335100480 _RevA OPERATING INSTRUCTION Walkie-Talkie + 123 6547 109811 13141512 Note: Please read the operating instructions carefully before using the device. GETTING STARTED Radio Battery Meter KEY FUNCTIONS Your radio uses 3 AA Alkaline batteries. 1. With the back of the radio facing you, there are a secret button to release the battery cover and remove. 2. Install 3 AA Alkaline batteries as shown on the inside of the battery compartment. 3. Re-cover the battery cover and press DOWN to secure. The walkie talkie can use a NiMH rechargeable battery instead of 3 AA Alkaline batteries. Battery full bars indicates battery high .When the battery meter shows 1 bar, device is on low battery mode and indicate low battery alert in the forms of alert tone. Turning Your Radio On and Off After you installed batteries turn the radio on, the radio chirps and the display briefly shows all feature icons available on your radio. The display then scrolls through the available channels and Interference Eliminator Codes. Press and hold button turn the radio off. Setting the Volume - Press the UP button to increase the speaker volume. - Press the DOWN button to decrease the speaker volume. - The speaker volume level is indicated by the number 1-16 displayed. Setting a Channel 1. Press the MENU button until the current channel flashes. 2. Press UP or DOWN button to select the channel number. 3. Press PTT to confirm and save the channel setting. Talking and Listening To communicate, all radios in your group must be set to the same channel and Interference Eliminator Code. To talk, press and hold PTT. Hold the radio 2 to 3 inches away from your mouth when DISPLAY SCREEN GUIDE Battery Level Key Lock Roger Beep Icon Scanning High/Low Power TX/RX Icon VOX SAFETY & GENERAL INFORMATION FCC Warning Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. Safety Information for Radios Your wireless handheld portable transceiver contains a low power transmitter. When the talk button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices. Important FCC RF Exposure Requirements: For body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Use only the supplied antenna. Unauthorized antennas, modifications or attachments could damage the transmitter and may violate FCC regulations. Normal Position Hold the transmitter approximately 25 mm from your face and speak in a normal voice, with the antenna pointed up and away. ISEDC Warning This product meets the applicable Industry Canada technical specifications. / Le présent matériel est conforme aux specifications techniques applicables d’Industrie Canada. This device complies with ISEDC license-exempt RSS standard (s). Operation is subject to the following two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'ISEDC applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. ISEDC Radiation Exposure Statement For body worn operation, this model device has been tested and meets the FCC/ISED RF exposure guidelines when used with an accessory designated for this product or when used with an accessory that Contains no metal and that positions of the face up minimum distance is 25 mm. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Pour le corps, ce modèle d’appareil a été testé et adapté à la RF renforcée Lignes directrices relatives à l’exposition lorsqu’elles sont utilisées avec un accessoire pour ce produit ou lorsqu’elles sont utilisées avec celui-ci Un acces-soire ne contenant pas de métal et dont la distance minimale de la face est de 25 mm. Tout changement ou modiÿcation non expressément approuvé par la partie responsable de la conformité…

Text truncated - open the document above for the full version.

GOCOM Technology Co.,Ltd. UNIT12, 14/F, LIPPO SUN PLAZA,28 CANTON ROAD,TSIM SHA TSUI, KOWLOON, Hong Kong, China Tel: +8618750555801 Email: [email protected] Fax: 0085223744662 FCC Confidential Authorization 2021/01/29 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ARRE-2020G125 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, GOCOM Technology Co.,Ltd hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature: Snow Huang Sales Executive

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Antenna

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS

FCC PART 15B TEST REPORT For GOCOM Technology Co., Ltd. UNIT12, 14/F, LIPPO SUN PLAZA,28 CANTON ROAD TSIM SHA TSUI, KOWLOON, Hong Kong, China FCC ID: 2ARRE-2020G125 Report Type: Original Report Product Type: walkie talkie Test Engineer Barry Yang, Jalon Liu, Joker Chen Report Number: RSZ210108003-00B Report Date: 2021-02-08 Reviewed By: Ivan Cao Assistant Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210108003-00B Page 2 of 24 TABLE OF CONTENTS General Information ...................................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 DECLARATIONS ............................................................................................................................................................ 4 System Test Configuration ............................................................................................................................................ 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 5 SUPPORT CABLE LIST AND DETAILS ............................................................................................................................ 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 TEST EQUIPMENT LIST ................................................................................................................................................. 7 ENVIRONMENTAL CONDITIONS .................................................................................................................................... 7 Sumary of Test Results .................................................................................................................................................. 8 FCC Part 15B §15.107 – Conducted emissions ........................................................................................................... 9 EUT SETUP .................................................................................................................................................................. 9 EMI TEST RECEIVER SETUP ......................................................................................................................................... 9 TEST PROCEDURE ...................................................................................................................................................... 10 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 10 TEST DATA ................................................................................................................................................................ 10 FCC Part 15B §15.109 – Radiated emissions ............................................................................................................ 15 EUT SETUP ................................................................................................................................................................ 15 EMI TEST RECEIVER SETUP ....................................................................................................................................... 16 TEST PROCEDURE ...................................................................................................................................................... 16 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 16 TEST DATA ................................................................................................................................................................ 16 Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ210108003-00B Page 3 of 24 GENERAL INFORMATION Product Description for Equipment under Test (EUT) EUT Name: walkie talkie EUT Model: G 150 Highest Operation Frequency: 467.7125 MHz Rated Input Voltage: DC 3.6V from Battery Serial Number: RSZ210108003-RF-S1 EUT Received Date: 2021.01.12 EUT Received Status: Good Objective This report is prepared on behalf of GOCOM Technol…
