2AQURZW922-V2Remote Switch

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. (2) This device must accept any interference received, including interference that may cause FCC warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer- ence to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following meas- ures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. NOTE: If you are unsure or uncomfortable about performing this installation consult a qualified electrician. Risk of Fire / Risk of Electrical Shock / Risk of Burns Please DO NOT use this plug to control Medical or Life Support equipment. This device should never be used to control the On/Off status of Medical and/or Life Support equipment. OTHER WARNINGS MEDICAL EQUIPMENT IMPORTANT SAFETY INSTRUCTIONS 1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. 2. Read and follow all instructions that are on the product or provided with the product. 3. do not use an extension cord. 4. Reference the National Electrical Code, NFPA 70, specifically for the installation of wiring 5. Installation work and electrical wiring must be done by qualified person(s) in accordance 6. do not install or use within 10 feet of a pool 7. do not use in a bathroom 8. WARNING: 9. WARNING: 10.WARNING: SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions. Risk of Electric Shock. Mount the unit at a height greater than 1 foot from the ground surface Risk of Electric fire. install only to a receptacle protected by 20A branch circuit over current protection. Risk of Electric Shock. When used outdoors, install only to a covered Class A GFCI protected receptacle that is weatherproof with the power unit connected to the receptacle. If one is not provided, contact a qualified electrician for proper installation. Ensure that the power unit andcord do not interfere with completely closing the receptacle cover. andclearances from power and lighting conductors. with allapplicable codes and standards, including fire-rated construction. This device is intended for installation in accordance with the National Electric Code and local regulations in the United States, or the Canadian Electrical Code and local regulations in Canada. CAUTION - PLEASE READ! Remote Switch Model – ZW922-V2 If you have any questions, please contact us at and nie-tech.com [email protected] Scan QR code or visit Temperature Range: 32°F~104°F Indoor use in dry location Features of S2 Remote Control Switch 2. Do not use it in direct contact with water. 3. Contains small parts, please keep away from children. Specifications: Battery: CR2032*2 2. Remove battery tabs. 2. Control other Z-wave devices and enable scenes with a click of a button. 3. The device with S2 and SmartStart support. Power the device Battery position Open and access the battery Add / Remove Z-Wave Network: Tap 6x Lower or Upper Button Wake up: Tap 7x Lower or Upper Button Program button: Inclusion: flashing blue RGB LED Indicator: Exclusion: flashing purple Wake up: stay solid blue Reset: flashing red Add / Remove Z-Wave Network: Tap 6x Lower or Upper Button 1. Power by battery. No wiring required. Note the ± direction of the battery. 1. Open the remote cover by hand and push it to separate the two halves. 1. Please read this online guide carefully at Minoston.com 1. Add the device to your Z-Wave network by following the instructions of your Z-Wave controller. 2. Once the controller is preparing to add your device, press the FIRST BUTTON(ONLY) 5 times. The LED is flashing in blue during inclusion, and it is solid green for 2 seconds after inclusion Inclusion/Exclusion Function To add the device This remote supports four scene controls Scene 3 : Third Button 1-Tap/2-Tap/3-Tap/Held/Released Scene 4 : Fourth Button 1-Tap/2-Tap/3-Tap/Held/Released Scene 1 : First Button 1-Tap/2-Tap/3-Tap/Held/Released Scene 2 : Second Button 1-Tap/2-Tap/3-Tap/Held/Released Scene Control: This remote supports 9 Association Group controls Group 1 Lifeline Group 2 First button press 1x send basic set 0xff, Second button press 1x send basic set 0x00. Group 3 Third button press 1x send basic set 0xff, Fourth button press 1x send basic set 0x00. Group 4 First button hold more than 0.5s send SWITCH_MULTI - LEVEL_START_LEVEL_CHANGE(Dim Up) Support group number: 9 Each group max. Support 10 devices Association Group: Parameter 7 indicates LED Indicator Brightness. Choose the LED indicator Brightness level. size=1 byte Available settings: 0--10 Value=0 LED off Value=1 10% Brightness Value=2 20% Brightness Value=3 30% Brightness Value=4 40% Brightness Value=5 50% Brightness Value=6 60% Brightness Value=7 70% Brightness Value=8 80% Brightness Value=9 90% Brightness Value=10 100% Brightness (DEFAULT) : 5 Down) Group 5 Second button release send SWITCH_MULTILEVEL_STOP_LEVEL_CHANGE Third button hold more…

Text truncated - open the document above for the full version.

1/1 NIE-TECHCo.,Ltd USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:LorenzHighDefinitionLLC FRN:0030963904 ContactName:ZbigniewLorenz Address:230Rt206STE401,Flanders,NJ07836,UnitedStates TelephoneNo:(848)200-0995 Email:[email protected] Applicant: Companyname:NIE-TECHCo.,Ltd ProductDescription:RemoteSwitch Granteecode:2AQUR FCCID:2AQURZW922-V2 ContactName:JianghaiNie Address:Jinliancommercialcenter9001,JinxiuroadNo.2,ChanganTown,DongguanCity, GuangDongProv.,CHINA TelephoneNo:13751285558 Email:[email protected] [NIE-TECHCo.,Ltd]certifiesthat,asofthedateofthisfilingoftheapplication withtheTCB,[LorenzHighDefinitionLLC]isourdesignatedUSagentfor serviceofprocessfortheabovereferencedFCCID.[NIE-TECHCo.,Ltd] acceptstomaintainanagentfornolessthanoneyearafterthegranteehas terminatedallmarketingandimportationortheconclusionofanycommission relatedproceedinginvolvingequipment.[LorenzHighDefinitionLLC]accepts, asofthedateofthefilingoftheapplication,theobligationofthedesignated USagentforserviceofprocessfortheabovereferenceFCCID. TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. Date:2023/08/17 Applicant’sName:JianghaiNieUSAgent’sName:ZbigniewLorenz Title:ManagerTitle:President SignatureSignature

C5266091_X24_Ed.2 1/1 NIE-TECHCo.,Ltd “AttestationStatements” TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 TheCommissionadoptedrulesthatprohibitequipmentauthorizationfor“covered” telecommunicationsequipmentandvideosurveillanceequipmentproducedbyentitiesidentified ontheCommission’sCoveredList 1 ,whichisperiodicallyupdated.SeetheCoveredListformore details.ThisAttestationStatementistoconfirmthatwefollowtheSection2.911(d)(5)(i)-(ii) Applicant Companyname:NIE-TECHCo.,Ltd Granteecode:2AQUR FCCID:2AQURZW922-V2 ContactName:JianghaiNie Address:Jinliancommercialcenter9001,JinxiuroadNo.2,ChanganTown,DongguanCity, GuangDongProv.,CHINA TelephoneNo:13751285558 FaxNo:86(769)82286661 Email:[email protected] i.[NIE-TECHCo.,Ltd](“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuanttosection2.903oftheFCCrules.The applicantmustsignthiscertification. ii.[NIE-TECHCo.,Ltd](“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,theapplicant[isnot](asaspecificallynamedentity oranyofitssubsidiariesoraffiliates)identifiedontheCoveredListasan entityproducing“covered”equipment.Theapplicantmustsignthis certification. [NIE-TECHCo.,Ltd](“theapplicant”)certifiesthat,asofthedateofthefilingof theapplication,theapplicant[isnot]identifiedontheCoveredListasanentity producing“covered”equipment. Date:2023/08/17 Applicant’sName:JianghaiNie Title:Manager Signature 1 TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedonthe Commission’swebsite.ThisCoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedby particularentities,thatconstitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

NIE-TECHCo.,Ltd ProductSimilarityDeclaration Productname:RemoteSwitch Modelname:ZW922-V2,ZEN34 FCCID:2AQURZW922-V2 We(NIE-TECHCo.,Ltd)herebystatethatallthemodelsare electricalidenticalincludingthesamesoftwareparameterand hardwaredesign(i.e.,circuitdesign,PCBLayout,RF module/circuit,antennatype(s)andantennalocation,components onPCB,etc.,),samemechanicalstructureanddesign(including productenclosure,materials,etc.,),theonlydifferenceisthe modelname. Signature: Name:JianghaiNie Title:Manager China,August17,2023

C5266091_X8_Ed.1 1/1 LetterofAuthorization NIE-TECHCo.,Ltd Company:NIE-TECHCo.,Ltd Address:Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangDongProv.,CHINA ProductName:RemoteSwitch ModelNumber:ZW922-V2,ZEN34 FCCIdentifier:2AQURZW922-V2 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:JianghaiNieDate:2023-08-17 Title:Manager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 NIE-TECHCo.,Ltd OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2023-08-17 Subject:RequestforConfidentiality FCCID:2AQURZW922-V2 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodofdaysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name:JianghaiNie Title:Manager

FCCID:2AQURZW922-V2 FCCID:2AQURZW922-V2 FCCID:2AQURZW922-V2

LabelLocation

FCCID:2AQURZW922-V2 ANT FCCID:2AQURZW922-V2

Page 1 of 3 RF EXPOSURE EVALUATION Product Name : Remote Switch Model Name : ZW922-V2, ZEN34 Operating frequency : 908.40MHz 908.42MHz 916.00MHz 912 MHz 920 MHz Numbers of Channel : 5 channels Antenna Type : PCB Antenna Antenna Gain : -15.59 dBi Type of Modulation : 2FSK for 908.40MHz 2FSK for 908.42MHz 2GFSK for 916.00MHz DSSS OQPSK LR for 912 MHz and 920 MHz Power supply : Battery: CR2032*2 Voltage: 6.0V Hardware Version : 1.0 Software Version : 1.0 Page 2 of 3 Standard Requirement According to § 15.247(i) and § 1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4. 3. 1. The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances ≤ 50mm are determined by: [ (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[ √f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g SAR extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison. The test exclusions are applicable only when the minimum test separation distance is ≤ 50mm and for transmission frequencies between 100MHz and 6GHz. When the minimum test separation distance is <5mm, a distance of 5mm is applied to determine SAR test exclusion. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. RF Output power Freq. (MHz) Field strength(max)(dBuV/m) EIRP (max) (dBm) 908.40 90.04 -5.16 908.42 89.91 -5.29 916.00 89.87 -5.33 Note: 1.EIRP=E-104.8+20logD, Where E is the electric field strength in dBμV/m. EIRP is the equivalent isotropically radiated power in dBm. d is the specified measurement distance in m.where D=3, EIRP=E-95.2. ERP=EIRP-2.15. Page 3 of 3 Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (mW) Distance( mm) Calculation results Limit 912 0.338 0.5±1 1.412538 5 0.269791 3 920 0.381 0.5±1 1.412538 5 0.270972 3 908.40 -5.16 -5.00±1 0.398107 5 0.075887 3 908.42 -5.29 -5.00±1 0.398107 5 0.075888 3 916.00 -5.33 -5.00±1 0.398107 5 0.076204 3 According to KDB 447498, no stand-alone required for SRD antenna, and no simultaneous SAR measurement is required. Signature Ronnie Liu EMC Manager Date: 2023-08-17

ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page1of9 TestingReport CustomerName:NIE-TECHCo.,Ltd ProductName:ZSE42ANT SampleModel:ZSE42ANT ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2023.7.10 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page2of9 Version VersionNo.DateDescriptionFormulateApproval A02023.7.10Forthefirsttime,formulateZkrisEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesing..........................................................................6 3.TestResults......................................................................................................................................7 3.1Teststandard.........................................................................................................................7 3.2Testuncertainty.....................................................................................................................7 3.3Testdata................................................................................................................................7 3.3.1Typicalfreespaceefficiencyandgain......................................................................7 3.3.2Typicalfreespaceradiationpattern...........................................................................8 （Thefollowingisblank）................................................................................................................9 ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page3of9 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ Tel 13682621346 E-mail [email protected] Equipment AlltheequipmentusedinthereportisfixedinZoneB,WestSideof1/F,Building1, TingweiIndustrialPark,No.6LiufangRoad,Bao'anDistrict,Shenzhen 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page4of9 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date OTATest System RayZone-5000 RFI-LAB-RF -D00 GTS2023.3.142025.3.13 Network Analyzer E5071C RFI-LAB-RF -D01 KEYSIGHT2023.5.112024.5.10 Network Analyzer E5071C RFI-LAB-RF -C02 KEYSIGHT2023.5.112024.5.10 1.4Testenvironment Temperature 23.6°C Humidity 58%RH Pressure 100.14kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page5of9 2.SampleInformation 2.1Clientinformation Name NIE-TECHCo.,Ltd Address / Contacts / Tel / E-mail / Manufacturer / 2.2DescriptionofEUT(S) ProductName ZSE42ANT SampleModel ZSE42ANT AntennaSize / SerialNo. / AntennaType PCBAntenna TestItem Antennagain;Efficiency;Radiationpattern FrequencyRange 902MHz-928MHz ReceivedDate 2023.7.5 TestDate 2023.7.5 Remark ThelengthoftheRFcableis90mm ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page6of9 2.3EUTappearance 2.4EUTsetupphotooffreespaceOTAtesing Planform Frontview ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page7of9 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-1979 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty Antennagain±0.72dB Radiationefficiency±0.72dB 3.3Testdata 3.3.1Typicalfreespaceefficiencyandgain Frequency/MHz 902904906908910912914916918920922924926928 PeakGain/dBi -21.15-21.00-20.85-20.74-20.39-20.14-19.76-19.46-18.80-18.13-17.26-16.54-15.95-15.59 Efficiency/% 0.240.250.270.290.320.360.390.440.500.580.670.750.820.86 ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page8of9 3.3.2Typicalfreespaceradiationpattern (1)X-ZPlane(unit:dBi): (2)Y-ZPlane(unit:dBi): ReportNo.:RFI-LAB-RF-202307-GG01-2 QP030-E41 Page9of9 (3)X-YPlane(unit:dBi): (4)TypicalFreeSpace3DRadiationPatternat928MHz(unit:dBi): -------------------------------------------------End------------------------------------------------ （Thefollowingisblank）

ReportNo.:PTC23061400604E-FC01 Page 1 of 34 FCCTESTREPORT FCCID:2AQURZW922-V2 ProductName:RemoteSwitch ModelName:ZW922-V2,ZEN34 BrandName:Moniston,ZOOZ ReportNo.:PTC23061400604E-FC01 Preparedfor NIE-TECHCo.,Ltd Jinliancommercialcenter9001,JinxiuroadNo.2,ChanganTown,DongguanCity, GuangDongProv.,CHINA Preparedby PreciseTesting&CertificationCo.,Ltd. Building1,No.6,TongxinRoad,DongchengStreet,Dongguan,Guangdong,China ReportNo.:PTC23061400604E-FC01 Page 2 of 34 1TESTRESULTCERTIFICATION Applicant’sname:NIE-TECHCo.,Ltd Address:Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangDongProv.,CHINA Manufacture'sname :NIE-TECHCo.,Ltd Address :Jinliancommercialcenter9001,JinxiuroadNo.2,Changan Town,DongguanCity,GuangDongProv.,CHINA Productname : RemoteSwitch Modelname : ZW922-V2,ZEN34 Standards : FCCPart15SubpartC,Paragraph15.249 Testprocedure : ANSIC63.10:2013 TestDate : Jul.01,2023toJul.19,2023 DateofIssue : Aug.28,2023 TestResult : Pass ThisdevicedescribedabovehasbeentestedbyPTC,andthetestresultsshowthatthe equipmentundertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicable onlytothetestedsampleidentifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofPTC,this documentmaybealteredorrevisedbyPTC,personalonly,andshallbenotedintherevision ofthedocument. TestEngineer: SimonPu/Engineer TechnicalManager: RonnieLiu/Manager ReportNo.:PTC23061400604E-FC01 Page 3 of 34 Contents Page 1TESTRESULTCERTIFICATION...............................................................................................................................2 2TESTSUMMARY..........................................................................................................................................................5 3TESTFACILITY.............................................................................................................................................................6 4GENERALINFORMATION..........................................................................................................................................7 4.1GENERALDESCRIPTIONOFE.U.T.....................................................................................................................7 4.2TESTMODE.........................................................................................................................................................8 4.3LISTOFCHANNELS..............................................................................................................................................9 5EQUIPMENTDURINGTEST....................................................................................................................................10 5.1EQUIPMENTSLIST.............................................................................................................................................10 5.2MEASUREMENTUNCERTAINTY.........................................................................................................................12 5.3DESCRIPTIONOFSUPPORTUNITS...................................................................................................................13 6TESTSTANDARDANDLIMIT...............................................................................................................................14 6.1.TESTSETUP.....................................................................................................................................................14 6.2.TESTPROCEDURE............................................................................................................................................14 6.3.TESTDATA.......................................................................................................................................................15 7.RADIATEDEMISSIONANDBANDEDGE..........................................................................................................16 7.1.TESTSTANDARDANDLIMIT.............................................................................................................................16 7.2.TESTSETUP.....................................................................................................................................................17 7.3.TESTPROCEDURE............................................................................................................................................18 7.4.TESTDATA.......................................................................................................................................................19 8.20DBBANDWIDTHTEST........................................................................................................................................26 8.1.TESTSTANDARDANDLIMIT.............................................................................................................................26 8.2.TESTSETUP.....................................................................................................................................................26 8.3.TESTPROCEDURE............................................................................................................................................26 8.4.TESTDATA.......................................................................................................................................................26 9.ANTENNAREQUIREMENT.....................................................................................................................................28 9.1.TESTSTANDARDANDREQUIREMENT.............................................................................................................28 9.2.ANTENNACONNECTEDCONSTRUCTION.........................................................................................................28 10TESTSETUP..........................................................................................................................................…

Text truncated - open the document above for the full version.

FCCID:2AQURZW922-V2 RadiatedEmissions From30MHz-1000MHz TestfrequencyfromAbove1GHz
