2AQPW-SB465Ultra Bright LCD Display with LED Backlight

WELCOME GUIDE Ultra Bright ™ UB4-50 UB4-65 UB4-85 WARRANTY REGISTRATION REGISTER FOR EXTRA BENEFITS Activate within 30 days of purchase: seura.com/activate 2 3 Specifications 50 INCH Model: UB4-50 65 INCH Model: UB4-65 85 INCH Model: UB4-85 GENERAL OPERATING TEMP.-40°F to 122°F IDEAL OPERATING TEMP. 32°F to 122°F NON-OPERATING TEMP. -40°F to 140°F OPERATING HUMIDITY 5%-90% Relative Humidity, Non-Condensing WATERPROOFIP55 Rating* VIDEO RESOLUTIONFull UHD Native 3840 x 2160 BRIGHTNESS1900 Nits CONTRAST RATIO5000:1 DOLBY DIGITAL COMPLIANT Yes (HDMI and Digital Audio Outs) HDR COMPATIBLEHDR-10 RESPONSE TIME8 ms VIEWING ANGLE178° Horizontal/Vertical DISPLAY POWER CONS. Standby: 3.5W Heating: 398W Normal: 361W Max Standby: 3.5W Heating: 682W Normal: 625W Max Standby: 3.5W Heating: 1096W Normal: 1018W Max INSTALLATION DIMENSIONS45.1” w x 26.2” h x 3.8” d58.2” w x 33.6” h x 3.8” d75.8” w x 43.5” h x 3.8” d TV WEIGHT65 lbs.90 lbs.140 lbs. VESA PATTERN400 x 400mm400 x 400mm600 x 400mm * IP Rating is an international standard that specifies the degree of protection against dust and water ingress. Séura Outdoor Displays are IP rated and designed to protect against rain, snow, ice, dust, and other outdoor elements. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. 4 This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. WARNING: READ ALL INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL OR SERVICE THIS PRODUCT. Warnings: Do not handle or remove your outdoor display from the packaging until it is ready to be installed. To avoid damage to the outdoor display, only transport it in a vertical position. It is highly recommended that at least two (2) persons assist in the installation of the outdoor display. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT OPEN BACK PANEL, NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Do not submerge Séura ® Outdoor Display in water: The Séura ® Outdoor Display will resist water exposure from normal rain, sprinklers, snow, etc.; however, it is not designed to be submerged in water. Do not wash with garden hose or pressure-wash: Séura ® Outdoor Display will resist water exposure from normal rain, sprinklers, snow etc.; however, it is not designed to withstand pressure washers, high-pressure water jets, projected snow from a blower, or hurricane-type weather. Do not let metal pieces or objects of any kind fall into the display. High voltage flows in the product, and inserting an object can cause electric shock and/or short internal parts. To prevent fire, never place any type of candle or flames on the top or near the display. To prevent fire or shock hazard, do not place the AC cord under the display or other heavy items. Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. Accessories Do not use accessories not specifically recommended by the manufacturer. Use of improper attachments can result in accidents. 5 Ce symbole est destiné à alerter l’utilisateur de la présence d’une «tension dangereuse» non isolée à l’intérieur de l’enceinte du produit qui peut être d’une amplitude suffisante pour constituer un risque de choc électrique pour les personnes. Ce symbole est destiné à alerter l’utilisateur de la présence d’instructions importantes d’utilisation et de maintenance dans la documentation accompagnant l’appareil. AVERTISSEMENT: LIRE TOUTES LES INSTRUCTIONS AVANT D’INSTALLER OU SERVICE CE PRODUIT. Avertissements: Ne pas manipuler ou supprimer votre moniteur extérieure de l’emballage jusqu’ à ce qu’ il soit prêt à être installé. Pour éviter d’endommager la moniteur en plein air, seul le transporter dans une position verticale. Il est fortement recommandé qu’au moins deux (2) personnes aident à l’ installation de la moniteur en plein air. CAUTION RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR. ATTENTION: POUR RÉDUIRE LE RISQUE DE CHOC ÉLECTRIQUE, NE RETIREZ PAS LE CAPOT (NI L’ARRIÈRE), AUCUNE PIÈCE RÉPARABLE PAR L’UTILISATEUR, RÉFÉREZ L’ENTRETIEN AU PERSONNEL DE SERVICE QUALIFIÉ. N’ immergez pas le Séura® Outdoor moniteur dans l’eau: le moniteur Séura® Outdoor résistera à l’exposition à l’eau causée par la pluie, les gicleurs, la neige, etc. Cependant, il n’est pas conçu pour être immergé dans l’eau. Ne lavez pas avec un tuyau d’arrosage ou avec un nettoyeur haute pression: Séura® Outdoor moniteur résistera à l’exposition à l’eau causée par la pluie, les sprinklers, la neige, etc. Cependant, il n’est pas conçu pour résister aux laveuses à pression, aux jets d’eau à haute pression, aux projections de neige d’un ventilateur ou aux intempéries de type ouragan. Ne laissez pas de morceaux de métal ou d’objets de toute sorte tomber dans la moniteur. Une tension élevée circule dans le produit et l’ insertion d’un objet peut provoquer un choc électrique et / ou un court-circuit des pièces internes. Pour éviter les incendies, ne placez jamais de bougies ni de flammes sur le dessus ou à proximité du moniteur. Pour éviter tout risque d’ incendie ou d’ électrocution, ne placez pas le cordon d’alimentation sous le moniteur ou d’autres objets lourds. Les lignes électriques Une antenne extérieure ne doit pas être située à proximité de lignes électriques aériennes ou d’autres circuits d’ éclairage ou de circuits électriques, ni à un endroit où ell…

Text truncated - open the document above for the full version.

承认书 客户：合肥京东方视讯科技有限公司 品名：天线 料号：61005-00244 型号：61005-00244 机种： 日期：2019-11-19 供应商签核 SUPPLIERAPPROVEDSIGNATURES 担当 PREPAREDby 审查 CHECKEDby 核准 APPROVEDby 刘荣韦进龙秋霖 供应商名称： 深圳市中天迅通信技术股份有限公司 供应商地址： 深圳市宝安区石岩镇石龙大道 34 号 ( 腾达工业园 ) 供应商电话：0755-27588320 供应商传真：0755-27588045 规格变更履历表 版本 变更 日期 变更原因变更内容ECN编号 负责 人 核准人 A12019-11-19 首版 NANA 刘荣龙秋霖 注：MP机种任何设计变更需提供ECN编码 产品环保要求： 请在方框内打勾确认 是  否  无卤HF(Br<900ppm,Cl<900ppm,Br+Cl<1500ppm) SPECIFICATION SPECIFICATION SHEETFORAPPROVAL （ Revision ： R ： A1 ） CUSTOMER( 客户名称 ) 合肥京东方视讯科技有限公司 CSP/N(客户机种)61005-00244 PARTNAME(品名)天线 FREQUENCY( 频率 ) 2.4G~2.5G ZTXNO.( 物料编号 ) 2.00004027 DATE( 日期 ) 2019-11-19 CUSTOMER QA CHECKED ME CHECKED RF CHECKED MANAGER CHECKED ZHONGTIANXUNTECHNOLOGYCO.,LTD MANAGER CHECKED MANAGER CHECKED ME CHECKED RF CHECKED LISTER 龙秋霖刘荣韦进 地址：深圳市宝安区石岩镇石龙大道34号(腾达工业园)邮编：518000 电话：0755-27588320传真：0755-27588045http:// www.chinaztx.com Remark(备注)： Sign(客户确认签字盖章)： ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 1 of16 Revisionhistory 版本日期状态 A12019-11-19首版 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 2 of16 Index Revisionhistory 1 lndex 2 1MechanicalSpecification 3 1-1 MechanicalSpecification（WIFI-2天线） 3 2Sizereport 4 3Testequipment 5 4Antennatestdata 6 4-1VSWR 6 4-2Returnlossplot 6 4-3SmithChart 7 4-4No-sourcetestdata 7 4-5Directionaldrawingofhorizontalplaneof 8~10 4-63Dradiationdrawing 10 4-7 产品实物图 10 5 产品成分表 10 6 REACH声明 11 7 RoHS限用物质成分表 12 8 Wirespecification 13 9Shippinginspectionreferencebook 14 10EnvironmentCharacteristic 15 11Thepackingway 16 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 3 of16 1.MechanicalSpecification 1-1MechanicalConfiguration（WIFI-2天线） ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 4 of16 2.Sizereport 客户名称京东方产品名称61005-00244天线数量5PCS 产品材质 PCB+同轴线 材料颜色/日期 2019/11/18 产品类型：☑新模样品□改模样品□量产□其它 NO工程图纸要求尺寸 实测尺寸判定备注 12345OK/NG 1595±6.0 598600598599600 OK 248.00±0.15 48.0448.0748.0948.0548.04 OK 37.40±0.20 7.447.457.467.447.45 OK 4 Ф 1.13±0.04 1.141.141.131.141.13 OK 50.50±0.10 0.550.540.560.550.56 OK 6 7 8 9 外观:OK 性能:OK(一致性测试OK) 总判定:☑OK□NG 批准：刘荣审核：胡春梅作成：谢永英 备注: ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 5 of16 3.Testequipment ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 6 of16 4.Antennatestdata 4-1VSWR 4-2Returnlossplot 4-3SmithChart ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 7 of16 4-4No-sourcetestdata 4-5Directionaldrawingofhorizontalplaneof ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 8 of16 XY平面Z=0 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 9 of16 XZ平面Y=0 YZ平面X=0 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 10 of16 4-63Dradiationdrawing 4-7产品实物图 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 11 of16 5.产品成分表 物料名称型号规格客户料号物料名称厂商备注 天线61005-0024461005-00244 PCB声美符合ROHS2.0 1.13低损线神宇符合ROHS2.0 RF一代端子彩美符合ROHS2.0 6.RoHS限用物质成分表 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 12 of16 7.REACH声明 ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 13 of16 8. Wirespecification ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 14 of16 9.Shippinginspectionreferencebook ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 15 of16 10.EnvironmentCharacteristic NO.ITEMTESTCONDITIONSPECIFICATION 10-1 HighTemperature/Humidity StorageTest(nonoperating) 1.Temperature:+70±2°C 2.Humidity:90~95%RH 3.Time:48hrs Nomaterialdeformationis allowed. TheVSWR,Gain,Radiation Patternmustbemet specificationsafterthesetest. 10-2 LowTemperature/Humidity StorageTest(nonoperating) 1.Temperature:-30±2°C 2.Humidity:0%RH 3.Time:48hrs ANTENNASPECIFICATION CUSP/N:61005-00244 天线 ApplicationDate:Nov,19,2019Rev:R:A1 ZTXP/N:61005-00244 天线 Editor:Page 16 of16 11.Thepackingway

< Innolux Corporation > < No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan > Date:2021-06-25 FCC ID: 2AQPW- SB465 Model Number: UB4-65 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We Innolux Corporation declare the following: The model UB4-65 with the equipment class DSS,DTS according to the FCC rule part 15.247 has the same design as model UB4-50; The difference is that model UB4-65 is 65 inch and model UB4-50 is 50 inch. Model UB4-65 and model UB4-50 BT modular PCB board, Schematic, Hardware version, Software version (including RF power setting), structure are the same. Both Models use the same BT frequency band. (2402-2480 MHz). For this reason, model UB4-65 (with FCC ID: 2AQPW-SB465) will reuse some test data as following of model UB4-50 (with FCC ID: 2AQPW-SB450, granted on 06/28/2021) for both FCC certification; Test Item Re-use test data from original test report RADIATED EMISSION - 9 KHZ TO 30 MHZ BTL-FCCP-1-2103T148,BTL-FCCP-2-2103T148 RADIATED EMISSION - 30 MHZ TO 1000 MHZ BTL-FCCP-1-2103T148,BTL-FCCP-2-2103T148 NUMBER OF HOPPING FREQUENCY BTL-FCCP-1-2103T148 AVERAGE TIME OF OCCUPANCY BTL-FCCP-1-2103T148 HOPPING CHANNEL SEPARATION BTL-FCCP-1-2103T148 BANDWIDTH BTL-FCCP-1-2103T148,BTL-FCCP-2-2103T148 CONDUCTED SPURIOUS EMISSION BTL-FCCP-1-2103T148,BTL-FCCP-2-2103T148 We declare, that Innolux Corporation takes full responsibility that the test data of the old FCC ID (FCC ID 2AQPW-SB450, granted on 06/28/2021) represents compliance for the new FCC ID (FCC ID: 2AQPW-SB465). < Innolux Corporation > < No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan > Date: 2021-06-29 City: Miaoli County Name: Janice Chao Function: Engineer Signature:

Report No.: 2103T149 Page 2 of 19 Report No.: 2103T149 Page 3 of 19 Report No.: 2103T149 Page 4 of 19 Report No.: 2103T149 Page 5 of 19

PRODUCT SPECIFICATION Version 2.0 18 Date： ：： ：12 Mar. 2021 2The copyright belongs to InnoLux. Any unauthorized use is prohibited 6.4 RATING LABEL

Report No.: 2103T149 Page 6 of 19 Antenna Report No.: 2103T149 Page 7 of 19 Report No.: 2103T149 Page 8 of 19 Report No.: 2103T149 Page 9 of 19 Report No.: 2103T149 Page 10 of 19 Report No.: 2103T149 Page 11 of 19 Report No.: 2103T149 Page 12 of 19 Report No.: 2103T149 Page 13 of 19 Report No.: 2103T149 Page 14 of 19 Report No.: 2103T149 Page 15 of 19 Report No.: 2103T149 Page 16 of 19 Report No.: 2103T149 Page 17 of 19 Report No.: 2103T149 Page 18 of 19 Report No.: 2103T149 Page 19 of 19

Report No.: BTL-FCCP-3-2103T149 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2AQPW-SB465 Project No. : 2103T149 Equipment : Ultra Bright LCD Display with LED Backlight Brand Name : Seura Test Model : UB4-65 Series Model : N/A Applicant : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Manufacturer : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Factory : Keewin Display (Suzhou) Co.，LTD Address : No. 17 Chengpu Rd,Suzhou Industrial Park,Jiangsu Date of Receipt : Mar. 30, 2021 Date of Test : Mar. 30, 2021 ~ May 11, 2021, Jul. 02, 2021 Issued Date : Jul. 05, 2021 Report Version : R02 Test Sample : Engineering Sample No.: DG20210325161 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-2103T149 Page 2 of 4 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Jun. 24, 2021 R01 Changed the product name. Jun. 21, 2021 R02 Modified the comments of telefication. Jul. 05, 2021 Report No.: BTL-FCCP-3-2103T149 Page 3 of 4 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3,Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: Ant. Brand Model Name Antenna Type Connector Gain(dBi) 1 SHENZHEN ZHONGTIAN XUN Communication Technology Shares Co., Ltd. 61005-00244 Internal N/A 2.99 Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-3-2103T149 Page 4 of 4 3. TEST RESULTS For BT: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.99 1.9907 8.87 7.7090 0.00305 1 Complies For LE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Max. Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.99 1.9907 1.75 1.4962 0.00059 1 Complies Note: The calculated distance is 20 cm. Output power including tune up tolerance. End of Test Report

Report No.: BTL-FCCP-2-2103T148 Page 1 of 76 FCC Radio Test Report FCC ID: 2AQPW-SB450 This report concerns: Original Grant Project No. : 2103T148 Equipment : Ultra Bright LCD Display with LED Backlight Brand Name : Seura Test Model : UB4-50 Series Model : N/A Applicant : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Manufacturer : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Factory : Keewin Display (Suzhou) Co.，LTD Address : No. 17 Chengpu Rd,Suzhou Industrial Park,Jiangsu Date of Receipt : Mar. 29, 2021 Date of Test : Mar. 29, 2021 ~ May 11, 2021 Issued Date : Jun. 21, 2021 Report Version : R01 Test Sample : Engineering Sample No.: DG20210325161 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 T he above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-2103T148 Page 2 of 76 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2103T148 Page 3 of 76 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.5 SUPPORT UNITS 13 3 . AC POWER LINE CONDUCTED EMISSIONS 14 3.1 LIMIT 14 3.2 TEST PROCEDURE 14 3.3 DEVIATION FROM TEST STANDARD 14 3.4 TEST SETUP 15 3.5 EUT OPERATING CONDITIONS 15 3.6 TEST RESULTS 15 4 . RADIATED EMISSIONS 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 DEVIATION FROM TEST STANDARD 18 4.4 TEST SETUP 18 4.5 EUT OPERATING CONDITIONS 19 4.6 TEST RESULT - 9 KHZ TO 30 MHZ 19 4.7 TEST RESULT - 30 MHZ TO 1000 MHZ 19 4.8 TEST RESULT - ABOVE 1000 MHZ 19 5 . BANDWIDTH 20 5.1 LIMIT 20 5.2 TEST PROCEDURE 20 5.3 DEVIATION FROM STANDARD 20 5.4 TEST SETUP 20 Report No.: BTL-FCCP-2-2103T148 Page 4 of 76 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 20 5.6 TEST RESULTS 20 6 . MAXIMUM OUTPUT POWER 21 6.1 LIMIT 21 6.2 TEST PROCEDURE 21 6.3 DEVIATION FROM STANDARD 21 6.4 TEST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 TEST RESULTS 21 7 . CONDUCTED SPURIOUS EMISSION 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION FROM STANDARD 22 7.4 TEST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 TEST RESULTS 22 8 . POWER SPECTRAL DENSITY 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM STANDARD 23 8.4 TEST SETUP 23 8.5 EUT OPERATION CONDITIONS 23 8.6 TEST RESULTS 23 9 . MEASUREMENT INSTRUMENTS LIST 24 10 . EUT TEST PHOTO 26 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 31 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 34 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 39 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 42 APPENDIX E - BANDWIDTH 67 APPENDIX F - MAXIMUM OUTPUT POWER 70 Report No.: BTL-FCCP-2-2103T148 Page 5 of 76 Table of Contents Page APPENDIX G - CONDUCTED SPURIOUS EMISSION 72 APPENDIX H - POWER SPECTRAL DENSITY 75 Report No.: BTL-FCCP-2-2103T148 Page 6 of 76 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jun. 18, 2021 R01 Changed the product name. Jun. 21, 2021 Report No.: BTL-FCCP-2-2103T148 Page 7 of 76 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.247(d) Conducted Spurious Emission APPENDIX G PASS ------ 15.247(e) Power Spectral Density APPENDIX H PASS ------ 1…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-2-2103T149 Page 1 of 33 FCC Radio Test Report FCC ID: 2AQPW-SB465 The output power tested by sample of FCC ID: 2AQPW-SB465, model name: UB4-65. Meanwhile, th e conducted emissions and radiated emissions of above 1GHz have been re-evaluated the worst case and recorded in this report, others test data were reissue from the FCC ID: 2AQPW-SB450, model name: UB4-50. The conducted emissions please see the Appendix A. The radiated emissions of above 1GHz please see the Appendix B, the output power test data please see Appendix C. Model difference: The difference is that model UB4- 65 is 65 inch and model UB4-50 is 50 inch. This report concerns: Original Grant Project No. : 2103T149 Equipment : Ultra Bright LCD Display with LED Backlight Brand Name : Seura Test Model : UB4-65 Series Model : N/A Applicant : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Manufacturer : Innolux Corporation Address : No. 160, Kesyue Rd. Jhunan Science Park, Miaoli County, Taiwan 350 Factory : Keewin Display (Suzhou) Co.,LTD Address : No. 17 Chengpu Rd,Suzhou Industrial Park,Jiangsu Date of Receipt : Mar. 30, 2021 Date of Test : Mar. 30, 2021 ~ May 11, 2021, Jul. 02, 2021 Issued Date : Jul. 05, 2021 Report Version : R02 Test Sample : Engineering Sample No.: DG20210325161 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 T he above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Nick Chen Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-2-2103T149 Page 2 of 33 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-2-2103T149 Page 3 of 33 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 PARAMETERS OF TEST SOFTWARE 9 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 SUPPORT UNITS 10 3 . AC POWER LINE CONDUCTED EMISSIONS 11 3.1 LIMIT 11 3.2 TEST PROCEDURE 11 3.3 DEVIATION FROM TEST STANDARD 11 3.4 TEST SETUP 12 3.5 EUT OPERATING CONDITIONS 12 3.6 TEST RESULTS 12 4 . RADIATED EMISSIONS 13 4.1 LIMIT 13 4.2 TEST PROCEDURE 13 4.3 DEVIATION FROM TEST STANDARD 14 4.4 TEST SETUP 14 4.5 EUT OPERATING CONDITIONS 14 4.6 TEST RESULT - ABOVE 1000 MHZ 14 5 . MAXIMUM OUTPUT POWER 15 5.1 LIMIT 15 5.2 TEST PROCEDURE 15 5.3 DEVIATION FROM STANDARD 15 5.4 TEST SETUP 15 5.5 EUT OPERATION CONDITIONS 15 5.6 TEST RESULTS 15 Report No.: BTL-FCCP-2-2103T149 Page 4 of 33 Table of Contents Page 6 . MEASUREMENT INSTRUMENTS LIST 16 7 . EUT TEST PHOTO 17 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 20 APPENDIX B - RADIATED EMISSION - ABOVE 1000 MHZ 23 APPENDIX C - MAXIMUM OUTPUT POWER 32 Report No.: BTL-FCCP-2-2103T149 Page 5 of 33 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jun. 18, 2021 R01 Changed the product name. Jun. 21, 2021 R02 Modified the comments of telefication. Jul. 05, 2021 Report No.: BTL-FCCP-2-2103T149 Page 6 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS Note(3) 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B PASS Note(3) 15.247(a)(2) Bandwidth ------ PASS Note(3) 15.247(b)(3) Maximum Output Power APPENDIX C PASS Note(3) 15.247(d) Conducted Spurious Emission ------ PASS Note(3) 15.247(e) Power Spectral Density ------ PASS Note(3) 15.203 Antenna Requirement ------ PASS Note(2) Note: (1) “N/A” denotes test is not applicable to this device. (2) The device what use a permanently attached antenna were considered sufficient to comply with the provisions of 15.203. (3) Reissue from the F…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2103T149 Page 18 of 38 7. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: BTL-FCCP-1-2103T149 Page 19 of 38 Radiated Emissions Test Photos Above 1 GHz Report No.: BTL-FCCP-1-2103T149 Page 20 of 38 Conducted Test Photos
