User Manual WOLKI Smartwatch WW1.57 Please read this manual carefully before using the product and keep it properly product description Packing list: Smartwatch (including strap) X 1, magnetic charging cable X 1, product manual X 1 Product overview Knob button Full touch display Buttons and touch Knob button Swipe right: Split screen function 1. Long press the switch; 2. Short press on the dial page to enter the menu, short press to return to the dial; 3. Double-click on the menu page to switch menus; 4. Rotate the button to zoom icons, turn pages, etc.; 5. Short press on the remaining pages to return to the dial page; Heart rate sensor Charging port Down: shortcut button Sliding left: Smart components Swipe up: message notification Connect the watch Open permissions Enable self-starting permission Background power consumption protection Clean up background protection Turn on message notification Scan code to download Weatfit PRO 1. Download the "Wearfit Pro" APP to your mobile phone and install it, you candirectly search for "Wearfit Pro" in the APP store to download, or scan the followingQR code to jump to the link to download (scan code in browsers, WeChat, etc.) 2. Connect the watch 1) Scan code connection: After the watch is turned on and enter the dial page, slide right to enter the split screen function, click the "scan code connection" shortcutbutton,the connection QR code will pop up, and you can directly scan the code connectioninWearfit Pro. 2) Manual connection: After the mobile phone turns on Bluetooth, enter theAPP to directly search for the device to manually connect. 3) Connect and call Bluetooth In the initial state of the watch, the Bluetooth for calls is turned off, and the call and music functions cannot be used at this time. Scroll down to open the shortcut menu, and click the call Bluetooth switch. After turning it on, you can find the call Bluetoothin the mobile phone system (when the mobile phone Bluetooth is turned on), find the corresponding Bluetooth name, and click connect. After successful connection, you can use the callfunction and music function. Watch operating instructions 1.Split screen function: Swipe right to appear on the dial page, slide leftto return. 2. Swipe left on the dial page to enter smart components. The system presets3 components. Click "Add component" at the right end to add components, up to5 components. Long press the component to enter the "Delete component" page. 3. Dial switching: Long press the screen on the dial page, the dial selection appears, select the corresponding dial and return to the main dial page. Note: The system presets five dial pages, and the last dial is named "Custom". This dial will change with the dial market on the APP side and the download settings of the custom dial. 4. Menu page: On the dial page, single press the side key to enter the menu page, after entering the menu page, double press the side key to switch between menus, and single press the side key to return to the main dial page. 5. Function page: In the menu page, click each application icon to enter the corresponding function, slide right to return, and press the side button toreturnto the main dial page. Features Contacts: Connect to the mobile phone to synchronize contacts on the mobile phone and set emergency contacts; phone Dial-up: connect to the mobile phone to dial out, and you can call on the watchside Call record: Connect the mobile phone to synchronize the call record of themobile phone; Exercise Record the exercise data of the day, including: calories, activity time, number record of activities, steps and distance. Sleep Check your sleep status every night Put the watch close to your wrist, and the best place to wear it is the wrist bone above your arm. The real-time heart rate Heart can be measured. The normal value of the average person is 60-90 beats/min.The watch records the last 7 measurement records, and records the highest and lowest values. rate blood Put the watch close to your wrist, and the best place to wear it is on the upperarm of the wrist bone. Blood pressure can be measured. The watch records the last 7 measurement records. pressure Blood Put the watch close to your wrist, and the best wearing position is on the wrist bone and above the arm. The blood oxygen value can be measured. The watch recordsthe oxygen last 7 measurement records and records the highest and lowest values. Indoor It includes 6 regular sports including indoor running, indoor cycling, pool activities swimming, sit-ups, push-ups, and free training. Includes 7 sports such as outdoor running, outdoor cycling, open water, sit-ups, Outdoor hiking, mountaineering, and other sports; 5 major sports data are recordedduring exercise: steps, calories, heart rate, cadence, pace, and can be set Sportsgoals,a sports comprehensive breakdown of your sports details. Breathing training can quickly relax oneself, relieve stress and quicklyreplenish Breath oxygen to the body. Three frequency options are provided: slow, normal, and slightly training faster; breathing time options: 1~5min. Music Connect APP to control music playback. control the Connect to the APP to synchronize the weather. weather Stopwatch The watch supports stopwatch timing. Timer The watch turns into a timer every second. The watch realizes the function of Mett, converts all daily exercise volume into Mett value and Mett displays it on the watch and APP, records the energy metabolism equivalentof one week of exercise, and forms a visual icon to let users clearly understand their exercise volume. The watch supports continuous pressure monitoring, monitors the user's 24 -hour pressure pressure changes, and uses scientific health algorithms to display the pressure as an icon, allowing users to adjust their status at any time. The pressure rangeshows: 1-29 relaxed; 30-59 normal; 60-79 medium; 80-99 high. Including brightness settings, constant on time, often off screen, phone settings, raise the Set up wris…
