2ARRB-PIP2000PBUVideo Baby Monitor

Meizhou Guo Wei Electronics Co., Ltd

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: May 18, 2026
Application Purpose: Original Equipment
Equipment Note: Video Baby Monitor
Frequency Range: 5180.00000000 - 5240.00000000
Company: Meizhou Guo Wei Electronics Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wi-Fi® Portable Video Baby Camera with Cry Detection and Translation User Guide For: PIP2000-P CONNECT Important Notes: Charge the camera unit of PIP2000-P CONNECT for 8 hours before use. Safety instructions WARNING Strangulation Hazard. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 1 meter or 3 feet away). Do not remove the tags from the AC Adapters. Only use the AC Adapters provided. Baby Camera setup and use: •Choose a location for the baby unit that will provide the best view of your baby in their crib. •Place the baby unit on a flat surface, such as a dresser, desk, shelf or wall mount the unit securely with the wall mount bracket provided in the pack. • NEVER place the baby unit or cords in the crib or within reach of the baby (the unit and cords should be more than 3 feet (1m) away). WARNING This Smart Video Baby Camera is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User Guide, safe to use. Therefore, always read the instructions in this User Guide carefully before using the device. •Adult assembly is required. Keep small parts away from children when assembling. •This product is not a toy. Do not allow children to play with it. • This baby camera is not a substitute for responsible adult supervision. •Keep this User Guide for future reference. • Do not place the baby (camera) unit or cords in the crib or within reach of the baby (the unit and cords should be more than 3 feet (1m) away). •Keep the cords out of reach of children. • Do not cover the baby camera with a towel, blanket, or other item that will stop air circulation. •Never use extension cords with power adapters. Only use the power adapters provided. • Test this camera and all its functions so that you are familiar with it prior to actual use. • Do not use the baby camera near water or allow water or other foreign substances to enter the power port or adapter. • Do not place the Baby Camera near a heat source. •Only use the chargers and power adapters provided. Do not use other chargers or power adapters as this may damage the device and battery packs. •Do not touch the plug contacts with sharp or metal objects. •The unit should be set up and used so that parts of the user's body other than the hands are maintained at a distance of approximately 8 inches (20 cm) or more. •The wall mounting height is less than 2 m for the baby unit. Welcome... to your new Smart Video Baby Camera! Thank you for purchasing your new Smart Nursery product. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Important To use your baby camera, you must be able to establish a Wi-Fi link between your baby camera and your Wi-Fi router, and the range will be affected by environmental conditions. Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or reinforced concrete between the baby camera and the Wi-Fi router may block the radio signal. The signal strength ma y also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. Other 2.4GHz products, Bluetooth™ systems, microwave ovens or other baby monitors, may cause interference with this product, so keep the baby camera at least 5 ft (1.5 m) away from these types of products, or switch them off if they appear to be causing interference. If the signal is weak, try moving the baby camera to different positions in rooms. Need help? If you have any problems setting up or using your PIP2000-P CONNECT, please visit us at: motorolanursery.com/support Alternatively, you may find the answer in the ‘Help’ section at the back of this guide. This User Guide provides you with all the information you need to get the most from your Smart Video Baby Camera. Read the instructions carefully, and be aware that this Smart Video Baby Camera is only intended as an aid. It is not a substitute for responsible and proper adult supervision. Before you use the Smart Video Baby Camera, follow the simple instructions in ‘Getting started’, on the next few pages. Important Use only the supplied power adapter (DC5V / 2000 mA). Got ev erything? •Baby (camera) unit • AC power adapter for the baby (camera) unit • Wall mount bracket and screws If you have purchased multi camera pack, you will also have the following additional items: •Baby (camera) unit(s) •AC power adapter(s) for the baby (camera) unit(s) For Wi-Fi® internet viewing you will need a suitable Android or iPhone/iPad device and Wi-Fi® internet connection of at least 1.5 Mbps upload bandwidth per baby (camera) unit. • USB-A to USB-C cable • USB-A to USB-C cable (s) 6 1. Getting started ...................................................................7 2. Getting to know your baby camera .......................... 9 3.Viewing the baby through your device ....................10 3.1 Minimum System Requirements .................................................................10 3.2 Connect your device .......................................................................................10 3.3 Set up the camera............................................................................................10 3.3.1 Set up user account and camera on your devices .............11 3.3.2 Connect the Camera .......................................................................11 3.3.3 Download the app ...........................................................................11 3.3.4 Sign up or log in to the app .........................................................11 3.3.5 Add a camera to your account .................................................. 11 3.4 Cry detection and translation on your device ....................................... 12 4. Help .......................................................................................14 5 . Tech…

Text truncated - open the document above for the full version.

Internal Photos

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 1 of 9 EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 2 of 9 Antenna Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 3 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 4 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 5 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 6 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 7 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 8 of 9 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-INP Page 9 of 9

Test Setup Photos

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-TSPB Page 1 of 4 TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-TSPB Page 2 of 4 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-TSPB Page 3 of 4 Radiated Emissions View (1-18 GHz) Radiated Emissions View (18-40 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-TSPB Page 4 of 4 RF Conducted Test DFS

Test Report

Note: The information marked # is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP or any agency of the U.S. Government. This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “▼”. Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn TR-EM-RF017 Page 1 of 29 Version 3.0 TEST REPORT Applicant Name:Meizhou Guo Wei Electronics Co., Ltd Address:AD1 Section, The Economic Development Area, Meizhou, Guangdong 514000 China Report Number:2601P43216E-RF-00 FCC ID:2ARRB-PIP2000PBU Test Standard (s) FCC PART 15.407 Sample Description Product Type:Video Baby Monitor Model No.:PIP2000-P CONNECT Multiple Model(s) No.:N/A Trade Mark:Motorola Date Received:2026-02-12 Issue Date:2026-05-06 Test Result:Pass ▲ ▲ In the configuration tested, the EUT complied with the standards above. Prepared and Checked By:Approved By: Wills YuNancy Wang RF EngineerRF Supervisor Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RF-00 TR-EM-RF017 Page 2 of 29 Version 3.0 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ..........................................................................................................................3 GENERAL INFORMATION ........................................................................................................................................4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)......................................................................................4 OBJECTIVE ....................................................................................................................................................................4 TEST METHODOLOGY....................................................................................................................................................4 MEASUREMENT UNCERTAINTY .....................................................................................................................................5 TEST FACILITY ..............................................................................................................................................................5 SYSTEM TEST CONFIGURATION ...........................................................................................................................6 DESCRIPTION OF TEST CONFIGURATION .......................................................................................................................6 EUT EXERCISE SOFTWARE ...........................................................................................................................................6 EQUIPMENT MODIFICATIONS ........................................................................................................................................6 SUPPORT EQUIPMENT LIST AND DETAILS .....................................................................................................................6 EXTERNAL I/O CABLE...................................................................................................................................................6 SUMMARY OF TEST RESULTS ................................................................................................................................7 TEST EQUIPMENT LIST ............................................................................................................................................8 APPLICABLE STANDARDS.........................................................................................................................................9 DFS REQUIREMENT ......................................................................................................................................................9 DFS MEASUREMENT SYSTEM .....................................................................................................................................13 SYSTEM BLOCK DIAGRAM ..........................................................................................................................................13 CONDUCTED METHOD.................................................................................................................................................14 RADIATED METHOD ....................................................................................................................................................15 TEST PROCEDURE........................................................................................................................................................15 TEST RESULTS ...........................................................................................................................................................16 DESCRIPTION OF EUT .................................................................................................................................................16 RADAR WAVEFORM CALIBRATION .............................................................................................................................16 TEST DATA.........................................................................................................…

Text truncated - open the document above for the full version.

Test Report

PIP2000-P CONNECT Antenna Specification Model Name PRSME0095 Frequency Peak Gain Frequency Peak Gain Frequency Peak Gain 2400 1.88 5100 1.95 5500 2.25 2410 1.99 5150 1.98 5550 2.28 2420 1.98 5200 1.99 5600 2.33 2430 2.05 5250 2.11 5650 2.35 2440 2.11 5300 2.15 5700 2.12 2450 2.16 5350 2.08 5750 2.22 2470 2.13 5400 2.18 5800 2.15 2500 2.08 5450 2.22 5850 2.11 Impedance 50 Ω Manufacturer Nanyang Changxun Technology Co.,Ltd. No.A8,Agricultural and Animal Husbandry Equipment Industrial Park, Tuandong Town, Neixiang County, Nanyang City, Henan Province Antenna Photo & Length (mm) (MHz) (dBi) (MHz) (dBi) (MHz) (dBi) 2400/2500MHZ 5100/5850MHZ

Test Report

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 349 of 380 Version 4.2 5470-5725MHz 802.11a_5500MHz 802.11a_5600MHz 802.11a_5700MHz 802.11a_5720MHz 802.11ac20_5500MHz802.11ac20_5600MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 350 of 380 Version 4.2 802.11ac20_5700MHz802.11ac20_5720MHz 802.11ac40_5510MHz802.11ac40_5590MHz 802.11ac40_5670MHz802.11ac40_5710MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 351 of 380 Version 4.2 802.11ax20_5500MHz_RU_Full802.11ax20_5600MHz_RU_Full 802.11ax20_5700MHz_RU_Full802.11ax20_5720MHz_RU_Full 802.11ax40_5510MHz_RU_Full802.11ax40_5590MHz_RU_Full Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 352 of 380 Version 4.2 802.11ax40_5670MHz_RU_Full802.11ax40_5710MHz_RU_Full 5725-5850MHz 802.11a_5745MHz 802.11a_5785MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 353 of 380 Version 4.2 802.11a_5825MHz 802.11ac20_5745MHz 802.11ac20_5785MHz802.11ac20_5825MHz 802.11ac40_5755MHz802.11ac40_5795MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 354 of 380 Version 4.2 802.11ax20_5745MHz_RU_Full802.11ax20_5785MHz_RU_Full 802.11ax20_5825MHz_RU_Full802.11ax40_5755MHz_RU_Full 802.11ax40_5795MHz_RU_Full Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 355 of 380 Version 4.2 Maximum Conducted Output Power Test Information: Sample No.:3H1V-1Test Date:2026/03/19 Test Site:RFTest Mode:Transmitting Tester:Cheeb HuangTest Result:Pass Environmental Conditions: Temperature: (°C) 25 Relative Humidity: (%) 40 ATM Pressure: (kPa) 101.1 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 356 of 380 Version 4.2 Test Data: 5150-5250MHz Mode Test Frequency (MHz) Average Output Power(dBm) FCC Limit (dBm) Antenna Gain (dBi) IC EIRP (dBm) EIRP Limit(dBm) Verdict 5180 11.23 23.98 2.1113.3422.24 Pass 5200 11.02 23.98 2.1113.1322.24 Pass 802.11a 5240 10.12 23.98 2.1112.2322.25 Pass 5180 11.38 23.98 2.1113.4922.53 Pass 5200 10.82 23.98 2.1112.9322.53 Pass 802.11ac20 5240 10.28 23.98 2.1112.3922.54 Pass 5190 11.68 23.98 2.1113.7923.00 Pass 802.11ac40 5230 10.78 23.98 2.1112.8923.00 Pass 5180 8.29 23.98 2.1110.422.84 Pass 5200 8.40 23.98 2.1110.5122.83 Pass 802.11ax20 _RU_Full 5240 7.54 23.98 2.119.6522.80 Pass 5190 8.64 23.98 2.1110.7523.00 Pass 802.11ax40 _RU_Full 5230 7.84 23.98 2.119.9523.00 Pass 5250-5350MHz Mode Test Frequency (MHz) Average Output Power(dBm) FCC Limit (dBm) IC Limit (dBm) Antenna Gain (dBi) IC EIRP (dBm) EIRP Limit (dBm) Verdict 5260 10.52 23.9823.24 2.1512.6729.24 Pass 5280 10.04 23.9823.21 2.1512.1929.21 Pass 802.11a 5320 9.03 23.9823.25 2.1511.1829.25 Pass 5260 10.22 23.9823.55 2.1512.3729.55 Pass 5280 9.49 23.9823.54 2.1511.6429.54 Pass 802.11ac20 5320 8.91 23.9823.53 2.1511.0629.53 Pass 5270 10.42 23.9823.98 2.1512.5730.00 Pass 802.11ac40 5310 9.31 23.9823.98 2.1511.4630.00 Pass 5260 7.16 23.9823.81 2.159.3129.81 Pass 5280 7.11 23.9823.81 2.159.2629.81 Pass 802.11ax20 _RU_Full 5320 6.08 23.9823.82 2.158.2329.82 Pass 5270 7.49 23.9823.98 2.159.6430.00 Pass 802.11ax40 _RU_Full 5310 6.42 23.9823.98 2.158.5730.00 Pass Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 357 of 380 Version 4.2 5470-5725MHz Mode Test Frequency (MHz) Average Output Power(dBm) FCC Limit (dBm) IC Limit (dBm) Antenna Gain (dBi) IC EIRP (dBm) EIRP Limit (dBm) Verdict 5500 9.81 23.9823.27 2.3512.1629.27 Pass 5600 11.67 23.9823.27 2.3514.0229.27 Pass 5700 11.04 23.9823.28 2.3513.3929.28 Pass 802.11a 5720 10.46 23.9823.29 2.3512.8129.29 Pass 5500 10.09 23.9823.56 2.3512.4429.56 Pass 5600 11.67 23.9823.55 2.3514.0229.55 Pass 5700 10.90 23.9823.59 2.3513.2529.59 Pass 802.11ac20 5720 10.19 23.9823.56 2.3512.5429.56 Pass 5510 10.26 23.9823.98 2.3512.6130.00 Pass 5590 12.01 23.9823.98 2.3514.3630.00 Pass 5670 10.89 23.9823.98 2.3513.2430.00 Pass 802.11ac40 5710 11.02 23.9823.98 2.3513.3730.00 Pass 5500 6.96 23.9823.81 2.359.3129.81 Pass 5600 8.86 23.9823.81 2.3511.2129.81 Pass 5700 8.12 23.9823.82 2.3510.4729.82 Pass 802.11ax20 _RU_Full 5720 7.20 23.9823.82 2.359.5529.82 Pass 5510 7.07 23.9823.98 2.359.4230.00 Pass 5590 8.94 23.9823.98 2.3511.2930.00 Pass 5670 7.76 23.9823.98 2.3510.1130.00 Pass 802.11ax40 _RU_Full 5710 7.88 23.9823.98 2.3510.2330.00 Pass Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 358 of 380 Version 4.2 5725-5850MHz Mode Test Frequency (MHz) Average Output Power(dBm) Limit (dBm) Verdict 5745 12.96 30Pass 5785 12.82 30Pass 802.11a 5825 12.22 30Pass 5745 12.89 30Pass 5785 12.62 30Pass 802.11ac20 5825 12.03 30Pass 5755 13.20 30Pass 802.11ac40 5795 12.84 30Pass 5745 10.03 30Pass 5785 9.90 30Pass 802.11ax20_RU_Full 5825 9.25 30Pass 5755 10.06 30Pass 802.11ax40_RU_Full 5795 9.80 30Pass Note ： EIRP = Average Output Power + Antenna Gain Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 359 of 380 Version 4.2 Power Spectral Density Test Information: Sample No.:3H1V-1Test Date:2026/03/19 Test Site:RFTest Mode:Transmitting Tester:Cheeb HuangTest Result:Pass Environmental Conditions: Temperature: (°C) 25 Relative Humidity: (%) 40 ATM Pressure: (kPa) 101.1 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 360 of 380 Version 4.2 Test Data: 5150-5250MHz Mode Test Frequency (MHz) Reading (dBm/MHz) Duty Cycle Factor(dB) Result (dBm/MHz) FCC Limit (dBm/MHz) IC EIRP PSD (dBm/MHz) EIRP PSD Limit (dBm/MHz) Verdict 5180-0.170.640.47112.5810Pass 5200-0.250.640.39112.5010Pass 802.11a 5240-1.400.64-0.76111.3510Pass 51800.070.190.26112.3710Pass 5200-0.320.19-0.13111.9810Pass 802.11ac20 5240-0.830.19-0.64111.4710Pass 5190-2.490.19 -2.30 11 -0.19 10Pass 802…

Text truncated - open the document above for the full version.

Test Report

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 307 of 380 Version 4.2 1-7GHz_Vertical_802.11ax-he20_5825MHz Fundamental Test with Band Rejection Filter Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 308 of 380 Version 4.2 7-18GHz_Horizontal_Peak_802.11ax-he20_5825MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 309 of 380 Version 4.2 7-18GHz_Horizontal_Average_802.11ax-he20_5825MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 310 of 380 Version 4.2 7-18GHz_Vertical_Peak_802.11ax-he20_5825MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 311 of 380 Version 4.2 7-18GHz_Vertical_Average_802.11ax-he20_5825MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 312 of 380 Version 4.2 1-7GHz_Horizontal_802.11ax-he40_5795MHz Fundamental Test with Band Rejection Filter Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 313 of 380 Version 4.2 1-7GHz_Vertical_802.11ax-he40_5795MHz Fundamental Test with Band Rejection Filter Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 314 of 380 Version 4.2 7-18GHz_Horizontal_Peak_802.11ax-he40_5795MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 315 of 380 Version 4.2 7-18GHz_Horizontal_Average_802.11ax-he40_5795MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 316 of 380 Version 4.2 7-18GHz_Vertical_Peak_802.11ax-he40_5795MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 317 of 380 Version 4.2 7-18GHz_Vertical_Average_802.11ax-he40_5795MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 318 of 380 Version 4.2 18-40GHz (Only Listed with the worst harmonic margin test plot) 18-40GHz_Horizontal_802.11a_5500MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 319 of 380 Version 4.2 18-40GHz_Vertical_802.11a_5500MHz Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 320 of 380 Version 4.2 26dB attenuated below the channel power Test Information: Sample No.:3H1V-1Test Date:2026/03/19~2026/04/27 Test Site:RFTest Mode:Transmitting Tester:Cheeb HuangTest Result:Pass Environmental Conditions: Temperature: (°C) 25.1-25.3 Relative Humidity: (%) 40-55 ATM Pressure: (kPa) 100.3-101.8 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 321 of 380 Version 4.2 Test Data: 5150-5250MHz Mode Test Frequency (MHz) Result (dBm) Limit (dBm) Verdict 5180-24.61 -14.77 Pass 5200-26.20 -14.98 Pass 802.11a 5240-23.89 -15.88 Pass 5180-24.76 -14.62 Pass 5200-26.62 -15.18 Pass 802.11ac20 5240-25.76 -15.72 Pass 5190-28.86 -14.32 Pass 802.11ac40 5230-27.80 -15.22 Pass 5180-24.94 -17.71 Pass 5200-27.08 -17.6 Pass 802.11ax20_RU_Full 5240-26.79 -18.46 Pass 5190-25.43 -17.36 Pass 802.11ax40_RU_Full 5230-25.61 -18.16 Pass Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 322 of 380 Version 4.2 5150-5250MHz 802.11a_5180MHz 802.11a_5200MHz Ref20dBmAtt30dB ** * * * Offset3.5dB 1RM MAXH A LVL RBW300kHz VBW2MHz SWT100ms * Start5.1921231GHzStop5.35GHz15.78769MHz/ SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -24.61dBm 5.192202117GHz D1-14.77dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:18:50 A Att30dB ** Ref20dBm Offset3.5dB LVL *1RM MAXH 13.71352MHz/Start5.2128648GHzStop5.35GHz * * RBW300kHz VBW2MHz SWT100ms * SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -26.20dBm 5.213002072GHz D1-14.98dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:21:43 802.11a_5240MHz 802.11ac20_5180MHz A Att30dB ** Ref20dBm Offset3.5dB LVL *1RM MAXH 9.81382MHz/Start5.2518618GHzStop5.35GHz * * RBW300kHz VBW2MHz SWT100ms * SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -23.89dBm 5.251861800GHz D1-15.88dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:23:46 A Att30dB ** Ref20dBm Offset3.5dB LVL *1RM MAXH SGL 15.74437MHz/Start5.1925563GHzStop5.35GHz * * RBW300kHz VBW2MHz SWT100ms * -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -24.76dBm 5.192950303GHz D1-14.62dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:32:03 802.11ac20_5200MHz 802.11ac20_5240MHz A Att30dB ** Ref20dBm Offset3.5dB LVL *1RM MAXH 13.70981MHz/Start5.2129019GHzStop5.35GHz * * RBW300kHz VBW2MHz SWT100ms * SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -26.62dBm 5.212970518GHz D1-15.18dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:36:55 A Att30dB ** Ref20dBm Offset3.5dB LVL * RBW300kHz * VBW2MHz SWT100ms * *1RM MAXH SGL 9.7217MHz/Start5.252783GHzStop5.35GHz -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -25.76dBm 5.252783000GHz D1-15.72dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:38:52 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601P43216E-RFB TR-EM-RF105 Page 323 of 380 Version 4.2 802.11ac40_5190MHz 802.11ac40_5230MHz A Att30dB ** Ref20dBm Offset3.5dB LVL 13.6527MHz/Start5.213473GHzStop5.35GHz * RBW500kHz * VBW3MHz SWT100ms * *1RM MAXH SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -28.86dBm 5.214907968GHz D1-14.32dBm ProjectNo.:2601P43216E-RF Tester:Cheeb Huang Date: 27.APR.2026 15:40:13 A Att30dB ** Ref20dBm Offset3.5dB LVL 9.7628MHz/Start5.252372GHzStop5.35GHz * RBW500kHz * VBW3MHz SWT100ms * *1RM MAXH SGL -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 SWP100of100 1 Marker1[T1] -27.80dBm 5.252420863GHz D1-15.22dBm ProjectNo.:2601P…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

AP Wang(Engineering Director)

[email protected]Fax: 0755-2573-6666

Technical Contact

Meizhou Guo Wei Electronics Co. LLCWai Chuk Leung

[email protected]

468 W Winnie Way · Arcadia, California, 91007 · United States

Test Firm

Bay Area Compliance Laboratories Corp (Shenzhen)Nana Liu

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	15.00 mW
2	15E	5.26 GHz - 5.32 GHz	11.00 mW
3	15E	5.50 GHz - 5.72 GHz	16.00 mW
4	15E	5.75 GHz - 5.83 GHz	21.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device supports 20 MHz and 40 MHz bandwidth modes.
