2AQURZW313SIn-Wall Dimmer Switch

ZW313S Dimmer Switch SPECIFICATIONS Model: ZW313S Power: 120VAC, 60Hz Signal (Frequency): 908.42 MHz Maximum Load: 150W LED, 500W incandescent (300 W with both sides of heat sink tabs off) Minimum Load: 5W for LED bulbs Range: Up to 100 feet line of sight Operating Temperature Range: 32-104° F (0-40° C) For indoor use. Specifications subject to change without notice due to continuing product improvement Approval: ETL/FCC/Z-Wave Plus Certified FCC Caution. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonableprotection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Portable device: The device has been evaluated to meet general RF exposure requirement. Thedevicecanbeusedinportable exposure condition without restriction. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Page 1 of 1 Declaration on model difference We, NIE-TECH CO., LTD the undersigned hereby confirm that these models are identical, and all models have the same RF module and Antenna, except for color of enclosure and model No. for trading purpose. Product name:In-Wall Dimmer Switch Model No.:ZW313S,ZW313TS Trade name:N/A FCC ID:2AQURZW313S INPUT:AC 120V 60HZ Confirmed by: Client’s signature: Client’s name / title: Jianghai Nie /Manager Date:2020-11-16

C5266091_X8_Ed.1 1/1 LetterofAuthorization NIE-TECHCO.,LTD Company:NIE-TECHCO.,LTD Address:Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangDongProv.,CHINA ProductName:In-WallDimmerSwitch ModelNumber:ZW313S,ZW313TS FCCIdentifier:2AQURZW313S WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:JianghaiNieDate:2020-11-16 Title:Manager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 NIE-TECHCO.,LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2020-11-16 Subject:RequestforConfidentiality FCCID:2AQURZW313S ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodofdaysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name:JianghaiNie Title:Manager

Model: ZW313S .

Model: ZW313S ANT

ReportNo.:PTC20092201705E-FC01 Page 1 of 33 FCCTESTREPORT FCCID:2AQURZW313S ProductName:In-WallDimmerSwitch ModelName:ZW313S,ZW313TS BrandName: N/A ReportNo.:PTC20092201705E-FC01 Preparedfor NIE-TECHCO.,LTD Jinliancommercialcenter9001,JinxiuroadNo.2,ChanganTown,DongguanCity, GuangdongProvince,China Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC20092201705E-FC01 Page 2 of 33 1TESTRESULTCERTIFICATION Applicant’sname: NIE-TECHCO.,LTD Address: Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangdongProvince,China Manufacture'sname : NIE-TECHCO.,LTD Address : Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangdongProvince,China Productname :In-WallDimmerSwitch Modelname :ZW313S,ZW313TS Standards : FCCPart15SubpartC,Paragraph15.249 Testprocedure : ANSIC63.10:2013 TestDate: Oct.26,2020toNov.06,2020 DateofIssue: Nov.06,2020 TestResult : Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevision ofthedocument. TestEngineer: LeoYang/Engineer TechnicalManager: ChrisDu/Manager ReportNo.:PTC20092201705E-FC01 Page 3 of 33 Contents Page 1TESTRESULTCERTIFICATION.....................................................................................................................2 2TESTSUMMARY...........................................................................................................................................................4 3TESTFACILITY..............................................................................................................................................................5 4GENERALINFORMATION..........................................................................................................................................6 4.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................6 4.2TESTMODE..........................................................................................................................................................7 4.3LISTOFCHANNELS..............................................................................................................................................8 5EQUIPMENTDURINGTEST.......................................................................................................................................9 5.1EQUIPMENTSLIST................................................................................................................................................9 5.2MEASUREMENTUNCERTAINTY..........................................................................................................................11 5.3DESCRIPTIONOFSUPPORTUNITS....................................................................................................................12 6TESTSTANDARDANDLIMIT................................................................................................................................13 6.1.TESTSETUP......................................................................................................................................................13 6.2.TESTPROCEDURE............................................................................................................................................13 6.3.TESTDATA........................................................................................................................................................14 7.RADIATEDEMISSIONANDBANDEDGE..........................................................................................................17 7.1.TESTSTANDARDANDLIMIT.............................................................................................................................17 7.2.TESTSETUP......................................................................................................................................................18 7.3.TESTPROCEDURE............................................................................................................................................19 7.4.TESTDATA........................................................................................................................................................20 8.20DBBANDWIDTHTEST........................................................................................................................................24 8.1.TESTSTANDARDANDLIMIT.............................................................................................................................24 8.2.TESTSETUP......................................................................................................................................................24 8.3.TESTPROCEDURE............................................................................................................................................24 8.4.TESTDATA........................................................................................................................................................24 9.ANTENNAREQUIREMENT......................................................................................................................................26 9.1.TESTSTANDARDANDREQUIREMENT..............................................................................................................26 9.2.ANTENNACONNECTEDCONSTRUCTION..........................................................................................................26 10APPENDIXI--PHOTOGRAPH...........................................................................................................…

Text truncated - open the document above for the full version.

Conducted Emissions Radiated Spurious Emissions From 30MHz-1000MHz Model: ZW313S TestfrequencyfromAbove1GHz
