702_HANDS 3 SPLIT_guide.indd 62019-07-03 오전 11:21:03 - 6 - 06. Notice There may be some events such as wireless charging begins after 4-5 seconds even though your device is positioned on a charging area properly. It is a normal situation that magnetic field is transferring between a charging pad and a mobile device. The device can be used in locations with an ambient temperature of 0°C to 35°C. You can store the device at an ambient temperatur…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 BROS & COMPANY INC. (November 26, 2019) To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ BROS & COMPANY INC. _____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AQIS-POUT-02201 Product Description: HANDS3 SPLIT Model: POUT-02201 Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected]

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 BROS & COMPANY INC. (November 26, 2019) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AQIS-POUT-02201 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected] SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 BROS & COMPANY INC. (November 26, 2019) To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AQIS-POUT-02201 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of / / not to exceed 180 days from the Grant Date. See KDB 726920. User Manual Internal Photos Test Setup photos External Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ______________________________ Client’s signature Client’s name / title : KIYEOL PARK / CEO Contact information Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Telephone: +82-31-286-8646 Fax No.: +82-303-0946-8646 E-mail: [email protected]

Page 1 of 1 IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The FCC ID shall be permanently affixed in the rear side of the equipment This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. Made in Korea FCC ID : 2AQIS-POUT-02201

Coil Antenna

Page 1 of 21 Report No.: OT-19N-RWD-043 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION COMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-19N-RWD-043 AGR No. : A19OA-294 Applicant : BROS&COMPANY INC. Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Manufacturer : Shenzhen Boli Technology Co.,Ltd Address : 301, No.5177, Yiyuan Rd, 74 Area, Buxin Community, Xin’an Street, Baoan District, Shenzhen Type of Equipment : HANDS3 SPLIT FCC ID. : 2AQIS-POUT-02201 Model Name : POUT-02201 Serial number : N/A Total page of Report : 21 pages (including this page) Date of Incoming : October 29, 2019 Date of issue : November 22, 2019 SUMMARY The equipment complies with the regulation; FCC CFR 47 PART 1.1310 and 2.1093 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Reviewed by: Approved by: Ha-Ram Lee / Assistant Manager Jae-Ho Lee / Chief Engineer ONETECH Corp. ONETECH Corp. Page 2 of 21 Report No.: OT-19N-RWD-043 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................ 5 2.1 PRODUCT DESCRIPTION ................................................................................................................................................. 5 2.2 MODEL DIFFERENCES.................................................................................................................................................... 5 3. EUT MODIFICATIONS .................................................................................................................... 5 4. RADIO FREQUENCY EXPOSURE ................................................................................................ 6 4.1 ENVIRONMENTAL EVALUATION AND EXPOSURE LIMIT ................................................................................................ 6 4.2 H / E FIELD STRENGTH ................................................................................................................................................... 8 4.2.1 EUT Operating condition .......................................................................................................................................8 4.2.2 Measurement procedure .........................................................................................................................................8 4.2.3 Test Data for 5V ......................................................................................................................................................9 4.2.4 Test Data for 9V ....................................................................................................................................................13 4.2.5 Test Data for 12V ..................................................................................................................................................17 5. LIST OF TEST EQUIPMENT ........................................................................................................ 21 Page 3 of 21 Report No.: OT-19N-RWD-043 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Issue Report No. Issued Date Revisions Effect Section OT-19N-RWD-043 November 22, 2019 Initial Release All Page 4 of 21 Report No.: OT-19N-RWD-043 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : BROS&COMPANY INC. Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Contact Person : KIYEOL PARK / CEO Telephone No. : +82-31-286-8646 FCC ID : 2AQIS-POUT-02201 Model Name : POUT-02201 Serial Number : N/A Date : November 22, 2019 EQUIPMENT CLASS DCD – Part 15 Low Power Transmitter Below 1 705 kHz KIND OF EQUIPMENT HANDS3 SPLIT THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2013 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC CFR 47 PART 1.1310 and 2.1093 MODIFICATIONS ON THE EQUIPMENT TO ACHIEVE COMPLIANCE No FINAL TEST WAS CONDUCTED ON 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximum emission levels emanating from equipment are within the compliance requirements. Page 5 of 21 Report No.: OT-19N-RWD-043 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 2. GENERAL INFORMATION 2.1 Product Description The BROS&COMPANY INC., Model: POUT-02201 (referred to as the EUT in this report) is a HANDS3 SPLIT. Product specification information de…

Text truncated - open the document above for the full version.

Page 1 of 50 Report No. : OT-19N-RWD-042 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) ELECTROMAGNETIC EMISSION COMPLIANCE REPORT FOR LOW-POWER, NON-LICENSED TRANSMITTER Test Report No. : OT-19N-RWD-042 AGR No : A19OA-294 Applicant : BROS&COMPANY INC. Address : A-402, InnoValley, 253, Pangyo-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, Korea Manufacturer : Shenzhen Boli Technology Co.,Ltd Address : 301, No.5177, Yiyuan Rd, 74 Area, Buxin Community, Xin’an Street, Baoan District, Shenzhen Type of Equipment : HANDS3 SPLIT FCC ID. : 2AQIS-POUT-02201 Model Name : POUT-02201 Multiple Model Name : N/A Serial number : N/A Total page of Report : 50 pages (including this page) Date of Incoming : October 29, 2019 Date of issue : November 22, 2019 SUMMARY The equipment complies with the regulation; FCC CFR47 Part 15 Subpart C Section 15.207 and 15.209 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. Reviewed by: Approved by: Ha-Ram Lee / Assistant Manager Jae-Ho Lee / Chief Engineer ONETECH Corp. ONETECH Corp. Page 2 of 50 Report No. : OT-19N-RWD-042 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-003 (Rev.2) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................. 5 2. TEST SUMMARY .............................................................................................................................. 6 2.1 TEST ITEMS AND RESULTS ............................................................................................................................................. 6 2.2 ADDITIONS, DEVIATIONS, EXCLUSIONS FROM STANDARDS ........................................................................................... 6 2.3 RELATED SUBMITTAL(S) / GRANT(S) ............................................................................................................................ 6 2.4 PURPOSE OF THE TEST ................................................................................................................................................... 6 2.5 TEST METHODOLOGY .................................................................................................................................................... 6 2.6 TEST FACILITY ............................................................................................................................................................... 6 3. GENERAL INFORMATION ............................................................................................................ 7 3.1 PRODUCT DESCRIPTION ................................................................................................................................................. 7 3.2 ALTERNATIVE TYPE(S)/MODEL(S); ALSO COVERED BY THIS TEST REPORT. ................................................................ 7 4. EUT MODIFICATIONS .................................................................................................................... 7 5. SYSTEM TEST CONFIGURATION ............................................................................................... 8 5.1 JUSTIFICATION ............................................................................................................................................................... 8 5.2 PERIPHERAL EQUIPMENT .............................................................................................................................................. 8 5.3 MODE OF OPERATION DURING THE TEST ...................................................................................................................... 8 5.4 CONFIGURATION OF TEST SYSTEM ............................................................................................................................... 9 5.5 ANTENNA REQUIREMENT .............................................................................................................................................. 9 6. PRELIMINARY TEST .................................................................................................................... 10 6.1 AC POWER LINE CONDUCTED EMISSIONS TESTS ....................................................................................................... 10 7. 20 DB BANDWIDTH ....................................................................................................................... 11 7.1 OPERATING ENVIRONMENT ......................................................................................................................................... 11 7.2 TEST SET-UP ................................................................................................................................................................. 11 7.3 TEST DATA .................................................................................................................................................................... 12 7.3.1 Test data for 5 V ....................................................................................................................................................12 7.3.2 Test data for 9 V ....................................................................................................................................................13 7.3.3 Test data for 12 V ..................................................................................................................................................14 8. SPURIOUS EMISSION TEST .......…

Text truncated - open the document above for the full version.

Page 1 of 6 - Radiated Emission Test (Below 30 MHz) Page 2 of 6 - Radiated Emission Test (Below 1 GHz) Page 3 of 6 - Conducted Emission Test Page 4 of 6 - EMF Test Position A Position B Page 5 of 6 Position C Position D Page 6 of 6 Position E Position F
