2AQY4-KA342Smart Lock

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 1 of 10 AppendixI: Photos of the EUT Product Name: Smart Lock Model Number: KA341, TE341, KA342, TE342 KA341 KA342 TE342 TE341 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 2 of 10 KA342： Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 3 of 10 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 4 of 10

Model: TE FCC ID: 2AQY4-KA342 IC: 24242-KA341 CAN ICES-003(B)/NMB-003(B) ESN: TEA 3222000001 BTMAC: AA:BB:CC:DD:EE:FF SN:TW2302TEAB00000 341 3.5cm 1.5cm ESN/BT MAC信息其中 ESN（13位）和SN（15位）是 变量，需要根据实际的数据进行 打印。 Model: TE FCC ID: 2AQY4-KA342 IC: 24242-KA342 CAN ICES-003(B)/NMB-003(B) ESN: TEB 3222000001 BTMAC: AA:BB:CC:DD:EE:FF SN:TW2302TEBB00000 342 3.5cm 1.5cm ESN/BT MAC信息其中 ESN（13位）和SN（15位）是 变量，需要根据实际的数据进行 打印。

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 5 of 10 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 6 of 10 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 7 of 10 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 8 of 10 BT Ant. WIFI Ant. Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 9 of 10 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q22052517-2E Page 10 of 10 END

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 1 of 8 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Equipment under Test : Smart Lock Model No. : KA341, TE341, KA342, TE342 Trade Mark : FCC ID : 2AQY4-KA342 Manufacturer : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Report No.: DDT-RE23052517-2E07 Issued Date: Jun. 20, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 2 of 8 Table of Contents Test report declares.......................................................................................................3 1. General Information .................................................................................................................. 5 1.1. Description of equipment ......................................................................................................... 5 1.2. Assess laboratory ..................................................................................................................... 6 2. RF Exposure Evaluation .......................................................................................................... 7 2.1. Requirement .............................................................................................................................. 7 2.2. Calculation method ................................................................................................................... 7 2.3. Estimation result ....................................................................................................................... 8 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 3 of 8 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-RE23052517-2E07 Date of Receipt: Jun. 01, 2023 Date of Test: Jun. 01, 2023 ~ Jun. 20, 2023 Prepared By: Approved By: ___________________ ______________________ Tiger Mo /Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Equipment under Test : Smart Lock Model No. : KA341, TE341, KA342, TE342 Trade Mark : Manufacturer : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Jun. 20, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 5 of 8 1. General Information 1.1. Description of equipment EUT Name : Smart Lock Model Number : KA341, TE341, KA342, TE342 Difference of models : All the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the difference are the the model number, the fingerprint and the trademark. The corresponding parts without fingerprints are not affixed. KA341, TE341 has no fingerprint. KA342, TE342 has fingerprint. KA341, KA342 has trademark, TE341, TE342 no trademark. Therefore, the KA342 model is tested. EUT function description : Please reference user manual of this device Power Supply : Battery 1.5V*4(Size: AA) Radio Technology : Bluetooth V5.0 IEEE 802.11b/g/n Operation frequency : BLE: 2402 MHz - 2480 MHz WIFI: IEEE 802.11b: 2412MHz-2462MHz IEEE 802.11g: 2412MHz-2462MHz IEEE 802.11n HT20: 2412MHz-2462MHz Modulation : BLE; GFSK WIFI: IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20: OFDM (64QAM, 16QAM, QPSK, BPSK) Transmitter rate : BLE: 1M IEEE 802.11b: up to 11 Mbps IEEE 802.11g: up to 54 Mbps IEEE 802.11n HT20: up to 72.2 Mbps Antenna Type : BLE: FPC antenna, maximum PK gain: 2.79 dBi WIFI: FPC antenna, Maximum PK gain: 2.78 dBi Sample Number : S23052517-03 for conductive S23052517-04 for radiation Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23052517-2E07 TRF No.: KDB447498 D01 Ver.1.0 Page 6 of 8 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. T…

Text truncated - open the document above for the full version.

SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 1/9 Acknowledgement SPECIFICATIONFORAPPROVAL CUSTOMERNAME: ShenzhenKaadasIntelligentTechnologyco.,Ltd. PRODUCTNAME:2.4GinternalantennaL=150/155mm CUSTOMERP/N: RenFengP/N:U00T02S000N03078REV:A MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY: HuangLei AUDITORBY:HuangChao APPROVEDBY: YaoDingjun DATE: 2023-06-14 SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 2/9 Contents ltemDescription 一、---------------------------------------Changeofresume 二、---------------------------------------Specificationsheet 三、--------------------------------------Finisheddrawing 四、--------------------------------------Testreport 五、---------------------------------------ROHS/Rawmateriallist SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 3/9 一、Changeofresume REVDATEChangerecord A2023-06-14Initialrelease SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 4/9 二、Specificationsheet: Productmaintechnicalparameters MaintechnicalspecificationsMaintechnicalspecifications FrequencyRange (MHZ) 2400-2500 FrequencyRange (MHZ) 2400-2500 Impedance(Ω)50Impedance(Ω)50 PeakGain(dBi) WIFI ≤ 2.78 BT ≤ 2.79 PeakGain(dBi) WIFI ≤ 2.78 BT ≤ 2.79 VSWR≦2.0VSWR≦2.0 RadiationOmni-directionalRadiationOmni-directional ConnectorTypeTerminalConnectorTypeTerminal PhysicalPropertiesPhysicalProperties AntennacoverFPCAntennacoverFPC OperatingTemp-20 °C ~+70 °C OperatingTemp-20 °C ~+70 °C StorageTemp-20°C~+70°CStorageTemp-20°C~+70°C SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 5/9 三、Finisheddrawing： SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 6/9 四、Antennaplacement 五、Test report 5.1：Networkanalyzertest report WIFI Antennaposition Antennaplacement(Black BT ; Grey WIFI) SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 7/9 BT BT SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 8/9 WIFI WIFIBT Frequency MHz Efficiency % Gain dBi Frequency MHz Efficiency % Gain dBi 2400 56.492.66 2400 54.021.05 2410 60.522.78 2410 59.191.32 2420 56.372.38 2420 56.511.23 2430 60.092.66 2430 61.512.23 2440 58.642.62 2440 63.422.79 2450 55.912.55 2450 61.852.77 2460 51.712.27 2460 62.72.69 2470 49.942.08 2470 66.032.64 2480 44.021.36 2480 67.132.4 2490 46.041.33 2490 67.422.28 2500 38.100.53 2500 64.492.28 SankengRoad,QinghutouCommunity,TangxiaTown,DongguanCity 9/9 五、ROHS/RawMaterialList: MeetRoHSrequirements。 Compo nent number Component name Material QTY UnitMaterialmanufacturer UL 1FPCPI 1pc Junyi / 2φ1.13Cable Tinning/FEP 2pc ChinaOceanUnicom / 3 TerminalCopper 2pc CAIMei/Kechinol /

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 1 of 79 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Equipment under Test : Smart Lock Model No. : KA341, TE341, KA342, TE342 Trade Mark : FCC ID : 2AQY4-KA342 Manufacturer : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Report No.: DDT-RE23052517-2E02 Issued Date: Jun. 20, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 2 of 79 Table of Contents Test report declares.......................................................................................................4 1. Summary of Test Results ............................................................................................... 6 2. General Test Information ............................................................................................... 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 7 2.3. Assistant equipment used for test .................................................................................. 8 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Deviations of test standard............................................................................................. 8 2.6. Test environment conditions .......................................................................................... 8 2.7. Test laboratory ............................................................................................................... 9 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment Used During Test ....................................................................................... 10 4. 6dB Bandwidth ............................................................................................................. 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 13 4.5. Test graphs .................................................................................................................. 13 5. 99% Bandwidth ............................................................................................................ 17 5.1. Block diagram of test setup .......................................................................................... 17 5.2. Limits ............................................................................................................................ 17 5.3. Test procedure ............................................................................................................. 17 5.4. Test Result ................................................................................................................... 17 5.5. Test Graphs .................................................................................................................. 18 6. Conducted Output Power ............................................................................................. 21 6.1. Block diagram of test setup .......................................................................................... 21 6.2. Limits ............................................................................................................................ 21 6.3. Test procedure ............................................................................................................. 21 6.4. Test result average ...................................................................................................... 21 7. Power Spectral Density ................................................................................................ 22 7.1. Block diagram of test setup .......................................................................................... 22 7.2. Limits ............................................................................................................................ 22 7.3. Test procedure ............................................................................................................. 22 7.4. Test result ..................................................................................................................... 23 7.5. Test graphs .................................................................................................................. 23 8. Band Edge Compliance (Conducted Method) ............................................................. 27 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 3 of 79 8.1. Block diagram of test setup .....................…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E01 TRF No.: FCC Part 15C BLE Ver.1.0 Page 1 of 58 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Equipment under Test : Smart Lock Model No. : KA341, TE341, KA342, TE342 Trade Mark : FCC ID : 2AQY4-KA342 Manufacturer : Shenzhen Kaadas Intelligent Technology Co., Ltd. Address : Floor 11, Building B2, Phase 2, Creative City, Xiandong Road, Xili Community, Xili Street, Nanshan District, Shenzhen, Guangdong, 518000, China Report No.:DDT-RE23052517-2E01 Issued Date: Jun. 20, 2023 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E01 TRF No.: FCC Part 15C BLE Ver.1.0 Page 2 of 58 Table of Contents Test report declares.......................................................................................................4 1. Summary of Test Results ............................................................................................... 6 2. General Test Information ............................................................................................... 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 8 2.3. Assistant equipment used for test .................................................................................. 8 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Test environment conditions .......................................................................................... 8 2.6. Deviations of test standard............................................................................................. 8 2.7. Test laboratory ............................................................................................................... 8 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment Used During Test ....................................................................................... 10 4. 6 dB Bandwidth ............................................................................................................ 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 13 4.5. Test graphs .................................................................................................................. 13 5. 99% Bandwidth ............................................................................................................ 15 5.1. Block diagram of test setup .......................................................................................... 15 5.2. Limits ............................................................................................................................ 15 5.3. Test procedure ............................................................................................................. 15 5.4. Test Result ................................................................................................................... 15 5.5. Test Graphs .................................................................................................................. 16 6. Maximum Peak Output Power ..................................................................................... 17 6.1. Block diagram of test setup .......................................................................................... 17 6.2. Limits ............................................................................................................................ 17 6.3. Test procedure ............................................................................................................. 17 6.4. Test result ..................................................................................................................... 18 6.5. Test graphs .................................................................................................................. 18 7. Power Spectral Density ................................................................................................ 20 7.1. Block diagram of test setup .......................................................................................... 20 7.2. Limits ............................................................................................................................ 20 7.3. Test procedure ............................................................................................................. 20 7.4. Test result ..................................................................................................................... 21 7.5. Test graphs .................................................................................................................. 21 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E01 TRF No.: FCC Part 15C BLE Ver.1.0 Page 3 of 58 8. Band Edge Compliance (Cond…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 51 of 79 Radiated Emission test (below 1GHz) TR-4-E-009 Radiated Emission Test Result Test Date: 2023-06-13 Tested By: Liaowanrong EUT: Smart Lock Model Number: KA341 Test Mode: TX Mode Power Supply: Battery Condition: Temp:24.8°C;Humi:59.2% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23052517-2E KA342\FCC BELOW 1G\20230718-185254_H Memo: 2.4GWIFI Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 43.20 7.5 12.74 4.64 0.00 24.88 40.00 15.12 QP Horizontal 2 52.57 5.76 12.94 4.74 0.00 23.44 40.00 16.56 QP Horizontal 3 392.17 6.39 15.24 6.66 0.00 28.29 46.00 17.71 QP Horizontal 4 637.08 7.33 19.10 7.49 0.00 33.92 46.00 12.08 QP Horizontal 5 833.35 8.78 21.67 8.10 0.00 38.55 46.00 7.45 QP Horizontal 6 938.19 6.94 22.60 8.47 0.00 38.01 46.00 7.99 QP Horizontal Note: 1. Result Level = Reading + Cable loss + Antenna Factor + AMP 2. If Peak Result complies with QP limit, QP Result is deemed to comply with QP limit. 3. Test setup: RBW: 120 kHz, VBW: 300 kHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 52 of 79 TR-4-E-009 Radiated Emission Test Result Test Date: 2023-06-13 Tested By: Liaowanrong EUT: Smart Lock Model Number: KA341 Test Mode: TX Mode Power Supply: Battery Condition: Temp:24.8°C;Humi:59.2% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23052517-2E KA342\FCC BELOW 1G\20230718-185338_V Memo: 2.4GWIFI Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 47.92 7.8 13.20 4.70 0.00 25.70 40.00 14.30 QP Vertical 2 102.19 5.96 11.00 5.08 0.00 22.04 43.50 21.46 QP Vertical 3 401.07 5.33 15.42 6.70 0.00 27.45 46.00 18.55 QP Vertical 4 549.47 5.99 17.79 7.13 0.00 30.91 46.00 15.09 QP Vertical 5 853.45 8.09 21.97 8.17 0.00 38.23 46.00 7.77 QP Vertical 6 926.42 7.44 22.50 8.43 0.00 38.37 46.00 7.63 QP Vertical Note: 1. Result Level = Reading + Cable loss + Antenna Factor + AMP 2. If Peak Result complies with QP limit, QP Result is deemed to comply with QP limit. 3. Test setup: RBW: 120 kHz, VBW: 300 kHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 53 of 79 TR-4-E-009 Radiated Emission Test Result Test Date: 2023-06-12 Tested By: Liaowanrong EUT: Smart Lock Model Number: KA342 Test Mode: TX Mode Power Supply: Battery Condition: Temp:24.8°C;Humi:59.2% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23052517-2E KA342\FCC BELOW 1G\20230612-101251_H Memo: 2.4GWIFI Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 30.25 40.03 10.23 4.47 -32.29 22.44 40.00 17.56 QP Horizontal 2 42.42 30.66 12.58 4.63 -32.28 15.59 40.00 24.41 QP Horizontal 3 64.69 27.01 10.69 4.77 -32.27 10.20 40.00 29.80 QP Horizontal 4 95.67 25.79 10.43 5.02 -32.24 9.00 43.50 34.50 QP Horizontal 5 255.87 32.92 12.42 5.96 -32.23 19.07 46.00 26.93 QP Horizontal 6 652.45 27.38 19.25 7.56 -32.79 21.40 46.00 24.60 QP Horizontal Note: 1. Result Level = Reading + Cable loss + Antenna Factor + AMP 2. If Peak Result complies with QP limit, QP Result is deemed to comply with QP limit. 3. Test setup: RBW: 120 kHz, VBW: 300 kHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 54 of 79 TR-4-E-009 Radiated Emission Test Result Test Date: 2023-06-12 Tested By: Liaowanrong EUT: Smart Lock Model Number: KA342 Test Mode: TX Mode Power Supply: Battery Condition: Temp:24.8°C;Humi:59.2% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23052517-2E KA342\FCC BELOW 1G\20230612-101336_V Memo: 2.4GWIFI Final Data List NO. Freq. [MHz] Reading [dBμV/m] Antenna Factor [dB] Cable Loss [dB] AMP [dB] Result [dBμV/m] Limit [dBμV/m] Margin [dB] Detector Polarity 1 42.39 34.87 12.58 4.63 -32.28 19.80 40.00 20.20 QP Vertical 2 46.76 31.85 13.18 4.69 -32.28 17.44 40.00 22.56 QP Vertical 3 51.30 30.5 13.07 4.73 -32.28 16.02 40.00 23.98 QP Vertical 4 63.13 33.53 11.07 4.77 -32.27 17.10 40.00 22.90 QP Vertical 5 265.93 26.4 12.62 6.01 -32.25 12.78 46.00 33.22 QP Vertical 6 719.75 25.95 20.30 7.80 -32.84 21.21 46.00 24.79 QP Vertical Note: 1. Result Level = Reading + Cable loss + Antenna Factor + AMP 2. If Peak Result complies with QP limit, QP Result is deemed to comply with QP limit. 3. Test setup: RBW: 120 kHz, VBW: 300 kHz, Sweep time: auto. Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E02 TRF No.: FCC Part 15C WIFI Ver.1.0 Page 55 of 79 Radiated Emission test (above 1GHz) TR-4-E-009 Radiated Emission Test Result Test Date: 2023-06-09 Tested By: Liaowanrong EUT: Smart Lock Model Number: KA342 Test Mode: TX Mode Power Supply: Battery Condition: Temp:25.8°C;Humi:57.2% Test Site: DDT 3# Chamber File Path: d:\ts\2023 report data\Q23052517-2E KA342\FCC ABOVE 1G 2.4GWIFI\35 Memo: 11B 2412 Test Graph Suspected Data List NO . Freq. [MHz] Reading [dBμV/ m] Cable loss [dB] Antenna Factor [dB] AMP [dB] Level [dBμV /m] Limit [dBμV /m] Margin [dB] Detector Polarity 1 1142.85 48.48 2.70 25.59 -38.41 38.36 74.00 35.64 PK Horizontal 2 3961.20 47.16 5.01 30.62 -41.38 41.41 74.00 32.59 PK Horizontal 3 4822.83 52.83 5.43 32.39 -41.15 49.50 74.00 24.50 PK Horizontal 4 7483.15 46.13 6.65 36.43 -41.00 48.21 74.00 25.79 PK Horizontal 5 12695.53 44.45 9.61 39.39 -39.60 53.85 74.00 20.15 PK Horizontal 6 15993.26 41.30 14.90 37.91 -40.40 53.71 74.00 20.29 PK Horizontal Final Data List NO . Freq. [MHz] Reading [dBμV/ m] Cable loss[d B] Antenna Factor [dB] AMP [dB] Level [dBμV /m] Limit[ dBμV/ m] Margin[ dB] Detector Polarity 1 126…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E01 TRF No.: FCC Part 15C BLE Ver.1.0 Page 54 of 56 15. Test Setup Photograph Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-RE23052517-2E01 TRF No.: FCC Part 15C BLE Ver.1.0 Page 55 of 56
