2AQTM-95008BASECAMP 4

BASECAMP™ 4 USER GUIDE Thanks for choosing Goal Zero. 1 Basecamp 4 Need Help?2 What’s in the Box4 Get to know Your Gear5 Using Your Product6 Technical Specs8 FAQs8 Certifications9 Français10 Español18 Table of Contents Assistance 2 Contact For assistance with your device in the United States, visit our contact page at www.goalzero.com/contact or call 1-888-794-6250. For assistance with your device outside of the United States, contact the local distributor. If you do not have contact information for the local distributor, contact us in the United States and we will help connect you to the local representative. • U.S. Phone: 1-888-794-6250 • Web: www.goalzero.com/contact • Email: [email protected] • FAQ Page: https://goalzero.com/pages/faq Ask Our Community Our loyal customer base is a great source of information from vehicle installs to home back up. See what they have to say or ask a question. https://community.goalzero.com/ Warranty Please refer to the Limited Warranty here https://goalzero.com/pages/limited- warranty for complete details regarding your product’s specific warranty. Returns • We offer a 30-day money back guarantee. • If for any reason you are not satisfied with your gear – no hassle returns. • Please contact us to innitiate a return at [email protected] or by phone at 1-888-794-6250 • Please note, 30-Day money back guarantee not applicable on open box products. All sales are final. No returns or exchanges. 3 Please read all warnings, instructions and cautions carefully before use to avoid personal injury, property damage or damage to your Goal Zero Products, or any other connected products. Goal Zero reserves the right to update this document without prior notice. Please visit www.goalzero.com to find the latest product information and the most recent version of the User Guide. WARNINGS Read all instructions and cautions carefully before use to avoid personal injury or damage to the unit and any connected products. To ensure proper function, use the certified cable that was provided with your Basecamp 4. Observe all Input/Output connectors ratings: To avoid fire or electrical shock hazard, observe all ratings on unit, and products you intend to use; check manuals for more information. DO NOT operate in wet conditions: In order to avoid short circuits or electric shock, do not allow the unit to get wet. Let the unit dry completely before using. Keep the unit clean and dry: Inspect the unit for dirt, dust, or moisture on a regular basis. Do not use if damaged. Any manipulation of the unit or its components will void all warranties. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS Getting Started 4 1 2 What’s in the Box 5 Getting Started Indicator lights Four 15 W magnetic wireless charging pads Get to Know Your Gear USB-C input: up to 100 W Foldable design with magnetic closure Getting Started 6 1. Plug the charging pad into a 100 W power source using the USB-C cable that came with the Basecamp 4. 2. Place devices on the charging pad on each individual magnetic ring. 3. A green light will come on to indicate that the device is connected and charging. IMPORTANT: For best results and efficient charging, always use the USB-C cable provided with the Basecamp 4. If you are plugging it into a USB-C port, make sure that port can output at least 100 W of power. If you cannot plug it into a USB port with 100 W, plug it into a 100 W USB adapter and then plug that into an AC outlet. How to Use The Product To power source 7 Getting Started Power Sources 100 W Power Supply USB-C USB-C 100 W Power Supply Must use AC Outlet Direct to USB-C Port USB-C 100 W Basecamp 4 to 100 W USB-C Outlet Basecamp 4 to 6th Generation Yeti, 100 W USB-C Outlet 100 W Basecamp 4 to 5th Generation Yeti AC Outlet Basecamp 4 to AC Outlet thru 100 W power supply Must use AC Outlet 100 W Power Supply USB-C USB-C 100 W Power Supply Direct to USB-C Port USB-C Technical Specs 8 How fast can the Basecamp 4 charge my devices? Charge times will vary by device. You can charge 4 devices at the same time. Basecamp 4 can charge 1-4 smartphones in about 1-3 hours. Please note that charge times may vary dramatically based on phone make and model, settings, temperature, and more. Why isn’t my device charging as expected? If your devices aren’t charging as expected, check to see if you have your Basecamp 4 plugged into a 100 W power source. Be sure to use the cable that was included with your Basecamp 4 for best results. What Goal Zero products can I plug the Basecamp 4 into? The Basecamp 4 works great with our new 6th generation products (Yeti PRO 4000, Yeti 300, 500, & 700). To use the Basecamp 4 with X-line power stations you’ll need a 100-Watt USB-C Charger. Then you can plug it into an AC outlet on your X-line power station. FAQs General: SKU95008 Dimensions16.54 x 3.23 x 0.35 inches (420 x 82 x 9 mm) Weight 11.04 oz (312.98 g) Operating Temperature 32°F to 104°F (0° C to 40° C ) INPUTS: USB-C 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A OUTPUTS: Wireless 5 W/ 7.5 W/10 W/ 15 W Assistance 10 Contact Pour obtenir de l'aide concernant votre appareil, consultez notre page Contact sur www.goalzero.com/contact ou appelez le 1-888-794-6250. Pour obtenir de l'aide avec votre appareil en dehors des États-Unis, contactez le distributeur local. Si vous ne disposez pas des coordonnées de votre distributeur local, contactez-nous aux États-Unis et nous vous mettrons en contact avec notre représentant local. • U.S.A. Téléphone : (+01)-1-888-794-6250 • En ligne : www.goalzero.com/contact • E-mail : [email protected] • Page de FAQ : https://goalzero.com/pages/faq Interroger notre communauté Notre clientèle fidèle est une grande source d'informations, qu'il s'agisse d’une installation sur un véhicule ou d'un système de secours à domicile. Voyez ce qu'ils ont à dire ou posez une question. https://community.goalzero.com/ Garantie Veuillez consulter la garantie limitée ici https://goalzero.com/pages/limited-warranty pour obtenir tous l…

Text truncated - open the document above for the full version.

Power System Electronic Technology Co., Ltd. 2024-07-31 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AQTM-95008) [Power System Electronic Technology Co., Ltd. ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Shirley Lam Merchandiser Power System Electronic Technology Co., Ltd. No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China Power System Electronic Technology Co., Ltd. 2024-07-31 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: 2AQTM-95008 ) [Power System Electronic Technology Co., Ltd. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. S incerely, Shirley Lam Merchandiser Power System Electronic Technology Co., Ltd. No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China

Attestation Statements (2024-07-31) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for (FCC ID: 2AQTM-95008) (Power System Electronic Technology Co., Ltd.), the undersigned, hereby authorize (GOAL ZERO LLC.) to act as our designated U.S. agent for service of process,( Power System Electronic Technology Co., Ltd.) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. (GOAL ZERO LLC.) accepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company name: Power System Electronic Technology Co., Ltd. Contact Name: Shirley Lam Address: No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China FRN: 0027747708 Telephone No: 18200812258 Email: [email protected] Signature [Shirley Lam] U.S. Agent Information: Company Name: GOAL ZERO LLC. Address: 287 WEST 12300 SOUTH DRAPER UT 84020 USA FRN: 0024557563 Contact Name: Kevin Klein Telephone No: 1-888-794-6250 Email: [email protected] Signature [Kevin Klein]

Power System Electronic Technology Co., Ltd. 2024-07-31 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Guangdong Global Testing Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Shirley Lam Merchandiser Power System Electronic Technology Co., Ltd. No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China

Power System Electronic Technology Co., Ltd. 2024-07-31 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: BASECAMP 4 /Model: 95008 /FCC ID: 2AQTM-95008) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram ,Operational Description,Schematics ) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Shirley Lam Merchandiser Power System Electronic Technology Co., Ltd. No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China

External Photographs View of EUT-1 View of EUT-2 Page 2 of 4 View of EUT-3 View of EUT-4 Page 3 of 4 View of EUT-5 View of EUT-6 Page 4 of 4 View of EUT-7

Internal Photographs Internal View of EUT-1 Internal View of EUT-2 Page 2 of 7 Internal View of EUT-3 Internal View of EUT-4 Page 3 of 7 Internal View of EUT-5 Internal View of EUT-6 Page 4 of 7 Internal View of EUT-7 Internal View of EUT-8 Page 5 of 7 Internal View of EUT-9 Internal View of EUT-10 Page 6 of 7 Internal View of EUT-11 Internal View of EUT-12 Page 7 of 7 Internal View of EUT-13

1 / 9 EUT Specification FCC ID: 2AQTM-95008 Characteristics Description Product Name BASECAMP 4 Model number 95008 Brand GOAL ZERO Power Supply DC 5V / DC 9V / DC 12V / DC 15V / DC 20V Operating Frequency Range 113-205kHz Modulation Technique ASK / FSK Antenna Type Coil Antenna Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Evaluation applied MPE Evaluation SAR Evaluation Applicable Standard: FCC Part 1(1.1310) ,Part 2(2.1091) and KDB 680106 D01 RF Exposure Wireless Charging Apps v03 Applicable Requirement: Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: 2 / 9 Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structures and the body of the user or nearby persons. Transmitters designed to be used by consumers or workers that can be easily re-located, such as a wireless modem operating in a laptop computer, are considered mobile devices if they meet the 20 centimeter separation requirement. The FCC rules for evaluating mobile devices for RF compliance are found in 47 CFR ß2.1091. Portable Devices: a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable device requirements are found in Section 2.1093 of the FCC's Rules (47 CFRß2.1093). The FCC also categorizes the use of the device as based upon the user’s awareness and ability to exercise control over his or her exposure. The two categories defined are Occupational/ Controlled Exposure and General Population/Uncontrolled Exposure. These two categories are defined as follows: Occupational/controlled exposure limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when a person is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. The phrase fully aware in the context of applying these exposure limits means that an exposed person has received written and/or verbal information fully explaining the potential for RF exposure resulting from his or her employment. With the exception oftransient persons, this phrase also means that an exposed person has received appropriate training regarding work practices relating to controlling or mitigating his or her exposure. Such training is not required for transient persons, but they must receive written and/or verbal information and notification (for example, using signs) concerning their exposure potential and appropriate means available to mitigate their exposure. The phrase exercise control means that an exposed person is allowed to and knows how to reduce or avoid exposure by administrative or engineering controls and work practices, such as use of personal protective equipment or time averaging of exposure. General population/uncontrolled exposure limits apply in situations in which the general public may be exposed, or in which persons who are 3 / 9 exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Licensees and applicants are responsible for compliance with both the occupational/controlled exposure limits and the general population/uncontrolled exposure limits as they apply to transmitters under their jurisdiction. Licensees and applicants should be aware that the occupational/controlled exposure limits apply especially in situations where workers may have access to areas in very close proximity to antennas and access to the general public may be restricted. In lieu of evaluation with the general population/uncontrolled exposure limits, amateur licensees authorized under part 97 of this chapter and members of his or her immediate household may be evaluated with respect to the occupational/controlled exposure limits in this section, provided appropriate training and information has been provided to the amateur licensee and members of his/her household. Other nearby persons who are not members of the amateur licensee's household must be evaluated with respect to the general population/uncontrolled exposure limits. Test Setup Block 4 / 9 Test Procedure 1.Connect the EUT and equipment as above diagram of test configuration. 2.EUT was placed on a table, and the measure probe was placed at a measurement distance of 20cm from the EUT to the center of the probe. 3.Power on the measuring probe, the EUT was set at the maximum field strength emission state. 4.The EUT was put in different directions (Left, Right, Front, Rear, Top and Bottom) toward to the measure probe. The distance from the top of the EUT to the probe is 20cm, and the distance from other directions is 20cm.Measure the value of field strength. 5.Record the worst data of the different directions. Measuring Device And Test Equipment Used Equipment Manufacturer Model No. Serial No. Last Cal. Due Date  E&H-Field Probe(9kHz-30M Hz) Narda EHP-200A 180ZX11012 2023/09/18 2024/09/17 Description of Support Device No. Equipment Manufacturer Model No. Serial No. Remark 1 phone Apple A2404 / Number: 4 …

Text truncated - open the document above for the full version.

产品规格书 ProductSpecification 客 户 名 称(CUSTOMER): YX 客户料号(PARTNO.): 品 名 (DESCRIPTION): 141P072IH45 规 格(SPECIFICATION): 线圈coil 15X37MM,G43.5X1.OMM磁片magnetic sheet 日 期 (DATE): 20240311 客 户 确 认CuSToMERVALIDATE): 日 期 (DATE): 东莞市德弗力五金电子材料有限公司 DongguancityDFLElectronicTechnologyCo.,LTD 东莞市石碣镇新风西路107号 No. 107, Xinfeng West Road, Shijie Town, Dongguan City 电话：0769-86016320 传真：0769-86372427 〇 东莞市德弗力五金电子材料有限公司 Dongguan city DFL Electronic Technology Co.,LTD SPECIFICATION 产品型号： DESC YX-Y15*37-45-FR 版本 Rev:A Customer: Description: 线圈+硬磁 Coil + hard magnetic Date: 20240311 一 、尺寸DIMENSION:(mm) A 15.0±1.0 B 37±1.5 C 45.0±2.0 D 3.5±1.5 E 1.0±0.1 F 43.5±0.5 G H I J K L E 注Remark ： 1.线圈反贴有孔直槽 硬磁The coil is retrofitted with hole straight slot hard magnetic，G43.5X1.0MM 2 . 磁片背面贴白色带 耳朵双面胶White double- sided tape with ears on the back of the disc. 3.线圈出线位置缠 The exit position of the coil is entangled8mm高温胶带 high-temperature tape 4.线圈不可松线The coil must not be loosened 二、原理图 (schematic diagram:) 三、绕线参数(WindingSpecification:) 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 0 . 08X72P丝包线 silk-covered wire 12TS 逆时针 anticlockwise 四、 电气特性 ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C,湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项 目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. 7UH±10% 100KHZ/1.0V SHDA 1062 2 IND. 3 Q值 Qnumbe r 4 DCR 拟制/日期PREPARED BY/DATE 审核/日期CHECKED BY/DATE 客户/日期CUSTOMEU/DATE

TRF No.: 04-E001-0B TRF Originator: GTG TRF Date: 2023-12-13 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 CFR 47 FCC PART 15 SUBPART C TEST REPORT For BASECAMP 4 MODEL NUMBER: 95008 REPORT NUMBER: E04A24030349F00101 ISSUE DATE: April 7, 2024 FCC ID: 2AQTM-95008 Prepared for Power System Electronic Technology Co., Ltd. No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China Prepared by Guangdong Global Testing Technology Co., Ltd. Room 101-105, 203-210, Building 1, No.2, Keji 8 Road, Songshan Lake Park, Dongguan city, Guangdong, People’s Republic of China, 523808 This report is based on a single evaluation of the submitted sample(s) of the above mentioned Product, it does not imply an assessment of the production of the products. This report shall not be reproduced, except in full, without the written approval ofGuangdong Global Testing Technology Co., Ltd. REPORT NO.: E04A24030349F00101 Page 2 of 30 TRF No.: 04-E001-0BGlobal Testing , Great Quality. Revision History Rev. Issue Date Revisions Revised By V0 April 7, 2024 Initial Issue REPORT NO.: E04A24030349F00101 Page 3 of 30 TRF No.: 04-E001-0BGlobal Testing , Great Quality. Summary of Test Results Test Item Limit/Requirement Result Antenna Requirement FCC Part 15.203 Pass AC Power Line Conducted Emission FCC Part 15.207 Pass 20dB Bandwidth FCC Part 15.215 Pass Radiated Emission FCC Part 15.205/15.209 Pass Note: 1. N/A: In this whole report not applicable. *This test report is only published to and used by the applicant, and it is not for evidence purpose in China. *The measurement result for the sample received is <Pass> according to <CFR 47 FCC PART 15 SUBPART C> when <Accuracy Method> decision rule is applied. REPORT NO.: E04A24030349F00101 Page 4 of 30 TRF No.: 04-E001-0BGlobal Testing , Great Quality. CONTENTS 1. ATTESTATION OF TEST RESULTS ..................................................................................... 5 2. TEST METHODOLOGY ......................................................................................................... 6 3. FACILITIES AND ACCREDITATION ..................................................................................... 6 4. CALIBRATION AND UNCERTAINTY ................................................................................... 7 4.1. MEASURING INSTRUMENT CALIBRATION ........................................................... 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................ 7 5. EQUIPMENT UNDER TEST .................................................................................................. 8 5.1. DESCRIPTION OF EUT ........................................................................................... 8 5.2. TEST MODE ............................................................................................................. 8 5.3. SUPPORT UNITS FOR SYSTEM TEST ................................................................... 8 5.4. SETUP DIAGRAM .................................................................................................... 9 6. MEASURING EQUIPMENT AND SOFTWARE USED......................................................... 10 7. RADIATED TEST RESULTS ............................................................................................... 11 7.1. Radiated Spurious Emission ................................................................................... 15 8. AC POWER LINE CONDUCTED EMISSION ...................................................................... 21 9. 20DB BANDWIDTH ............................................................................................................. 24 10. ANTENNA REQUIREMENT ................................................................................... 28 APPENDIX: PHOTOGRAPHS OF TEST CONFIGURATION ..................................................... 29 REPORT NO.: E04A24030349F00101 Page 5 of 30 TRF No.: 04-E001-0BGlobal Testing , Great Quality. 1. ATTESTATION OF TEST RESULTS Applicant Information Company Name: Power System Electronic Technology Co., Ltd. Address: No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China Manufacturer Information Company Name: Power System Electronic Technology Co., Ltd. Address: No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China Factory Information Company Name: Power System Electronic Technology Co., Ltd. Address: No.1 Shangbian Road, Puxin Industrial District, Shipai Town, Dongguan City, Guangdong Province, China EUT Information Product Description: BASECAMP 4 Model: 95008 Brand: GOAL ZERO Sample Received Date: March 27, 2024 Sample Status: Normal Sample ID: A24030349 001 Date of Tested: March 27, 2024 to March 30, 2024 APPLICABLE STANDARDS STANDARD TEST RESULTS CFR 47 FCC PART 15 SUBPART C Pass Prepared By: Checked By: Jok Yang Alan He Project Engineer Laboratory Leader Approved By: Shawn Wen Laboratory Manager REPORT NO.: E04A24030349F00101 Page 6 of 30 TRF No.: 04-E001-0BGlobal Testing , Great Quality. 2. TEST METHODOLOGY All tests were performed in accordance withthe standardCFR 47 FCC PART 15 SUBPART C 3. FACILITIES AND ACCREDITATION Accreditation Certificate A2LA (Certificate No.: 6947.01) Guangdong Global Testing Technology Co., Ltd. has been assessed and proved to be in compliance with A2LA. FCC (FCC Designation No.: CN1343) Guangdong Global Testing Technology Co., Ltd. has been recognized to perform compliance testing on equipment subject to Supplier's Declaration of Conformity (SDoC) and Certification rules ISED (Company No.: 30714) Guangdong Global Testing Technology Co., Ltd. has been registered and fully described in a report filed with ISED. The Company Number is 30714 and the test lab Conformity Assessment Body Identifier (CABID) is CN0148. Note: All tests measurement facilities use to collect the measurement data a…

Text truncated - open the document above for the full version.

Radiated Spurious Emission AC Power Line Conducted Emission
